Toro 20786 User manual

Operator’s Manual
FORM NO. 3319–572GB
53cm Recycler 
Walk Power Mower
Model No. 20786–8900001 & Up
Model No. 20787–8900001 & Up

EThe Toro Company – 1997
All Rights Reserved Printed in USA
i
Figures
2302
1
1. Model and serial number engraved in mower housing
492






1. Handle knob
2. Control cable
3. Handle stud
4. Handle latch
5. Cable tie
210


1. Rope guide 2. Starter rope
1914

1. Discharge door handle 2. Plug rotated clockwise
1
2
3
4

ii
1915

1. Spring clip
m-2826






1. Battery case
2. Battery
3.
Carriage bolt (2)
4. Flat washer (2)
5. Lock nut (2)
6. Battery terminal


m-3665/284
1. Oil fill tube 2. Dipstick

m-3665

1. Fuel tank cap 2. Primer
5
6
7
8

iii
972





1. Throttle control
2. Ground speed control
3. Self-propelled control bar
4. Key switch*
5. Recoil starter
* electric start model
m-3662

1. Spark plug wire
488



1. Control bar
2. RUN/SHIFT position
3. DRIVE position
1912


1. Bag frame on retaining
post
2.
Pin contacting catch
3. Handle fully forward.
Discharge door closed.
9
10
11
12

iv
1913

1. Pin locked in bag notch
971

1. Sparse/normal grass
cutting scale
2. Lush grass cutting scale

788


1. Height-of-cut lever
ÎÎÎÎÎ
ÎÎÎÎÎ
ÎÎÎÎÎ
m-3664




1. Knob
2. Cover 3.
Foam pre-cleaner
4. Paper cartridge
13
14
15
16
