Toro 21611T User manual

Form No. 3456-267 Rev B
21in 60V Lawn Mower
2161 1, 2161 1T
Cortacésped 60 V de 53 cm (21")
2161 1, 2161 1T
T ondeuse 60 V de 53 cm (21 po)
2161 1, 2161 1T
www .T oro.com.
*3456-267*

Form No. 3456-248 Rev B
21in 60V Lawn Mower
Model No. 2161 1 —Serial No. 400000000 and Up
Model No. 2161 1T —Serial No. 400000000 and Up
Register at www .T oro.com.
Original Instructions (EN)
*3456-248*

For assistance, please see
www .T oro.com/support
for instructional videos
or contact 1-888-384-9939
before returning this
product.
W ARNING
CALIFORNIA
Proposition 65 W arning
The power cord on this product contains
lead, a chemical known to the State
of California to cause birth defects
or other reproductive harm. W ash
hands after handling.
Use of this product may cause exposure
to chemicals known to the State of
California to cause cancer , birth defects,
or other reproductive harm.
Introduction
This rotary-blade, walk-behind lawn mower is intended
to be used by residential homeowners. It is designed
primarily for cutting grass on well-maintained lawns
on residential properties. It is not designed for cutting
brush or for agricultural uses. It is designed to use
T oro 60V lithium-ion battery packs. These battery
packs are designed to be charged only by T oro 60V
lithium-ion battery chargers. Using these products for
purposes other than their intended use could prove
dangerous to you and bystanders.
Model 2161 1T does not include a battery or a
charger .
Read this information carefully to learn how to operate
and maintain your product properly and to avoid
injury and product damage. Y ou are responsible for
operating the product properly and safely .
V isit www .T oro.com for more information, including
safety tips, training materials, accessory information,
help nding a dealer , or to register your product.
Whenever you need service, genuine T oro parts, or
additional information, contact an Authorized Service
Dealer or T oro Customer Service and have the model
and serial numbers of your product ready . Figure 1
identies the location of the model and serial numbers
on the product. W rite the numbers in the space
provided.
Important: W ith your mobile device, you can
scan the QR code on the serial number decal (if
equipped) to access warranty , parts, and other
product information.
g275230
Figure 1
1. Model and serial number location
Model No.
Serial No.
Safety-Alert Symbol
The safety-alert symbol ( Figure 2 ) shown in this
manual and on the machine identies important safety
messages that you must follow to prevent accidents.
g000502
Figure 2
Safety-alert symbol
The safety-alert symbol appears above information
that alerts you to unsafe actions or situations and
is followed by the word DANGER ,W ARNING , or
CAUTION .
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious
injury .
W ARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury .
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury .
This manual uses two other words to highlight
information. Important calls attention to special
© 2023—The T oro® Company
81 1 1 L yndale A venue South
Bloomington, MN 55420
2
Contact us at www .T oro.com.
Printed in Mexico
All Rights Reserved

mechanical information and Note emphasizes general
information worthy of special attention.
Contents
Safety-Alert Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety and Instructional Decals . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1 Unfolding the Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Attachments/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1
Installing the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1
Adjusting the Cutting Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Recycling the Clippings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
During Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Starting the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Adjusting the Blade Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Shutting Of f the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Removing the Battery Pack from the
Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Operating T ips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
After Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Charging the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Folding the Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Storing the Machine in the V ertical-Stow
Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Lubricating the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Replacing the Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preparing the Battery Pack for
Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
T roubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Safety
IMPORT ANT SAFETY
INSTRUCTIONS
W ARNING
When using electric lawn mowers, basic
safety precautions should always be followed
to reduce the risk of re, electric shock, and
personal injury , including the following:
Read All Instructions
I. T raining
1. The operator of the machine is responsible for
any accidents or hazards occurring to others or
their property .
2. Do not allow children to use or play with the
machine, battery pack, or the battery charger;
local regulations may restrict the age of the
operator .
3. Do not allow children or untrained people to
operate or service this machine. Allow only
people who are responsible, trained, familiar
with the instructions, and physically capable to
operate or service the machine.
4. Before using the machine, battery pack, and
battery charger , read all the instructions and
cautionary markings on these products.
5. Become familiar with the controls and proper
use of the machine, battery pack, and battery
charger .
II. Preparation
1. Keep bystanders, especially children and pets,
out of the operating area.
2. Do not operate the machine without all guards
and safety devices, such as deectors and grass
catchers, in place and functioning properly on
the machine.
3. Inspect the area where you will use the machine
and remove all objects that could interfere with
the operation of the machine or that the machine
could throw .
4. Before using the machine, ensure that the blade,
blade bolt, and blade assembly are not worn or
damaged. Replace any damaged or unreadable
labels.
5. Use only the battery pack specied by T oro.
Using other accessories and attachments may
increase the risk of injury and re.
6. Plugging the battery charger into an outlet that is
not 120V can cause a re or electric shock. Do
3

not plug the battery charger into an outlet other
than 120V . For a dif ferent style of connection,
use an attachment plug adapter of the proper
conguration for the power outlet if needed.
7. Do not use a damaged or modied battery
pack or battery charger , which may exhibit
unpredictable behavior that results in re,
explosion, or risk of injury .
8. If the supply cord to the battery charger is
damaged, contact an Authorized Service Dealer
to replace it.
9. Charge the battery pack with only the battery
charger specied by T oro. A charger suitable for
1 type of battery pack may create a risk of re
when used with another battery pack.
10. Charge the battery pack in a well-ventilated area
only .
1 1. Follow all charging instructions and do
not charge the battery pack outside of the
temperature range specied in the instructions.
Otherwise, you may damage the battery pack
and increase the risk of re.
12. Dress properly—W ear appropriate clothing,
including eye protection; long pants; substantial,
slip-resistant footwear (not barefoot or wearing
sandals); and hearing protection. T ie back long
hair and do not wear loose clothing or loose
jewelry that can get caught in moving parts.
W ear a dust mask in dusty operating conditions.
Use of rubber gloves is recommended.
III. Operation
1. Contact with the moving blade will cause serious
injury . Keep your hands and feet away from the
cutting area and all moving parts of the machine.
Keep clear of any discharge opening.
2. Using this machine for purposes other than its
intended use could prove dangerous to you and
bystanders.
3. Disengage the self-propel drive (if equipped)
before starting the machine.
4. Do not tilt the machine when starting the motor .
5. Prevent unintentional starting—Ensure that
the electric-start button is removed from the
electric-start switch before connecting the
battery pack and handling the machine.
6. Use your full attention while operating the
machine. Do not engage in any activity that
causes distractions; otherwise, injury or property
damage may occur .
7. Stop the machine, remove the electric-start
button, remove the battery pack from the
machine, and wait for all movement to stop
before adjusting, servicing, cleaning, or storing
the machine.
8. Remove the battery pack and electric-start
button from the machine whenever you leave it
unattended or before changing accessories.
9. Do not force the machine—Allow the machine to
do the job better and safer at the rate for which it
was designed.
10. Stay alert—W atch what you are doing and use
common sense when operating the machine.
Do not use the machine while ill, tired, or under
the inuence of alcohol or drugs.
1 1. Do not use a battery-operated lawn mower in
rain.
12. Operate the machine only in good visibility and
appropriate weather conditions. Do not operate
the machine when there is the risk of lightning.
13. Use extreme caution when reversing or pulling
the machine toward you.
14. Keep proper footing and balance at all times,
especially on slopes. Mow across the face
of slopes, never up and down. Use extreme
caution when changing directions on slopes. Do
not mow exceedingly steep slopes. W alk, never
run with the machine.
15. Do not direct the discharge material toward
anyone. A void discharging material against a
wall or obstruction; material may ricochet toward
you. Stop the blade(s) when crossing surfaces
other than grass.
16. W atch for holes, ruts, bumps, rocks, or other
hidden objects. Uneven terrain could cause you
to lose your balance or footing.
17. W et grass or leaves can cause serious injury if
you slip and contact the blade. Do not mow in
wet conditions. Do not mow when it is raining.
18. If the machine strikes an object or starts to
vibrate, immediately shut of f the machine,
remove the electric-start button, remove the
battery pack, and wait for all movement to stop
before examining the machine for damage.
Make all necessary repairs before resuming
operation.
19. Stop the machine and remove the electric-start
button before loading the machine for hauling.
20. Under abusive conditions, the battery pack may
eject liquid; avoid contact. If you accidently
come into contact with the liquid, ush with
water . If the liquid contacts your eyes, seek
medical help. Liquid ejected from the battery
pack may cause irritation or burns.
4

IV . Maintenance and Storage
1. Stop the machine, remove the electric-start
button, remove the battery pack from the
machine, and wait for all movement to stop
before adjusting, servicing, cleaning, or storing
the machine.
2. Do not attempt to repair the machine except as
indicated in the instructions. Have an Authorized
Service Dealer perform service on the machine
using identical replacement parts.
3. W ear gloves and eye protection when servicing
the machine.
4. Sharpen a dull blade on both edges to maintain
balance. Clean the blade and ensure that it is
balanced.
5. Replace the blade if it is bent, worn, or cracked.
An unbalanced blade causes vibration, which
could damage the motor or cause personal
injury .
6. When servicing the blade, be aware that the
blade can still move even though the power
source is of f.
7. Check the grass collection bag frequently for
deterioration or wear , and replace a worn bag
with a T oro [replacement] bag.
8. For best performance, use only genuine T oro
replacement parts and accessories. Other
replacement parts and accessories could be
dangerous, and such use could void the product
warranty .
9. Maintain the machine—Keep cutting edges
sharp and clean for the best and safest
performance. Keep handles dry , clean, and free
from oil and grease. Keep guards in place and in
working order . Keep blades sharp. Use identical
replacement blades only .
10. Check the machine for damaged parts—If there
are damaged guards or other parts, determine
whether the machine will operate properly .
Check for misaligned and binding moving parts,
broken parts, mounting, and any other condition
that may af fect its operation. Unless indicated
in the instructions, have an Authorized Service
Dealer repair or replace a damaged guard or
part.
1 1. When the battery pack is not in use, keep it
away from metal objects such as paper clips,
coins, keys, nails, and screws that can make a
connection from 1 terminal to another . Shorting
the battery terminals may cause burns or a re.
12. Check the blade and motor mounting bolts
frequently for tightness.
13. When you are not using the machine, store it
indoors in a dry , secure place out of the reach
of children.
14. Do not expose a battery pack or machine to re
or excessive temperature. Exposure to re or
temperature above 130°C (265°F) may cause
explosion.
15. CAUTION—A mistreated battery pack may
present a risk of re, explosion, or chemical
burn.
•Do not disassemble the battery pack.
•Replace the battery pack with a genuine
T oro battery pack only; using another type of
battery pack may cause a re or risk of injury .
•Keep battery packs out of the reach of
children and in the original packaging until
you are ready to use them.
SA VE THESE
INSTRUCTIONS
5

Safety and Instructional Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger . Replace any decal that is damaged or missing.
decal140-2395
140-2395
1. W arning—read the
Operator ’ s Manual .
4. Thrown object
hazard—keep bystanders
away; shut of f the engine
and wait for all moving
parts to stop before
leaving the machine; pick
up debris before mowing.
2. Cutting/dismemberment
hazard of the hand, mower
blade—stay away from
moving parts; keep all
guards and shields in
place.
5. Cutting/dismemberment
hazard of the foot, mower
blade—do not mow up
or down slopes; only
mow across slopes; look
behind you when mowing
in reverse.
3. Cutting/dismemberment
hazard of the hand, mower
blade—remove the key
and read the Operator ’ s
Manual before performing
maintenance.
decal94-8072
94-8072
decal133-8054
133-8054
Model 88610
decal144-3098
144-3098
Model 88640
decal140-2155
140-2155
1. Read the Operator ’ s
Manual .
3. Keep the Lithium Ion
battery away from open
re or ames.
2. Call2Recycle
®
battery
recycling program
4. Do not expose to rain.
6

decal144-3094
144-3094
1. The battery pack is
charging.
3. The battery pack is over
or under the appropriate
temperature range.
2. The battery pack is fully
charged.
4. Battery pack charging fault
decal137-9461
137-9461
1. Battery charge status
decal144-3175
144-3175
1. Read the Operator ’ s
Manual .
3. T o shut of f the machine,
release the bar .
2. T o start the machine,
squeeze the bar to the
handle and press the
button.
decal144-3096
144-3096
7

Setup
Important: The battery pack is not fully charged when it is purchased. Before using the machine for
the rst time, refer to Charging the Battery Pack ( page 16 ) .
1
Unfolding the Handle
No Parts Required
Procedure
Important: Remove and discard the protective plastic sheet that covers the motor and any other
plastic or wrapping on the machine.
W ARNING
Unfolding the handle improperly can damage the cables, causing an unsafe operating
condition.
• Do not damage the cable(s) when folding or unfolding the handle.
• Ensure that the cable(s) are routed to the outside of the handle.
• If a cable is damaged, contact an Authorized Service Dealer .
8

Important: Hold the handle while engaging the handle locks to avoid pinching your hands.
1. Remove the handle knobs (A of Figure 3 ).
g415126
Figure 3
2. Using the holes at the ends of the handle, attach the handle to the machine (B of Figure 3 ).
3. Move the handle rearward to the operating position (C of Figure 3 ).
4. Ensure that the cables are routed in front of the handle (D of Figure 3 ).
5. Engage the handle locks until the pin clicks in place to lock the handle into the operating position (E of
Figure 3 ).
Note: Y ou may adjust the height of the handle by changing the hole for the handle lock.
6. Secure the knobs to the handle bolts to secure the handle (F of Figure 3 ).
9

Product Overview
g440589
Figure 4
1. Electric-start button
4. Rear deector
2. Blade-control bar 5. Battery compartment
3. Handle lock (2) 6. Cutting-height lever (2)
g413066
Figure 5
1. Battery charger Model
88610 (included with
Model 2161 1)
2. Battery pack Model 88640
(included with Model
2161 1)
Specications
Battery Pack
Model 88640
4.0 AhBattery pack
capacity
216 Wh
Battery manufacturer rating = 60V maximum and 54V nominal.
Actual voltage varies with load.
Battery Charger
Model 88610
T ype Adapter 60V MAX Lithium-Ion
Battery Charger
Input
120V AC ~2.0A, 60Hz
Output 60V MAX DC 1.0A
Appropriate T emperature Ranges
Charge/store the battery pack
at
5°C (41°F) to 40°C (104°F)*
Use the battery pack at
-30°C (-22°F) to 49°C (120°F)*
Use the machine at
0°C (32°F) to 49°C (120°F)*
*Charging time will increase if you do not charge the
battery pack within this range.
Store the machine, battery pack, and battery charger
in an enclosed clean, dry area.
Attachments/Accessories
A selection of T oro approved attachments and
accessories may be available for use with the machine
to enhance and expand its capabilities. Contact
your Authorized Service Dealer or authorized T oro
distributor or go to www .T oro.com for a list of all
approved attachments and accessories.
T o ensure optimum performance and continued safety
certication of the machine, use only genuine T oro
replacement parts and accessories. Replacement
parts and accessories made by other manufacturers
could be dangerous, and such use could void the
product warranty .
10

Operation
Note: Determine the left and right sides of the machine from the normal operating position.
Before Operation
Installing the Battery Pack
Important: Use the battery pack only in temperatures that are within the appropriate range; refer
to Specications ( page 10 ) .
1. Make sure that the vents on the battery are clear of any dust and debris.
2. Lift up the battery-compartment lid (A of Figure 6 ).
3. Line up the cavity in the battery pack with the tongue on the machine and slide the battery pack into the
compartment until it locks into place (B of Figure 6 ).
4. Close the battery-compartment lid (C of Figure 6 ).
Note: If the battery-compartment lid does not close completely , the battery is not fully installed.
g409957
Figure 6
1 1

Adjusting the Cutting Height
DANGER
Adjusting the height-of-cut could bring your hands into contact with a moving blade and
result in serious injury .
• Shut off the motor , remove the battery , and wait for all moving parts to stop before adjusting
the cutting height.
• Do not put your ngers under the housing when adjusting the cutting height.
Adjust the cutting height as desired. Set all wheels to the same cutting height ( Figure 7 ).
g409959
Figure 7
12

Recycling the Clippings
Y our machine comes from the factory ready to recycle the grass and leaf clippings back into the lawn.
Important: Ensure that the rear plug is locked in place. T o lock the plug, raise the rear deector (A of
Figure 8 ), and rmly push the plug down until it snaps into place (B of Figure 8 ).
g3781 12
Figure 8
During Operation
Starting the Machine
1. Ensure that the battery pack is charged and installed in the machine; refer to Installing the Battery Pack
( page 1 1 ) .
2. Squeeze the blade-control bar and hold it to the handle (A of Figure 9 ).
3. Press the electric-start button and keep it pressed until the motor starts (B of Figure 9 ).
g409982
Figure 9
13

Adjusting the Blade Speed
This machine has 2 blade-speed settings: A UTO and M AX .
•When set to the A UTO setting, the blade speed is adjusted automatically for greater ef ciency; changes in
cutting conditions are detected and the blade speed increases when necessary to maintain quality of cut.
•When set to the M AX setting, the blade speed remains at the highest speed at all times.
Press the blade-speed button on the electric-start housing to adjust the blade speed setting ( Figure 10 ).
g410773
Figure 10
1. Blade-speed button
Shutting Off the Machine
1. Release the blade-control bar (A of Figure 1 1 ).
g410266
Figure 1 1
2. Remove the battery pack; refer to Removing the
Battery Pack from the Machine ( page 14 ) .
Note: Whenever you are not using the machine,
remove the battery pack.
Removing the Battery Pack
from the Machine
1. Lift up the battery-compartment lid.
2. Press the battery-pack latch to release the
battery pack and remove the battery pack.
3. Close the battery-compartment lid.
Operating T ips
General Mowing T ips
•Inspect the area where you will use the machine
and remove all objects that the machine could
throw .
•A void striking solid objects with the blade. Never
deliberately mow over any object.
•If the machine strikes an object or starts to vibrate,
immediately shut of f the machine, remove the
battery pack from the machine, wait for all moving
14

parts to stop, and examine the machine for
damage.
•For best performance, install a new T oro blade
before the cutting season begins or when
necessary .
Cutting Grass
•Cut only about a third of the grass blade at a time.
For improved quality of cut, runtime, and bagging,
cut grass at a higher height of cut.
•Do not cut below 51 mm (2 inches) unless the
grass is sparse or it is late fall when grass growth
begins to slow down.
•When cutting grass over 15 cm (6 inches) tall,
mow at the highest cutting height setting and walk
slower; then mow again at a lower setting for the
best lawn appearance. If the grass is too long, the
machine may plug and cause the motor to stall.
•W et grass and leaves tend to clump on the yard
and can cause the machine to plug or the motor to
stall. A void mowing in wet conditions.
•Be aware of a potential re hazard in very dry
conditions, follow all local re warnings, and keep
the machine free of dry grass and leaf debris.
•Alternate the mowing direction. This helps
disperse the clippings over the lawn for even
fertilization.
•If the nished lawn appearance is unsatisfactory ,
try 1 or more of the following:
– Replace the blade or have it sharpened.
– W alk at a slower pace while mowing.
– Raise the cutting height on your machine.
– Cut the grass more frequently .
– Overlap cutting swaths instead of cutting a full
swath with each pass.
Cutting Leaves
•After cutting the lawn, ensure that half of the lawn
shows through the cut leaf cover . Y ou may need
to make more than a single pass over the leaves.
•If there are more than 13 cm (5 inches) of leaves
on the lawn, mow at a higher cutting height and
then again at the desired cutting height.
•Slow down your mowing speed if the machine
does not cut the leaves nely enough.
15

After Operation
Charging the Battery Pack
Important: The battery pack is not fully charged
when you purchase it. Before using the tool for
the rst time, place the battery pack in the charger
and charge it until the LED display indicates the
battery pack is fully charged. Read all safety
precautions.
Important: Charge the battery pack only in
temperatures that are within the appropriate
range; refer to Specications ( page 10 ) .
Note: At any time, press the battery-charge-indicator
button on the battery pack to display the current
charge (LED indicators).
1. Ensure that the vents on the battery and charger
are clear of any dust and debris.
g347460
Figure 12
1. Battery pack cavity 4. Battery-charge-indicator
button
2. Battery pack venting areas
5. LED indicators (current
charge)
3. Battery pack terminals 6. Handle
2. Line up the cavity in the battery pack ( Figure 12 )
with the tongue on the charger .
3. Slide the charger into the battery pack until it is
fully seated ( Figure 12 ).
4. T o remove the battery pack, slide the charger
backward out of the battery pack.
5. Refer to the following table to interpret the LED
indicator light on the battery charger .
Indicator
light
Indicates
Of f
No battery pack inserted
Green
blinking
Battery pack is charging
Green
Battery pack is charged
Red
Battery pack and/or battery charger is over or under
the appropriate temperature range
Red
blinking
Battery pack charging fault*
*Refer to T roubleshooting ( page 20 ) for more
information.
Important: The battery can be left on the charger
for short periods between uses.
If the battery will not be used for longer periods,
remove the battery from the charger; refer to
Storage ( page 19 ) .
Cleaning the Machine
Service Interval : After each use
Cleaning under the Machine
Service Interval : After each use
For best results, clean under the machine soon after
you have completed mowing.
1. Shut of f the machine and remove the battery
pack and the safety key .
2. Lower the machine to its lowest cutting-height
setting.
3. Set the machine in the vertical-stow position;
refer to Storing the Machine in the V ertical-Stow
Position ( page 17 ) .
4. Using a brush or broom, clean any debris away
from the underside of the machine.
Important: Do not use water to clean the
machine; water may damage electrical
components.
5. Clean the grass box.
16

Folding the Handle
W ARNING
Folding or unfolding the handle improperly
can damage the cables, causing an unsafe
operating condition.
• Do not damage the cables when folding or
unfolding the handle.
• If a cable is damaged, contact an
Authorized Service Dealer .
1. Remove the battery from the machine.
2. Disengage the handle locks until you can move
the upper handle freely ( Figure 13 ).
Note: Hold the handle while disengaging the
handle locks to avoid pinching your hands.
g410315
Figure 13
3. Fold the handle forward to the fully forward
position as shown in Figure 14 .
Important: Route the cables to the outside
of the handle locks as you fold the handle.
4. T o unfold the handle, refer to 1 Unfolding the
Handle ( page 8 ) .
Storing the Machine in the
V ertical-Stow Position
Y ou can store your machine in the vertical position to
minimize storage space.
W ARNING
Folding or unfolding the handle improperly
can damage the cables, causing an unsafe
operating condition.
• Do not damage the cables when folding or
unfolding the handle.
• If a cable is damaged, contact an
Authorized Service Dealer .
1. Remove the battery pack from the machine.
2. Ensure that the cutting-height setting on the
machine is 44 mm (1-3/4 inches) or higher; if
it is not, raise it; refer to Adjusting the Cutting
Height ( page 12 ) .
3. Disengage the handle locks ( Figure 13 ).
4. Fold the handle fully forward.
Important: Route the cables to the outside
of the handle locks as you fold the handle.
5. Engage the handle locks.
6. Lift the front of the machine by the handle and
move it into a storage space ( Figure 14 ).
g410317
Figure 14
17

Maintenance
Remove the electric-start button and battery pack
from the machine before maintaining or cleaning the
machine.
Always shut of f the machine, wait for all moving
parts to stop, and allow the machine to cool before
adjusting, servicing, cleaning, or storing it.
Use only the manufacturer ’ s recommended
replacement parts and accessories.
Inspect and maintain the machine regularly . Have
the machine repaired only by an Authorized Service
Dealer .
Lubricating the Machine
Y ou do not need to lubricate the machine; all the
bearings have been lubricated at the factory for the
life of the machine.
Replacing the Blade
Service Interval : Y early
Important: Y ou will need a torque wrench to
install the blade properly . If you do not have a
torque wrench or are uncomfortable performing
this procedure, contact an Authorized Service
Dealer .
If the blade is damaged or cracked, replace it
immediately . If the blade edge is dull or nicked, have
it sharpened and balanced, or replace it.
W ARNING
When servicing the blade, the blade can still
move even though the power source is off.
The blade is sharp; contacting the blade can
result in serious personal injury .
• Keep your hands and feet away from a
moving blade.
• W ear gloves when servicing the blade.
1. Remove the battery pack from the machine.
2. Use a block of wood to hold the blade steady
(Figure 15 ).
3. Remove the blade bolt and blade; save the
blade bolt ( Figure 15 ).
g410331
Figure 15
4. Install the new blade and the blade bolt ( Figure
16 ).
g410334
Figure 16
Important: Position the curved ends of the
blade facing up toward the machine housing.
5. Use a torque wrench to tighten the blade bolt
to 82 N∙m (60 ft-lb).
18
