FormNo.3404-468RevA
BladeSharpeningKit
LT-F3000Heavy-DutyTripleTurfFlailMower
ModelNo.111-9684
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato
causecancer,birthdefects,orreproductiveharm.
Note:Thecentercuttingunitrequiresremovalfor
sharpeningunlessanoverheadliftisavailable.
1.Parkthemachineonalevelsurfaceandengagethe
parkingbrake.
2.Raiseandsecurethecuttingunitswiththetransport
latches.
3.Shutofftheengineandremovethekeyfromthe
ignitionswitch.
4.Ifnecessary,removethecentercuttingunit.
5.Removethecastweightfromthecuttingunit.
6.Locktherotorintoplacebyttingtherotorlockwith
theexistingfasteners(Figure1).
Figure1
1.Rotorlock2.Bladeretainerbracket
7.Attachthebladeretainerbracketontopofthelugand
theblade(Figure1).
8.Clampthebracketusinglockingpliers(Figure2).
Note:Thebladeedgeshouldbefacingyou.
Figure2
9.Useananglegrindertosharpentheblade.
WARNING
Usingagrinderinanunsafemannercould
causeseriouspersonalinjuryorproperty
damage.
Ensurethatthepersonsharpeningtheblades
hasbeenadequatelytrainedinhowtosafely
useahand-heldgrinder.
Gentlysharpentheanglededgeonthebackoftheail
bladeusingasmallanglegrinder.Whilegrindingthe
blade,keepthecuttingedgeperfectlyhorizontaland
theangledsurfaceattotheground(Figure3).Donot
grindthefrontfaceoftheailblade.Usethegrinder
gentlysotheaildoesnotgethot;otherwise,thesteel
willloseitshardness.Keepanewbladeasareference
andrefertoitwhengrinding.Neversharpenthe
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3404-468*A

bladespastthewearlinethatisindicatedbythe
5dots(Figure3).Ensurethatalltheailbladesare
sharpenedequallytomaintainthebalanceofeachrotor.
Figure3
1.Surfacetogrind2.Wearindicators
10.Repeattheprocedurewiththeotherblades.
