Torrey Pines Logic T15 User manual

T15
USER’S GUIDE
T15 |T15-C
KIT CONTENTS
T15 Thermal Imager Quick Release Rail Mount Allen wrenches: .050” and 1/8”
CR123 lithium battery (2) ¼-20” rail mount fastener (2) USB cable
UNIT SPECIFICATIONS
T15-C T15
Size 4.1”x 2.7”x 1.7” (105 x 70 x 44mm) 4.5”x 2.7”x 2.5” (114 x 79 x 70mm)
Weight w/o battery 225g 310g w/ mount
Zoom 3-8x Continuous optical zoom with auto focus adjustment
Field-of-View from 18.7° to 7°
Minimum Focus Distance 2 meters
Range Performance Human Detection Range: 162m @ 3x – 436m @8x
Human Recognition Range: 81m @ 3x - 218m @ 8x
Human Identification Range: 40m @ 3x - 109m @ 8x
Focus Focus free
Spectral Range 8-14 micron
Power 2 CR123, 3V – 8+ hours of operation
Resolution 160x120 pixels FLIR Lepton 3
Display 1.5” OLED
Operating Temperature -10° to +45° C
Frame Rate/Shutter 9Hz with Shutter
Accessories Optional 2x afocal adapter; Optional Clip-On adapter
INSTALLING CR123 BATTERIES
The T15 uses two 3 volt CR123 batteries. Quality photo lithium
batteries are recommended for optimal unit performance.
1. Remove the threaded battery cap and install the batteries
according to unit markings.
2. Replace the battery cap.

2
POWER ON T15
Remove the dust cover from the T15 lens. Press the
power button for 1 second to power the T15 on. A
splash screen will appear followed by the thermal
display. Press the power button again for 1 second
to power the T15 o. Replace the T15 lens dust
cover when not in use.
NON-UNIFORMITY CORRECTION (NUC)
The NUC calibration optimizes the T15 thermal sensor. Perform a
NUC calibration as needed to maintain a uniform appearance on
the display.
Quickly press the power button while the T15 is powered on. The
calibration takes about a second.
Note: A light ring may appear in the center of the display when no
thermal return is on screen. This is normal.
OPTICAL ZOOM CONTROL
The T15 has 3-8x optical zoom control. Turn the lens clockwise to reduce
image zoom and counter-clockwise to increase image zoom.
COLOR MODE SELECTION
The T15 has 4 color modes. Quickly depress the mode button to cycle
through the color modes until the desired mode is displayed.
MODE 1 Grayscale – white-hot
MODE 2 Grayscale – black-hot
MODE 3 Green only
MODE 4 Color
The T15 restarts in the last set mode when powered on.
TOGGLE DISPLAY RETICLE
Depress the mode button for 1.25 seconds to toggle the on-screen reticle
on or o.
MENU MODE
Depress the mode button for 5 seconds to select
T15 options, including: Display settings, Reticle
adjustments, Sleep power settings, unit Version,
and factory Reset options.
MENU NAVIGATION
Depressing the middle button enters sub-menus and menu option
selections. Depressing the top button scrolls down menu options
and changes menu option values.
The display provides
battery status
Power
Button
Power Button
Short Press
Mode Button
Short Press
Mode Button
1.25 sec Press
Mode Button
Long Press
Scroll/Set
Value
Enter/Select

3
DISPLAY MENU
Display brightness (Bright) can be optimized for dierent conditions.
Brightness can be adjusted between 5 settings, ranging from 20%
(darkest) to 100% (brightest).
Sharp toggles the image sharpness lter On/O. Squelch minimizes
display noise when no thermal return is present.
RETICLE MENU
The T15 reticle can be enabled or disabled.
There are six reticle types. The reticle can be
sighted using horizontal (Hor) and vertical (Ver)
osets between +/-9 pixels.
SLEEP MENU
The sleep menu oers battery saving options. Each sleep mode
(Dim, Standby, Shuto) can individually be set to 1, 5, or 10 minute
timers.
Dim - Screen Dims; O (never), 1, 5, 10 min..
Standby - System Standby; O (never), 1, 5, 10 min.
Shuto - Power Down; O (never), 1, 5, 10 minutes
SLEEP OPTIONS
The T15 will exit Dim and Standby modes after a slight unit movement. The unit fully powers
down if a unit shuto activates. The deeper sleep mode will have higher priority if two or more
sleep modes are set to the same timer. Timer order of priority is (highest to lowest):
Shuto > Standby > Dim
VERSION/UPDATE SCREEN
When selected from the main menu, the version screen provides
T15 unit version information. Select Allow Update to begin a
rmware update process. A MAC or PC with the updated rmware
le is required.
T15 UPDATE
Connect the T15 to a PC or MAC with the supplied USB cable while the
T15 is on the UPDATE screen. NOTE: The only way to exit the UPDATE
screen is to Shutdown the unit and power the unit back on.
While the T15 is connected to a PC/MAC in the update mode, the T15
will mount to the computer like an SD card as ‘T15 Drive’. Download the
new T15 rmware le and copy the le into the ‘T15 Drive’ directory.
Reticle disabled Reticle enabled with
adjustments
Reticle Types
1 2 3 4 5 6
To PC / Mac

After the update le is loaded into the above
‘T15 Drive’ directory, the T15 screen indicates
an ‘Update’ option. Select ‘Update’ to begin.
A ‘Success’ update status message appears
when complete. Select Shutdown and power
the T15 back on to nish the update.
RESET MENU
The T15 settings can be restored to factory
defaults if desired. Select Reset All and T15
settings will be restored to factory defaults.
MOUNT OPTIONS
The T15 has a threaded ¼”-20 mounting base for using the T15 with
hand grips, tripods and other standard mounts. Additionally, a Picatinny
rail mount is supplied with the T15.
RAIL MOUNT INSTALLATION
Attach the quick release rail mount onto the T15 with the two supplied
¼”-20 fasteners and 1/8” Allen wrench. Tighten the fasteners until
secure.
RAIL MOUNT ADJUSTMENT
The quick release mount can be adjusted for any rail.
If the mount does not rmly lock onto the rail or the unit wiggles
on the rail after locked, an adjustment should be made.
Loosen the grub set screw on the bottom of the rail mount with the
supplied .050 Allen wrench as shown.
After the grub screw is loose, use a athead screwdriver to adjust
rail preload. Adjust the screw clockwise to increase arm preload or
counterclockwise to reduce arm preload.
When the mount attaches to the rail correctly, retighten the grub set
screw back down until snug.
10505 Roselle Street, #100 • San Diego, CA 92121 • 1.858.755.4549 •www.tplogic.com
COPYRIGHTS AND OTHER NOTICES
DISCLAIMER: TORREY PINES LOGIC, INC. RESERVES THE RIGHT TO MAKE CHANGES IN SPECIFICATIONS AT ANY TIME AND WITHOUT NOTICE. THE
INFORMATION PROVIDED BY THIS DOCUMENT IS BELIEVED TO BE ACCURATE AND RELIABLE. HOWEVER, NO RESPONSIBILITY IS ASSUMED BY
TORREY PINES LOGIC, INC. FOR ITS USE; OR FOR ANY INFRINGEMENTS OF PATENTS OR OTHER RIGHTS OF THIRD PARTIES FROM ITS USE. NO
LICENSE IS GRANTED UNDER ANY PATENTS OR PATENT RIGHTS OF TORREY PINES LOGIC, INC.
THIS DEVICE MAY CONTAIN COMMODITIES, TECHNOLOGY OR SOFTWARE SUBJECT TO EXPORT LAWS AND REGULATIONS FROM THE US AND
OTHER COUNTRIES. DIVERSION CONTRARY TO LAW IS PROHIBITED.
FCC STATEMENT
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY
NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
WARRANTY
TPL, INC. WARRANTS THIS PRODUCT AGAINST DEFECTS IN MATERIAL/WORKMANSHIP FOR 60 DAYS FROM PURCHASE. IF THE PRODUCT IS
DEFECTIVE, CONTACT TPL TO OBTAIN AN RMA NUMBER AND RETURN INSTRUCTIONS. TPL IS NOT RESPONSIBLE FOR WARRANTY SERVICE AS A
RESULT OF MISUSE, ABUSE, NEGLECT OR BY DAMAGE FROM ANY DISASTERS SUCH AS FIRE OR FLOOD. THE T10 SYSTEM IS NOT WATERPROOF.
ANY SIGNS OF WATER SUBMERSION OR TAMPERING WILL VOID THIS WARRANTY.
12/05/16A
