Toshiba H20 User manual

User’s Manual
Camileo H10
IT
NL
NO
DE
DK
ES
FI
FR
PT
SE
User’s Manual

Introduction
Welcome and thank you for choosing a TOSHIBA product.
For your convenience, your TOSHIBA product is furnished with two
guides:
a) a Quick Start Guide, and
b) a comprehensive PDF User’s Manual on the included CD.

1
EN
Contents
Section 1 Getting to Know Your Camcorder........................................ 3
Overview................................................................................. 3
Check the Components ........................................................ 3
Safety Instructions ................................................................ 4
System Requirements........................................................... 4
Front View .............................................................................. 5
Rear View ............................................................................... 5
Side View................................................................................ 6
Bottom View........................................................................... 6
Section 2 Getting Started....................................................................... 7
Loading the Battery............................................................... 7
Inserting and Removing an SD Card (Optional) ................. 7
Turning the Camcorder On and Getting Started................. 8
Turning the Camcorder Off................................................... 8
Section 3 Record Mode.......................................................................... 9
Button Function..................................................................... 9
LCD Monitor Information .................................................... 10
Movie Recording.................................................................. 11
Picture Recording................................................................ 12
Taking Close up Pictures.................................................... 12
Using Zoom.......................................................................... 12
Options for Record Menu ................................................... 13
Operations for Record Mode.............................................. 13
Movie Mode Submenu Setting ........................................... 14
Picture Mode Submenu Setting ......................................... 15
Effect Submenu Setting...................................................... 17

2
EN
Contents
Section 4 Playback Mode..................................................................... 20
Button Function................................................................... 20
LCD Monitor Information .................................................... 21
Operations for Playback Mode........................................... 22
Movie Playback.................................................................... 22
Movie Playback Mode Menu............................................... 23
Picture Playback.................................................................. 25
Picture Playback Mode Menu............................................. 26
Section 5 Setting Your Camcorder ..................................................... 28
Setting Menu ........................................................................ 28
Section 6 Viewing Pictures and Movies on a TV ............................... 32
Connecting to a high-denition TV.................................... 32
Connecting to a non-high-denition 16:9 or 4:3 TV......... 32
Section 7 Viewing Pictures and Movies on PC.................................. 33
Installing Bundled Software ............................................... 33
Transferring Data to a Computer ....................................... 33
Section 8 Burning the Recorded Clip into DVD................................. 34
Section 9 Uploading Video Files to YouTube..................................... 36
Section 10 Specications .................................................................... 40
Section 11 Troubleshooting................................................................. 41
Section 12 Other Information .............................................................. 42
TOSHIBA Support.............................................................. 42
Operating Environment Conditions................................. 42
Regulatory Information ..................................................... 42
Additional Information ...................................................... 44

3
EN
Section 1
Getting to Know Your Camcorder
Overview
The Camcorder with 5 Mega Pixel sensor and 5X Optical Zoom Lens can take H.264 movies. By way
of using H.264 technology, more videos can be taken within certain amount of memory. High quality
images with up to 8 mega-pixels can also be delivered smoothly. With a color LCD monitor, users can
compose images and examine them easily.
The Camcorder also features movie recording at HD resolution of 1080p. You can also connect it to an
HDTV via HDMI cable, and easily playback recorded high-denition videos on the wide screen HDTV.
Exposure and color balance can either be adjusted automatically or allowed to be changed manually. An
2x/4x zoom increases user control over the movies and pictures you take.
Built-in memory allows you to take pictures and movies without memory card. The memory card slot
allows users to increase the storage capacity.
Note
Partial memory of the built-in memory is used for Firmware code.
Check the Components
Unpack the package and make sure all standard accessories listed are included:
Cloth
Cleaning
SET
Remote Control
Cloth Bag

4
EN
Safety Instructions
1. Do not drop, puncture or disassemble the camcorder; otherwise the warranty will be voided.
2. Avoid all contact with water, and dry hands before using.
3. Do not expose the camcorder to high temperature or leave it in direct sunlight. Doing so may
damage the camcorder.
4. Use the camcorder with care. Avoid pressing hard on the camcorder body.
5. For your own safety, avoid using the camcorder when there is a storm or lightning.
6. Do not use batteries of different specications. Doing so may lead to the potential for serious
damage.
7. Remove the battery during long periods between usage, as a deteriorated battery may
affect the functionality of the camcorder.
8. Remove the battery if it shows signs of leaking or distortion.
9. Use only the accessories supplied by the manufacturer.
10. Keep the camcorder out of the reach of infants.
11. Risk of explosion if battery is replaced by an incorrect type.
12. Dispose of used batteries according to the instructions.
System Requirements
Microsoft Windows 2000/XP/Vista•
Intel Pentium III 800MHz or above•
256 MB RAM•
CD-ROM Drive•
700 MB free HDD space•
Available USB port•
16-bit Color Display•
Note
The LCD screen is manufactured using extremely high-precision technology. However, some
tiny black and/or bright dots (white, red, blue or green) may appear on the LCD screen.
These dots are a normal result of the manufacturing process, and do not affect the recording.

5
EN
Front View
Rear View
Tele/Wide Button
Speaker
Flash Light
Lens
Picture Shutter Button
Microphone
Direction Button
Movie Shutter Button
Record/Play Button
Menu / OK Button
Self-timer LED

6
EN
Side View
Bottom View
LCD Panel
Ports Slide Cover
Power Button
TV Port
HDMI Port
Mini USB2.0 Port
Tripod Socket
Battery/ SD Card Cover

7
EN
Section 2
Getting Started
Loading the Battery
Before using the camcorder, users must load Lithium-ion
rechargeable battery
Insert the battery following to the correct polarity marks1.
( + or -).
Close the battery cover rmly.2.
Inserting and Removing an SD Card (Optional)
The camcorder comes with internal memory which allows you to store pictures and movies. You can
expand the memory capacity by using an optional SD memory card.
Insert the memory card into the right position. Please1.
refer to the gure.
To remove an installed SD card, press the card inwards2.
to release it.
When the card pops out, gently remove it from its slot.3.
Recommended memory capacity: 1GB or above4.
Note
When a memory card is tted, movies/pictures are saved on card rather than on the built-in •
memory.
Protecting Data on an SD Card: SD card is read-only by locking the SD card. No pictures•
and movies can be recorded when the SD card is locked. Make sure the lock is on writeable
position before recording any media.
Writeable
position
Write-Protected
Position

8
EN
Turning the Camcorder On and Getting Started
• To turn on the Camcorder: Flip out the LCD panel or press Power Button for one second. When the
Camcorder is turned on, the green LED will light up.
• To take a movie, press the Movie Shutter Button ( ).
• To take a picture: Press the Picture Shutter Button ( ) halfway down till the focusing frame turns
from white to green. Then, press the Picture Shutter Button fully down to take picture.
Focusing Frame: White Focusing Frame:Green
.
• To view stored movies, pictures, press Record/Play Button ( ) once to switch to Playback Mode.
Press a second time to return to Record Mode.
Turning the Camcorder Off
To turn off the Camcorder, you can either press the Power Button for one second, or you can place•
the LCD panel back to its original position.

9
EN
Section 3
Record Mode
Button Function
Direction Button
Right Button: Flash Auto/Red-Eye-Reduction/OFF
Left Button: Self timer ON/OFF
Up Button: LCD Information ON/OFF
Down Button: HD(1080p) / VGA mode switch
Menu/OK Button: Menu On / Validate the setting
Tele Button : Zoom In
Wide Button : Zoom out
Power Button: Press down for one second to turn on or turn
off the Camcorder
RECORD/PLAY Button functions:
Switch between Record /Playback Mode1.
Return to the previous page2.
For quick review, press it after recording3.
Movie Shutter Button:
Start to take movie.1.
To stop recording, press it again.2.
Picture Shutter Button: Start to take picture.

10
EN
LCD Monitor Information
The indicators shown below may display on LCD when movies and pictures are recorded:
(1)
Movie Resolution
HD (1080p) (30fps)
HD (720p) (30fps)
WVGA (60fps)
VGA (30fps)
QVGA (30fps)
Picture Resolution
High
Standard
Low
(2)
Number of images that can still be taken at current resolution
Recording time of movie that can still be taken at current resolution
(3)
Auto Flash
Red Eye Reduction
Flash Off
(4) Self-timer enabled

11
EN
(5)
Scene
Skin
Night
Backlight
(6) Macro Position Focusing
(7) Exposure compensation value
(8) Manual White Balance
(9) SD Card inserted
(10)
Battery: full power
Battery: medium power
Battery: low power
Battery: power empty
(11)
Zoom meter:
The Optical Zoom:1X~10X (5X Optical + 2X Digital)
Other video resolution:1X~20X (5X Optical + 4X Digital)
Note
Scene: B/W / Classic / Nagative effect can be previewed immediately without indicator on the
LCD
Movie Recording
Press Movie Shutter button (• ) to start recording. When a movie is recording, a time indicator will
display on LCD monitor. To stop recording, press Movie Shutter Button ( ) again.
Press RECORD/PLAY Button to view the recorded movie.•
Five resolution settings are available:•
Video Quality
HD (1080p) (30fps)
HD (720p) (30fps)
WVGA (60fps)
VGA (30fps)
QVGA (30fps)

12
EN
Picture Recording
Press the Picture Shutter Button (• ) halfway down till the focusing frame turns from white to
green. Then, press the Picture Shutter Button fully down to take picture.
Press RECORD/PLAY Button to view the picture.•
Three resolution settings are available:•
Image Quality
High Quality:8 Mega Pixels
Standard Quality:5 Mega Pixels
Low Quality:3 Mega Pixels
Taking Close up Pictures
The Camcorder has one close-up picture mode to allow you to take pictures at close range. The Macro
Mode ( ) should be used for objects located within 80 cm.
To take close-up pictures:
Operation Display Screen
In Effect Mode Submenu, press Up/Down Button1.
to select Macro.
Use Right/Left Buttons to choose Macro or2.
Normal.
Press Menu/OK Button to validate the setting.3.
Using Zoom
The zoom magnies images, when recording movies or taking pictures.•
To zoom in/out, press the Tele/Wide Button.1.
The zoom can be set as 1X~10X (5X Optical + 2X Digital) / 1X~20X (5X Optical + 4X Digital).2.

13
EN
Options for Record Menu
Movie Mode Picture Mode Effect
Resolution• Resolution•
Flash•
Self-timer•
Macro•
Scene•
Exposure•
White Balance•
Operations for Record Mode
Operation Screen
Press Menu/OK Button when in Record Mode.1.
Use Right/Left Buttons to move between main Menu2.
options, which are Movie Mode, Picture Mode, Effect,
and Setting.
Press Down Button to enter the folder of main option3.
you select.
Press Right/Left button to select the setting options,4.
then press Menu/OK button to validate.
Press RECORD/PLAY button to exit.5.

14
EN
Movie Mode Submenu Setting
Operation Display Screen
In Record Mode, press Menu/OK Button to enter1.
record Menu screen
Use Right/Left Buttons to select Movie Mode.2.
The Movie Mode Submenu contains 1 option.3.
Resolution, for you to adjust the camera
setting.
Movie Resolution
Operation Display Screen
In Movie Mode Submenu, press Down button to1.
enter Resolution.
Use Right/Left Buttons to move between ve 2.
settings.
Press Menu/OK Button to validate the setting.3.

15
EN
Picture Mode Submenu Setting
Operation Display Screen
In Record Mode, press Menu/OK Button to enter1.
record Menu screen.
Use Right/Left Buttons to select Picture Mode.2.
The Movie Mode Submenu contains 3 options,3.
Resolution, Flash, and Self-timer, for you to
adjust the camcorder setting.
Picture Resolution
Operation Display Screen
In Picture Mode Submenu, press Down button1.
to enter Resolution.
Use Right/Left Buttons to move between three2.
settings.
Press Menu/OK Button to validate the setting.3.

16
EN
Flash (Picture Record Mode Only)
This camcorder has three ash settings. To change ash setting by either hot key (Right Button) or
Option Setting:
Auto (• ): The ash res automatically according to light conditions. Use this mode for general
photography.
Red Eye• ( ): The pre-ash will re to reduce the red-eye effect.
Off (• ): The ash will not re under any circumstances. Use this mode when taking images in a
place where ash photography is prohibited, or when the subject is distant (beyond the range of the
ash).
Operation Display Screen
In Picture Mode Submenu, press UP/Down button1.
to select Flash.
Use Right/Left Buttons to move between 32.
settings.
Press Menu/OK Button to validate the setting.3.
Note
Theashwillbedisabledautomaticallywhenbatterypowerislow( ).
Self-timer (Picture Record Mode Only)
The self-timer allows you to take pictures with a ten-second time delay. The self-timer LED on the front
of the camcorder will also blink. The speed of blinking will increase just before the picture is taken.
Operation Display Screen
In Picture Mode Submenu, press Up/Down Button1.
to select Self-timer.
Use Right/Left Buttons to choose On or Off.2.
Press Menu/OK Button to validate the setting.3.

17
EN
Effect Submenu Setting
Operation Display Screen
In Record Mode, press Menu/OK Button to enter1.
record Menu screen.
Use Right/Left Buttons to select Effect.2.
The Effect Submenu contains 4 options, Macro,3.
Scene, Exposure, and White Balance, for you to
adjust the camcorder setting.
Macro
The Camcorder has one close-up picture mode to allow you to take pictures at close range. The Macro
Mode ( ) should be used for objects located within 80 cm.
Operation Display Screen
In Effect Mode Submenu, press Up/Down Button1.
to select Macro.
Use Right/Left Buttons to choose Macro or2.
Normal.
Press Menu/OK Button to validate the setting.3.

18
EN
Scene
You can select the mode according to the scene condition.
Auto: • Shoot without any special effect on the image.
Skin: • Shoot with an effect that makea skin tones more natural
Night• : Use Night mode for night scenes or low light conditions.
Backlight:• You can take shots when bright light is behind the subject.
B/W:• The image is converted to black-and-white.
Classic: • The image is converted to sepia look.
Negative: • The image is converted as the negative of the normal
Operation Display Screen
In Effect Submenu, press Down button to enter1.
Scene.
Use Right/Left Buttons to move between 72.
settings.
Press OK Button to validate the setting.3.
Note
Toavoid blurry pictures,place theCamcorder on aat, steady surface,or usea tripod when
taking shots in Night mode.
Exposure
The camcorder adjusts image exposure automatically. In certain circumstances you may wish to adjust
the exposure compensation setting.
Operation Display Screen
In Effect Submenu, press Down button to select1.
Exposure.
Use Right/Left Buttons to choose preferred2.
EV(Exposure Value). The change can be
previewed immediately.
Press OK Button to validate the setting.3.
