INFINIA 7160 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 7160.doc Rev. 21 04/04/00 nmm. Page 1 of 4
Infinia 7160
1.9GB: DT7160U
PROCESSOR
Intel Pentium166Mhz (3.3v) w/VRT Yes
External data bus width 64-bit
External data/address bus speed 66MHz
Integrated Coprocessor Yes
Processor Cache 16KB: (8KB code; 8KB data)
Socket: (321-pin Socket 7 ZIF) Support to Intel Pentium200Mhz
LEVEL 2 (L2) CACHE Yes: 256KB Direct Mapped
Data Bus Width 64-bit
DATA RAM:
(2) 32k x 32 Pipeline Burst SRAM Yes
TAG-RAM:
8KB x 8 external TAG SRAM (5.0v) Yes: Provides caching to 64MB of system memory
SYSTEM ARCHITECTURE
PCI BUS: (32-bit, 33mhz) Connecting devices: HDD, video, PCI card slots
MEMORY: EDO DRAM 8MB x 8-bits or 2MB x 32-bits SIMM
Standard 16 MB: (8MB x 8-bits or 2MB x 32-bits SIMM)
Maximum 128 MB
Speed 60ns
Parity No parity
Hyper Page mode memory access Yes
Data width 64 bit
Socket
Type: (4) 72-pin SIMM sockets
Socket data width 64/72 bit
Support: Single or Double sided 1M x 32 (4MB), 2M x 32 (8MB), 4M x 32 (16MB), 8M x 32 (32MB)
BIOS (256KB FLASH EPROM, ) Yes
PnP 1.0a SUPPORT Yes
Advanced Power Management 1.2 Support Yes
EPA energy Star Compliant Yes
VIDEO
Video Memory 2 MB EDO DRAM
Speed 50ns
PCI Bus Architecture w/burst mode Yes
VESA Feature connector Yes: Supports 34-pin or 26-pin VESA feature connector
Controller Chip S3 Virge Video Controller
YUV to RGB conversion Off-loads conversion from CPU for higher performance full motion video
without compromising picture quality or frame rate.
2D/3D SVGA Graphics Support Includes BitBLT, 64-bit graphics accelerator, Linedraw & polygon fill
functions
3D Features Flat shading, Gourand shading, texture mapping
Texture mapping functions
Perspective Correction Yes
Bi-linear & tri-linear Filtering Yes
Fast Linear Addressing Maps display memory to CPU’s upper memory to reduce software overhead
MIP mapping & Z-Buffering Yes
Supported Resolutions 640 x 480 16.7M colors/16.7M colors
800 x 600 16.7M colors/16.7M colors
1024 x 768 64K colors/64K colors
1280 x 1024 256 colors/256 colors

INFINIA 7160 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 7160.doc Rev. 21 04/04/00 nmm. Page 2 of 4
Infinia 7160
1.9GB: DT7160U
STORAGE
HDD ( Enhanced IDE) 1.9 GB
FDD 3.5” Floppy Disk Drive
CD-ROM: Toshiba 5602B 8X- speed
Interface ATAPI ( Enhanced IDE )
Random Access Time 145 ms
Sustained Transfer Rate 1360 KB/sec
Supported Disk Formats CD-DA, CD-ROM, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Plus)
SOUND SYSTEM
Chipsets: Yamaha YMF701 OPL3 FM Synthesizer
16 bit stereo audio playback/record Yes: 44kHz Maximum sampling rate
Full duplex function Yes: Supports simultaneous playback and capture, digital and analog mixing
SRS 3D Surround Sound Chip Yes
Sound formats supported: SoundBlaster Pro, .WAV, MIDI, CD-ROM audio
Digital audio and analog mixing function Yes
Speakers Integrated with Monitor ( See monitor page for details )
INTERNAL MODEM 28.8 /14.4 Kbps Voice/Data/Fax modem (Software upgradeable to 33.6 Kbps)
Data support
Protocols supported V.34, V.32bis, V.32, V.22bis, V.22, V.21, Bell 212A,103 and Bell 202 Rec.
Error correction V.42 and MNP 2-4
Data compression V.42bis and MNP 5
Fax support
Protocols supported ITU-T V.17, V.29, V.27ter.,V.21
Fax class Class 1 and 2 fax interface 14,400 to 2400 bit/sed
Supported Functions Speaker phone, Telephony Answering Machine, Ring Wake-up Resume
Incoming Call Discrimination, Caller ID
EXPANSION SLOTS
Number of ISA Slots ( Available/Total ) 2/3
Number of PCI Slots ( Available/Total ) 2/3
EXPANSION BAY
Internal Bay One open - One occupied with HDD
External 5.25” Bay Two open - One occupied with 8X CD-ROM
EXTERNAL INTERFACES All Ports are color coded for easy installation
One RJ-11 port for internal modem (supplied) Yes
One 9-Pin Serial (16550 UART compliant) Yes
Two Universal Serial Bus ports1One open - One occupied with Toshiba In-Touch Module 1
One 25-Pin Parallel (IEEEP1284 compliant) Yes: EPP compliant
One 15-Pin RGB (SVGA video) Yes
One (PS/2) Mouse Port Yes
One (PS/2) 101 Keyboard Yes
Joystick/MIDI Port (15 pin D-sub) Yes
Microphone (3.5mm mini jack, monaural) Yes
Headphone (3.5mm mini jack, stereo,16Ωmin) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
AC IN (Standard 3 prong ) Yes
1. Both ports operate from a single controller allowing 128 devices total, not per port. The In-Touch Module should remain
on its own port. Throughput for the Universal Serial Bus (UBS) is 12Mbits/sec.

INFINIA 7160 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 7160.doc Rev. 21 04/04/00 nmm. Page 3 of 4
Infinia 7160
1.9GB: DT7160U
TOSHIBA IN-TOUCH MODULE 1: Centralized Control to various devices
Standard Functions Speakerphone, Digital answering machine, CD-ROM
Sleep mode1
Digital answering machine functions See coded references below
Previous message2Replays last message (Refers to track, station or channel in other modes)
Delete message3Stop/Deletes current message
Play message4Play messages (Refers to track, station or channel in other modes)
Next message5Forward to next message (Refers to track, station or channel in other modes)
Quit6Deactivates digital answering machine or corresponding mode
Message indicator7Active when message present
Speakerphone mode8Activates speakerphone
Digital answering machine mode9Activates/deactivates phone answering machine
CD-ROM mode10 Activates CD-ROM mode
FM mode11 (Standard unit is FM ready) Actives FM tuner: Requires TV/FM Capture Kit (DT1001)
TV mode12 (Standard unit is TV ready) Activates TV tuner
Volume Control13 Controls monitor speaker volume
IR Remote Ready Feature14 Requires optional remote (DT-1002)
Optional TV/FM Capture Kit (DT1001) Includes In-Touch Remote (DT-1002)
PCI 2.0 plug-and-play complaint Yes: Includes PCI BUS board (Dimensions: 9” x 4.2”)
TV Section:
Video Quality Live video: 4:2:2 YUV resolution
Video Processor & PCI BUS Video decoding using Brooktree Bt848 chipset
TV tuner Cable Ready, NTSC compatible
Stereo TV (Chipset: Phillips TEA5582) Phase-locked loop stereo decoder for BTSC system
FM Radio (Chipset: Phillips OM5606) Automatically decodes stereo and mono broadcasts
Video Input: Support 1 internal and 1 external video source
Internal: Yes: Composite video from on-board tuner
External: Yes: Composite NTSC/PAL video from VCR/LD player
Audio In: Supports 4 internal and 1 external audio source
Internal: Line-in level for CD-ROM player
TV audio from TV stereo decoder
FM radio from radio receiver module
Mono line-out telephony audio from system board
External: Standard line in source
TOSHIBA IN-TOUCH MODULE 1
IR14
Receiver
MSG7
Volume13
TEL8ANS9CD10 FM11 TV12
<<
<<2!
!3>
>4>> >>5OFF
Quit6
Sleep
Sleep1

INFINIA 7160 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1996 TAIS 7160.doc Rev. 21 04/04/00 nmm. Page 4 of 4
Infinia 7160
1.9GB: DT7160U
KEYBOARD
104-key keyboard with the Windows 95 keys Yes
3.8mm Travel Yes
12 dedicated function keys Yes
Numeric keypad Yes
POINTING DEVICE
Microsoft for Toshiba PS/2 Mouse Yes
POWER SUPPLY( 200Watts )
Input (Voltage/Frequency) 100-240V; 50-60Hz, Switch Selectable
Output Connectors Five AMP 1480426-0 type ( HDD, CD-ROM....)
One AMP 171822-4 type ( FDD )
One Motherboard
Safety UL recognized, CSA Certified, TUV approved
UL/CSA listed AC Cable(115V)
VDE/IEC Approved Type(220V/240V)
DIMENSIONS 7.72” x 15.75” x 17.05”
WEIGHT 29.1 LBS
BUNDLED SOFTWARE:
Maxis Sim City 2000 Ver.1.1; Diagsoft QA Plus 5.41; Prodigy 1.03; Sony Music Screeners;
Rand Mcnally Tripmaker SE 1.01B; Investor Insight (Intuit) 1.0; America Online 3.0;
Dow Personal Journal 2.1; Compuserve; Netscape Personal Edition 2.01; Intel INDEO Video 4.1
Mediascape CD player; Mediamatics MPEG Arcade Player 2.0; Synchro Multimedia Home Connect 2.0
CD’s included:
Windows 95; MS Works 4.0A; MS Plus Pack 1.0 CD; MS Golf 2.0 CD; MS Encarta Encyclopedia 1996 CD;
Virgin-Charlie Brown -Get Ready for School 1.0 CD; Virgin-Terratopia 1.1 CD; IVI-Mayo Clinic 2.0 CD;
Activision Mech Warrior 2 Ver.17 CD; Creative Wonders Family Album Creator 1.0 CD;
Intuit Quicken SE 5.0 Release 13K CD; Activision Shanghai Great Moments CD;
WARRANTY 1 Parts & Labor (On-site); 7 x 24 phone support free during warranty period
ENVIRONMENTAL SPECIFICATIONS
Temperature: Operating 50°F (10°C) to 95°F (35°C)
Non-operating -4°F (-20°C) to 149°(65°C)
Relative Humidity: Operating 30%to 80%non-condensing
Non-operating 10%to 90%non-condensing
Shock: Operating 10G; 1.5G
Non-operating 60G; 10G
Vibration: Operating 0.3G
Non-operating 0.6G
Acoustic Noise Impulsive 55dB
Non-Impulsive 45dB
INFINIA OPTIONS AND PRICING
PART NUMBER DESCRIPTION PRICE
DT7130U Infinia 7130 w/133 Mhz Pentium & 1.5GB HDD $1,699
DT7160U Infinia 7160 w/166 Mhz Pentium & 1.9GB HDD $1,999
DT7200U Infinia 7200 w/200 Mhz Pentium & 3.0GB HDD $2,799
DA-1566M-01 15-inch autoscan monitor $449
DA-1766M-01 17-inch autoscan monitor $749
DT1001 TV/FM Radio Capture Card (Includes In-Touch Remote) -- Standard on 7200 $199
DT1002 In-Touch Remote -- Standard on Infinia 7200 $29
DT1003 LCD In-Touch Module 4 -- Standard on Infinia 7200 $169
