TOSHIBA V3100 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to
change without notice. Copyright 1998 TAIS Toshiba V3100.doc Rev. 11 03/22/00 nmm. Page 1of 4
PLATFORM
SERIES NAME TOSHIBA V3100
PART NUMBER As Listed: See Configuration Page
PROCESSOR
Intel Celeron Yes
Ziff Socket Yes
Available processor speeds 433, 466, or 500MHz
Integrated CoprocessorYes
MMX support Yes
ECC support Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
Bus Speed 66MHz Front Side Bus
LEVEL 2 (L2) CACHE Yes: 128KB Pipeline Burst SRAMIntegrated into CPU
Data Bus Width/Address Bus Width 64-bit/64-bit
Local Clock Bus Speed Same as processor
SYSTEM BOARD
Form Factor MicroATX
Chipset Intel 810
Down Components
I/O Controller Yes
Graphics Controller Integrated into Intel 810 chipset
Audio Controller Aureal 8810 PCI Audio
SYSTEM ARCHITECTURE
PCI BUS (V2.2): (32-bit, 33mhz) 3-PCI slots
HARDWARE MONITORING (DMI ASIC) Yes: W83781 (Voltage, Temperature and Fan Speed)
MEMORY: SDRAM Note: Memory Speed must match/exceed Front Side Bus speed.
Type 168-pin SDRAM DIMM’s with gold-plated contacts, unbuffered
Available Standard Configurations 32MB, 64MB or 128MB SDRAM
Maximum 256MB
Local Clock Bus Speed 100MHz
Socket type: (2) 168-pin gold plated DIMM sockets: Accepts 64/128/256MB memory
BIOS (4Mbit FLASH EEPROM, 512KB) Yes
Supported Standards DMI (v.2.0), System BIOS, USB (v.1.0), APM (v.1.2), PnP (v.1.0a),
VESA (DPMS & DCC), UDMA33, UDMA66, POST, ACPI (v.1.0),
WfM (v.2.0), Machine ID
EXTERNAL INTERFACES
One 9/25-Pin Serial Yes (NS16C550 UART compatible)
Two Universal Serial Bus ports1Supports 2 USB peripherals without external hub
One 25-Pin Parallel Yes: (EPP/ECP compatible)
One 15-Pin RGB (SVGA video) Yes
One (PS/2) Mouse Port Yes
One (PS/2) 104 Keyboard Yes
One External Microphone jack Yes
Joystick/MIDI port Yes
Line-out (3.5mm mini jack, stereo, 0.7V rms) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
1. Both ports operate from a single controller allowing 128 devices total, not per port. Throughput for the Universal Serial Bus (UBS) is
12Mbits/sec.

TOSHIBA V3100 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to
change without notice. Copyright 1998 TAIS Toshiba V3100.doc Rev. 11 03/22/00 nmm. Page 2of 4
SERIES NAME TOSHIBA V3100
PART NUMBER As Listed: See Configuration Page
VIDEO
Video Memory: SDRAM Intel Dynamic System Memory(Shares System Main Memory)
Speed 100MHz
Data Bus width 64-bit
Graphic Controller
Controller Chip Integrated into Intel 810 chipset(Intel 752 graphics compatible)
Connected Bus type CPU system bus
Standards Supported DPMS Power Management, PnP Compliant
2D Supported Features BitBLT, Hardware Cursor (up to 64 x 64 x 2), DirectDraw,
Rectangle Fill, Line Draw, BitBlt, Polygon Fill, Panning/Scrolling,
Bit Masking, Monochrome Expansion, Scissoring and full ROP support
3D Supported Features Yes
Triangle Setup Yes
Modeling Fogging, lighting
Shading Gouraud shading
Rendering Texture mapping: Bilinear,Trilinear, Anti-aliasing, MIP mapping, Z-Buffering
AGP texturing Yes
Alpha-blending Yes
Direct3D support Yes
Open GL support Yes
Digital Video Accelerator
YUV Color Space Conversion Yes: Off-loads conversion from CPU for higher performance full motion video
Without compromising picture quality or frame rate.
Scaling/ Interpolation Yes: vertical & horizontal
Direct Video, DirectMPEG Yes (Windows 95 only)
Motion Compensation Yes
SUPPORTED VIDEO RESOLUTIONS Colors/ Refresh Rate
(Non-interlaced unless otherwise specified) Vertical Refresh Rate
640 x 480 32-bit (4.3B) 85 Hz
800 x 600 32-bit (4.3B) 85 Hz
1024 x 768 32-bit (4.3B) 85 Hz
1280 x 1024 32-bit (4.3B) 85 Hz
1600 x 1200* 8-bit (256) 75 Hz
* With 64MB or more Main memory.

TOSHIBA V3100 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to
change without notice. Copyright 1998 TAIS Toshiba V3100.doc Rev. 11 03/22/00 nmm. Page 3of 4
SERIES NAME TOSHIBA V3100 (PLATFORM con.)
PART NUMBER As Listed: See Configuration Page
SOUND SYSTEM
Chipset Aureal 8810
Compatibility Windows Sound System, MIDI
16-bit stereo audio Yes
Built-in microphone No
CHASSIS (DESKTOP DESIGN)
EXPANSION BAY TOTAL AVAILABLE CONFIGURED
Internal 3.5” 2 1 1 (HDD)
5.25” 0 0 0
External 3.5” 1 0 1 (FDD)
As Listed: See Configuration Page 5.25” 2 1 1 (CD-ROM)
EXPANSION SLOTS TOTAL AVAILABLE CONFIGURED
(As Listed: See Configuration Page)
PCI: Full-Length 3 2 1 (NIC Card)
POWER SUPPLY
Watts 150W
Input (Voltage/Frequency) 115-230/50-60Hz
Switched Yes
SUPPORTED SAFETY STANDARDS
US/Canada UL 1950 – CSA950-95, 3rd Edition, 7/28/95
CSA22.2 No.950-93, 3rd Edition
ICES-003, Issue 2
FCC Class B
International IEC 950, 2nd Edition, 1991 (w/amendments 1,2, & 3)
CISPR 22, 2nd Edition 1993
Europe EN 60950 w/Nordic deviation; CE Mark;
EN61000-4-4; EN61000-4-2; EN61000-4-3
TUV/GS
Blue Angel
CERTIFICATIONS: Windows 98 & Windows NT logo, Novell Client, Energy Star
HARDWARE COMPLIANT: PC98, ACPI, Wired For Management (WfM), DMI 2.0, Year 2000 NSTL hardware tested
SECURITY
Hardware Yes - Padlock loop on rear of chassis (lock not included with system)
Password Support Power-on, Supervisor/Administrator, User & Setup Utility
DIMENSIONS
Measurements 7.13”W x 15.6”D x 14.3”H
Weight 22 lbs.
BUNDLED SOFTWARE (Windows 95 models)
MicrosoftWindows95, Microsoft Internet Explorer, Toshiba V3100 On-Line User’s Guide
CD’s Included: Bootable Toshiba Configuration Builder CD for Windows 95, Enhanced Recovery CD, Companion Disk
BUNDLED SOFTWARE (Windows 98 models)
MicrosoftWindows98 Second Edition,Microsoft Internet Explorer, Toshiba V3100 On-Line User’s Guide
CD’s Included: Bootable Toshiba Configuration Builder CD for Windows 98, Enhanced Recovery CD, Companion Disk
BUNDLED SOFTWARE (Windows NT models)
MicrosoftWindowsNT 4.0, Microsoft Internet Explorer, Toshiba V3100 On-Line User’s Guide
CD’s Included: Bootable Toshiba Configuration Builder CD for Windows 98, Enhanced Recovery CD, Companion Disk
WARRANTY: 1 Year Parts & Labor
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 50°F (10°C) to 95°F (35°C) -4°F (-20°C) to 140°F (60°C)
Packaged: -30°C to 70°C -- --
Relative Humidity: 30%to 80%non-condensing 10%to 90%non-condensing
Shock: 10G; 1.5G w/CD-ROM installed 60G; 10G w/CD-ROM installed
Vibration (5~150Hz f/30 minutes, each axis) 0.3G 0.6G
Packaged: 1.0G

TOSHIBA V3100 Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to
change without notice. Copyright 1998 TAIS Toshiba V3100.doc Rev. 11 03/22/00 nmm. Page 4of 4
SERIES NAME TOSHIBA V3100
PART NUMBER As Listed: See Configuration Page
COMPONENT
STORAGE
FDD 3.5” 1.44MB Floppy Disk Drive
HDD (3.5” Half-height Enhanced IDE) As Listed: See Configuration Page
Controller Integrated (ATA-4)
Type SMART, Ultra-DMA
Capacity options 4GB, 6GB, 8GB, 10GB or 12.9GB (As Listed: See Configuration Page)
RPM (+/- 0.1%) 5400
Buffer 512KB
Access Time (average) 9.5msec (read); 11.5msec (write)
Ultra DMA support Yes
Burst Data Transfer Rate Ultra DMA mode 4 (66.6MB/sec); Ultra DMA Mode2 (33.3MB/sec);
PIO Mode 4 (16.3MB/sec)
Certifications SMART, UDMA-66
MULTIMEDIA OPTIONS As Listed: See Configuration Page
Available options 40X CD-ROM or None
CD-ROM (Lite-on LTN-403L) 40X Max speed
Interface ATAPI ( Enhanced IDE ) with 128KB Buffer
Random Access Time 80ms
Sustained Data Transfer Rate Up to 6,000KB/sec @ sustained 17X to 40X
Data Transfer modes Ultra DMA Mode2 (33MB/sec); Sustained PIO Mode 4 (16.7MB/sec)
Supported Disk Formats CD-DA, CD-ROM/XA, CD-I, Karaoke CD, Video CD, Multi-session Photo CD,
CD extra, CD Plus, CD-R and CD-RW Discs compliant (Read only)
ETHERNET SUPPORT As Listed: See Configuration Page
Model options 3ComFast Etherlink XL PCI 10/100 w/RJ-45 portorNone
Chipset 3C905B
Support Network 100Base-TX, 10Base T
Port RJ-45
INTERNAL MODEM As Listed: See Configuration Page
Options 3ComV.90/K56flex Internal Modem orNone
Type Internal V.90/K56flex
Data support
Protocols supported ITU-T V.90, 3Com x2, ITU-T V.34 (1996), ITU-T V.34, ITU-T V.32bis, ITU-T V.32,
ITU-T V.22bis, ITU-T V.22, ITU-T V.23, Bell 212A, ITU-T V.21, ITU-T V.8,
ITU-T V.8bis, Bell 103, ITU-T V.80
Error correction & Data compression ITU-T V.42, MNP 2-4, ITU-T V.42bis, MNP 5
MNP 5 for upto 2X data compression, CCITT V.42 bis for upto 4X data compression
Fax Class 1 & 2.0
Fax Protocols & Modulation ITU-T V.17, ITU-T V.29, ITU-T V.27ter, ITU-T V.21 (Channel 2), Group 3 FAX
KEYBOARD (PS/2) As Listed: See Configuration Page
Keyboard Options available Value Keyboard Option
Enhanced 104-key keyboard Yes
Windows 95/98 support Yes
3.5mm Travel Yes
12 dedicated function keys Yes
Numeric keypad Yes
Keyboard tilt Yes: (6 degrees)
Indicators Yes: Scroll Lock, CapsLock, NumLock
Dimensions 18.9”W x 6.57”D x 1.46”H w/o feet
POINTING DEVICE
PS/2 Mouse Yes: 2 Button with 6 foot cable
