Toshiba SD-770SR User manual

2
18
26
34
54
66
Introduction
Connections
Basic playback
Advanced playback
Function setup
Others
DVD VIDEO PLAYER
SD-770SR
OWNER’S MANUAL
© 2006Toshiba Corporation
DIGITAL VIDEO

2
Introduction
SAFETY PRECAUTIONS
In the spaces provided below, record the Model and Serial No.located on the rear panel of your DVD video player.
Model No. Serial No.
Retain this information for future reference.
WARNING: TO REDUCETHE RISK OF FIRE OR ELECTRIC SHOCK,DO NOT EXPOSETHIS APPLIANCE
TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE
ENCLOSURE.DO NOT OPENTHE CABINET.REFER SERVICINGTO QUALIFIED PERSONNEL
ONLY.
CAUTION: This Digital Video Disc Player employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
CLASS 1
LASER PRODUCT

3
Introduction
Location of the required label
The rating plate and the safety caution are
on the rear of the unit.

4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALLWARNINGS AND INSTRUCTIONS GIVEN INTHIS OWNER’S
MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE
REFERENCE.
This set has been designed and manufactured to assure personal safety.Improper use can result in electric shock
or fire hazard.The safeguards incorporated in this unit will protect you if you observe the following procedures for
installation, use and servicing.This unit is fully transistorized and does not contain any parts that can be repaired
by the user.
DO NOT REMOVETHE CABINET COVER, ORYOU MAY BE EXPOSEDTO DANGEROUS VOLTAGE.
REFER SERVICINGTO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

5
Introduction
S3125A
8. Do not restrict the air flow of the unit by placing it in a place with poor air flow, by covering it with a cloth,
or by placing it on carpeting.
9. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
10.Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13.Unplug this apparatus during lightning storms or when unused for long periods of time.
14.Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.

6
Introduction
18.Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and apparatus malfunction.
IMPORTANT SAFETY INSTRUCTIONS
17.Do not place a heavy object on or step on the apparatus.The object may fall, causing serious personal
injury and serious damage to the apparatus.
19.Be sure to use the unit near the wall outlet. If a malfunction occurs, disconnect the plug from the wall
outlet at once.
20.The mains plug is used as the disconnect device, the disconnect device shall remain readily operable at
any time.
14.When you use headphones, keep the volume at a moderate level.If you use the headphones continuously
with high volume sound, it may cause hearing damage.
15.Do not overload wall outlets; extension cords, or integral convenience receptacles as this can result in a
risk of fire or electric shock.
16.Keep your fingers well clear of the disc tray as it is closing. Neglecting to do so may cause serious
personal injury.
ADDITIONAL SAFETY INSTRUCTIONS

7
Introduction
SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT
This equipment has been designed and manufactured to meet international safety standards but, like
any electrical equipment, care must be taken if you are to obtain the best results and safety is to be
assured. So, please read the points below for your own safety. They are of a
general nature, intended to help you with all your electronic consumer products and some points may
not apply to the goods you have just purchased.
**************
DO read the operating instructions before you attempt to use the equipment.
DO ensurethat allelectrical connections(including themains plug,extensionleadsandinter- connections
between the pieces of equipment) are properly made and in accordance with the manufacturer’s
instructions. Switch off and withdraw the mains plug before making or changing connections.
DOconsultyourdealerif youare everindoubtabouttheinstallation,operationor safetyof yourequipment.
DO be careful with glass panels or doors on equipment
**************
DON’T remove any fixed cover as this may expose dangerous voltages.
DON’T obstruct the ventilation openings of the equipment with items such as newspapers, tablecloths,
curtains, etc. Overheating will cause damage and shorten the life of the equipment.
DON’T allow electrical equipment to be exposed to dripping or splashing, or objects filled with liquids,
such as vases, to be placed on the equipment.
DON’T place hot objects or naked flame sources such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and lead to fires.
DON’T use makeshift stands and NEVER fix legs with wood screws - to ensure
completesafetyalways fit the manufacturer’sapproved standor legs with thefixingsprovided according
to the instructions.
DON’T useequipment suchas personalstereos orradios sothat youare distractedfrom therequirements
of traffic safety. It is illegal to watch television whilst driving.
DON’T listen to headphones at high volume, as such use can permanently damage your hearing.
DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is
designedfor unattended operation orhas a stand-bymode. Switch offusing theswitchon the equipment
and make sure that your family know how to do this. Special arrangements may need to be made for
infirm or handicapped people.
DON’T continue to operate the equipment if you are in any doubt about it working
normally, or if it is damaged in any way -switch off, withdraw the mains plug and consult your dealer.
ABOVEALL
—NEVER let anyone especially children push anything into holes, slots or any other opening in
the case - this could result in a fatal electrical shock;
—NEVER guess or take chances with electrical equipment of any kind
—it is better to be safe than sorry!
*************

8
Introduction
Precautions
Notes on handling
When shipping the DVD video player, the original
shipping carton and packing materials come in handy.
For maximum protection, repack the unit as it was
originally packed at the factory.Take care not to give it
a shock or shake when carrying.
Do not use volatile liquids, such as insect spray, near
the DVD video player. Do not leave rubber or plastic
productsin contact with the DVDvideo playerfora long
time.They will leave marks on the finish.
The top and rear panels of the DVD video player may
become warm after a long period of use.This is not a
malfunction.
When the DVD video player is not in use, be sure to
remove the disc and turn off the power.
Ifyoudo not use the DVD video playerfora long period,
the unit may not function properly in the future.Turn on
and use the DVD video player occasionally.
Notes on locating
Place the DVD video player on a level surface. Do not
useit ona shaky orunstablesurfacesuchas a wobbling
table or inclined stand.The loaded disc may come off
theproper positionand cause damageto the DVDvideo
player.
When you place this DVD video player near aTV, radio,
or VCR, the playback picture may become poor and
thesound maybe distorted.In this case,place the DVD
video player away from the TV, radio, or VCR.
Notes on cleaning
Use a soft, dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe.Use a dry cloth to wipe it
dry.
Do not use any type of solvent, such as thinners and
benzene, as they may damage the surface of the DVD
video player.
If you use a chemical saturated cloth to clean the unit,
follow that product’s instructions.
Inspection and Maintenance
This DVD video player is a high technology, precision
device. If the optical pick-up lens and disc drive parts
become dirty or worn down, the picture quality may be
reduced. To avoid reduction in picture quality, it is
recommended that regular inspection and maintenance
(cleaningor partsreplacement)be performed every 1,000
hours of use. For further details, contact your nearest
consumer electronics dealer.
Notes on moisture condensation
Moisture condensation damages the DVD video player.
Please read the following carefully.
Moisturecondensation occurs,forexample,whenyoupour
a cold drink into a glass on a warm day. Drops of water
formon the outside of theglass.Inthe same way,moisture
may condense on the optical pick-up lens inside this unit,
one of the most crucial internal parts of the DVD video
player.
Moisture condensation occurs during the following
cases.
When you bring the DVD video player directly from a
cold place to a warm place.
When you use the DVD video player in a room where
you just turned on the heater, or a place where the cold
wind from the air conditioner directly hits the unit.
Insummer,whenyou use the DVD video playerin a hot
and humid place just after you move the unit from an
air conditioned room.
When you use the DVD video player in a humid place.
Do not use the DVD video player when moisture
condensation may occur.
If you use the DVD video player in such a situation, it
maydamage discs and internal parts.Removethe disc,
connect the power cord of the DVD video player to the
wall outlet, turn on the DVD video player, and leave it
fortwoor three hours.After two or threehours, the DVD
video player will have warmed up and evaporated any
moisture.Keep the DVD video player connected to the
walloutlet and moisturecondensation willseldom occur.

9
Introduction
Notes on Discs
Playback side
Track 1 Track 2 Track 3 Track 4 Track 5
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc cause picture and
sound deterioration. Wipe the disc from the center
outwards with a soft cloth.Always keep the disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Donot use anytype ofsolventsuch as thinner, benzine,
commercially available cleaners or antistatic spray for
vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
VIDEO CD/audio CD
DVD video disc
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titlesare sub-divided into chapters.VIDEOCDsand audio
CDs are divided into tracks.
DVD video disc
VIDEO CD/audio CD
Each title, chapter or track is assigned a number, which is
called “title number”, “chapter number” or “track number”
respectively.
There may be discs that do not have these numbers.
Notes on copyright
The unauthorized recording, use, distribution, or revision
of copyrighted materials including, without limitation,
television programs, videotapes, and DVDs, is prohibited
under the Copyright Laws of the United States and other
countries,andmaysubjectyoutocivil and criminal liability.
Thisproduct incorporatescopyrightprotection technology
that is protected bymethod claims of certain U.S.patents
andotherintellectual property rightsownedbyMacrovision
Corporationand other rights owners.Use of this copyright
protectiontechnology must be authorizedby Macrovision
Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering or
disassembly is prohibited.

10
Introduction
Playable discs
This DVD video player can play the following discs.
• You cannot play discs other than those listed above.
• Youcannot playDVD-RAMdiscsor non-standardized discs,
etc., even if they may be labeled as above.
• This DVD video player uses the NTSC/PAL colour system,
and cannot play DVD video discs recorded in any other
colour system (SECAM, etc.).
Because of problems and errors that can occur during the
creation of DVD and CD software and/or the manufacture of
DVD and CD discs,Toshiba cannot assurethat this DVD video
player will successfully play every disc bearing the DVD and
CD logos. As one of the creators of DVD technology,Toshiba
DVD players are manufactured using the highest standards
of quality, and as a result, such incompatibilities are rare.
Notes on Discs (continued)
DVD
video
discs
Disc Mark Contents
Disc
Size Maximum
playback time
VIDEO
CDs
Approx.4 hours
(single sided disc)
Approx.8 hours
(double sided disc)
Approx.80 minutes
(single sided disc)
Approx.160 minutes
(double sided disc)
Approx.74 minutes
Approx.20 minutes
8 cm
12 cm
8 cm
12 cm
Audio
+
video
(moving
pictures)
Audio
+
video
(moving
pictures)
Audio
CDs
Approx.74 minutes
Approx.20 minutes
8 cm
(CD
single)
12 cm
Audio
The following discs are also available.
DVD-R/DVD-RW discs of DVD video format
CD-R/CD-RW discs of CD-DA, Video CD, SVCD, MP3
or JPEG format.
Some of these discs may be incompatible.
About this owner’s manual
Thisowner’s manual explainsthebasic instructions of this
DVD video player.Some DVD video discs are produced in
a manner that allows specific or limited operation during
playback.As such, the DVD video player may not respond
to all operating commands.This is not a defect in the DVD
video player. Refer to instruction notes of discs.
“ ” may appear on the TV screen during operation.
A “ ” means that the operation is not permitted by the
DVD video player or the disc.
Notes on region numbers
The region number of this DVD video player is 5.If region
numbers, which stand for their playable area, are printed
on your DVD video disc and you do not find or ,
disc playback will not be allowed by the player. (In this
case, the DVD video player will display a message on-
screen).
OnVIDEO CDs
ThisDVD video playersupportsVIDEO CDs equippedwith
the PBC (Version 2.0) function. (PBC is the abbreviation
ofPlaybackControl.)Youcanenjoytwoplaybackvariations
depending on types of discs.
• VIDEOCD not equippedwith PBC function (Version1.1)
Soundand moviecanbe playedonthis DVD videoplayer
in the same way as an audio CD.
• VIDEO CD equipped with PBC function (Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the TV screen (Menu Playback).
Some of the functions described in this owner’s manual
may not work with some discs.
DivX®
Audio
+
video
(moving
pictures)
It depends on DivX
®
quality
8 cm
12 cm
DIGITAL VIDEO

11
Introduction
Table of Contents
Introduction
SAFETY PRECAUTIONS ............................2
IMPORTANT SAFETY INSTRUCTIONS ....4
Precautions................................................. 8
Notes on Discs ........................................... 9
Notesonregion numbers.................................10
Tableof Contents .......................................11
Identificationof Controls..........................12
Front panel ..................................................... 12
Rear panel...................................................... 13
DVD display.......................................................13
Remote control ............................................... 14
Loading batteries ........................................... 15
Operating with the remote control .................. 15
Connections
Connectingto aTV ....................................18
Connecting to a TV (Using the SCART socket)
..........................................................................18
Connecting to a TV (Using the phono type jacks)
..........................................................................18
Connecting to a TV (Using the component video
jacks)...............................................................19
Connecting to a display (Using a HDMI cable) 20
Connecting to Optional Equipment ........ 22
Connecting to an amplifier equipped with a
Dolby®Digitaldecoder ....................................23
Connecting to an amplifier equipped with
Dolby Surround Pro Logic............................ 23
Connecting to an amplifier equipped with a
DTS decoder ................................................ 24
Connecting to an amplifier equipped with an
MPEG2 audio decoder................................. 24
Connecting to an amplifier equipped with a
digital audio input......................................... 24
Basic playback
Playing a Disc......................................... 26
Basic playback ............................................... 26
Variable Speed Playback ....................... 28
Playing in fast reverse or fast forward
directions...................................................... 28
Playing frame by frame ..................................28
Playing in slow-motion ...................................29
Resuming playback from the same location .. 29
Locating a Desired Section ................... 30
Locating a title using the top menu ................ 30
Locating a desired section by entering the
corresponding number ................................. 31
Locating a specific chapter or track ...............31
Advanced playback
Accessing a Specific Location Directly ... 34
Entering the time counter of the desired
location......................................................... 34
Repeating a Specific Segment .............. 35
Repeating a specific segment ........................ 35
Playing in aVaried Order ....................... 36
Playing titles, chapters or tracks in a varied
order.............................................................36
Playing in a Favourite Order.................. 37
Setting titles, chapters, or tracks in a favourite
order.............................................................37
Zooming a Picture.................................. 38
Zooming a picture ..........................................38
Selecting the Picture Enhancement
(E.P.M.) .................................................... 39
Selecting the picture enhancement................ 39
Selecting the Sound Enhancement
(E.A.M.) ................................................... 40
Selecting the sound enhancement.................40
Selecting the Camera Angle.................. 41
Changing the camera angle ........................... 41
Selecting Subtitles ................................. 42
Selecting a subtitle language ......................... 42
Selecting a Language ............................ 43
Selecting a playback audio setting.................43
On-screen Display Operation................ 44
On-screen display operation ..........................44
Playing MP3 Files................................... 46
Playing MP3 files............................................46
Viewing JPEG Files................................ 48
Viewing JPEG files ......................................... 48
Viewing a thumbnail view............................... 49
Slide Show playback ......................................49
Playing DivX®/MPEG-4 Files .................. 51
Playing DivX®/MPEG-4 files ........................... 51
Function setup
Customizing the Function Settings ...... 54
Setting procedure...........................................54
Setting details.................................................55
Table of Languages................................ 64
Others
Before Calling Service Personnel ......... 66
Specifications......................................... 67

12
Introduction
Identification of Controls
See the page in for details.
Front panel
26
27
26
15
26 13
20
HDMI indicator
26
31
SKIP buttons

13
Introduction
Rear panel
DVD display
Chapter/Track
numberIndicator
The indicators vary depending on the kinds of discs you play.
Multifunctionalindicator (indicates
operating status or messages, etc.)
Bad disc
• During playback:
Example • During playback: Example • During playback: Example
Some discs may only
display chaper numbers. Some discs may only display track numbers. Some discs may only display track numbers.
LOAD/CLOSE
No disc
OPENAudio CDVIDEO CDDVD video disc
20
HDMI OUT
jack 19
18
18 19
20
AV (SCART) socket 22 23 24
Power cord

14
Introduction
Identification of Controls (continued)
The instructions in this manual describe the functions on the remote control. See the page in for details.
Remote control
* MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
30
* RETURN button
Return to menu display forVCD (2.0) discs with menu.

15
Introduction
Open the cover.
Insert batteries (R03/AAA size).
Make sure to match the + and – on the batteries
to the marks inside the battery compartment.
Caution
• Never throw batteries into fire.
Notes
• Be sure to use R03/AAA size batteries.
• Dispose of batteries in a designated disposal area.
• Attention should be drawn to the environmental aspects of
battery disposal.
• Do not mix different battery types or combine used batteries
with new ones.
• If the remote control does not operate correctly, or if the
operating range becomes reduced, replace both batteries
with new ones.
• Ifthe batteries are dead or if you will notbe usingthe remote
control for a long time, remove the batteries to prevent
battery acid from leaking into the battery compartment.
Operating with the remote control
Point the remote control at the remote
sensor and press the buttons.
Distance: About 7 m (23 feet) from the front of the
remote sensor
Angle: About 30° in each direction of the front of
the remote sensor
* Do not expose the remote sensor of the DVD video
playerto a strong light source suchas direct sunlight
or other illumination. If you do so, you may not be
able to operate the DVD video player via the remote
control.
Notes on the remote control
• Direct the remote control at the remote sensor of the DVD
video player.
• Whenusingthe remote control, pressthe buttonsatintervals
of about 1 second to ensure the correct mode of operation.
• Do not drop or give the remote control a shock.
• Do not leave the remote control near an extremely hot or
humid place.
• Do not spill water or put anything wet on the remote control.
• Do not open the remote control.
2
Loading batteries
1

Connections
Read this chapter first to make all necessary
preparations.
Connecting to aTV
(Using the SCART socket)
Connecting to aTV
(Using the phone type jacks)
Connecting to aTV
(Using the component video
jacks)
Connecting to a display
(Using a HDMI cable)
Connecting to an amplifier
equipped with a Dolby®Digital
decoder
Connecting to an amplifier
equipped with Dolby Surround
Pro Logic
Connecting to an amplifier
equipped with a DTS decoder
Connecting to an amplifier
equipped with an MPEG2 audio
decoder
Connecting to an amplifier
equipped with a digital audio
input

18
Connections
Connecting to a TV
Connect the DVD video player to your TV.
For details of output sound, see
43
.
Connecting to aTV (Using the SCART socket)
Notes
• Refer to the owner’s manual of the connected TV as well.
• When you connect the DVD video player to your TV, be sure to turn off the
power and unplug both units from the wall outlet before making any connections.
• If your television set has one audio input, connect the left and right audio outputs
of the DVD video player to aY cable adapter (not supplied) and then connect to
your TV.
• Connect the DVD video player directly to yourTV. If you connect the DVD video
player to a VCR, TV/VCR combination or video selector, the playback picture
may be distorted as DVD video discs are copy protected.
• Analog audio out will not have sound if DTS playback is selected.
Connecting to aTV (Using the phono type jacks)
• Make the following setting.
On-screendisplay Select:
Page
Composite
Component
RGB
P-Scan
HDMI
“VideoOutput”
59
• Make the following setting.
On-screendisplay Select: Page
“PCM”or
“Raw”
“DigitalOutput”
“VideoOutput” Composite
Component
RGB
P-Scan
HDMI
59
61

19
Connections
Connecting to aTV (Using the component video jacks)
Interlaced outputs
Some TVs or monitors are equipped with component video
inputs.Connecting to these inputs allows you to enjoy higher
quality picture playback.
Actuallabels forcomponent video inputs mayvary depending
on the TV manufacturer. (ex.Y, R-Y, B-Y orY, CB, CR)
In some TVs or monitors, the colour levels of the playback
picture may be reduced slightly or the tint may change. In
such a case, adjust the TV or monitor for optimum
performance.
Progressive outputs
Some TVs or monitors are equipped with component video
inputs that are capable of reproducing a progressively scanned
video signal. Connecting to these inputs allows you to view the
highest quality pictures with less flicker.
Consumers should note that not all high definition television
sets are fully compatible with this product and may cause
artifacts to be displayed in the picture. In case of 525 or 625
progressive scan picture problems, it is recommended that
the user switch the connection to the “standard definition”
output.If there are questions regarding our TV set compatibility
with this model 525p or 625p DVD player, please contact our
Customer Service Center.
Switching the output signal (interlaced /
progressive) using the remote control
You can temporarily switch the output signal for better
picture quality.
Press PROGRESSIVE on the remote control during
stop mode.
Press PROGRESSIVE again to turn off progressive
mode.
Notes
• Refer to the owner’s manual of the connected equipment as well.
• When you connect the DVD video player to other equipment, be sure to turn off the power and unplug all of the equipment from
the wall outlet before making any connections.
• If you place the DVD video player near a tuner or radio, the radio broadcast sound might be distorted. In this case, place the
DVD video player away from the tuner and radio.
• The output sound of the DVD video player has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate
listening level. Otherwise, high volume sound may damage your hearing as well as the speakers.
• Turn off the amplifier before you connect or disconnect the DVD video player’s power cord. If you leave the amplifier power on,
the speakers may be damaged.
• Progressive can be on/off only when “Video Output” is set to Component or P-Scan
59
.
• When the TV system is set to NTSC mode, all output will be forced to NTSC type (eg. 525p (480p), 525i (480i), etc.)
• When the TV system is set to PAL mode, all output will be forced to PAL type (eg. 625p (576p), 625i (576i), etc.)
• Analog audio out will not have sound if DTS playback is selected.
• Make the following setting.
On-screendisplay Select: Page
“PCM”or
“Raw”
“DigitalOutput”
Component
*P-Scan
(Progressive)
“VideoOutput”
59
* Only for TV equipped with component
video input jacks which support the
progressive scan.
61

20
Connections
Connecting to a display (Using a HDMI cable)
About HDMI
HDMI (High Definition Multimedia Interface) supports both
video and audio on a single digital connection for use with
DVD players, DTV, set-top boxes, and other AV devices.HDMI
was developed to provide the technologies of High Bandwidth
Digital Content Protection (HDCP) as well as Digital Visual
Interface (DVI) in one specification. HDCP is used to protect
digital content transmitted and received by DVI-compliant or
HDMI-compliant displays.
Connecting to a TV (Continued)
HDMIhas the capability to support standard,enhanced, or high-
definition video plus standard to multi-channel surround-sound
audio. HDMI features included uncompressed digital video, a
bandwidth of up to 2.2 gigabytes per second (with HDTV)
signals), one connector (instead of several cables and
connectors), and communication between the AV source and
AV devices such as DTVs.
HDMI, the HDMI logo and High-Definition Multimedia Interface
aretrademarksor registered trademarks of HDMIlicensing LLC.
Available output signals are below:
• 576p (progressive)
• 720p (progressive)
• 1080i (interlaced)
Switching the video quality (HDMI mode) using
HDMI button on the remote control.
Press HDMI on the remote control to receive a suitable
video quality.The video quality is required to match your
TV having HDMI feature and suitable quality. Please also
check your TV owner’s manual.
Press HDMI button on the remote control to change the
outputsignals asbelow.See theHDMI indicatorand select
the appropriate output signal.
576p, 720p and 1080i are signals created with this DVD
Playerfrom original 480i/576i signal.The resolution ofthe
picture may not be increased even if they are selected.
HDMI indicator Video output signal
illuminates “ • 1080i” 1080i(interlaced)
illuminates “ • 720p” 720p (progressive)
illuminates “ • 576p” 576p (progressive)
Press
Press
Press
(notsupplied)
• Make the following setting.
On-screendisplay Select:
Page
“PCM”
“DigitalOutput”
HDMI
“VideoOutput”
59
61
