Toshiba SD-K510 User manual

DVD VIDEO PLAYER
SERVICE MANUAL
Aug., 2002
S
FILE NO. 810-200214I-JP
SD-K510 SD-K610 SD-K710
SD-310V SD-K620
SD-1800 SD-2900
SD-K510

CONTENTS
1. PRINTED WIRING BOARD AND SCHEMATIC DIAGRAM
Printed Wiring Board and Schematic Diagram................................................................3
2. BLOCK DIAGRAM
Overall Block Diagram (mk1) .........................................................................................4
Overall Block Diagram (mk2) .........................................................................................5
3. CIRCUIT DIAGRAM
Power Circuit Diagram.....................................................................................................6
Power LED Circuit Diagram............................................................................................ 7
Front Display Circuit Diagram.........................................................................................8
Main Circuit Diagram (mk1)........................................................................................... 9
Main Circuit Diagram (mk2)......................................................................................... 10
4. PC Boards
Power Supply PC Board (Top)...................................................................................... 11
Power Supply PC Board (Bottom)................................................................................ 12
Power Supply PC Board (Pattern)................................................................................. 13
5. PARTS LIST....................................................................................................................... 14

14P Press-fit
E +9V 1 1 E+9V
GND 2 2 GND
E -9V 3 3 E-9V
PW ON 4 4 PWON
E +5V 5 5 E+5V
VDD +5V 6 6 VDD+5V
VDD +3V 7 7 VDD+3V
GND 8 8 GND
GND 9 9 GND
M +8V 10 10 M+8V
M GND 11 11 MGND
VKK -34V 12 12 VKK-34V
F- 13 13 F-
F+ 14 14 F+
Mechanism W501
FFC 1mm 23P
23 VCC 1
22 RF 2
21 LD2 3
20 MON2 4
19 VOR2 5
18 GND 6
17 VREF 7
16 VCC 8
15 F0 9
14 E0 10
13 A0 11
12 D0 12
11 C0 13
10 B0 14
9F+ 15
8T- 16
7T+ 17
6F- 18 GND 1
5VCC 19 5V 2
4GND 20 TXD 3
3LD 21 CTS 4
2MON 22 RXD 5
1VOR 23 RTS 6
W502
FFC 1.25mm 5P
5GND 1
4LDMP 2
3OPN/CLS 3
2LDMN 4
1MEDET 5
W503
FFC 1mm 8P
8FMN 1
7FMP 2
6GND 3
5LMT 4
4DMN 5
3DMP 6
2VCC 7
1DMFG 8
1 2 3 4 5 6 7 8 9
10 11 12 13
W602
W102
RIBBON CABLE FFC 1mm 13P
FFC 2mm 5P
13 12 11 10 9 8 7 6 5 4 3 2 1
1GND 1
2RMT IN 2
3EVER5V 3
4POWLED 4
5POWKEY 5
Printed Wiring Board and Schematic Diagram
SD-K510U
RSTOX
PWRCNT
E+5V
HMUTE
DSPRSTX
DSPSIO-D-M
DSPSIO-D-M
DSPCKX
F-
DSTBX
GND
VKK-34V
F+
MAIN
FRONT
POWER-SW
POWER CN601
CN501
CN502
CN503
CN603
PUH
TRAY
MOTOR
CN101
CN102CN105
CN701
CN801
Boad-in

SD-K510 (mk1) Overall Block Diagram
VIDEO DRIVER
MM1567AJBE
AV-1Chip Processor
ZR36732
16M-S-DRAM
HY57V1616DTC x2
YCBCR
/ S
Composit
Main-CPU
TMP94CS251AF
8M-FROM
MBM29F800TB
EE-PROM
BR24C01AF
9MHz
CeraOSC
Analog
Audio
Out
Data/Control Bus
DVD AV Data
Audio-DAC
PCM1742KE
27MHz
Xtal OSC
1M DRAM
M11B11664A
Digital
Audio
Out
PUH Driver
&
Motor Driver
BA5813FM
Integrated
Data processor
TC94A03F
RF Amp.
TA1323F 1M-DRAM
M11B11664A
NEW PARTS
Buffer
TC74HCU04AF
LPF AMP
NJM4580
PUH&MOTOR
ASSY
Front-CPU
TMP86CK74AFG
-3UA6
FL
22.5792MHz
CeraOSC

SD-K510 (mk2) Overall Block Diagram
VIDEO DRIVER
MM1567AJBE
AV-1Chip Processor
ZR36732
16M-S-DRAM
HY57V1616DTC x2
YCBCR
/ S
Composit
Integrated
Data Processor
TC94F33AF
8M-FROM
MBM29LV800BT
EE-PROM
BR24C01AF
Analog
Audio
Out
Data/Control Bus
DVD AV Data
Audio-DAC
PCM1742KE
27MHz
Xtal OSC
16M SDRAM
HY57V1616DTC
Digital
Audio
Out
PUH Driver
&
Motor Driver
BA5813FM
RF Amp.
TA1363F
NEW PARTS
Buffer
TC74HCU04AF
LPF AMP
NJM4580
PUH&MOTOR
ASSY
Front-CPU
TMP86CK74AFG
-3UA6
FL
22.5792MHz
CeraOSC

Safety Location
No. Part No. Description
ZF23
79088028
CORD POWER, UL
ZF01
79078066
REMOCON HAND UNIT Black,SE-R0047
ZF01
79078069
REMOCON HAND UNIT Silver, SE-R0049
ZF10
79077224
OWNER'S MANUAL, ENGLISH, SD-K510
ZF11
79077225
OWNER'S MANUAL, SPANISH, SD-K510
ZF10
79077226
OWNER'S MANUAL, ENGLISH, SD-310V/1800
ZF11
79077227
OWNER'S MANUAL, SPANISH, SD-310V/1800
ZF10
79077228
OWNER'S MANUAL, ENGLISH/FRANCE, SD-310V/1800
PARTS LIST
SAFETY PRECAUTION
The parts identified by mark are critical for safety. Replace only with part number
specified. The mounting position of replacement is to be identical with originals.
The substitute replacement parts which do not have the same safety characteristics as specified
in the parts list may create shock, fire or other hazards.

4-1
SPECIFICATIONS
DVD Video Player/Outputs/Supplied Accessories
[DVD Video Player]
Power supply 120 V AC, 60 Hz
Power consumption 14 W
Mass 2.2 kg
External dimensions 430 x 60 x 222 mm (W/H/D)
Signal system Standard NTSC
Laser Semiconductor laser, wavelength 650/780 nm
Frequency range DVD linear sound :48 kHz sampling 4 Hz to 22 kHz
96 kHz sampling 4 Hz to 44 kHz
Signal-to-noise ratio More than 112 dB
Audio dynamic range More than 102 dB
Harmonic distortion Less than 0.002%
Wow and flutter Below measurable level (less than ± 0.001% (W. PEAK))
Operating conditions Temperature: 5 °C to 35 °C, Operation status: Horizontal
[Outputs]
Video output 1.0 V (p-p), 75 Ω, negative sync., pin jack x 1
S video output (Y) 1.0 V (p-p), 75 Ω, negative sync., Mini DIN 4-pin x 1
(C) 0.286 V (p-p), 75 Ω
Component video output (Y) 1.0 V (p-p), 75 Ω, negative sync., pin jack x 1
(PB)/(PR) 0.7 V (p-p), 75 Ω, pin jack x 2
Audio output (BITSTREAM/PCM 0.5 V (p-p), 75 Ω, pin jack x 1
COAXIAL)
Audio output (ANALOG) 2.0 V (rms), 680 Ω, pin jacks (L,R) x 1
[Supplied Accessories]
Audio/video cable ..............................................................................................................1
Remote control (SD-K510:SE-R0047) (SD-1800, SD-K310V:SE-R0047/SE-R0049) ........1
Batteries (AA) ....................................................................................................................2
* Designs and specifications are subject to change without notice.
