Toshiba TLS-WPD User manual

TLS-WPD:
Length: 9.05in
Width: 18.1in
Height: 9.05in
Weight: 11.50lbs
Toshiba TLS-WPD LED Wallpack Luminaire
Important Notice
These instructions are not intended to cover all details or variations
in the products, nor do these instructions provide for every possible
contingency concerning the installation, operation, or maintenance of
the wallpack. Should additional information be required, contact your
Toshiba Customer Support Center at 855-829-5959.
The contents of this manual shall not become a part of or modify
any prior or existing agreement, commitment or relationship. The
sales contract contains the entire obligation of Toshiba International
Corporation. Toshiba International Corporation’s standard limited
warranty is the sole warranty obligation of Toshiba International
Corporation and any statements contained herein do not create new
warranties or modify the existing warranty.
Service and maintenance of luminaires should be performed
by a qualied, licensed electrician. Any electrical or mechanical
modications to the wallpack without the prior written consent of
Toshiba International Corporation may void all warranties or other
safety certications. Unauthorized modications may also result in
safety hazards or damage to the wallpack. Misuse of the wallpack
could result in injury and equipment damage. In no event will Toshiba
International Corporation be responsible or liable for direct, indirect,
special or consequential damage or injury that may result from the
misuse of the wallpack.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Save these instructions for future use.
Installation Instructions
©2013 Toshiba International Corporation QD-GL02-WI05-101113-0
WARNING
Risk of electric shock. Disconnect power before servicing
or installing luminaire.
WARNING
Risk of injury or damage. Luminaire will fail if not installed
properly. Follow installation instructions.
WARNING
Risk of injury. Wear safety glasses and gloves during
installation and servicing. Allow ample time to cool
before handling.

Inspection
• The packaging has been designed to protect the wallpack from damage during transit. Inspect
product for damage before installation.
Direct mounting to recessed box Wall Mounting
1. Remove the mounting plate loosening 2 set screws from the xture. (gure a)
2. Mount luminaire to wall over recessed wiring box using hardware by others (minimum size 8-32
screws) while leveling the product.
3. Complete the wiring to the power source and ground. Push connections into outlet box.
NOTE: Make sure that all electrical connections are in accordance with the National Electrical Code
(NEC) and any applicable local code requirements.
NOTE: Check the rated input voltage on the luminaire product label, and verify that the supply voltage
meets the product requirements.
Make supply wiring and luminaire wiring connections inside the wiring box:
»CONNECT WHITE (common) SUPPLY WIRE TO WHITE FIXTURE LEAD.
»CONNECT BLACK (hot) SUPPLY WIRE TO BLACK FIXTURE LEAD.
»CONNECT GREEN (ground) SUPPLY WIRE TO GREEN FIXTURE LEAD.
4. Care should be taken when mounting xture not to pinch the wire leads. Align the xture against the
mounting plate. (gure b)
5. Secure the xture by tighten the 2 set screws to lock the mounting plate. (gure a)
6. To weather-proof for outdoor installation, be sure to seal all holes in xture housing (mounting,
conduit, plugs, photocontrols, etc.) with silicone sealant.
»DO NOT OPEN THE LENS.
» DO NOT TOUCH THE SURFACE OF THE LEDS.
CAUTION: This xture must be mounted in the LENS DOWN position.
Maintenance
• Depending on environmental conditions, it may be necessary to clean the lens in order to maintain a
high-efciency lens. (Use solvent-free cleaners.)
Storage
• Prior to installation, the product should be placed in a covered, dry storage. The storage location
should not exceed the normal operating temperature of the product.
Installation Instructions
©2013 Toshiba International Corporation QD-GL02-WI05-101113-0
gure a
gure b
