TOSHIBA PORTEGE 7010CT Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS P7010.doc Rev. 14 04/04/00 nmm. Page 1 of 3
FEATURED SKU’s DESCRIPTION
PAP701U-T2W5 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows 95
PAP701U-T2N4 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows NT Workstation 4.0
PROCESSOR (All models) Intel Mobile PentiumII (As Listed: See Featured SKU’s)
Available Processor speeds 300MHz (1.6v/1.8v/3.3v)
Integrated Coprocessor Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
LEVEL 2 (L2) CACHE Yes: 512KB Integrated into CPU
Data Memory Type 2 Mbit Pipelined Burst Synchronous SRAM (3.3V)
Access Time 8 ns
Data Bus Width/Address Bus Width 64-Bit/32-bit
Front Side Bus Speed 66 Mhz
SYSTEM ARCHITECTURE (All models) Chipset Connecting Devices:
PCI (V.2.1) Bus: (32-bit, 33 MHz) Intel 440BX Graphics, PC Card, Expansion Bus, Modem DSP, HDD
ISA Bus: (8-bit, 8mhz) BIOS, KBC, FDD, Sound chip
MEMORY: 64Mbit SO-DIMM SDRAM, 3.3V (All models)
Standard/ Maximum 32 MB/160 MB
Speed 66MHz w/ Hyper Page mode support
Data Bus Width/Address Bus Width 64-bit/32-bit
Front Side Bus Speed 66 MHz
BIOS (4Mbit FLASH EPROM, 100ns,5.0V) Yes: 512KB
Supported standards APM(1.2); PnP(1.0a); VESA(2.0); DDC2B; DPMS; PCI BIOS;
DMI(2.0); ACPI(1.0)
DISPLAY (All models)
Type 12.1” Diagonal TFT Active Matrix Color, 800 x 600
Dot Pitch 0.30mm x .30mm
Contrast Ratio 100:1 (Min)
VIDEO (All models)
Memory: SGRAM 2.5MB (integrated into Controller chip)
Speed 83MHz w/ Hyper Page mode support
Controller Chip NeoMagic (2200) w/256-bit Data Bus Width
PCI Bus Architecture w/burst mode Yes: 32-bit, 33 MHz
Graphics Accelerator: Yes: 128-bit BitBLT engine
2D Graphics support BitBLT, H/W Cursor, DirectDraw
3D Graphics support Direct3D, OpenGL
Digital Video Accelerator: Yes
YUV-to-RGB color space conversion Yes
Scaling Support Yes
Zoom (vertical and horizontal) Yes
Interpolation (vertical and horizontal) Yes
DirectVideo, DirectMPEG support Yes
TV Encoder support (NTSC/PAL) Yes: Requires CD Network Dock (Part# PA2723U)
INTERNAL SUPPORT (All models)
Full screen 800 x 600 x 16.7M colors
Smaller Image 640 x 480 x 16.7M colors (Full screen using Stretch mode utility)
Virtual Image 1024 x 768 x 16.7M colors
Virtual Image 1280 x 1024 x 256 colors
EXTERNAL SUPPORT (All models) Vert. Refresh Rate (Non-Interlaced)
Colors External Mode/Simultaneous Mode
640 x 480 16.7M colors 85Hz/60Hz
800 x 600 16.7M colors 85Hz/60Hz
1024 x 768 64K colors 85Hz/60Hz
1280 x 1024 256 colors 60Hz/60Hz

TOSHIBA PORTEGE 7010CT Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS P7010.doc Rev. 14 04/04/00 nmm. Page 2 of 3
FEATURED SKU’s DESCRIPTION
PAP701U-T2W5 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows 95
PAP701U-T2N4 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows NT Workstation 4.0
STORAGE (All models)
HDD (2.5” Enhanced IDE, 9.5mm height) 4.3 billion bytes (13msec)
Removable Yes: User removable, 1 service screw required
Transfer rates supported Ultra DMA33, DMA mode 2, PIO Mode 4
FDD (3.5” 1.44MB, 15mm height) -- External External use via bundled floppy connector
CD-ROM See Optional CD Network Dock Section
Future DVD Hardware Solution Available (Optional: for Windows 95 models only)
DVD-ROM Compatibility DVD-ROM only (DVD-RAM not supported)
DVD-Movie compatibility Region 1 (North America).
ActiveMovie support Yes
Motion Video Playback Currently standard on all models
MPEGII video support Yes: using C-Cube Microsystems ZiVA-PC Decoder chip
MPEGII audio support Yes
DolbyDigital Surround Sound AC-3 Yes: (5.1 channel, common with Headphone jack/AC3 digital)
KEYBOARD (All models)
84 keys with Windows support Yes (full-size key caps; 3mm Travel)
12 dedicated function keys Yes
Numeric keypad (Integrated Overlay) Yes
Integrated Pointing Device (All models) AccuPoint
EXPANSION SLOTS (All models)
Two Stacked PC Card Slot (CardBus Ready) Yes: Holds two - 5mm PC Cards Type II or one - 10.5mm PC Card Type III.
32-bit, 3.3V PC CardBus Support Yes
16-bit, 5.0V PC Card Support Yes
Internal Memory Slot (One only) Yes
EXPANSION PORTS (All models) LOCATION
One Headphone (3.5mm mini jack, stereo) Yes: Front of unit
One Microphone (3.5mm mini jack, stereo) Yes: Front of unit
One 15-Pin RGB (SVGA video) Yes: Rear of unit
One DC Power-in Jack Yes: Rear of unit
One 240-pin expansion bus Yes: Bottom of unit
One Kensington cable lock slot Yes: Right side
One RJ11 Port for internal modem Yes: Right side
One External Floppy Drive port Yes: Left side
One Universal Serial Bus (USB) port Yes: Left side (Supports 127devices. Throughput Rate: 12Mbits/sec.)
One Fast Infrared port (IrDA1.1: 4Mbps) Yes: Left side
One Power Switch Yes: Left side
I/O BAR (Port Expander) (1) Standard: Connects to I/O Port Adapter Port -- Left side
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One (PS/2) 101 Keyboard/Mouse port Yes: Supports use of Y-cable
SOUND SYSTEM (As Listed)
Chipsets: Yamaha 3D sound effect-enabled OPL3-SA3
Functions supported
DolbyDigital Surround Sound AC-3 Yes: (with Windows 95 only)
Sound formats supported: SoundBlaster Prov.3.01, MIDI, Windows Sound System v.2.0
16 bit stereo audio playback/record Yes: w/48kHz maximum sampling rate
Synthesis Policy FM synthesis with Wavetable software support
Full duplex function Yes: including simultaneous playback and record
DirectSound/Direct3DSound support Yes: (with Windows 95 Game SDK driver from Microsoft only)
Volume control Yes
Speaker system: Single top-mounted speaker (28mm, 16 Ω)

TOSHIBA PORTEGE 7010CT Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS P7010.doc Rev. 14 04/04/00 nmm. Page 3 of 3
FEATURED SKU’s DESCRIPTION
PAP701U-T2W5 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows 95
PAP701U-T2N4 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows NT Workstation 4.0
INTERNAL MODEM (As Listed) K56flex with DSVD, V.34, V.70, V.80 and (V.90 upgradeable)
Data support (All models)
Protocols supported Bell-103/212A, CCITT-V.21/V.22, V.23, V.22bis, V.32, V.32bis, V.34, K56flex
Error correction MNP 1-4
Data compression MNP 5 for upto 2X data compression, CCITT V.42 bis for upto 4X data compression
Fax support (All models) Fax class 1, Class 1 ECM
Protocols supported V.21 ch2, V.27 ter, V.29, V.17
Telephony Functions (Windows 95 only)
Standard software Ring Zero RingCentral telephony software
Functions supported Speaker phone, Telephony Answering Machine, Ring Wake-up Resume
Incoming Call Discrimination
DSVD protocols supported ITU-T V.70, V.75, V.76, G.729, V.80, V.25terA, V.34, V.8bis
CD Network Dock (Optional )
Part Number Part# PA2723U
Dimensions/ Weight 11.89”L x 10.12”D x 1.02”H (Weight: 2.64 lbs.)
Ethernet connection 10/100BaseT Ethernet (Intel Chipset)
System Management support Wake-On-LAN; Alert-on-LAN; and Remote Service Boot
Integrated FDD Yes
CD-ROM (5.25”, 12.7mm height) 24X Maximum speed CD-ROM
Interface: .ATAPI (Enhanced IDE) Yes: with Local Bus Support & 128KB buffer
Random Access Time 130ms
Sustained Transfer Rate 3600 KB/sec (24X); 2400KB/sec (Average)
Supported Disc formats Red Book, Yellow Book, CD-ROM XA, CD-I Bridge (Photo CD), CD-I,
CD-RW (read only), Multisession (Photo-CD, CD-Extra), CD-I Ready, CD-G
Two Stereo speakers Yes
One 9-Pin Serial (16550 UART compliant) Yes
One 25-Pin Parallel (8 bit ECP) Yes
One SVGA port Yes
One Composite Video port (NTSC/PAL) Yes
One RJ-45 ethernet port Yes
Two Universal Serial Bus (USB) port Yes: Supports 127devices. Throughput Rate: 12Mbits/sec.
One (PS/2) 101 Keyboard port Yes
One (PS/2) Mouse port Yes
One Microphone Yes: (3.5mm mini jack, monoaural)
One Headphone/digital audio port Yes: (3.5mm mini jack, stereo)
One Line-in Yes: (3.5mm mini jack, stereo, 2V rms)
One Line-out Yes: (3.5mm mini jack,stereo, 0.7V rms)
One Manual volume control Yes
One Cable lock slot Yes
CERTIFICATIONS (All models)
USA UL 1012, FCC Part 15 class B
Canada CSA 223, I.Canada
Europe EN 60950, SEV, EN55022
Japan VCCI EMI standard
Australia SAA, SMA
Other Energy Star Compliant, Year 2000 compliant (NSTL Hardware Tested)

TOSHIBA PORTEGE 7010CT Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS P7010.doc Rev. 14 04/04/00 nmm. Page 4 of 3
FEATURED SKU’s DESCRIPTION
PAP701U-T2W5 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows 95
PAP701U-T2N4 PII300, 12.1”, 32MB, 4.3bb HDD, Modem, Windows NT Workstation 4.0
POWER (All models)
Autosensing External AC Adapter: PA2450U 4.9”L x 2.46”W x .97”H --- Weight: .66lbs.
Input (Voltage/Frequency) 100-240V; 50-60Hz
Output (Voltage/Amps) 15 VDC; 3.0A
Power Output (Watts) 45W
Battery Type: Li-Ion Standard (PA2505U) Optional High Capacity (PA2506UR)
Battery Rating 10.8V, 2500mAH 10.8V, 5000mAH
Dimensions 8.18”L x 1.91”W x .77”H 8.18”L x 1.91”W x .77”H
Weight .58 lbs. .58 lbs.
Battery Life: (Full Power) 2.5+ 5.5+ hrs.
Recharge Time (Computer Off/On) 2.5 hrs./4-10 hrs. N/A
Power Saving Features APM v.1.2 BIOS, CPU Sleep mode , HDD Auto Off, Display Auto Off,
Processing speed change, Auto Resume, Hibernation
LCD Brightness switch (software)
CASE CONSTRUCTION Magnesium for extra rigidity and durability
DIMENSIONS (All models) 11.69"L x 9.29"W x 1.1"H (0.9”Front)
WEIGHT (includes . 6 lb. battery) 4.1 lbs.
BUNDLED SOFTWARE (Windows 95 models)
Windows 95; Microsoft Internet Explorer (3.02); Yamaha OPL3-SA3 Audio Rack; Puma Intellisync 97; Ring Zero Ring Central;
Mediamatics Arcade Pak; America On Line; Intel Indeo Video Interactive (32-bit, 4.01)
Additional Software on Configuration Builder CD: LANDesk Client Manager 3.3; Microsoft Internet Explorer (4.1) w/Service Pak;
On-line Registration; Electronic Manual; SMS Connect
CD’s Included: Configuration Builder/Windows 95 CD
BUNDLED SOFTWARE (Windows NT models)
Windows NT 4.0, Service Pack 3; Yamaha OPL3-SA3 Audio Rack; Puma Intellisync 97; Microsoft Internet Explorer (3.02);
Intel Indel Video Interactive (32-bit, 4.1)
Additional Software on Configuration Builder CD: Intel LANDesk Client Manager 3.3; Microsoft Internet Explorer (4.01);
Electronic manual; Symantec Norton AntiVirus (Scan and Repair)
CD’s Included: Configuration Builder CD --- Allows HDD restore, Create custom pre-install, &/or install of individual drivers,
applications, or utilities.
SECURITY (All models)
Password security Power-on, Supervisor, HDD, Eject
Lock mechanisms Kensington cable lock, Main memory & HDD (screw only),
PC Card (when docked)
Miscellaneous Keyboard (by Hotkey), Screen blank (by Hotkey)
WARRANTY (All models) 3 YR Parts & Labor (1 YR Battery)
ENVIRONMENTAL SPECIFICATIONS (All models) Operating Non-operating
Temperature 41°F (5°C) to 95°F (35°C) -4°F (-20°C) to 149°F (65°C)
Thermal Gradient:20º C per hour (max.) N/A N/A
Relative Humidity 20%to 80%non-condensing 10%to 90%non-condensing
Altitude: -197 to 9,843ft. (-60 to 3000m) -197 to 32,808ft. (-60 to 10,000m)
Shock: 10G (11ms); 1.5G (docked) 60G (66ms); 50G (docked)
Vibration: 0.5G (5~500Hz); 0.25G (docked) 1G (5~500Hz); 1G (docked)
