Toshiba Satellite Pro M70-198 User manual

Satellite Pro M70-198
Part Number : PSM76E-00E005G3
Key Features
Ideal for the image-conscious home or business user who values superb widescreen performance, this stylish notebook features a 15.4" XGA Toshiba
TruBrite (on selected models) display for a crystal-clear picture- Experience the ultimate thrill of high definition viewing. Thanks to "HD to go" from Toshiba,
HD viewing is now going mobile with video images so vivid they almost seem alive- Seamless mobility with Intel® Centrino™ mobile technology plus
Microsoft® Office OneNote™ 2003 for intuitive information management and Toshiba ConfigFree™ for easy management of wireless and wired network
connectivity- Thrilling and breathtaking graphics with ATI MOBILITY™ RADEON™ X700 or X600 SE featuring HyperMemory™ technology or Intel® 915GM
with up to 128 MB RAM (UMA)- Enjoy instant-on entertainment (without having to boot the operating system) via the Express Media Player (on selected
models), along with stunning audio quality courtesy of Harman Kardon® stereo speakers (on selected models)- Offers state-of-the-art connectivity and a
broad range of expansion options, including ireless LAN 802.11b/g, i.LINK, TV-out (S-video), 5-in-1 bridge media slots and Express Card slot (on selected
models) for future-proof PC Card support
S ecifications
Dis lay
size : 15.4 "
type : Toshiba TruBrite® XGA TFT display
internal resolution : 1,280 x 800
dot pitch (HxV) : 0.25875 x 0.25875 mm
typical contrast ratio : 300:1
response rise/fall : 25/25 ms
LCD brightness levels 1-8 : 26-41-57-73-88-103-115-131 cd/m²
Ex ansion
1 x PC Card slot for 1 Type II card
1 x Express Card™ slot
2 x memory slots
Hard disk
capacity : 80 GB
certification : S.M.A.R.T.
height : 9.5 mm
drive rotation : 5,400 rpm
number of disks : 2
number of heads : 4
interface : Serial ATA
buffer size : 8 MB
desktop or notebook? : notebook
Keyboard
manufacturer : Alps
Keys : 86
indows® keys : 2
function keys : 13
Euro key : yes
key pitch : 19.05 mm
key stroke : 2.7 mm
Easy Keys : 5
inlaid numeric keypad : yes
Hot Keys : 2
Non-o erating environmental
conditions
temperature : -20°C - 65°C
maximum thermal gradient : 20°C/hour
relative humidity : 10-95% non-condensing
altitude relative to sea level : -30 to 40,000 feet
shock with optical disk drive installed (without optical disk drive installed) : 60G
vibration with optical disk drive installed (without optical disk drive installed) : 1G
O erating environmental
conditions
temperature : 5°C - 35°C
maximum thermal gradient : 15°C/hour
relative humidity : 20-80%
altitude relative to sea level : -30 to 10,000 feet
shock with optical disk drive installed (without optical disk drive installed) : 10G
vibration with optical disk drive installed (without optical disk drive installed) : 0.5G
System memory
standard : 512 MB
maximum expandability : 2,048 MB
technology : DDR2 RAM
expansion module sizes : 128, 256, 512, 1,024 MB
Interfaces
1 x DC-in
1 x RJ-11
1 x RJ-45
1 x TV-out (S-video)
1 x i.LINK® (IEEE 1394)
1 x built-in speaker
1 x external monitor

1 x headphone (stereo)
3 (Rear 2, Left 1) x USB 2.0
1 x 5-in-1 Bridge Media slot (supports SD™ Cards, Memory Stick®, Memory Stick Pro™, MultiMedia Card™, xD-Picture Card™)
1 x microphone-in
Pointing device
manufacturer : ALPS
type : Touch Pad
interface : PS/2
AC ada ter
input voltage : autosensing AC adapter (100/240 V) for worldwide usage
frequency : 50-60 Hz
output voltage : 19 V
output current : 3.42 A
power dissipation : 65
weight : 305 g
Battery
type : main
technology : lithium-ion
performance : 10.8 V x 4000 mAh
maximum life : up to 2:26 (Mobile Mark™) hours
power on : 12:00 hours
power off : 4:00 hours
Gra hics ada ter
manufacturer : ATI
type : MOBILITY™ RADEON® X700
memory amount : 256 MB
connected bus : 16x PCI Express
Physical dimensions
x L x H : 360 x 263 x 38,5 mm
weight : 2,71 kg
Sound system
manufacturer : Toshiba Bass Enhanced Sound System with SRS® TruSurround XT™ System
supported audio format : 16-bit stereo
speakers : built-in Harman Kardon® stereo speakers
microphone : external
type : Realtec ALC 250
maximum sampling rate : 48 kHz
full duplex support : Yes
direct sound : Yes
direct 3D sound : Yes
volume dial : Yes
External video modes
The following video modes are supported:
resolution:800 x 600 , maximum number of colours:16.7 million, maximum refresh rate (non interlaced) : 100 Hz
resolution:1,024 x 768 , maximum number of colours:16.7 million, maximum refresh rate (non interlaced) : 100 Hz
resolution:1,280 x 1,024 , maximum number of colours:16.7 million, maximum refresh rate (non interlaced) : 100 Hz
resolution:1,600 x 1,200 , maximum number of colours:16.7 million, maximum refresh rate (non interlaced) : 100 Hz
resolution:1,920 x 1,440 , maximum number of colours:16.7 million, maximum refresh rate (non interlaced) : 75 Hz
resolution:2,048 x 1,536 , maximum number of colours:16.7 million, maximum refresh rate (non interlaced) : 60 Hz
Internal video modes
resolution : 1,280 x 800
maximum number of colours : 16.7 million
O erating system
Genuine Microsoft® indows® XP Professional
Wired communication
manufacturer : Askey
topology : international V.90 modem (V.92 ready)
speed : 56 Kbps data (V.90) and 14.4 Kbps fax
features : ring wake-up resume
connector : RJ-11
manufacturer : Realtek
type : 8100CL (on board)
topology : Ethernet LAN
speed : 10/100 Base-TX
features : ake-On-LAN, remote boot
connector : RJ-45
Wireless communication
Manufacturer : Intel® PRO/ ireless 2200BG LAN Mini PCI adaptor integrated in Intel® Centrino® mobile technology
ireless Technology : ireless LAN (802.11b/g)
Manufacturer : Taiyo-Yuden
ireless Technology : Bluetooth®
Version : 2.0
Max. external video modes
max. resolution : 2,048 x 1,536
max. colours : 16.7 million
max. refresh rate : 100 Hz
non-interlaced resolution with max. refresh rate : 1,600 x 1,200
Technology
type : Intel® Centrino® mobile technology including Intel® Pentium® M Processor 760, Intel® PRO/ ireless 2200BG network connection and
Intel® 915PM Express chipset
clock speed : 2.0 GHz
Front Side Bus : 533 MHz
2nd level cache : 2 MB
DVD Su er Multi drive
(Double Layer)
buffer size : 2 MB
compatibility : CD-ROM, CD-R, CD-R , DVD-ROM, DVD-R, DVD-R , DVD+R, DVD+R , DVD-RAM
interface : ATAPI
maximum speed : Read: 24x CD-ROM, 8x DVD-ROM/ rite: 24x CD-R, 4x CD-R , 10x HS CD-R , 10x US CD-R , 8x DVD-R, 2x DVD-R
(Double Layer), 4x DVD-R , 8x DVD+R, 2.4x DVD+R (Double Layer), 4x DVD+R , 5x DVD-RAM
type : DVD Super Multi (Double Layer) drive
weight : 200 g
Bundled hardware
AC adapter
AC power cable
Quick Start guide
user manual
Bundled software
Toshiba utilities and drivers
online user manual
Toshiba ConfigFree™
Sonic™ Record Now!
InterVideo® inDVD
Norton Internet Security™ 2005 (includes free Internet updates for 90 days)
Casework
polycarbonate ABS
Security features
system password security
S ecial features
Multimedia Bar with 6 Easy Keys (Internet Browser, CD-Contol, Rewind, Play, Stop, Forward)
Warranty
2-year international warranty
2-year pick-up-and-return warranty
1-year international warranty. Upgrade your standard warranty with Toshiba warranty extension and uplift packs. Contact your nearest Toshiba
Authorised Reseller for details.
