Toshiba 22D1333G User manual

English - 1 -
English
Contents
Safety Precautions ................................................. 3
Air Circulation ..................................................... 3
Heat Damage...................................................... 3
Mains Supply ...................................................... 3
Warning ............................................................. 3
Do ....................................................................... 3
Do not ................................................................. 3
Installation and Important Information .................... 4
EXCLUSION CLAUSE........................................ 4
Important safety information .................................. 5
Removing the pedestal stand................................. 6
The Remote Control (TV - DVD) ............................ 7
Inserting Batteries and Effective Range of the
Remote Control................................................... 7
Connecting External Equipment............................. 8
Connecting an HDMI®or DVI Device to the HDMI
Input........................................................................ 9
To Connect an HDMI Device .............................. 9
To Connect a DVI Device (PC, DVD Player etc) 9
Connecting a Computer........................................ 10
To Connect a Computer.................................... 10
Connecting a DVD Player..................................... 10
Connecting to a DVD Player via YPbPr............ 10
Connecting a USB Memory...................................11
To Connect a USB Flash Drive..........................11
Power Save Mode ................................................ 12
Environmental Information ............................... 12
Controlling the TV................................................. 13
Switching on ..................................................... 13
Using the Remote Control ................................ 13
Using the Controls on the TV............................ 13
Initial Installation .................................................. 14
Auto Tuning....................................................... 15
Auto Tuning .......................................................... 15
Manual Tuning, Analogue Fine Tuning ................. 16
Digital Aerial Manual Search............................. 16
Digital Cable Manual Search ............................ 16
Analogue Manual Search ................................. 16
Analogue Fine Tune.......................................... 16
General Operation................................................ 17
Stereo and Bilingual Transmissions.................. 17
Displaying Subtitles .......................................... 17
Viewing Main Menu .......................................... 17
Controlling Volume and Muting Sound ............. 17
Selecting Programme Positions........................ 17
Standby Notications........................................ 17
Channel List, Sorting Programmes, Programme
Locking ................................................................. 18
Viewing Channel List ........................................ 18
Moving a Channel............................................. 18
Deleting a Channel ........................................... 18
Renaming a Channel........................................ 18
Locking a Channel............................................ 18
Viewing Info Banner, Electronic Programme
Guide.................................................................... 19
Viewing Info Banner.......................................... 19
Electronic Programme Guide............................ 19
Language Selection.............................................. 20
Language Settings............................................ 20
Preferred....................................................... 20
Current.......................................................... 20
Digital Settings - Parental Control, Menu Lock,
Set PIN ................................................................. 21
Viewing Parental Control Menu ........................ 21
Menu Lock ........................................................ 21
Maturity Lock (*)................................................ 21
Child Lock......................................................... 21
Set PIN ............................................................. 21
Conguring Picture Settings................................. 22
Conguring Picture Settings ............................. 22
Picture Mode..................................................... 22
Contrast ............................................................ 22
Brightness......................................................... 22
Sharpness......................................................... 22
Colour ............................................................... 22
Power Save Mode ............................................ 22
Backlight (optional) ........................................... 22
Noise Reduction ............................................... 22
Advanced Settings........................................ 22
Reset ................................................................ 23
Changing Picture Format...................................... 24
Conguring PC Picture Settings........................... 25
PC Picture Settings (*)...................................... 25
PC Position....................................................... 25
Autoposition...................................................... 25
H Position ......................................................... 25
V Position.......................................................... 25
Dot Clock .......................................................... 25
Phase................................................................ 25
Conguring Sound Settings.................................. 26
Conguring Sound Settings.............................. 26
Operating Sound Settings Menu Items............. 26
Volume.............................................................. 26
Equalizer (Only for speaker)............................. 26
Balance (Only for speaker)............................... 26
Headphone ....................................................... 26
Sound Mode ..................................................... 26
AVL ................................................................... 26
Dynamic Bass................................................... 26
Surround Sound................................................ 26
Digital Out......................................................... 26

English - 2 -
English
Settings Menu Operation, Conditional Access ..... 27
Conguring Your TV’s Settings ......................... 27
Viewing Settings Menu ..................................... 27
Conditional Access ........................................... 27
Language.......................................................... 27
Parental ............................................................ 27
Timers............................................................... 27
Date/Time ......................................................... 27
Sources............................................................. 27
Other Settings................................................... 27
Using a Conditional Access Module ................. 27
Setting Timers, Setting Date/Time........................ 28
Timers............................................................... 28
Setting Sleep Timer .......................................... 28
Setting Programme Timers............................... 28
Conguring Date/Time Settings........................ 28
Source Settings, Other Controls........................... 29
Conguring Source Settings............................. 29
Input Selection.................................................. 29
Conguring Other Settings - General ............... 29
Operation.......................................................... 29
Menu Timeout................................................... 29
Scan Encrypted Channels ............................... 29
Blue Background .............................................. 30
Software Upgrade............................................. 30
Application Version ........................................... 30
Hard of Hearing ................................................ 30
Audio Description.............................................. 30
Auto TV Off ....................................................... 30
Broadcast Type (optional)................................. 30
Standby Search (*) .......................................... 30
Store Mode ....................................................... 30
Power Up Mode................................................ 30
DVD Mode............................................................ 31
Handling Discs.................................................. 31
Cleaning Discs.................................................. 31
DVD - Features................................................ 31
DVD - Control buttons on the TV...................... 32
How to watch a DVD ............................................ 34
Notes on DVD Playback ................................... 34
DVD Mode Conguration.................................. 35
TV Type......................................................... 35
Language Setup ........................................... 35
OSD LANG ................................................... 35
AUDIO .......................................................... 35
DISC MENU.................................................. 35
SUBTITLE..................................................... 35
DEFAULT ...................................................... 35
DOWNMIX .................................................... 35
SURROUND ................................................. 35
STEREO ....................................................... 35
PARENTAL.................................................... 35
PASSWORD ................................................. 35
SPDIF OUTPUT............................................ 35
The DVD picture quality is poor........................ 36
Appendix A: DVD Mode Supported le formats.... 37
Appendix B: Compatible disc types...................... 37
Manual Start ..................................................... 38
Auto Start.......................................................... 38
USB Media Browser ............................................. 38
Playing MP3 Files............................................. 39
Viewing JPEG Files .......................................... 39
Slideshow Feature............................................ 40
Video Playback ................................................. 40
Media Browser Settings.................................... 41
Using MENU button in Media Browser Mode ... 41
To Close the Media Player................................ 41
Analogue Only Text Services................................ 42
Using Text Button -TXT..................................... 42
Acessing Sub-Pages ........................................ 42
Revealing Concealed Text ................................ 42
Holding a Page ................................................. 42
To display an initial page................................... 42
Appendix A: PC Input Typical Display Modes....... 43
Appendix B: AV and HDMI Signal Compatibility
(Input Signal Types).............................................. 44
Appendix C: PIN Information ............................... 45
Appendix D: Supported File Formats for USB
Mode..................................................................... 46
Specications and Accessories ............................ 47
License Information .............................................. 48
Q & A Section ....................................................... 49

English - 3 -
English
Safety Precautions
This equipment has been designed and manufactured to meet international safety standards but, like any electrical equip-
ment, care must be taken to obtain the best results and for safety to be assured. Please read the points below for your own
safety. They are of a general nature, intended to help with all electronic consumer products and some points may not apply
to the goods you have just purchased.
Air Circulation
Leave more than 10cm around all edges when wall mounting
the television to allow adequate ventilation. This will prevent
overheating and possible damage to the television. Dusty
places should also be avoided.
Heat Damage
Damage may occur if the television is left in direct sunlight
or near a heater. Avoid places subject to extremely high
temperatures or humidity, or locations where the temperature
is likely to fall below 5°C (41°F).
Mains Supply
The set should be operated only from a 220-240 V AC 50 Hz
outlet. DO ensure that the television is not standing on the
mains lead. DO NOT cut off the mains plug from this equip-
ment, this incorporates a special Radio Interference Filter, the
removal of which will impair its performance. It should only
be replaced by a correctly rated and approved type. IF IN
DOUBT PLEASE CONSULT A COMPETENT ELECTRICIAN.
Warning
To prevent the spread of re, keep candles or other open
ames away from this product at all times.
Do
DO read the operating instructions before you attempt to
use the equipment.
DO ensure that all electrical connections (including the mains
plug, extension leads and interconnections between pieces
of equipment) are properly made and in accordance with
the manufacturers’ instructions. Switch off and withdraw the
mains plug before making or changing connections.
DO consult your dealer if you are ever in doubt about the
installation, operation or safety of your equipment.
DO be careful with glass panels or doors on equipment.
Do not
DON’T remove any xed cover as this may expose danger-
ous voltages.
DON’T obstruct the ventilation openings of the equipment
with items such as newspapers, tablecloths, curtains, etc.
Overheating will cause damage and shorten the life of the
equipment.
DON’T allow electrical equipment to be exposed to dripping
or splashing or objects lled with liquids, such as vases, to
be placed on the equipment.
DON’T place hot objects or naked ame sources, such as
lighted candles or nightlights on, or close to equipment. High
temperatures can melt plastic and lead to res.
DON’T use makeshift stands and NEVER x with wood
screws. Use only the manufacturers supplied screws.
DON’T leave equipment switched on when it is unattended,
unless it is specically stated that it is designed for unat-
tended operation or has a standby mode. Switch off by
withdrawing the plug, make sure your family know how to do
this. Special arrangements may need to be made for people
with disabilities.
DON’T continue to operate the equipment if you are in any
doubt about it working normally, or it is damaged in any way
- switch off, withdraw the mains plug and consult your dealer.
WARNING - excessive sound pressure from earphones or
headphones can cause hearing loss.
ABOVE ALL - NEVER let anyone, especially children,
push or hit the screen, push anything into holes, slots
or any other openings in the case.
NEVER guess or take chances with electrical equipment
of any kind - it is better to be safe than sorry.
THE MAINS PLUG IS USED AS A DISCONNECTING
DEVICE AND THEREFORE SHOULD BE READILY OP-
ERABLE.
Note : Interactive video games that involve shooting
a “gun” type of joystick at the on-screen target may
not work with this TV.

English - 4 -
English
Locate the television away from direct sunlight and strong
lights. Soft, indirect lighting is recommended for comfortable
viewing. Use curtains or blinds to prevent direct sunlight
falling on the screen.
Place the TV on a stable, level surface that can support the
weight of the TV. In order to maintain stability and prevent
it falling over, secure the TV to a wall using a sturdy tie on
the back of the stand.
The LCD display panels are manufactured using an extreme-
ly high level of precision technology; however, sometimes
some parts of the screen may be missing picture elements
or have luminous spots. This is not a sign of a malfunction.
Make sure the television is located in a position where it
cannot be pushed or hit by objects, as pressure will break
Please take note
The digital reception function of this television is only effective in the countries listed in the “Country” section
during the rst time installation menu. Depending on country/area, some of this television’s functions may not
be available. Reception of future additional or modied services cannot be guaranteed with this television.
If stationary images generated by 4:3 broadcasts, text services, channel identication logos, computer displays,
video games, on screen menus, etc. are left on the television screen for any length of time, they could become
conspicuous. It is always advisable to reduce both the brightness and contrast settings.
Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at
the 4:3 outlines. This is not a defect of the LCD TV and is not covered under the manufacturer’s warranty.
Regular use of other size modes will prevent permanent retention.
EXCLUSION CLAUSE
Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by:
i) re;
ii) earthquake;
iii) accidental damage;
iv) intentional misuse of the product;
v) use of the product in improper conditions;
vi) loss and/or damage caused to the product whilst in the possession of a third party;
vii) any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set out in the
owner’s manual;
viii) any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously with
associated equipment;
Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not
limited to the following, loss of prot, interruption of business, the loss of recorded data whether caused during normal opera-
tion or misuse of the product.
Installation and Important Information
Where to install
or damage the screen. Also, please be certain that small items
cannot be inserted into slots or openings in the case.
Avoid using chemicals (such as air refreshers, cleaning
agents, etc.) on or near the TV pedestal. Studies
indicate that plastics may weaken and crack over time
from the combination effects of chemical agents and mechanical
stress (such as weight of TV). Failure to follow these instructions
could result in serious injury and/or permanent damage to TV
and TV pedestal.
Cleaning the screen and cabinet…
Turn off the power, and clean the screen and cabinet with a
soft, dry cloth. We recommend that you do not use any pro-
prietary polishes or solvents on the screen or cabinet as this
may cause damage.
* Button and stand
style is dependent on
model.
Sturdy tie (as
short as possible)
P CLIP
“P” Clip position on TV is dependent on model.

English - 5 -
English
Important safety information
• Any function relative to the digital television (with the DVB logo) is available only within the country or area
where such signals are transmitted. Verify with the salesperson if it is possible to receive a DVB-T signal in
the zone where you live.
• Even if the television conforms to the DVB-T specications, the compatibility to future digital DVB-T
transmissions is not guaranteed.
• Some digital television functions may not be available in some countries.
• The DVB-T system present in this device is FTA (Free to air).
• DVB is a registered trademark of the DVB Project. This logo indicates that the product is compliant with
European Digital Broadcasting.
IMPORTANT INFORMATION
TV Installation
• Not standing the televisions on cloth or other materials placed between the television and supporting furniture.
• Educating children about the dangers of climbing on furniture to reach the television or its controls.
• Always hold the plug when disconnecting the unit from the socket outlet. Do not pull on ex. The ex can
become damaged and cause a short circuit.
• Use a soft, dry cloth to clean the unit.
• Set up unit so that no one will trip over the ex.
• If you intend to wall mount the unit, contact the shop where you purchased the unit for advice, and leave the
installation work to professionals. Improper installation can cause damage and/or injuries.
• To protect the unit during a thunder storm, unplug the AC power cord and disconnect the aerial, cable and
satellite decoder/systems etc.
Caution: Do not touch the aerial connector.
• The unit becomes warm when in operation. Do not place any covers or blankets on the unit in order to
prevent overheating.
The ventilation holes should not be blocked. Do not set up near radiators. Do not place in direct sunshine.
• Moisture condensation occurs in the following situations:
- When you move the unit from a cold place to a warm place.
- When you use the unit in a room where the heater was just turned on.
- When you use the unit in an area where cold air from an air conditioner directly hits the unit.
- When you use the unit in a humid place.
• Never use the unit when moisture condensation could occur.
• Using the unit when moisture condensation exists may damage its own internal parts. After two or three
hours, the unit will warm up and moisture will be evaporated.

English - 6 -
English
Removing the pedestal stand
When using a Wall Bracket
Please use a wall bracket appropriate for the size and weight of the LCD TV.
• Two people are required for installation.
• To install a wall-mount from another manufacturer.
(1) Unplug and remove any cables and/or other component connectors from the rear of the TV.
(2) Carefully lay the front of the unit face down on a at, cushioned surface such as a quilt or blanket.
(3) Follow the instructions provided with your wall bracket. Before proceeding, make sure the appropriate
bracket(s) are attached to the wall and the back of the TV as described in the instructions provided with the
wall bracket.
(4) Always use the screws supplied or recommended by the wall mount manufacturer.
Note :
• The bracket shown above is a sample image. The bracket and xings are not supplied with the TV.
Removing the pedestal stand
(1) Carefully lay the front of the unit face down on a at, cushioned surface with the stand hanging over the edge.
(2) Remove the screws.
(3) After the screws are removed, hold the pedestal stand in place,then remove the pedestal stand and the
plastic moulding from the TV by removing away from the TV.
NOTE: Extreme care should always be used when removing the pedestal stand to avoid damage to the LCD
panel.
For 22D1333G and 22D1334G models

English - 7 -
English
Inserting Batteries and Effective Range of the Remote Control
Remove the back cover to reveal the battery compartment and make sure
the batteries are inserted the right way round. Suitable battery types for this
remote are AAA, IEC R03 1.5V.
Do not combine a used, old battery with a new one or mix battery types.
Remove exhausted batteries immediately to prevent acid from leaking into
the battery compartment. Dispose of them in a designated disposal area.
Warning: Batteries must not be exposed to excessive heat such as sunshine,
re or the like.
The performance of the remote control will deteriorate beyond a distance
of ve metres or outside an angle of 30 degrees from the IR receiver. If the
operating range becomes reduced the batteries may need replacing.
The Remote Control (TV - DVD)
Simple at-a-glance reference of your remote control.
SLEEP
SCREEN
PRESETS
LANG.
FAV
EPG SWAP
SOURCE
C
DISP.
SEARCH
MODE
INFO
CH V
1. Standby
Standby
2. Image size
3. Sleep Timer
4. Mono/Stereo - Dual I-II / Current
Language
(in DVB channels)
Language selection (Set
language)
5. No function
6. Numeric buttons
Numeric buttons
7. Electronic programme guide(in
DVB channels)
8. No function
9. Media Browser
Angle
10. Navigation buttons
(Up/Down/Left/Right)
Navigation buttons (Up/Down/
Left/Right)
11. No function
12. No function
Clear
13. Programme Down /
Page up -
Programme Up / Page down
Display time / DVD menu
14. Mute
Mute
15. No function
16. Pause
Pause
17. Rapid reverse
Rapid reverse
18. Play
Play
19. Red button
Zoom
20. Green button
Repeat
21. Picture mode selection
22. No function
23. Teletext / Mix (in TXT mode)
24. Subtitle on-off (in DVB channels)
Subtitle
25. Previous programme
26. AV / Source selection
AV / Source selection
27. Menu on-off
Menu
28. Okay (Conrm) / Hold (in TXT
mode) / Channel List
OK
29. Exit / Return / Index page (in TXT
mode)
Return
30. No function
Search Mode
31. Info / Reveal (in TXT mode)
Info
32. Volume Up / Down
Volume Up / Down
33. No function
Skip Previous
34. No function
Skip Next
35. Rapid advance
Rapid advance
36. Stop
Stop
37. Blue button
Title
38. Yellow button
Root
Note: The references in Bold are when in
DVD mode.

English - 8 -
English
Connecting External Equipment
Before connecting any external equipment, remove the mains plug from the wall socket.
Aerial cable:...........................................................
Connect the aerial to the ANT. socket on the rear of the TV.
SCART lead:..........................................................
If you use a decoder* or a media recorder, it is essential
that the scart cable is connected to the TV.
Before running rst time installation, any connected devices
need to be set to standby mode.
The DIGITAL AUDIO socket enables the connection of a
suitable surround sound system.
HDMI® (High-Denition Multimedia Interface) is for using
with a DVD decoder or other equipment with digital audio and
video output. It is designed for best performance with 1080i
and 1080p high-denition video signals but will also accept
and display VGA, 480i, 480p, 576i, 576p and 720p signals.
PC format signals will also be displayed.
NOTE: Although this TV is able to connect to HDMI equipment,
it is possible that some equipment may not operate correctly.
When connecting a device via the Side AV input, you must
use the supplied connection cable to enable connection.
When connecting a device via YPbPr input, you must use the
supplied connection cable to enable connection.
A wide variety of external equipment can be connected to the
TV; therefore, the relevant owner’s manuals for all additional
equipment must be referred to for exact instructions.
If the TV automatically switches over to monitor external
equipment, return to normal TV by pressing the desired
programme position button. To recall external equipment,
press SOURCE button repeatedly to switch between sources.
Regardless of source’s property, audio output from the DIGI-
TAL AUDIO socket cannot be copied.
D IH M 1
SPDIF
Coax.OUT
HDMI Input
Socket
RGB/PC
Input
SCART
Socket
Aerial
Input
TV
* a decoder
could be Digital
Satellite, Free to
Air or any other
compatible
decoder.
decoder*
DIGITAL AUDIO
Socket
Side View
COMMON INTERFACE
The Common Interface is
for a Conditional Access
Module (CAM).
USB Input
YPbPr
Menu Wheel
Headphone
SIDE AV
USB Input
MODE
o
SIDE AV
YPbPr
5Vdc
Max:500mA
5Vdc
Max:500mA

English - 9 -
English
Connecting an HDMI®or DVI Device to the HDMI Input
The HDMI input on your TV receives digital audio and
uncompressed digital video from an HDMI source device
or uncompressed digital video from a DVI (Digital Visual
Interface) source device.
This input is designed to accept HDCP (High-Bandwidth
Digital-Content Protection) programme material in digital
form from EIA/CEA-861-D–compliant [1] consumer electronic
devices (such as a set-top box or DVD player with HDMI or
DVI output).
NOTE:
• Some early HDMI equipment may not work properly with
your latest HDMI TV.
• Supported Audio format: Linear PCM, sampling rate
32/44.1/48kHz.
To Connect an HDMI Device
Connect an HDMI cable (type A connector) to the HDMI ter-
minal. For proper operation, it is recommended that you use
an HDMI cable with the HDMI Logo ( ).
• If your HDMI connection is capable of 1080p and/or
your TV is capable of refresh rates greater than 50Hz, you
will need a Category 2 cable. Conventional HDMI/DVI cable
may not work properly with this mode.
• HDMI cable transfers both video and audio. Separate
analogue audio cables are not required (see illustration).
• To view the HDMI device video, press SOURCE button to
select HDMI1.
HDMI Input
Socket
(Back)
HDMI device
D IH M 1
To Connect a DVI Device (PC, DVD Player etc)
Connect an HDMI-to-DVI cable (HDMI type A connector) to the
HDMI input socket and audio cables to the RED and WHITE
SIDE AV AUDIO inputs on the Audio/Video connection cable
supplied (see illustration).
• The maximum recommended HDMI - DVI cable
length is 0.6Ft (2m).
• An HDMI-to-DVI cable transfers video only. Separate
analogue audio cables are required.
D IH M 1
NOTE:
To ensure that the HDMI or DVI device is reset properly, it is
recommended that you follow these procedures:
• When turning on your electronic components, turn on the
TV rst, and then the HDMI or DVI device.
• When turning off your electronic components, turn off the
HDMI or DVI device rst, and then the TV.

English - 10 -
English
To Connect a Computer
With either an RGB/PC or an HDMI connection, you can watch
your computer’s display on the TV and hear the sound from
the TV’s speakers.
When connecting a PC to the RGB/PC input on TV, use an
analogue RGB (15-pin) computer cable and use the SIDE
AV socket with a PC audio cable (not supplied) for audio
connection, using the supplied Side AV connection cable’s
RED and WHITE inputs (see illustration).
RGB/PC Input
(back)
SIDE AV Input
PC VGA Cable
(not supplied)
PC Audio Cable
(not supplied)
Side Audio/Video
Connection Cable
(supplied)
or
SIDE AV
To use a PC, set the monitor output resolution on the PC
before connecting it to the TV. To display the optimum picture,
use the PC setting feature.
NOTE:
• Some PC models cannot be connected to this TV.
An adaptor is not needed for computers with a
compatible mini D-sub15-pin terminal.
• Depending on the DVD’s title and the specications
of the PC on which you are playing the DVD-Video,
some scenes may be skipped or you may not be
able to pause during multiangle scenes.
Connecting a Computer Connecting a DVD Player
Connecting to a DVD Player via YPbPr
Some DVD players are connected through
COMPONENT SOCKETS (YPbPr). In this case,
you must use the supplied Component YPbPr video
connection cable for enabling connection. First, plug
the single jack of the cable to the TV’s YPbPr socket
(side). Afterwards, insert your YPbPr cable’s (not
supplied) connectors into the plural part of the supplied
YPbPr video connection cable (see illustration below).
Colours of the connected jacks should match.
To enable audio connection, use the supplied Side AV
connection cable. First, plug single jack of the cable
to the Side AV Input of the TV. Afterwards, insert your
DVD player’s audio cable’s connectors into the plural
part of the supplied Side AV connection cable (see
illustration below). Colours of the connected jacks
should match.
YP Pr b
C nnection o
Cable
(s pplied u )
YPbPr
V eo id
Cable
(N t supp ed) o li
DVD Player
Side AV Input Audio Cable
(Not supplied)
Side AV
Connection cable
(supplied)
Side AV
To RED & WHITE inputs
Video Connection
Audio Connection

English - 11 -
English
Connecting a USB Memory
To Connect a USB Flash Drive
• You can connect a USB Flash Drive to your TV by
using the USB input of the TV. This feature allows
you to display/play music, photo or video les stored
in a USB stick.
• It is possible that certain types of USB devices (e.g.
MP3 Players) may not be compatible with this TV.
• You may back up your les before making any
connections to the TV set in order to avoid any
possible data loss. Note that manufacturer will not
be responsible for any le damage or data loss.
• Do not pull out USB module while playing a le.
CAUTION: Quickly plugging and unplugging USB
devices may cause damage to the USB device.

English - 12 -
English
Environmental Information
This television is designed to consume less energy to save environment. You not only help to save the
environment but also you can save money by reducing electricity bills thanks to the energy efciency feauture
of this TV. To reduce energy consumption, you should take the following steps:
You can use Power Save Mode setting, located in the Picture Settings menu. If you set Power Save Mode as
Eco, the TV will switch to energy-saving mode and luminance level of TV set will be decreased to optimum
level. Note that some picture settings will be unavailable to be changed when the TV is in Power Save Mode.
If Picture Off is selected, “Screen will be off in 3 seconds.” message will be displayed on the screen. Select
PROCEED and press OK to continue. The screen will be off in 15 seconds. If you disable Power Save Mode,
Picture mode will be automatically set to Dynamic.
When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce
energy consumption.
Disconnect power when going away for longer time.
It is highly recommended to activate Power Save Mode setting to reduce your annual power consumption. And
also it is recommended to disconnect the TV from the mains plug to save energy more when you do not use.
Please helps us to save environment by following these steps.
Repair Information
Please refer all servicing to qualied personnel. Only qualied personnel must repair the TV. Please contact
your local dealer, where you have purchased this TV for further information.
Power Save Mode

English - 13 -
English
Controlling the TV
A wide variety of external equipment can be connected via the sockets located on the side and back of the TV. Whilst all the
necessary adjustments and controls for the TV are made using the remote control, the menu wheel on the left side of the
TV may be used for some functions.
Switching on
If the standby LED is unlit, check that the mains plug is con-
nected to the power and press the middle of the button on
the left side of the TV to switch the television on.
To put the television into Standby, press button on the
remote control. To view the television, press button again.
The picture may take a few seconds to appear.
Note: The active Standby LED colour will turn to red in a few
moments when the TV is switched off.
For energy saving:
Turning the TV off at its mains supply, or un-plugging it, will
cut energy use to nearly zero for all TV’s. This is recom-
mended when the TV is not being used for a long time, e.g.
when on holiday.
Reducing the brightness of the screen will reduce energy
use. Energy efciency cuts energy consumption and thus
saves money.
NOTE: Putting the TV into standby mode, will reduce energy
consumption, but will still draw some power.
Using the Remote Control
Press the MENU button on the remote control to see the
menus.
The main menu appears as a group of icons each for a menu
option. Press the Left or Right button to select a topic.
In sub menu screen mode the menu appears as a list. Press
the Up or Down button to select a topic.
To use the options press the Up and Down buttons on the
remote control to move up and down through them and OK,
Left or Right buttons to select the required choice. Follow
the on screen instructions. The functions of each menu are
described in detail throughout the manual.
Using the Controls on the TV
Using the menu wheel on the side of the TV:
To change volume: Press the middle button until the
volume level OSD appears. Increase the volume by
pushing the button up. Decrease the volume by pushing
the button down.
To change channel: Press the middle button until the
channel information banner appears. Scroll through the
stored channels by pushing the button up or down
To change source: Press the middle button until the
source list appears. Scroll through the available sources
by pushing the button up or down.
To turn the TV off: Press the middle of the button down
and hold it down for a few seconds, the TV will turn into
standby mode.
Please always refer to the owner’s manual of the equipment
to be connected for full details.
Standby LED
Up Direction
Programme / Volume /
IR receiver
Down Direction
AV / Standby On
selection switch
MODE
o
SIDE AV
YPbPr
5Vdc
Max:500mA
5Vdc
Max:500mA

English - 14 -
English
Initial Installation
Before switching on the TV, put your decoder and media recorder to Standby if they are connected and
ensure the aerial is connected to your TV. To set up the TV, use the buttons on the remote control as
detailed on page 7.
IMPORTANT: Ensure that the aerial is connected and
a Common Interface module is not inserted before
switching on the TV for the rst time installation.
1. Connect the mains plug and switch the TV to on
on using the side control switch. If the TV does
not switch on, press any numbered or button
on the remote control, then the language selection
menu will be displayed. This screen will appear
the rst time that the TV is switched on and each
time the TV is reset.
2. By pressing Up or Down button, highlight the
language you want to set and press OK button.
The following message will be displayed next:
3. By pressing Left or Right button, select the
country you want to set and press Down button
to highlight the Search Type option. Use Left or
Right to set the desired search type. Available
search types are digital only, analog TV only
and full.
4. When set, Down button to select Teletext
Language. Use Left or Right button to select
desired Teletext Language.
5. Press OK button on the remote control to continue
and the following message will be displayed on
the screen:
6. Select Yes button by using Left or Right button
and press OK button to continue. Afterwards, the
following OSD will be displayed on the screen:
7. If you select Cable option, the following screen
will be displayed:
8. You can select frequency ranges from this
screen. For highlighting lines you see, use Up or
Down button. You can enter the frequency range
manually by using the numeric buttons on the
remote control. Set Start and Stop Frequency as
desired by using numeric buttons on the remote
control. After this operation, you can set Search
Step as 8000 kHz or 1000 kHz. If you select
1000 kHz, the TV will perform search process
in a detailed way. Searching duration will thus
increase accordingly. When nished, press OK
button to start automatic search.
9. If you select Aerial option from the Search Type
screen, the television will search for broadcasts.

English - 15 -
English
10. The Auto tuning screen will appear and the television
will start to search for available stations. The
progress bar will move along the line. You must
allow the television to complete the search. The
following OSD will be displayed on the screen and
the television will search for the selected broadcasts:
Note:You can press MENU button to cancel.
After the available stations are stored, Channel List
will be displayed on the screen. If you like the sort
channels, according to the LCN, please select Yes
and then press OK button (if available).
• Press OK button to quit channel list and watch TV.
Note:
Do not turn off the TV while initializing rst time
installation.
Keep the menu of Store Mode Disabled and do not
change it, when using at home.
• Press the Left or Right button to choose the required
language region.
• After the Teletext language is selected, press MENU
button to exit.
Auto TuningInitial Installation - continued
Auto Tuning
As new services are broadcast, it will be necessary to
retune the television in order to view them.
• Auto Tuning will completely retune the television
and can be used to update the channel list. It is
recommended that Auto Tuning is run periodically
to ensure that all new services are added. All current
channels and settings, i.e. locked channels, will
be lost.
• Press MENU button on the remote control and select
Install and Retune by using Left or Right button.
Press OK button and the following menu screen
will be displayed.
• Select Automatic Channel Scan (Retune) by using
Up or Down button and press OK button. Automatic
Channel Scan options will be displayed. You can select
options by using Up or Down and OK buttons.
Auto Channel Scan Menu Operation
Digital: Searches and stores aerial DVB stations.
Analogue: Searches and stores analogue stations.
Full: Searches and stores both analogue and aerial
DVB stationsres both analogue and cable DVB
stations.
• Whenever you select an automatic search type and
press OK button, a conrmation screen will appear
on the screen. To start installation process, select
Yes, to cancel select No by using Left or Right
and OK button.
• After auto channel scan type is set and selected
and conrmed, installation process will start and
progress bar will move along. Press MENU button
to cancel process. In such a case, located channels
are not stored. The television will start to search for
all available stations. You must allow the television
to complete the search.

English - 16 -
English
Digital Aerial Manual Search
The feature is available for service engineers or
can be used for direct channel entry if the multiplex
channel is known.
• Select Manual channel scan from the Install and
Retune menu and press OK.
After selecting search type as Digital Aerial, you
can enter the multiplex or frequency number using
the numeric buttons and press OK button to search.
• Enter the multiplex number using the numeric
buttons. The television will automatically search
for that multiplex. When the multiplex is found any
channels not currently on the programme list will be
added and the programme information at the top of
the screen will be updated.
• Repeat as necessary.
Digital Cable Manual Search
• In cable manual scan, you can enter frequency,
modulation, symbol rate and network channel scan
options. After selecting search type as Digital Cable,
you can set the desired options and press OK button
to search.
Analogue Manual Search
The television can be tuned-in manually. For example:
if the television cannot be connected to a media
recorder/decoder with a SCART lead or to tune-in a
station on another System.
To allocate a programme position on the television
for a decoder and media recorder: turn the decoder
on, insert a pre-recorded lm into the media recorder
and press PLAY, then manually tune.
After selecting search type as Analogue, you can
use Up or Down button to highlight an item and then
press Left or Right button to set an option.
Enter the channel number or frequency using the
numeric buttons. You can then press OK button
to search. When the channel is located, any new
channels that are not on the list will be stored.
Analogue Fine Tune
• Select Analogue Fine Tune from the Install and
Retune menu by using Up or Down and OK
buttons. Analogue ne tune screen will be displayed.
Analogue Fine Tune feature will not be available
if there are no analogue channels, only digital
channels and external sources stored.
• Use Left or Right button to set Fine Tune. When
nished, press OK button.
Manual Tuning, Analogue Fine Tuning
The television can be tuned-in manually using Manual Search feature.

English - 17 -
English
Stereo and Bilingual Transmissions
If stereo or dual language broadcasts are transmitted, the
word Stereo or Dual will appear on the screen each time posi-
tions are changed, disappearing after a few seconds. If the
broadcast is not in stereo, the word Mono will appear.
Stereo… Press LANG. to select Stereo or Mono.
Bilingual… Bilingual transmissions are rare. If they are
transmitted, the word Dual will be displayed. Choose the
required programme number, and if the word Dual appears,
press LANG. to select Dual 1, Dual 2 or Mono.
For DTV broadcasts
To view current language and for changing to an
alternative language (if available), press LANG. button.
Available options will be listed.
Displaying Subtitles
In digital broadcasts, this feature will show subtitles
on the screen in the selected language provided they
are being broadcast.
Press SUBTITLE button to activate available
subtitles. Press SUBTITLE button again to turn off
subtitles.
Viewing Main Menu
• This set has “Menu Wheel”.
• Press MENU button on the remote control to view
main menu.
Controlling Volume and Muting Sound
Volume
Press V or Vbutton on the remote control to
adjust the volume.
Sound Mute
Press “ ” button once to turn the sound off and
again to cancel.
Selecting Programme Positions
To select a programme position use the numeric
buttons on the remote control. Programme positions
can also be selected using CH or CH buttons.
Press INFO button to display the on-screen information
i.e. programme position, stereo/mono signal and
picture format.
Standby Notications
If the TV switches off while in No Signal mode, the
following on-screen message will be displayed on the
next switch-on:
When the Auto Tv Off timeout is reached, the following
message will be displayed on the screen. Select YES
to shut down the TV. Select NO to cancel. The TV
will switch off as well, if you do not make a selection
on this screen.
If the TV switches off owing to the auto power down
feature, the following on-screen message will be
displayed on the next switch-on:
General Operation

English - 18 -
English
Viewing Channel List
The channel order may be changed to suit your personal
preference.
• Select Channel List from the main menu and press
OK button. The following menu will be displayed:
• Select Edit Channel List to manage all stored
channels. Use Up or Down and OK buttons to select
Edit Channel List.
• Press Up or Down button for selecting a channel.
You can press CH or CH button to move page
up or page down.
• To watch a specic channel, highlight it by using
Up or Down button. Afterwards press OK button.
• Press BLUE button to view ltering options.
• Press MENU button to exit.
Note: The channels listed are mixed at the channel
list. Channel types can be differentiated by the icons
next to them: DTV (digital tv), HD (HD TV) , ATV
(Analogue TV) ,TV (TV), RD (Radio), encrypted, lock,
and at the favourite list. Listed channels can also be
sorted by using the active channel list lter.
Moving a Channel
• Highlight the desired channel by using Up or Down
button.
• Select Move option in the channel list and press
OK button.
• Edit Number screen will be displayed. Enter the
desired channel number by using the numeric
buttons on the remote control. If there is a previously
stored channel on that number, a warning screen
will be displayed. Select Yes if you want to move the
channel and press OK.
• Selected channel is now moved.
Deleting a Channel
You can press GREEN button to tag/untag all
channels; YELLOW button to tag/untag channel.
• Select the channel that you want to delete and select
Delete option. Press OK button to continue.
• A warning screen will appear. Select Yes to delete,
select No to cancel. Press OK button to continue.
Renaming a Channel
• Select the channel that you want to rename and
select Edit Name option. Press OK button to
continue.
• Pressing Left or Right button moves to the previous/
next character. Pressing Up or Down button
changes the current character. Pressing the numeric
buttons ‘0...9’ replaces the highlighted character with
the characters printed above the button one by one
as the button is pressed.
• When nished, press OK button to save. Press
MENU to cancel.
Locking a Channel
You can press GREEN button to tag/untag all
channels; YELLOW button to tag/untag a single
channel.
• Select the channel that you want to lock by using
Up or Down button.
• Select Lock option by using Left or Right button.
Press OK button to continue.
• You will be asked to enter parental control PIN. Enter
the PIN number.
Note: Default PIN is set to 0000.
• Press OK button when the desired channel is
highlighted to lock/unlock the channel. Lock symbol
will be displayed next to the selected channel.
Channel List, Sorting Programmes, Programme Locking
You can view stored channels and sort them by using the Channel List feature.

English - 19 -
English
Viewing Info Banner
• Press INFO button. The information screen will
appear giving details of the channel and programme
currently being viewed.
• Whenever you change channel, the TV displays the
broadcast picture along with an information banner at
the bottom of the screen (available only in DTV mode).
This will remain on the screen for a few seconds.
• If the selected channel is locked, you must enter the
correct four numeric code to view the channel. “Enter
PIN” will be displayed on the screen in such a case:
• Enter the 4-digit PIN number to continue.
Note: Factory set default PIN code is 0000. It is not
available for France country setting.
Electronic Programme Guide
• Select the on-screen guide by pressing EPG button,
the guide screen will appear highlighting details of
the channel and programme currently being viewed.
This may take a few moments to appear.
• For details of other programmes currently available,
press navigation buttons to scroll up and down
or scroll left/right through the list. As channels are
selected, details of the programme currently being
broadcast will appear.
• Press RED button to view the previous day.
• Press GREEN button to view the next day.
• Press YELLOW button for zooming to a programme.
• Press BLUE button to display ltering options.
• Press SUBTITLE button to sort channels by a genre.
• For information on a highlighted programme, press
i button.
• Use numeric buttons for quickly selecting a
broadcast.
• To set the timer for a selected programme, press
OK button to select Options menu.
• Press TXT button to display searching options.
• Press SWAP button for displaying current
programmes.
Viewing Info Banner, Electronic Programme Guide
