TDP-ET20U

Extreme.

The TDP-ET20U, the first all-in-one multimedia projector from Toshiba, is the optimum projec-

tor for both home entertainment and business or academic settings. With an integrated DVD

player and 5.1-channel Dolby®surround sound, the TDP-ET20U delivers “extreme short pro-

jection” with up to a 100-inch diagonal screen image from just 3.9 feet away. The projector

comes packaged in a sleek, black piano finish casing with an RGB computer input and HDMI

port, making it ideal for movie nights, sports events, video games, digital photos and business

or educational presentations.

Super Close Projection™ with All-In-

One Multimedia Features

Toshiba’s TDP-ET20U is the optimum projec-

tor for users who expect and demand con-

nectivity flexibility, usage versatility and per-

formance at a tremendous value. With an

integrated DVD player and 5.1-channel Dolby

Pro Logic surround sound for true cinema

sound quality, the TDP-ET20U delivers all the

big screen drama, sound and excitement

with “extreme short projection” capabilities.

The TDP-ET20U can project up to a 100-inch

screen image from just 3.9 feet away.

Use it Anywhere

Weighing just 10.6 pounds1, the sleekly

designed Toshiba TDP-ET20U is extremely

portable so it fits perfectly on a coffee table,

conference room table or classroom A/V cart.

Set up in the family room or den for “movie

night” with family and friends. Take it to the

office for presentations, enjoy fullimmersion

larger-than-life video games, or bring it along

to your next social gathering.

Easy Setup and Operation

Ready to go out of the box, the feature-

packed TDP-ET20U is easy to setup and

operate. It plays multiple video and audio for-

mats with its built-in DVD player and 5.1-

channel Dolby surround sound including one

subwoofer. A feature rich remote control is

also included. Whether it sits on the coffee

table in the family room, on the conference

room table or in the classroom, the TDP-

ET20U assures the best projection results

even in the most difficult environments with

its 130-degree offset angle.

Reliable Image Quality

Toshiba’s TDP-ET20U projector is intelligently

designed with DLP®(digital light processing)

technology for optimum image quality and

display consistency. This proven technology

combined with the unique features of the

TDP-ET20U provides impressive visual

impact and advanced clarity, brightness and

color fidelity.

TDP-ET20U1Detailed Product Specifications

External Dimensions

• 12.7" (W) x 13.5" (D) x 6.1" (H)

Weight2

• 10.6 lbs.

Power Source

• 100-240V, 50/60Hz

Replacement Lamp

• TLPL-ET10

Box Contents

• Remote control with batteries

• Power cord

• RGB Cable

• CD-ROM

• User's Manual

Compatible Scanning Frequency

• Horizontal (kHz): 15 - 82kHz

• Vertical (Hz): 15 - 85Hz

Input Signal Format

• Video: NTSC, PAL, SECAM

• HDTV: 720p, 1080i

• Component Video: 480p/480i/576p/576i

• RGB: WVGA (native), SVGA (compressed), XGA (compressed), SXGA

(compressed)

Output Terminal

• Coaxial Audio Out: 1 x Coaxial Audio-out

Other Terminals

• RS-232: 1x DB9

Digital Keystone Correction

• Vertical +/- 40°, Horizontal +/- 30°

Internal Speaker

• Integrated 5.1 channel Dolby®digital surround

Noise Level

• 35dB (32dB in eco mode)

Product Specifications

Display Technology

• Shape: 0.55" DMD DLP®

Projection Lens

• Off set 130%

• F/f (mm): F = 2.6, f = 7.56mm manual focus

Projection Format

• 16:9 switchable to 4:3

Light Source

• 230W

Brightness

• 1100 lumens

Native Resolution

• Real Wide Panel 854 x 480 (480p)

Color Reproduction

• Full 16.7 Million Colors

Contrast Ratio

• 2000:1

Projection Screen Size (Diagonal)

• 30" -180"

Projection Distance

• 3.9 feet/100" screen

Input Terminals

• Video: 1x RCA for Composite Video, 1x S-Video

• RGB: 1x D-sub 15-pin

• Component Video: 3x RCA

• RGB Audio: 1x stereo mini-jack

• HDMI: 1x HDMI

• Coaxial Audio In: 1 x Coaxial Audio-in

© 2006 Toshiba America Information Systems, Inc. DLP and the DLP logo are trademarks of Texas Instruments. All other trademarks are the property of their respective owners. While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications, configurations, prices, system/component/options availability are all subject to change without notice.

1 This projector is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment (RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its projector component suppliers to meet RoHS requirements and verifi es its suppliers’ commitment to meeting RoHS requirements by conducting component sampling
