INSTRUCTION MANUAL
CCD COLOR CAMERA
IK-DF01A
Pleasereadthismanualthoroughlybefore use,andkeepithandy
for future reference.
TABLE OF CONTENTS
Important safeguards
1. Features & Description ................................................. 3
2. Cautions........................................................................ 3
3. Components ................................................................. 3
4. Part Names & Functions............................................... 4
5. Connections and Operations ........................................ 5
6. Installations................................................................... 7
7. Line Lock Phase ........................................................... 9
8. Note on use and Installation ......................................... 9
9. In Case of Problems ..................................................... 10
10. Specifications................................................................ 11
11. Exterior View................................................................. 12
Recordinspaceprovidedbelowthe ModelNo.and
the Serial No.as found on the label on the bottom
of this unit.
Model. No.IK-DF01A Serial No.
Retain this information for future reference.

- 1 -
IMPORTANT SAFEGUARDS
1. Read Instructions
All the safety and operating instructions should
be read before the product is operated.
2. Retain Instructions
The safety instructions and instruction manual
should be retained for future reference.
3. HeedWarnings
All warnings on the product and in the instruction
manual should be adhered to.
4. Follow Instructions
All operating and use instructions should be
followed.
5. Cleaning
Disconnect this video product from the power
supply before cleaning.
6. Attachments
Donotuse attachments not recommendedbythe
video product manufacturer as they may cause
hazards.
7. Water and Moisture
Do not use this video product near water-for
example, near abathtub,washbowl,kitchensink,
or laundry tub, in a wet basement, or near a
swimming pool and the like.
8. Accessories
Do not place this video product on an unstable
cart, stand, tripod, bracket or table. The video
product may fall, causing serious injury to a child
or adult, and serious damage to the product.Use
only with stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the video product. Any mounting of the product
shouldfollow the manufacturer’s instructions,and
should use a mounting accessory recommended
by the manufacturer.
9. Ventilation
This video product should never be placed near
or over a radiator or heat register. This video
product should not be placed in a built-in
installation such as a bookcase or rack unless
properventilationis providedorthe manufacturer’s
instructions have been adhered to.
10.Power Sources
This video product should be operated only from
thetype of powersource indicatedonthe marking
label. If you are not sure of the type of power
supply to your location, consult your product
dealer.
11.Power-Cord Protection
Power-Supplycordsshould be routed sothat they
are not likely to be walked on or pinched by items
placed upon or against them, paying particular
attention to cords at plugs, screws and the point
where they exit from the product.
12.Lightning
Foradded protection forthis videoproductduring
alightning storm,or when it isleftunattended and
unused for long periods of time, unplug it from
the wall outlet and disconnect the power supply
and cable system. This will prevent damage to
the video product due to lightning and power-line
surges.
13.Overloading
Donot overload powersupplyandextensioncords
as this can result in a risk of fire or electric shock.
14.Object and Liquid Entry
Never push objects of any kind into this video
product through openings as they may touch
dangerous voltage points or short-out parts that
couldresultin a fire orelectricalshock.Neverspill
liquid of kind on the video product.
15.Servicing
Do not attempt to service this video product
yourself as opening or removing covers may
exposeyoutodangerous voltageor otherhazards.
Refer all servicing to qualified service personnel.
16.Damage Requiring service
Disconnect this video product from the power
supply and refer servicing to qualified service
personnel under the following conditions.
a. When the power-supply cord or plug is
damaged.
b.If liquid has been spilled, or objects have fallen
into the video product.
c. If the video product has been exposed to rain
or water.
d.If the video product does not operate normally
by following the operating instructions in the
instruction manual.Adjustonlythose controls that
are covered by the instruction manual as an
improper adjustment of other controls may result
in damage and will often require extensive work
by a qualified technician to restore the video
product to its normal operation.
e. If the video product has been dropped or the
cabinet has been damaged.
f. When the video product exhibits a distinct
change in performance-this indicates a need for
service.
17.Replacement Parts
When replacement parts are required, be sure
theservicetechnician hasusedreplacement parts
specified by the manufacturer with the same
characteristics as the original part.Unauthorized
substitutions may result in fire, electric shock or
other hazards.
18.Safety Check
Upon completion of any service or repairs to this
video product, ask the service technician to
performsafetychecksto determine that the video
product is in proper operating condition.

- 2 -
• The CAUTION label, shown on the left,
is attached on the camera.
The lightening flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage”within theproduct’senclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operatingandmaintenance(servicing)
instructions in the literature
accompanying the appliance.
WARNING :
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION :
CONNECT 24V AC UL LISTED CLASS 2
POWER SUPPLY.
FIELD INSTALLATION MARKING :
WORDED:“THISINSTALLATION SHOULD
BE MADE BY A QUALIFIED SERVICE
PERSON AND SHOULD CONFORM TO
ALL LOCAL CODES.”
Note :The camera is indoor used
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuantto Part 15of theFCC Rules.Theselimits are designed to providereasonableprotection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interferenceinwhich casethe user willbe requiredto correct theinterferenceathisownexpense.
USER-INSTALLER CAUTION :Your authority to operate this FCC verified equipment could be
voided if you make changes or modifications not expressly approved by the party.
CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

- 3 -
1. FEATURES & DESCRIPTION :
IK-DF01A has following function.
(1) Quick install Design- you can manually set the camera direction.
(2) Built in vari-focal lens with auto-iris
Focal length 2.8~5.8mm
(3) Incorporated 1/4type CCD image sensor gives high resolution and excellent
sensitivity
480 lines horizontal resolution
0.5 lx minimum illumination with smoke cover
(4) 50dB Signal-To Noise Patio
(5) Power supply- AC24V or DC12V - This camera automatically detects the power.
(6) BLC, AGC, and Line-Lock (AC24V)
2. Cautions :
(1) Inorder toprotect the camera,avoidplacing or using it under direct sunlight, rain or
dust.
(2) Avoid touching the CCD sensor with your fingers. If necessary, use a soft cloth
moistened with alcohol to wipe off any dust.
(3) When the camera is not in use, keep the lens cap attached to protect the CCD
sensor.
(4) Avoid aiming the camera at the sun.
(5) Avoid shooting the camera at intense light. Intense light such as a spotlight may
cause a bloom or smear.A vertical stripe may appear on the screen.
However, this is not a malfunction.
(6) Install the camera away from video noise.If cables are wired near electric lighting
wires or a TV set, noise may appear in images. In this event, relocate cables or
reinstall equipment.
3. Components :
(1) Camera 1
(2) Accessories
(a) Instruction Manual 1
(b) Installation Screw 2

- 4 -
4. PART NAMES & FUNCTIONS :
Knockout
VIDEO Cable (BNC Tap)
Power Input Cable
"Bottom" mark
Focus Lever
Zoom Lever
Lens Iris ADJ
Mode Setting Switch
1:BLC ( Backlight Compensation Control )
When switched on, it
automatically adjusts to
compensate for subjects that
are lit from behind.
2:AGC (Auto Gain Control)
When switched on, it
automatically adjusts the
image in relation to the
brightness of the subject.
3:DC/AES
Not available for this camera.
Be sure to switch to ON.
4: LL (Line Lock)
Use this switch to set the
camera synchronization to
internal or line lock. Line
Lock is available with AC24V
only.
Installation Holes
Installs camera to ceiling with
attached screws.
Lens ADJ Screw
Turn the ring-type screw to adjust the lens pan angle.
Fasten and lock it after completing the adjustment.
Tilt ADJ Screws
Turn the screws to adjust the lens tilt
angle. Fasten and lock them after the
adjustment completes.
V Phase ADJ
Cut with a knife or scissors
and insert the cables through
the knockout so the cables will
not pinched when installed.
The "Bottom" mark indicates the
lens position. The "Bottom" mark
should be on the top when installing
in a ceiling.
Adjusts the image into focus. Its screw
design allows locking capability.
Use to compensate
for the iris level.
Turn towards L (low)
for a darker picture.
Turn towards H (high)
for a brighter picture.
Optimum value is
adjusted at the
default setting.
Adjusts the phase
difference between
this camera and other
cameras when in Line
Lock mode.
Connect the power
cable to AC24V or
DC12V. (RED:+12,
Black:GND)
Connect the Video Cable to
a monitor or video device.
The image is outputted
when powered on.
Changes the picture range.
Its screw design allows
locking capability.

- 5 -
5. CONNECTIONS AND OPERATIONS :
Notes on connecting
• Power plugs connected equipment must be disconnected before installations.
• A 75-ohm coaxial cable (3C-2V or 5C-2V) is required for standard connection.
• For details of wiring and operation of equipment to be connected, refer to their
operation manuals.
• Coaxial cables for video signals and the power cord are not supplied with the
camera.
Refer to the operations manuals of connected equipment for detailed wiring and
overall operation instructions.
5-1 Basic connection single system configuration
24V AC UL Listed Class 2 power supply / 12V DC power supply
CAUTION : Never input 24V AC and 12V DC at the same time.
In case of DC12V, connect “+12” to red cable and “GND” to black cable.
Do not overload power supply
Since this camera uses 24V AC UL Listed Class 2 power supply or 12V DC power
supply, it should be connected to a power supply that allows for at least 5w
consumption.
Video Monitor
AC 120V
( ) POWER CORD (twisted pair line)
minimum wire size of 18 AWG is recommended.

- 6 -
5-2 Line-Lock Control
• Matching the vertical synchronization with the power frequency is called the Line-
Lock.
• This function is activated when the SYNC menu is selected to LL.
• Whentwoor more camerasare switchedbythevideo switcherforviewingbya monitor
TV, the vertical sync. phase can be locked with the power frequency, and a stable
vertical sync. is obtained without being disturbed at the time of switching.
Note :
• The camera is synchronized to the power frequency of 60±1Hz covering a normal
fluctuation of the power frequency. However, the camera may not cover a large
fluctuation caused from the power generated by an engine generator, etc.
• It takes about 10 seconds or more until a stable synchronization is obtained after
the power is turned on. This is normal, because several seconds are required to
stabilize the camera against power noise.
• Refer to “7. LINE-LOCK PHASE” for adjustment.
CAMERA1
VIDEO SWITCHER
Video Monitor
TO AC 24V UL Listed
class 2 power supply
CAMERA2

- 7 -
6. Installations :
(1) Turn the cover left to unfasten it.
(2) Connect the cable of the camera and the cable from the designated power supply
with respective BNC connectors.
(3) Fix the camera base to the ceiling firmly with the attached 2 screws. Otherwise it
might drop and cause injury.
Note :
• The camera’s weight is about 290g.
• The attached screws are designed to install the camera to a board.
When installing to a surface of other materials, prepare the screws to fix it firmly.
• The screw diameter is φ4mm.
6-1 Adjust the Angle ofView
(1) Thelens direction inpan direction canbe adjusted byturningring 1left tounfasten
it without moving the lens. After adjustment, turn the ring 1right to fasten it.
Note :
• Do not turn the lens over 360°. Otherwise the inner connector may be broken and
the image may not appear.
(2) The lens direction at the tilt angle can be adjusted by turning screw 2. After
adjustment, turn screw 2to fasten it.
(3) Adjust the zoom position by turning zoom lever 3. After adjustment, fasten the
zoom lever 3.
(4) Adjust thefocusbyturning focuslever4.Afteradjustment,fastenthe focuslever4.
(5) Repeat the adjustments from step (1) to step (4) till the optimum image appears.
1
43
2

- 8 -
6-2 Installing to Wall
The camera head at shipping is set for installing the camera to the ceiling.The camera
head angle should be changed when installing to a wall.
(1) Turn 2 screws of 1to unfasten the camera head.
Note :
• The camera head is connected to the inside with cable, do not pull it with strength.
Otherwise the inner connector may be broken and the image may not appear.
(2) Reverse the camera head 180°from default setting and install it. The direction of
the camera head is shown as above.With the “Bottom” mark 2upwards, the tilt
range is adjusted as shown above.
(3) Fasten the screw 1to fix the camera head.
1
2
Tilt Range
"Bottom" Mark
Camera Head
6-3 Installing the Cover
As shown in the illustration, adjust the cover
position to the camera’s installation position and
turn it right to install it.

- 9 -
7. LINE LOCK PHASE
When a video switcher switches two or more cameras, the picture may fluctuate on the
video monitor due to the different AC line phase of each camera.In this case, adjust the
V PHASE controller to get a stable image.
8. NOTE ON USE AND INSTALLATION
• Do not aim the camera at the sun
Do not aim the camera at the sun or point it at sun even if you are not shooting.
• Do not shoot intense light
Intense light such as a spotlight may cause a bloom or smear. A vertical stripe may
appear on the screen. However, this is not a malfunction.
• Treat the camera with care
Donot drop thecameraor subjectit to strongshockofvibration.Otherwise,the camera
may malfunction.
• Never touch internal parts
Donot touch theinternalparts of thecameraother than the parts specified.Otherwise,
the camera may malfunction.
• Do not splash water on the camera
Install the camera where the camera can be kept dry.If the camera gets wet, turn off
the power and contact your dealer.
• Check the ambient temperature and humidity
Avoid using the camera where the temperature is hotter or colder than specified.
Otherwise, the quality of images may deteriorate or internal parts may be affected.
Special care is required to use the camera at high temperature and humidity.
• Should you notice any trouble
If any trouble occurs while you are using the camera, turn off the power and contact
your dealer.If you continue to use the camera when there is something wrong with it,
the trouble may much worse and an unpredictable accident may occur.
V PHASE CONTROL

- 10 -
9. IN CASE OF PROBLEMS
Condition
No image
Unnatural color
The image is out of
focus.
The image is dark.
Check Points
• Are the camera and connected equipment turned on?
• Is the mode setting switch DC/AES set to OFF? Be sure to
set to ON.
• Are cables connected correctly?
• Is the monitor TV adjusted correctly?
• Is the lighting too weak?
• Is the lens focus adjusted?
• Is the lens or cover dirty?
• Are there any large barrier or bright illumination near the
camera?
• Is the lens iris adjustment volume correctly set?

- 11 -
10.SPECIFICATIONS
1. Image System
Image Device
Pixel Elements
2. Electrical
TV System
Horizontal Resolution
S/N Ratio
Minimum Illumination
Auto Gain Control (AGC)
Iris Control Mode
White Balance
White Balance Range
Line lockVertical phase adjustment
γcompensation
Backlight Compensation (BLC)
Video Output Signal
Synchronizaiton System
3. Mechanical
Weight
Dimension
4. Optical
Built-in Lens
View Angle
Focus Length
5. Power
Input Voltage
Power Consumption
6. Environmental
Operating Temperature
Storage Temperature
7. Regulation
Safety
Emission
1/4” IT CCD
768 (H) x 494 (V)
2:1 Interlace, 15.734KHz Horizontal, 59.94Hz
Vertical
480 TV lines
50dB (TYP.AGC Off, Weight On)
0.2 lux (More than 10% of image output, Clear cover)
0.5 lux (More than 10% of image output, Smoke cover)
Average AGC (24dB)
Auto Iris Lens
Auto
2500°K ~ 10000°K
Provided (VR :range 300deg)
0.45
On / Off (DIP-SW)
VBS (1.0Vp-p, 75ohm unbalance, BNC)
Internal for DC or Linelock for AC
290g
110mm (φ) x 96mm (H)
Vari-focus Lens
f=2.8 ~ 5.8mm, F1.4 : Auto Iris
Wide : 97.5°(D), 76.7°(H), 56.8°(V)
Tele : 47.9°(D), 38.2°(H), 28.7°(V)
0.2m ~ ∞
DC12V or AC24V
3.5W
-10°C~50°C 90%RH max
-20°C~60°C 70%RH max
UL2044
FCC Class A / DOC ClassA

- 12 -
11.EXTERIORVIEW
φ110
φ5
96
83.5 （Unit : mm
）

- 13 -
Wall
2-hold φ3.2 (1/8") driver,
depth about 40mm.
2-TP4 X 37

- 14 -
