Toshiba IK-WB16A User manual

NETWORK CAMERA
Model: IK-WB16A / IK-WB16A-W
Quick Start Guide and Important Safeguards
This guide describes the hardware installation.
Refer to the user's manual (PDF le) contained in the CD-ROM for settings, operations
and other information.
The application Adobe Reader is needed to view PDF les. If you do not have this
application, download it from the Adobe Systems Incorporated website.
For information on our latest products and peripheral devices, refer to the following
Website:
nhttp://www.toshibasecurity.com
If the URL changes, refer to the Toshiba website (http://www.toshiba.com).
IK-WB16A IK-WB16A-W

2
Introduction
FCC (USA)-INFORMATION
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and receiver.
lConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
lConsult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.
USER-INSTALLER CAUTION: Your authority to operate this FCC veried
equipment could be voided if you make changes or modications not expressly
approved by the party.

3
Thank you for purchasing the IK-WB16A/IK-WB16A-W Network Camera. Before
you start using the camera, read this quick start guide carefully to ensure
correct usage. Once you have nished reading this quick start guide, keep it in a
convenient place for future reference.
The design, specications, software, and quick start guide contents are subject to
change without prior notice.
Terms and Trademarks
lThe term "OS" is used in this manual to indicate operating systems compatible
with this product.
-- Windows®XP: Microsoft®Windows® XP operating system
-- Windows Vista®: Microsoft®Windows Vista® Business operating system
-- Windows 7®: Microsoft® Windows 7® Professional operating system
lThe formal name of Windows®is Microsoft®Windows® Operating System.
lMicrosoft®, Windows®and Windows Vista®are trademarks or registered
trademarks of Microsoft®Corporation in the United States and other countries.
lAdobe is a registered trademark and Adobe Reader is a trademark of Adobe
Systems Incorporated.
lOther product names appearing in this quick start guide may be trademarks or
registered trademarks of their respective holders.
NOTE
lThe performance of the network camera may vary depending on the network
environment.

4
Table of Contents
Introduction
Introduction....................................................................................................... 2
Terms and Trademarks ..............................................................................................3
Table of Contents.............................................................................................. 4
IMPORTANT SAFEGUARDS ........................................................................... 5
NOTES ON USE AND INSTALLATION.......................................................... 10
Setting the Network Camera Environment ..................................................... 12
Items needed for network camera monitoring.........................................................12
Contents ......................................................................................................... 13
Physical Description ....................................................................................... 14
Hardware Installation...................................................................................... 15
Network Deployment ...................................................................................... 18
General Connection (without PoE)...........................................................................18
Power over Ethernet (PoE) (IK-WB16A only)...........................................................19
Assigning IP Address...................................................................................... 20
Retrieving Images........................................................................................... 21
Congure the Wireless Connection (IK-WB16A-W only)................................ 22
Quick Start Guide

5
IMPORTANT SAFEGUARDS
1. Read Instructions
Read all the safety and operating instructions before operating the product.
2. Retain Instructions
Retain the safety instructions and user's manual for future reference.
3. Warnings
Comply with all warnings on the product and in the user's manual.
4. Follow Instructions
Follow all operating and use instructions.
5. Cleaning
Disconnect this video product from the power supply before cleaning.
6. Attachments
Do not use attachments not recommended by the video product manufacturer
as they may pose safety risks.
7. Water and Moisture
Do not use this video product near water. Some examples are: near a bath tub,
wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming
pool.
8. Accessories
Do not place this video product on an unstable cart, stand, tripod, bracket
or table. The video product may fall, causing serious injury to a person, or
serious damage to the product. Use only with stand, tripod,bracket,or table
recommended by the manufacturer, or sold with the video product. Any
mounting of the product should follow the manufacturer's instructions, and
should use a mounting accessory recommended by the manufacturer.
9. Ventilation
This video product should never be placed near or over a radiator or heat
register. If this product is placed in a built in installation verify that there is proper
ventilation so that the camera temperature operates within the recommended
temperature range.

6
IMPORTANT SAFEGUARDS (Cont.)
10. Power Sources
This video product should be operated only from the type of power source
indicated on the information label. If you are not sure of the type of power
supply at your location, consult your product dealer.
11. Power-Cord Protection
Power cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them. Pay particular attention to cords
at plugs, screws and the point where they exit the product.
12. Installation
Install this video product on a secure part of the ceiling or wall. If installed on an
unsecured location, the camera could fall causing injury and damage.
13. Lightning
For additional protection on this video product during a lightning storm, or when
it is left unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the power supply and cable system. This will prevent
damage to the video product due to lightning and power-line surges. If lightning
occurs, do not touch the unit or any connected cables in order to avoid electric
shock.
14. Overloading
Do not overload the power supply or extension cords as this can result in a risk
of re or electric shock.
15. Object and Liquid Entry
Never push objects of any kind into this video product through openings as they
may touch dangerous electrical points or short-out parts that could result in a
re or electrical shock. Never spill liquid of any kind on the video product.
16. Servicing
Do not attempt to service this video product yourself as opening or removing
covers may expose you to dangerous electrical or other hazards. Refer all
servicing to quali ed service personnel.

7
17. Damage Requiring Service
Disconnect this video product from the power supply and refer servicing to
qualied service personnel under the following conditions.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been submerged in water.
d. If the video product does not operate normally by following the operating
instructions in the user's manual. Adjust only those controls that are covered
by the user's manual as an improper adjustment of other controls may result
in damage and will often require extensive work by a quali ed technician to
restore the video product to its normal operation.
e. If the video product has been dropped or the cabinet has been damaged.
f. When the video product exhibiting a distinct change in performance which
indicates a need for service.
18. Replacement Parts
When replacing parts be sure the service technician uses parts specied
by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in re, electric shock or other hazards.
19. Safety Check
Upon completion of any service or repairs to this video product, ask the service
technician to perform safety checks to determine that the video product is in
proper operating condition.
20. When using a wireless LAN function (IK-WB16A-W):
• Do not use near people with heart pacemakers.
• Do not use near electronic medical equipment, or in hospitals or other
medical institutions.
• Do not use inside aircraft or in places where the wireless LAN function
could interfere with electromagnetic signals.
The electromagnetic interference could cause a malfunction, resulting in an
accident.

8
21. If the use of a wireless LAN function interferes with another device’s
electromagnetic signals, cease use immediately. (IK-WB16A-W)
The electromagnetic interference could cause a malfunction, resulting in an
accident.

9
IMPORTANT SAFEGUARDS (Cont.)
CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
FIELD INSTALLATION MARKING:
WORDED: “THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE
PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.”

10
NOTES ON USE AND INSTALLATION
lDo not aim the camera at the sun
Never aim the camera at the sun even with the camera power off.
lDo not shoot intense light
Intense light such as a spotlight may cause a bloom or smear. A vertical stripe
may appear on the screen. However, this is not a malfunction.
lTreat the camera with care
Dropping or subjecting the camera to intense vibration may cause it to
malfunction.
lAvoid Volatile Liquid
Do not use volatile liquids, such as an insect spray, near the unit. Do not leave
rubber or plastic products touching the unit for a long time. They will leave
marks on the nish. Do not use a chemically saturated cloth.
lNever touch internal parts
Do not touch the internal parts of the camera other than the parts specied.
lKeep the camera installation away from video noise
If cables are wired near electric lighting wires or a TV set, noise may appear in
images. In this event relocate cables or reinstall equipment.
lCheck the ambient temperature and humidity
Avoid using the camera where the temperature is hotter or colder than the
specied operating range. Doing so could affect the internal parts or cause the
image quality to deteriorate. Special care is required to use the camera at high
temperature and humidity.
lShould you notice any trouble
If any trouble occurs while you are using the camera, turn off the power and
contact your dealer. If you continue to use the camera when there is something
wrong with it, the trouble may get worse and an unpredictable problem may
occur.

11
lCaution when using the wireless LAN functions (IK-WB16A-W)
The Wireless LAN in this unit uses the 2.4 GHz waveband. If there is a similar
wireless LAN in the area, or a wireless device using the 2.4 GHz waveband,
or a microwave oven, the communication efciency of this apparatus will be
reduced, and may become unusable, but it is not a fault. If this happens, check
an area away from the current location that will not cause radio interference to
medical, industrial and public equipment, and change to it, or stop using the
unit.

12
Setting the Network Camera Environment
Items needed for network camera monitoring
lAdministrator's personal computer
The personal computer that allows setting, operating, monitoring and other
functions with the network camera is called the "administrator's personal
computer" in this guide.
* The personal computer for viewing monitored images is called the "user's
personal computer" in this quick start guide. The network camera can be
viewed by more than one personal computer at the same time.
lRecommended personal computer system requirements:
-- Windows® XP, Vista Business, or Windows 7 professional.
-- Internet Explorer Ver 8.0
-- CPU: Minimum of 2GHz CPU
-- Memory: 1GB RAM and 512MB Graphics Adapter
lConnection equipment such as Ethernet cables, and switch or router.
-- The LAN cable type differs depending on the connection method.
lCamera search application "Installation Wizard"
-- Install this application from the CD-ROM supplied as an accessory (Double-click
"Setup.exe" in the CD-ROM and install the application by following the onscreen
instructions.)
-- This application is the tool to discover the IP address of a camera. Using this
application, the IP address of a camera can be easily determined.

13
IK-WB16A
lIK-WB16A/IK-WB16A-W
lWarranty Card
lAC Adapter
lQuick Start Guide and Important
Safeguards
lCD-ROM
Contents
Content:
User's Manual
Quick Installation Guide
Installation Wizard
Cord length: 72 inches (1828 mm)
lAntenna (IK-WB16A-W only) lCeiling Mount Brackets / Alignment
sticker
NETWORK CAMERA
Model: IK-WB16A / IK-WB16A-W
Quick Start Guide and Important Safeguards
This guide describes the hardware installation.
Refer to the user's manual (PDF file) contained in the CD-ROM for settings, operations
and other information.
The application Adobe Reader is needed to view PDF files. If you do not have this
application, download it from the Adobe Systems Incorporated website.
For information on our latest products and peripheral devices, refer to the following
Website:
http://www.toshibasecurity.com
If the URL changes, refer to the Toshiba website (http://www.toshiba.com/tai/products/
prod_biz.jsp).
IK-WB16A IK-WB16A-W
lScrews / LAN cable and RJ45
Female/Female Coupler
AB
Back Cover
Drill holeDrill hole
Alignment Sticker
Drill hole
(Drill hole)
IK-WB16A / IK-WB16A-W

14
4 3 2 1
WPS/RESET
microSD
Power Cord Socket
Ethernet 10/100 RJ45 Socket
WPS/Reset Button
General I/O Terminal Block
Audio Out
Microphone In
lFront Panel
lBack Panel
Built-in Microphone
Lens
Status LED
MicroSD/SDHC Card Slot
Physical Description
Antenna
(IK-WB16A-W only)
Cable Clip

15
Hardware Installation
1. Attach ceiling mount bracket A to the Network Camera and secure it with two small
screws.
2. Attach the supplied alignment sticker to the ceiling. Drill a hole in the ceiling to feed
the cables. And drill three pilot holes into the ceiling; then hammer the plastic anchors
into the holes.
3. Fasten ceiling mount bracket B to the ceiling with three screws. And connect the
cables to the camera.
4. Slide the Network Camera into ceiling mount bracket B.
5. Secure ceiling mount bracket A and B with a small screw.
6. Attach the back cover and fasten with two screws.
7. Adjust the antenna to the appropriate position.(IK-WB16A-W only).
lCeiling mount with supplied bracket
2
3
1
A
B
4
5
6
7
Drill hole
Drill hole
Alignment Sticker
Drill hole
(Drill hole)
IK-WB16A / IK-WB16A-W

16
NOTE
l When RJ45 plug is large and the back cover is not attached to the camera, use an
attached LAN cable and RJ45 female/female coupler.
lWhen Microphone plug and Audio out plug are large and the back cover is not
attached to the camera, use a right angle mini-plug cable. (Right angle plug is not
included.)
lWhen you do not lead the cable to the backside hole of the camera, cut out the knock
out of the back cover.
l The position of an antenna may change by vibration after installation. In this case,
readjust to the appropriate position.

17
1. Drill a hole in the wall to feed the cables.
2. Drill four pilot holes into the wall; hammer the plastic anchors into the holes.
3. Fasten JK-WM16 to the wall with four screws.
4. Lead the cables through the hole, and connect the cable to the camera. Attach the
back cover and fasten with two screws.
5. Secure Network Camera with two screws.
6. Adjust the antenna to the appropriate position. (IK-WB16A-W only)
lWall Mount with JK-WM16 (JK-WM16 is not included.)
2
3
5
6
1

18
1. If you have external devices such as sensors and alarms, make the connections
from general I/O terminal block.
2. Use Category 5 or equivalent Cable to connect the Network Camera to a
network switch.
Use Category 5 or equivalent Crossover Cable when Network Camera is directly
connected to a PC.
3. Connect the supplied AC adapter.
4 3 2 1
WPS/RESET
microSD
PO W E R CO LLI SIO N
LIN K
RE C E I V E
PA RTI T I ON
12345
Ethernet switch
(not supplied)
1: 12V DC Output
2: Digital Output
3: Digital Input
4: Ground
Network Deployment
General Connection (without PoE)
Connect the AC adapter jack to the Network Camera before plugging in to the
power socket. This will reduce the risk of accidental electric shock.
NOTE
lWhen installing in high locations, take caution to secure the camera from falling and
causing possible injury.
lUse the Cable Clip to prevent unplugging of power cord or other cable. (Tie
is not included.)
1
2
3

19
lWhen using a non-PoE switch
Use a PoE power injector to connect between the Network Camera and a non-PoE
switch.
4 3 2 1
WPS/RESET
microSD
P O W E R C O L L I SI ON
LI N K
RE C E I VE
PA R T I T I O N
12345
lWhen using a PoE switch
The Network Camera is PoE-compliant, allowing transmission of power and data
to both run in a single Ethernet cable. See the following illustration to connect the
Network Camera to a PoE switch via Ethernet cable.
4 3 2 1
WPS/RESET
microSD
PO W E R CO LL I SI O N
LIN K
RE C E I VE
PA RT I T I O N
12345
PoE switch
(not supplied)
Non-PoE switch
(not supplied)
PoE power injector
(not supplied)
Power over Ethernet (PoE) (IK-WB16A only)
For this connection method, the
AC adapter is not used.
For this connection method, the
AC adapter is not used.

20
DC INPUT:12V 0.8A
This device complies with Part 15 of the FCC Rules. Operation is
subject tothe following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
MODELNo. IK-WB16A
S/N:
MAC: 0002D1714270
B1010XXXX
0002D1714270
00-02-D1-71-42-70 169.254.0.99 IK-WB16A
Installation
Wizard
1. Install the "Installation Wizard" under the Software Utility directory from the CD-
ROM.
2. The program will analyze your network environment. After your network is
analyzed, please click on the "Next" button to continue the program.
3. The program searches for other Network Cameras on the same network.
4. After searching, the main installer window will pop up. Click on the MAC that
matches the one labeled on the side of the camera lens to connect to the
Network Camera.
Assigning IP Address
NOTE
lIf "Installation Wizard" does not perform normally or the camera can not be found
during the search even though the camera and a PC are connected correctly, please
switch off the wireless LAN of a PC.
lInstallation Wizard can search the location of the Network Camera even though
DHCP is not used on the network. Reassign the static IP address because IP address
of the Network Camera has been set 169.254.*.* by default.
