Toshiba G9000 SERIES User manual

Part # 98485-002
December 2019
Manufactured in the USA
© Copyright 2019 TOSHIBA International Corporation
All rights reserved.
G9000 SERIES
SCiB Energy Storage System
INSTALLATION AND OPERATION MANUAL

G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
Product Use and Warranty Restrictions
The Toshiba products listed in this document are intended for usage in general electronics applications (computer, personal
equipment, o󰀩ce equipment, measuring equipment, industrial robotics, domestic appliances, etc.). These Toshiba products
are neither intended nor warranted for usage in certain applications outlined in Section 3.3 Unintended Usage on page 6
of this manual.
NOTICE
PLEASE INFORM TOSHIBA INTERNATIONAL CORPORATION OR AUTHORIZED REPRESENTATIVE IN
CASE OF INCONSISTENCIES, OMISSIONS, OR QUESTIONS.
Contact us at: [email protected] or visit us at:
www.toshiba.com/tic/industrial/uninterruptible-power-systems
The instructions contained in this manual are not intended to cover all of the details or variations in equipment, or to provide
for every possible contingency concerning installation, operation, or maintenance. Should further information be required
or if problems arise which are not covered su󰀩ciently, contact your Toshiba sales o󰀩ce or call Toshiba Power Electronics
Division at 855-803-7087
Nothing in this manual shall alter Toshiba International Corporation’s standard terms and conditions or the
conditions of any written sales contract.
Any electrical or mechanical modications to the equipment discussed herein, without prior written consent of Toshiba
International Corporation, will void all warranties and may void the UL/CUL/CE/ETL listing. Unauthorized modications can
also result in personal injury, loss of life, or destruction of the equipment.
QUALIFIED PERSONNEL ONLY
Only qualied persons are to install, operate, or service this equipment according to all applicable codes and
established safety practices. The denition of Qualied Personnel is detailed in Section 2.3

G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
SCiB ENERGY STORAGE SYSTEM
Please complete the following information and retain for your records.
JOB NUMBER
MODEL NUMBER
SERIAL NUMBER
APPLICATION
SHIPMENT DATE
INSTALLATION DATE
STARTUP
PERFORMED BY

G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
Purpose
This manual provides information on how to safely install your Toshiba International Corporation power electronics product.
This manual includes a section of general safety instructions that describes the warning labels and symbols that are
used throughout the manual. Read the manual completely before installing, operating, or performing maintenance on this
equipment.
This manual and the accompanying drawings should be considered a permanent part of the equipment and should be
readily available for reference and review. Dimensions shown in the manual are in metric and/or the English customary
equivalent.
Toshiba International Corporation reserves the right, without prior notice, to update information,
make product changes, or discontinue any product or service identied in this publication.
(See https://www.toshiba.com/tic/industrial/uninterruptible-power-systems. )
Toshiba and SCiB are registered trademarks of the Toshiba Corporation. All other product or trade references appearing in
this manual are registered trademarks of their respective owners.
Toshiba International Corporation shall not be liable for direct, indirect, special, or consequential damages resulting from the
use of the information contained within this manual.
This manual is copyrighted. No part of this manual may be photocopied or reproduced in any form without the prior written
consent of Toshiba International Corporation.
© Copyright 2019 Toshiba International Corporation
All rights reserved.
Printed in the U.S.A.
Toshiba Customer Support Center
Contact the Toshiba Customer Support Center for assistance with application information or for any problems that you may
experience with your Toshiba SCiB Energy Storage System.
Toshiba Customer Support Center
8 a.m. to 5 p.m. (CST) – Monday through Friday
USA Toll Free [phone]
Tel [phone] Fax [phone]
E-mail – [email protected]
Web – https://www.toshibaups.com
You may also contact Toshiba by writing to:
TOSHIBA INTERNATIONAL CORPORATION
SOCIAL INFRASTRUCTURE SYSTEMS GROUP
POWER ELECTRONICS DIVISION
13131 West Little York Road
Houston, Texas 77041-9990
Attn.: G9000 UPS Product Manager
For further information on Toshiba products and services, please visit our website at:
www.toshiba.com/tic/industrial/uninterruptible-power-systems

This Page Left Intentionally Blank

i
G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
1 Contents
1 Introduction................................................................................................................................... 1
2 General Safety Instructions......................................................................................................... 2
2.1 Symbols ............................................................................................................................ 2
2.2 Signal Words .................................................................................................................... 3
2.3 Qualied Personnel .......................................................................................................... 3
2.4 Factory Authorized Personnel........................................................................................... 4
3 Important Safety Instructions...................................................................................................... 4
3.1 Maximum Operating Temperature .................................................................................... 4
3.2 SCiB Energy Storage System Safety ............................................................................... 5
3.3 Unintended Usage ............................................................................................................ 6
3.4 Disclaimer ......................................................................................................................... 6
3.5 General Maintenance ....................................................................................................... 7
3.6 Transporting ...................................................................................................................... 8
3.7 Battery Disposal................................................................................................................ 9
4 Unpacking ................................................................................................................................... 10
4.1 General Instructions........................................................................................................ 10
4.2 Unpacking the SCiB Energy Storage Cabinet ................................................................ 10
4.3 Transporting By Forklift ................................................................................................... 12
5 Warning Labels........................................................................................................................... 13
5.1 SCiB ESS Warning Labels ............................................................................................. 13
6 Storage/Operating Environment ............................................................................................... 14
6.1 Inspection/Storage .......................................................................................................... 14
6.2 Storage Environment ..................................................................................................... 14
6.3 Operating Precautions .................................................................................................... 15
6.4 Maintenance Precautions ............................................................................................... 16
7 Installation................................................................................................................................... 17
7.1 Installation Precautions................................................................................................... 17
7.2 Installation Procedure ..................................................................................................... 18
7.3 Wiring Safety .................................................................................................................. 18
7.4 Anchorage....................................................................................................................... 24
7.5 Procedure for Cable/Wire Connections .......................................................................... 25
7.6 Customer Supplied Equipment ....................................................................................... 26
7.7 RS-485 Connections....................................................................................................... 30
8 Operation..................................................................................................................................... 32
8.1 Operating Instructions (G9000 UPS 80–750kVA) ........................................................... 32
8.2 Operating Instructions (G9000 UPS 1000–2000kVA) ..................................................... 33
9 Specications ............................................................................................................................. 34
10 Interfaces................................................................................................................................... 35
10.1 Communication Circuit Overview.................................................................................. 35

ii G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
10.2 LEDS ............................................................................................................................ 36
10.3 Unit Fault Conditions .................................................................................................... 37
Appendix A – Dimensional Drawings .............................................................................................. 38
Appendix B – Modbus Register Map ............................................................................................... 40
Register Details ........................................................................................................................ 42
Cell Level Monitoring Registers (Firmware Version 2 Only) ..................................................... 45
Appendix C – Test Codes ................................................................................................................. 47

1
G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
1 Introduction
This manual provides information on how to safely install and operate your G9000 Series UPS System with the SCiB Energy
Storage System (ESS). This manual includes a section of general safety instructions that describes the warning labels
and symbols that are used throughout the manual. Read the manual completely before installing, operating, or performing
maintenance on this equipment.
Qualied personnel should read this manual carefully before transporting, installing, and wiring the SCiB ESS. In addition
they should have a thorough understanding of the information provided in the chapters titled:
• General Safety Instructions
• Important Safety Instructions
• Safety Precautions
• Installation Precautions
Read this SCiB ESS Installation and Operation Manual for important instructions on operating the G9000 UPS with the SCiB
ESS. This manual and the accompanying drawings should be considered a permanent part of the equipment and should be
readily available for reference and review.
Keep the Installation Manual and the Operation Manual near the SCiB ESS for necessary reference.
Dimensions shown in the manual are in metric and/or the English customary equivalent.
SAVE THESE INSTRUCTIONS

2G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
2 General Safety Instructions
DO NOT attempt to transport, install, operate, maintain or dispose of this equipment until you have read and understood all
of the product safety information provided in this manual.
2.1 Symbols
The symbols listed below are used throughout this manual. When symbols are used in this manual they will include important
safety information that must be carefully followed.
Safety Alert Symbol indicates that a potential
personal injury hazard exists.
Prohibited Symbol indicates DO NOT take action.
Mandatory Symbol indicates that the following
instruction is required.
Ground Symbol indicates the location of the
equipment grounding conductor.
Electrical – Voltage & Shock Hazard Symbol
indicates parts inside may cause electric shock.
Explosion Hazard Symbol indicates parts may
explode.

3
G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
2.2 Signal Words
The signal words listed below are used throughout this manual. When the words DANGER, WARNING, CAUTION and
ATTENTION are used in this manual they will include important safety information that must be carefully followed.
2.3 Qualied Personnel
Installation, operation, and maintenance shall be performed by Qualied Personnel Only. A Qualied Person is one
that has the skills and knowledge relating to the construction, installation, operation, and maintenance of the electrical
equipment described herein and has received safety training on the hazards involved (Refer to the latest edition of NFPA
70E for additional safety requirements).
Qualied Personnel shall:
• Have read the entire operation manual.
• Be familiar with the construction and function of the SCiB Energy Storage System, the equipment being driven, and
the hazards involved.
• Be trained and authorized to safely energize, de-energize, ground, lockout/tagout circuits and equipment, and clear
faults in accordance with established safety practices.
• Be trained in the proper care and use of protective equipment such as safety shoes, rubber gloves, hard hats, safety
glasses, face shields, ash clothing, etc., in accordance with established safety practices.
• Be trained in rendering rst aid.
For further information on workplace safety visit www.osha.gov.
The word DANGER in capital letters preceded
by the safety alert symbol indicates that an
imminently hazardous situation exists, and if not
avoided will result in loss of life or serious injury
to personnel.
The word WARNING in capital letters preceded by
the safety alert symbol indicates that a potentially
hazardous situation exists, and if not avoided
may result in loss of life or serious injury to
personnel.
The word CAUTION in capital letters preceded by
the safety alert symbol indicates that a potentially
hazardous situation exists, and if not avoided may
result in minor or moderate injury.
The word NOTICE in capital letters without
the safety alert symbol indicates a potentially
hazardous situation exists, and if not avoided may
result in equipment and property damage.
NOTICE
CAUTION
WARNING
DANGER

4G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
2.4 Factory Authorized Personnel
Factory authorized personnel have been factory trained and certied to install, service, and repair the G9000 UPS & SCiB
Energy Storage System (ESS). Contact the Toshiba Customer Support Center for assistance in locating the factory-
authorized personnel nearest you.
3 Important Safety Instructions
The following contains important instructions that should be followed during the installation, operation, and maintenance of
the SCiB ESS with the G9000 UPS System.
3.1 Maximum Operating Temperature
The maximum operating ambient temperature for the UPS System is 104 °F (40 °C).
CAUTION
Misuse of this equipment could result in personal injury and/or equipment damage.
In no event will Toshiba Corporation be responsible or liable for either indirect or
consequential damage or injury that may come from the use of this equipment.

5
G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
3.2 SCiB Energy Storage System Safety
The following contains important instructions that should be followed during the installation, operation, and maintenance of
the SCiB Energy Storage System.
To be performed by Qualied Personnel only.
1. Verify that the UPS is o󰀨 and that the power is disconnected from the power source.
2. Remove watches, ring, jewelry, or other metal objects.
3. Use tools with insulated handles to prevent inadvertent shorts.
4. Wear rubber gloves and boots.
5. Do not place tools or any metal parts on top of Toshiba SCiB Modules.
6. Determine if the SCiB modules are inadvertently grounded. If inadvertently grounded, remove source of ground.
Contact with any part of a grounded Toshiba SCiB Module can result in electrical shock.
The likelihood of shock will be reduced if such grounds are removed prior to installation or maintenance.
INSTRUCTIONS IMPORTANTES CONCERNANT LA SÉCURITÉ
CONSERVER CES INSTRUCTIONS Cette notice contient des instructions importantes concernant la sécurté
ATTENTION Un SCiB module puet présenter un risque de choc électrique, de brûlure par transfert d’
énergie.
ATTENTION L’élimination des SCiB modules est règlementèe. Consultar les codes locaux à cet e󰀨et
DANGER
Hazardous DC voltages are present in the system. This hazard will always be present
in a battery system including when it is o󰀪ine. The Toshiba SCiB Modules within the
SCiB ESS can present a risk of electrical shock and high short circuit current. Use
extreme caution when installing and maintaining the system.
In the event of a re, use carbon dioxide gas, a powder re extinguisher, or dry sand
to extinguish the ames.

6G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
3.3 Unintended Usage
DANGER
Never use this Energy Storage System in any of the following applications:
a. Medical Operation Room Equipment
b. Life Support Equipment
c. Fire Prevention or Suppression Equipment
Use of this Energy Storage System in any of the above applications will result in serious personal injury or death.
WARNING
Always read all applicable regulations and standards for the specic application of this Energy Storage System.
Special precaustions must be undertaken when this Energy Storage System is used in the following applications:
a. Nuclear Power Plants
b. Communications Equipment
c. Transportation Equipment
Always consult highly trained and qualied technicians in these applications.
Improper use of the Energy Storage System in any of the above applications may result in serious personal injury or
death.
3.4 Disclaimer
IN NO EVENT WILL TOSHIBA CORPORATION BE RESPONSIBLE OR LIABLE FOR EITHER INDIRECT OR
CONSEQUENTIAL DAMAGE OR INJURY THAT MAY COME FROM THE MISUSE OF THIS EQUIPMENT. ANY
MODIFICATIONS WITHOUT AUTHORIZATION BY TOSHIBA COULD RESULT IN PERSONAL INJURIES, DEATH OR
DESTRUCTION OF THE SCIB ESS.
TOSHIBA RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN
TO IMPROVE RELIABILITY, FUNCTION OR DESIGN. TOSHIBA DOES NOT ASSUME ANY LIABILITY ARISING OUT
OF THE APPLICATION OR USE OF ANY PRODUCT OR UPS DESCRIBED HEREIN; NEITHER DOES IT CONVEY ANY
LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.

7
G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
3.5 General Maintenance
WARNING
DO NOT remove the rear/side panels, or any sheet metal not designed to be
removed.
Removing rear/side panels may result in electric shock, burns, personal injuries or
UPS/ESS failure.
Keep the area around the ESS clean.
Use a vacuum cleaner to clean dust and foreign material from and ESS. Keep the
exterior clean.
Only factory authorized personnel should perform internal general maintenance
on the SCiB ESS and accompanying cabinets.
Contact the authorized Toshiba Customer Support Center or an authorized
Toshiba representative for information on proper disposal of SCiB ESS
components.
It is illegal to dispose of certain components without conforming to environmental
regulations for industrial/commercial waste.

8G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
3.6 Transporting
WARNING
DO NOT tilt any cabinets in the ESS or UPS system more than 10°
from upright position.
Tilting the units more than 10° may cause crushing, trapping or other
personal injuries.
CAUTION
DO NOT transport, move, store, or place the any of the units in
the SCiB ESS on its side.
Excessive force applied from heavy components inside may damage
the unit.
Avoid vibration or shock exceeding 0.5 g.
Failing to observe this precaution may cause damage to the SCiB
ESS.
DO NOT allow any units to su󰀨er shock or impact when unpacking.
Tools used to remove packaging materials may cause damage to the
SCiB ESS system.
DO NOT install any units where water may fall on or enter it.
Water may cause electrical shock, personal injury or system failure.
DO NOT push or pull on the sides of the packaging or any units
to move them. Always use a crane, forklift, or pallet jack for
transporting and positioning the units.
Pushing/pulling on the sides of the unit to move it may result in damage
to the SCiB ESS.

9
G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
3.7 Battery Disposal
CAUTION
Do not dispose of lithium ion batteries via incineration.
Lithium battery disposal shall be in compliance with the local and/or
regional hazardous waste disposal regulations for your area
Other nations and some US states may di󰀨er in the requirements for dis-
posing of hazardous waste. Contact your state and/or local environmen-
tal agency for specics on disposing of hazardous waste in your area.
Steps shall be taken to prevent the short circuit of disposed batter-
ies by insulating the terminals (e.g. insulating tape) (Ref. Section 13,
MSDS SB-SDS-P0045E dated 7/21/2011)
For any questions regarding disposal please contact Toshiba Customer Support Center [phone].

10 G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
4 Unpacking
4.1 General Instructions
Unpack the SCiB Energy Storage Cabinet indoors on a paved oor. The system should be as close as possible to its nal
location. Allow enough space for forklift operations to unpack the units from their packing crates. Then remove the crates.
Properly dispose of the crate.
Points to observe:
• Retain all small articles during unpacking and installation.
• Make sure that exterior paint is not scratched and that no cabinets are damaged before uncrating.
• DO NOT damage the units when using tools to remove packaging materials.
• If provided, DO NOT remove the protective plastic sheet cover until installation.
• Immediately report any abnormalities to Toshiba Customer Support Center or an authorized representative.
4.2 Unpacking the SCiB Energy Storage Cabinet
CAUTION
TOP HEAVY EQUIPMENT. THIS EQUIPMENT WILL TIP OVER EASILY
UNTIL FIXED IN PLACE.
Lift and move carefully, and only with adequate equipment and trained
personnel. IMPROPER LIFTING CAN RESULT IN INJURY OR DEATH.
1. Remove the crate sections B-D from the shipping pallet section A as shown in Figure 4.1.
2. Remove shrink wrap and honeycomb packing from the cabinet.
3. Carefully inspect the SCiB Energy Storage Cabinet for shipping damage.

11
G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
C
A
B
D
CB
FIGURE 4.1: SCIB ENERGY STORAGE SHIPPING
CRATE
Front

12 G9000 Series SCiB Energy Storage Cabinet Installation and Operation Manual – 98485-002
Insert the forks here
FIGURE 4.2: SCIB ENERGY STORAGE CABINET: FRONT
VIEW - FORK ACCESS DIMENSIONS IN CHANNEL BASE
4.3 Transporting By Forklift
Verify forklift maximum load capacity and ensure that the forks are long enough to properly support the SCiB Cabinet.
Insert the forks into the space shown in Figure 4.2. Spaces for the forks are provided underneath the maintenance bypass
cabinet which can be accessed from either the front or the back.
DO NOT tilt units when lifting and/or transporting. Minimize the impact when lowering the cabinet to the oor.
