Toshiba MW 27FP1 User manual

• 27" set with Full-Featured DVD Player and built-in VCR for the ultimate in convenience
• Full-function 4 Head Hi-Fi Stereo VCR for special effects and optimum audio quality
• FST PURE®Flat tube eliminates unwanted reflections from room light compared to conventional tube designs
and increases viewing angle
• Stereo TV with Double Baffle Speaker System offers outstanding audio performance
• New Icon TV/VCR Menu for intuitive control of various video and audio functions
• New Picture Preference Modes allows quick access to preset video settings
• DVD-Video/CD/Video CD playback. DVD-R/CD-R/CD-RW* Compatible playback ensures discs made with personal
computers can be played back in the home theater system, too
• Front AV Inputs for easy connection of video games or a camcorder
• Front Panel Headphone Jack allows for individual listening privacy
MW27FP1 TV/DVD/VCR Tri-Play
KEY FEATURES
• Stereo TV with Double Baffle
Speaker System
• VHS Hi-Fi Stereo
• WMA & MP3 Playback
• StableSound®
• Headphone Jack
• FST PURE®Flat Tube Design
• 4-Head/19-Micron Head Hi-Fi VCR
• JPEG Viewer
• Digital Comb Filter
• New Icon TV/VCR Menu,
Text DVD
• 4 Picture Preference Modes
• Sleep Timer
• Auto Clock for VCR
• Commercial Skip for VCR
• Glow System Remote Control
ADVANTAGE TOSHIBA

TECHNOLOGY & BENEFITS
VIDEO
• FST PURE®Flat Tube Design - Due to its flat design, viewing angle
and picture linearity are greatly improved over traditional tube
designs, delivering the most accurate, life-like images possible.
• 4-Head/19-Micron Head System - Offers superior slow motion
effects over conventional 2 head VCR designs. Toshiba's 19-Micron
Heads match precisely the width of the SP and SLP azimuths and
read only the signal recorded on each azimuth (not adjoining
tracks). The benefit is significantly enhanced SLP performance so
good, it rivals the quality of tapes recorded in the SP Mode.
• Digital Picture Zoom - This interactive DVD feature allows you to
select an area of the picture you want to zoom in on and magnify it.
Enhanced digital processing during moving video or freeze-frame
playback produces superior color fidelity and resolution, even when
you're zoomed in. Also can be used to expand letterbox-only films
to increase the viewable area on-screen.
• JPEG Viewer - Enables the display of digital photographs captured
in the JPEG format. Simply load the CD with your favorite photos
and create custom slide shows with a few simple clicks of the
player's remote control.
AUDIO
•Double Baffle Stereo Speaker System - These front-firing, side-
mounted speakers deliver the best stereo sound by keeping the
sonic image widely separated within the cabinet.
• VHS Hi-Fi Stereo - Delivers the highest quality stereo sound from
tapes recorded with a high fidelity soundtrack.
• WMA & MP3 Playback - Recordable Compact Discs (CD-R &
CD-RW) with music stored in either the Windows Media™ Audio or
MP3 file formats can be enjoyed.
• StableSound®- This feature maintains television volume within a
preset range regardless of the source signal. This eliminates the
annoyance of normal program volume being followed immediately
by extremely loud commercial messages or drastic volume
fluctuations while changing channels.
CONVENIENCE
• New Icon TV/VCR Menu, Text DVD - Offers simple operation by
using picture symbols of key menu functions instead of plain text.
Quickly access various TV features via pull down menus.
• Picture Preference Modes - Includes preset picture settings
tailored for various programs and allows quick adjustments at the
touch of a button. Instead of accessing Brightness, Contrast, Color,
or Tint each time you switch from a movie to a sporting event, use
the preset Picture Preference Modes (Standard, Sports, Movie,
Memory) to change the quality of the picture without all the fuss.
The Memory Mode allows you to customize your own settings and
save them into the television's memory.
• Commercial Skip - After a program has been recorded, pressing
the SKIP button once during playback will automatically advance
the tape 30-seconds forward bypassing recorded commercials.
Pressing the skip button on the remote again will advance the
recorded tape for another 30-seconds for a total of 60-seconds
(30 sec x 6 Maximum).
SPECIFICATIONS
TV
27" FST PURE®Flat Tube Design x
Digital Comb Filter x
New Icon TV/VCR Menu, Text DVD x
Picture Preference Modes 4
181-Channel Tuner x
Double Baffle Stereo TV x
StableSound®x
Auto Shut Off x
Auto Channel Memory x
Sleep Timer x
Closed Caption x
DVD
Disc Qty 1
Disc Play DVD-Video/CD/CD-R/CD-RW*/VCD/DVD-R
WMA & MP3 Playback x
JPEG Viewer x
Digital Picture Zoom x
Fast Scan 2x, 4x, 8x, 20x
Slow Motion x
Parental Lock x
Tray Lock x
Multi-Camera Angle Select x
Multi-Language Select x
Multi-Subtitle Select x
Coaxial Dolby®Digital and DTS®x
VCR
Video Heads 4
Resolution 240 Lines
Record Speeds SP/SLP
Hi-Fi VHS Stereo x
MTS/SAP Tuner x
MW27FP1
MW27FP1
http://www.tacp.toshiba.com Customer Service: 800.631.3811
Marketing Communications © Toshiba America Consumer Products, L.L.C.
82 Totowa Road, Wayne, NJ 07470 (2004). All Rights Reserved (05/04.02)
Dolby is a registered trademark of Dolby Laboratories. DTS is a registered
trademark of Digital Theater Systems. FST PURE and StableSound are
registered trademarks of Toshiba America Consumer Products.
Product design and specification subject to change or modification
without notice.
Commercial Skip x
Auto Clock x
8 Event/1 Month Programming x
One-Touch Record x
Auto Tracking x
Auto Head Cleaner x
Auto Play x
OSD Language English/French/Spanish
V-Chip x
Remote Control DVD/VCR/TV Glow Remote
Terminals
RCA Video Out 1 rear
RCA Video In 1 front & 1 rear
L-R Audio Out 1 rear
L-R Audio Inputs 1 front & 1 rear
Coaxial Digital Audio Output 1 - DVD only
RF Input (rear) 1
Headphone Jack (front) 1
Weight 97 lbs
Box Weight 107 lbs
Dimension (WHD) 29-1/4 x 25-1/2 x 19-1/2 inches
Carton Dimension 33-1/4 x 30 x 24-1/2 inches
UPC Code 022265271056
*CD-R/CD-RW discs recorded by CD-CA method can be played back. Some CD-R/CD-RW discs may be incompatible due to laser
pick-up and disc design. DVD-R discs recorded by DVD Video method can be played. Some DVD-R discs may be incompatible due to
laser pick-up and disc design. WMA, MP3 and JPEG discs may be incompatible due to different recording format or condition of disc.
