Toshiba 34HF83 User manual

FILE NO. 070-200307
SERVICE MANUAL
COLOR TELEVISION
N3WS Chassis
34HF83
PUBLISHED IN JAPAN. May. 2003 So
(TAC0322)

– 2 –
GENERAL ADJUSTMENTS
TABLE OF CONTENTS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS ........................................................................................................................................ 3
SET-UP ADJUSTMENT ............................................................................................................................................ 4
SERVICE MODE ...................................................................................................................................................... 6
ELECTRICAL ADJUSTMENTS ................................................................................................................................ 9
CIRCUIT CHECKS ................................................................................................................................................. 11
CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA .............................................................................................................................. 12
LOCATION OF CONTROLS ................................................................................................................................... 13
ADDING CHANNELS TO THE TV'S MEMORY ...................................................................................................... 15
CHASSIS AND CABINET REPLACEMENT PARTS LIST ......................................................................................16
PC BOARDS BOTTOM VIEW................................................................................................................................. 31
TERMINAL VIEW OF TRANSISTORS ................................................................................................................... 40
CIRCUIT BLOCK DIAGRAM .................................................................................................................................. 42
SPECIFICATIONS .............................................................................................................................................. END
APPENDIX:
CIRCUIT DIAGRAM

–3 –
GENERAL ADJUSTMENTS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”INSTRUCTIONS BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous
X-RAY RADIATION. To avoid such hazards, the high volt-
age must not be above the specified limit. The nominal
value of the high voltage of this receiver is (A) kV at zero
beam current (minimum brightness) under a 120V AC
power source. The high voltage must not, under any cir-
cumstances, exceed (B) kV.
Refer to table-1 for high voltage (A), (B).
(See SETTING & ADJUSTING DATA on page 12)
Each time a receiver requires servicing, the high voltage
should be checked following the HIGH VOLTAGE CHECK
procedure in this manual. It is recommended that the read-
ing of the high voltage be recorded as a part of the service
record. It is important to use an accurate and reliable high
voltage meter.
2. This receiver is equipped with a Fail Safe (FS) circuit which
prevents the receiver from producing an excessively high
voltage even if the B+ voltage increases abnormally. Each
time the receiver is serviced, the FS circuit must be checked
to determine that the circuit is properly functioning, follow-
ing the FS CIRCUIT CHECK procedure in this manual.
3. The only source of X-RAY RADIATION in this TV receiver
is the picture tube. For continued X-RAY RADIATION pro-
tection, the replacement tube must be exactly the same
type tube as specified in the parts list.
4. Some part in this receiver have special safety-related char-
acteristics for X-RAY RADIATION protection. For contin-
ued safety, parts replacement should be undertaken only
after referring to the PRODUCT SAFETY NOTICE below.
SAFETY PRECAUTION
Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15
µF, AC type capacitor, between a known good earth ground
(water pipe, conduit, etc.) and the exposed metallic parts,
one at a time. Measure the AC voltage across the combi-
nation of 1500 ohm resistor and 0.15 µF capacitor. Re-
verse the AC plug at the AC outlet and repeat AC voltage
measurements for each exposed metallic part. Voltage
measured must not exceed 0.3 volts rms. This corresponds
to 0.2 milliamp. AC. Any value exceeding this limit consti-
tutes a potential shock hazard and must be corrected im-
mediately.
WARNING : Service should not be attempted by anyone unfa-
miliar with the necessary precautions on this receiver. The fol-
lowing are the necessary precautions to be observed before
servicing this chassis.
1. An isolation Transformer should be connected in the power
line between the receiver and the AC line before any serv-
ice is performed on the receiver.
2. Always discharge the picture tube anode to the CRT con-
ductive coating before handling the picture tube. The pic-
ture tube is highly evacuated and if broken, glass frag-
ments will be violently expelled. Use shatter proof gog-
gles and keep picture tube away from the unprotected body
while handling.
3. When replacing a chassis in the cabinet, always be cer-
tain that all the protective devices are put back in place,
such as; non-metallic control knobs, insulating covers,
shields, isolation resistor-capacitor network etc.
4. Before returning the set to the customer, always perform
an AC leakage current check on the exposed metallic parts
of the cabinet, such as antennas, terminals, screwheads,
metal overlays, control shafts etc. to be sure the set is
safe to operate without danger of electrical shock. Plug
the AC line cord directly into a 120V AC outlet (do not use
a line isolation transformer during this check). Use an AC
voltmeter having 5000 ohms per volt or more sensitivity in
the following manner:
AC VOLTMETER
0.15µF
Good earth ground
such as a water
pipe, conduit, etc.
Place this probe on
each exposed
metallic part.
1500 ohm
10 watt
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety charac-
teristics are identified in this manual and its supplements; electrical components having such features are identified by the
international hazard symbols on the schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement
parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray radiation
or other hazards.

–4 –
GENERAL ADJUSTMENTS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”ON PAGE 3 OF SERVICE MANUAL.
SET-UP ADJUSTMENT FOR FLAT TUBE
■The following adjustments should be made when a complete realignment is required or a new picture tube is installed.
Perform the adjustments in order as follows :
1. Color Purity
2. Convergence
3. White Balance
Note: The PURITY/CONVERGENCE MAGNET assembly and rubber wedges need mechanical positioning.
Refer to figure 1.
COLOR PURITY ADUSTMENT
(1)Let the screen face in the installing direction or toward the east (when it is to be moved), bring up the service mode
screen after demagnetizing (front, left, right, and top) with the degaussing coil, receive white signals by pressing the
[TV/VIDEO] button, and then the receiver should be operated for more than 40 minutes.
(2)Perform rough adjustment of the central convergence with the P/C magnet according to the adjustment item.
(3)Receive built-in green signals, loosen set screws on the deflection yoke, remove rubber wedges, and shift the deflection
yoke to toward front.
(4)Move alternately the two 2-pole magnets of the P/C magnets so that the green raster can come to the center of the
screen.
Figure 1.
(5)Receive built-in red and blue signals, check that there is no inclination of the single color raster toward one side, and if
each color tilts to a great extent, make adjustment with the 2-pole magnet so that the 3 colors will come to the center
evenly.
(6)Receive the green raster, shift the deflection yoke from a
foremost position (hitting against the picture tube) to a
backward position horizontally, stop the deflection yoke
at a position where it begins to become a green raster,
and perform accurate marking on the picture tube.
(7)Shift the deflection yoke further backward, and perform
accurate marking at a position where the green raster
begins to being luck.
(8)Fix the deflection yoke at a position 60% forward within
the range marked in items (6) and (7) above.
CONVERGENCE ADJUSTMENTS
* Adjust the convergence magnet to get vest convergence in the the order to (1) ~ (5).
■ CENTER CONVERGENCE:
(1)Receive the white crosshatch or dot pattern from the service signal generator.
(2)Use the 2 pieces of main 4-pole magnets of P/C magnets, change the open angle, and align the red and blue vertical
lines on the screen center.
(3)Freeze the open angle of the main 4-pole magnets, turn them simultaneously, and align the horizontal lines.
(4)Take the same steps for items (2) and (3) above and align red/blue with green on the screen center using two 6-pole
magnets.
A
P/C magnet installing position A
•30"=26.5 mm
•32"=30.5 mm or 32.5 mm
•34"=37 mm
•34"=39 mm
Green Belt
2-pole purity magnet
(27": Magnet is fixed with deflection yoke.)
Main 4-pole convergence magnet (30" : 32")
6-pole convergence magnet (34")
Sub-4-pole convergence magnet (32" : 34")
Sub-4-pole convergence magnet (to be installed on deflection yoke for 30", 32”)
6-pole convergence magnet (30" : 32")
Main 4-pole convergence magnet (34")
Fix the deflection yoke at a position 60% forward from a point
between (6) and (7)
Picture tube
Shift deflection yoke
(6)
(8)
(7) Perform marking of each point on
the tape of picture tube
CRT-D board
P/C Mag
100 60 0%

–5 –
GENERAL ADJUSTMENTS
(5)Adjust the sub-4-pole magnets only in case there is any deviation of Xv bow-shaped convergence. (To be usually set at
the initial position)
Align both sides with the sub-4-pole magnets and minimize the deviation of blue and red with the main 4-pole magnets.
blue
blue
red
red
Main 4-pole magnet
red/blue
red/blue
green
green
6-pole magnet
Xv bow-shaped deviation of convergence
blue
red
Sub-4-pole magnet
■CIRCUMFERENCE CONVERGENCE:
*Perform correction in the following manner.
A
D
E
F
A
B
C
B
C
S
N
D
E
F
A
B
C
D
E
F
N
S
VR3
YV YHC
GH
GH
VR2 VR1
blue
green
red
•Adjust coils and minimize deviation
(The 27”unit has coils underneath it)
blue
green
red
(Parts code:23 948 274) TC-S
Blue color or blue mark
*Insert the correction piece between the
picture tube and the deflection yoke.
(Insertion position of correction
piece)
Bonded surface
blue
green
red
(Parts code:23 948 464)
Transparent
Bonded surface
Adjust VR 1 and minimize the deviation of YH. *Only 27", 30" and 32".
Red
green
blue
Red green blue
Red
green
blue
Red
green
blue
Adjust VR 2 (YHC) and minimize the deviation of YH.
Red
green
blue
Red
green
blue
Red
green
blue
Red green
blue
Adjust VR 3 (YV) and minimize the deviation of YV.
Red
blue
green
Red
blue
green
Red
blue
green
Red
blue
green
Red
blue
green
blue
red
green
Red
blue
green
blue
red
green
■ 30", 27", 32"
■ 34"
27" (Part No. 23 947 371)
32", 30" (Part No. 23 947 121)
34" (Part No. 23 993 080)
Perform correction by inserting the
correction piece into the clear-
ance of terminal board coils of
the deflection yoke.
Note:
Perform insertion by turning the
metal side to the terminal board
side of the deflection yoke.

–6 –
GENERAL ADJUSTMENTS
SERVICE MODE
1. ENTERING TO SERVICE MODE
MUTE
S
(Service mode display)
1/2 MUTE
3) While pressing the MUTE button,
press MENU button on TV set.
2) Press MUTE button
again to keep pressing.
1) Press MUTE button twice
on Remote Control.
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on TV.
Adjustment mode
Press
Press
Service mode
Item
Data
S
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
A single horizontal line ON/OFF: TV (ANT)/VIDEO button (on TV)
Test signal selection : TV (ANT)/VIDEO button (on Remote)
Selection of the adjustment items : Channel s/t(on TV or Remote)
Change of the data value : Volume s/t(on TV or Remote)
Adjustment menu mode ON/OFF : MENU button (on TV)
Initialization of the memory (QA02, QA04) : RECALL+Channel (s) button on TV
Initialization of the self diagnostic data: RECALL+Channel (t) button on TV
“RCUT”selection : 1 button
“GCUT”selection : 2 button
“BCUT”selection : 3 button
“CNTX”selection : 4 button
“COLC”selection : 5 button
“TNTC”selection : 6 button
Test audio signal ON/OFF (1kHz) : 8 button
Self diagnostic display ON/OFF : 9 button

–7 –
GENERAL ADJUSTMENTS
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL sbutton in the service mode changes the adjustment items in the order of table-2.
(tbutton for reverse order)
Refer to table-2 for preset data of adjustment mode.
(See SETTING & ADJUSTING DATA on page 12)
5. ADJUSTING THE DATA
1) Pressing of VOLUME sor tbutton will cahnge the value of data in the range from 00H to FFH. The variable range
depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■INITIALIZATION OF MEMORY DATA OF QA02 AND QA04
After replacing QA02 and QA04, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the RECALL button on the Remote, then press the CHANNEL sbutton on the TV. The initialization of QA02
and QA04 has been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Programming Channel Memory”on the owner's manual.
CAUTION: Never attempt to initialize the data unless QA02, QA04 has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of TV/VIDEO button on the Remote Control in the Service mode changes the built-in test patterns
on screen in the following order.
Normal picture
All white
Signals Picture
•All White
2) Press “8”button while any built-in test pattern to on the screen to output the 1 kHz sound. Press the button again to
cut off the sound.
Note: If the video cable is connected to the VIDEO1 INPUT jack, the built-in pattern signals are not displayed.

– 8 –
GENERAL ADJUSTMENTS
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s are executed properly.
2) During diagnosis, the following displays are shown.
SELF CHECK
NO. 23 * * * * * *
POWER : 000
BUS LINE : OK
BUS CONT : OK
BLOCK : MAIN SUB
SET ID : FF
EEP VER : FF
OPT1 : 02 OPT2 : A4
DVI
NO 23009621
ERR CODE : 030000








Part number of microprocessor (QA01)
Operation number of protection circuit (current limiter) . . . . “000”is normal.
BUS line check “OK”................... Normal
“SCL-GND”or “NG”.......... SCL-GND short circuit
“SDA-GND”or “NG”.......... SDA-GND short circuit
“SCL-SDA”or “NG”........... SCL-SDA short circuit
BUS line ACK (acknowledge) check
“OK”..................... Normal
Display of Location Number . . . . NG
(Display example)
“QA02 NG”, “H001 NG”, “Q501 NG”etc.
Note: The indication of failure place is only one place though failure places are plural. When
repair of a failure place finishes, the next failure place is indicated. (The order of priority of
indication is left side.)
Sync. signal check Green display ..... Normal
Cyan display ...... No check
Red display ........ NG
MAIN....... Main sync
SUB ........ Sub sync (when turn on the PIP)
ID code for TV set
Version of "EEP"
Data for "OPT"

–9 –
GENERAL ADJUSTMENTS
ELECTRICAL ADJUSTMENTS
Vertical retrace line
1. Enter the service mode, then select any register item.
2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern ap-
pears on the screen.
3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture
screen.
FOCUS VR ADJ
SUB-BRIGHTNESS
(BRTC)
1. Constrict the picture height until the verti-
cal retrace line appears adjusting the item
HIT (HEIGHT).
2. Adjust the CONTRAST control to the mini-
mum.
3. Call up the adjustment mode display, then
select the item BRTC.
4. Press the VOLUME sor tbutton so the
belt of vertical retrace line just disappear.
5. Adjust the CONTRAST control for the de-
sired contrast.
6. Perform the HEIGHT adjustment.
ITEM ADJUSTMENT PROCEDURE
SUB-COLOR
(SCOL)
SUB-TINT
(TNTC)
1. Receive color-bar signal from color-bar
generator.
2. Press the RESET button.
3. Connect oscilloscope to TP501 on SIG-
NAL board.
4. Adjust the CONTRAST control to the
minimum.
5. Call up the adjustment mode display,
then select the item TNTC.
6. Adjust the SUB-TINT by pressing the
VOLUME sor tbutton to obtain a blue
bar to magenta bar ratio of 3:2 as shown.
7. Press the RESET button.
8. Select the item SCOL.
9. Adjust the SUB-COLOR by pressing the VOLUME sor tbutton to achieve
1.6V0-p of a blue bar on scope.
10. Check the picture with off-air signal.
0
Blue
Magenta
2
3 (1.6V
0-P
)
WIDTH
(WID)
1. Call up the adjustment mode display, then select the item WID.
2. Press the VOLUME sor tbutton to get the picture so the left and right edges of
raster begins to lack.
3. Press the VOLUME sor tbutton to advance the data by 7 steps.
Note : Check the horizontal picture position is correct.

–10 –
GENERAL ADJUSTMENTS
ITEM ADJUSTMENT PROCEDURE
E-W PARABOLA (DPC)
(PARA)
1. Call up the adjustment mode display, then select the item PARA.
2. Press the TV/VIDEO button on Remote until the cross-hatch pattern appears on
the screen.
3. Press the VOLUME sor tbutton to make vertical lines straight as shown below.
HORIZONTAL POSITION
(HPOS)
VERTICAL POSITION
(VPOS)
1. Call up the adjustment mode display, then select the item HPOS or VPOS.
2. Press the TV/VIDEO button on Remote until the
white cross-bar or black cross-bar pattern appears
on the screen.
3. Adjust the HORIZONTAL and VERTICAL position
alternately by pressing the VOLUME sor tbut-
ton for proper picture position.
4. Check the picture with off-air signal.
HEIGHT
(HIT)
1. Call up the adjustment mode display, then select the item HIT.
2. Press the VOLUME sor tbutton to get the picture so the top of raster begins to
lack.
3. Press the VOLUME sbutton to advance the data by 9 steps.
Note : Check the vertical picture position is correct.
WHITE BALANCE
(RCUT)
(GCUT)
(BCUT)
(GDRV)
(BDRV)
1. Adjust the CONTRAST control to the center, and BRIGHTNESS control to the
maximum.
2. Call up the adjustment mode display, and press the TV/VIDEO button on Remote
until the white and black pattern appears on the screen.
3. Adjust the following items with the CHANNEL s/tand VOLUME s/tbuttons.
4. Press the TV/VIDEO button on TV to display a single horizontal line on the screen.
5. Turn the SCREEN control (FBT) fully counterclockwise and gradually rotate clock-
wise until the first horizontal line appears slightly on the screen.
6. Press the TV/VIDEO button to display the normal picture.
7. Adjust the remaining two “?CUT”items (CHANNEL s/t→TV/VIDEO →VOL-
UME s/tin order) to obtain the slightly lighted horizontal line in the same levels of
three (red, green, blue) colors. The line should be white if the adjustments are
proper.
Bright area
Adjust "GDRV" or "BDRV" to be white.
Dark area
Fine adjust "RCUT", "GCUT" or "BCUT" to be black.
RCUT Data : 40H
GCUT Data : 40H
BCUT
Item :
Item :
Item :
Item :
Item :
Data : 40H
GDRV Data : 40H
BDRV Data : 40H

– 11 –
GENERAL ADJUSTMENTS
CIRCUIT CHECKS
Troubleshooting Guide for Fail Safe Circuit
HIGH VOLTAGE CHECK
CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on
this chassis. Checking should be done following the steps
below.
1. Connect an accurate high voltage meter to the second an-
ode of the picture tube.
2. Turn on the receiver. Set the BRIGHTNESS and CON-
TRAST controls to minimum (zero beam current).
3. High voltage must be measured below (B) kV.
Refer to table-1 for high voltage (B).
(See SETTING & ADJUSTING DATA on page 12)
4. Vary the BRIGHTNESS control to both extremes to be sure
the high voltage does not exceed the limit under any con-
ditions.
FS CIRCUIT CHECK
The Fail Safe (FS) circuit check is indispensable for the final
check in servicing. Checking should be done following the
steps below.
1. Turn the receiver on and press the RESET button.
2. Temporarily short TP-(R) and TP-(X) with a jumper wire.
Raster and sound will disappear.
3. The receiver must remain in this state even after removing
the jumper wire. This is the evidence that the FS circuit is
functioning properly.
4. To obtain a picture again, temporarily turn the receiver off
and allow the FS circuit more than 5 seconds to reset. Then
turn the power switch on to produce a normal picture.
Check that the set returns to normal operation when pin 12
of Z801(or emitter of Q472) is grounded with jumper wire.
Check the voltage across
Capacitor C471 is
approximately
(C) volts.
Refer to table –3 for
FBT detection voltage
(C) .
Faulty power
circuit or hori-
zontal circuit.
Defective Fail Safe Circuit
(See SETTING & ADJUSTING
DATA on page 12)
YES NO
NO
YES

–12 –
GENERAL ADJUSTMENTS
SETTING & ADJUSTING DATA
34"
HIGH VOLTAGE AT ZERO BEAM: (A) 30.0 kV
MAX HIGH VOLTAGE: (B) 35.0 kV
Table-1
RCUT
GCUT
BCUT
GDRV
BDRV
BRTC
TNTC
SCNT
HIT
R CUT OFF
(Basis)
G CUT OFF (Basis)
B CUT OFF (Basis)
G DRIVE (Basis 1,4,7,10)
B DRIVE (Basis 1,4,7,10)
BRIGHT CENTER (1-12)
TINT CENTTER (1,2,3)
SUB CONTRAST (1,2,3)
PICTURE HIT (1080)
SERVICE MODE
ADJUSTING ITEMS AND DATA IN THE SERVICE MODE:
CHAPTER 2 SPECIFIC INFORMATIONS
SAFETY INSTRUCTIONS
Item Name of adjustment Item Name of adjustment Preset
Table-2
CIRCUIT CHECKS
FBT DETECTION VOLTAGE (C) 20.1 V
40H
40H
40H
40H
40H
80H
46H
15H
38H
Preset
12H
00H
16H
15H
35H
39H
14H
10H
82H
LIN
WID
PARA
CNR
TRAP
HPS
TCNR
BCNR
VPSI
V-LINEARITY
(1080)
PICTURE WIDTH (1080)
E-W PARABOLA (1080)
EW M CORRECTION
EW TRAPEZIUM
H-POSITION
EW TOP CORNER
(1080)
EW BOTTOM COR (1080)
VTRAP (VPS1) (1080)
←
←
←
←
←
←
←
12H
24H
NORMAL
& FULL
←
20H
←
←
←
46H
←
←
6DH
SPECIFIC INFORMATIONS
NORMAL
& FULL
Table-3

–13 –
GENERAL ADJUSTMENTS
LOCATION OF CONTROLS
TV Front
Video 3
Video/Audio inputs
(behind the door)
MENU ;:ts
Volume ;:
Remote sensor
TV Rear
Channel tsTV/VIDEO
SPECIFIC INFORMATIONS
CHANNELVOLUMEMENU TV/VIDEO
R L/MONO
AUDIOVIDEO
S-VIDEO
POWER
VIDEO-3 IN
POWER
Power indicator
OUT
IN
ANT( 75 )
ANT-1 ANT-2OUT
L/
MONO
AUDIO
VIDEO
S-VIDEO
VIDEO 1
PB
PR
Y
COLOR
STREAM HD-1
COLOR
STREAM HD-2
R
VIDEO
S-VIDEO
VIDEO 2
L/
MONO
AUDIO
VIDEO
R
L
VAR
AUDIO
R
AUDIO
R
L
PB
PR
Y
AUDIO
R
L
L/
MONO
AUDIO
R
ON OFF
AUDIO CENTER
CHANNEL IN
DVI/HDCP IN
R
AUDIO
L
MENU
ANT-1 IN
ANT OUT
ANT-2 IN DV/HDCP IN
VIDEO 1/2
ColorStream
HD-1
ColorStream
HD-2
Video/
Audio OUT Variable Audio OUT
Audio Center Channel IN

– 14 –
GENERAL ADJUSTMENTS
Remote Control
SPECIFIC INFORMATIONS
123
456
789
ENT
100
0
POWER
RECALL
CHRTN
FAV
FAV
TV / VIDEO
+10
PIC SIZE
EXIT
INFO
STOP
POP DIRECT CH MUTE SLEEP
TV/VCR PAUSE
FFREW
SKIP / SEARCH
SPLIT
SWAP POP CH
LIGHT
REC
CH SCAN
FREEZE SOURCE
PLAY
TV
CBL/SAT
VCR
DVD
VOLCH
FAVORITE
ENTER
DVDMENU
MENU
T
O
P
M
E
N
U
G
U
I
D
E
C
L
E
A
R
E
N
T
E
R
POWER
INFO (CBL/SAT only)
Channel Numbers (0-9)
GUIDE (CBL/SAT only)
89; :(DVD only)
CLEAR (DVD only)
CH 89
PLAY
STOP
SKIP/SEARCH (DVD only)
SKIP/SEARCH (DVD only)
+10 (DVD only)
TOP MENU (DVD only)
ENTER
Device Switch
PAUSE
TV/VCR (VCR only)
REW
REC (VCR only)
FF

–15 –
GENERAL ADJUSTMENTS
ADDING CHANNELS TO THE TV’S MEMORY
SPECIFIC INFORMATIONS
Programming channels automatically
Your TV can automatically detect all active channels in your
area and store them in its memory. After the channels are
stored automatically, you can manually add or erase
individual channels (see “Adding and erasing channels
manually,”below).
To program channels automatically:
1Press MENU, and then press ;or :until the SET UP
menu appears.
2Press 8or 9until the TV/CABLE is highlighted.
3Press ;or :to highlight either TV or CABLE, depend-
ing on which you use. If you use an antenna, highlight
TV; if you use cable, highlight CABLE.
4Press 9to select CH PROGRAM.
5Press ;or :to start channel programming. The TV will
automatically cycle through all the TV or Cable channels
(depending on which you selected), and store all active
channels in the channel memory.
While the TV is cycling through the channels, the
message “Programming Now—Please Wait”appears.
6When channel programming is complete, the message
“Completed”appears.
7Press Channel 8or 9to view the programmed chan-
nels.
Adding and erasing channels manually
After you have programmed the channels automatically, you
can manually add or erase specific channels.
To add or erase channels:
1Select the channel you want to add or erase. If you are
adding a channel, you must select the channel using the
Channel Number buttons.
2Press MENU, and then press ;or :until the SET UP
menu appears.
3Press 8or 9to highlight ADD/ERASE.
4Press ;or :to select ADD or ERASE, depending on
the function you want to perform.
5Repeat steps 1-4 for other channels you want to add or
erase.
Using the Quick Connect Guide
The Quick Connect Guide automatically starts the first time
the TV is turned on.
You can change the current settings any time.
1Press MENU, and then press ;or :until the SET UP
menu appears.
2Press 8or 9to highlight “QUICK CONNECT GUIDE”.
3Press ;or :to enter the Quick Connection Guide
mode.
Advance the setup according to the guide displayed on
the screen.
You can set up the following items.
On-screen display language selection
Cable box selection (Yes/No)
Cable box connection
Cable box output channel selection
(ch3/ch4)
Select channels using Cable box
(Confirmation only)
Clock setting
Picture mode selection
Basic setup has been completed
Cable or Antenna connection
TV (antenna)/Cable source selection
Automatic channel programming
Ye s No
When you press Channel 8or 9, your TV will stop only on the channels stored in the TV’s channel memory.
Follow the steps below to program all active channels into the TV’s memory.

– 16 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
CAPACITORS
C101 24796339 ELECTROLYTIC CE04G 35V 3.3UF M
C102 24665221 ELECTROLYTIC, 10V 220UF M 3A
C105 24100102 CERAMIC CHIP, 50V F 1000PF Z
C106 24669479 ELECTROLYTIC, 50V 4.7UF M 3A
C107 24666221 ELECTROLYTIC, 16V 220UF M 3A
C112 24665221 ELECTROLYTIC, 10V 220UF M 3A
C115 24100102 CERAMIC CHIP, 50V F 1000PF Z
C117 24666221 ELECTROLYTIC, 16V 220UF M 3A
C118 24665221 ELECTROLYTIC, 10V 220UF M 3A
C201 24109103 CERAMIC CHIP, 50V B 0.01UF K
C205 24766229 ELECTROLYTIC, 50V 2.2UF M
C206 24794220 ELECTROLYTIC, 16V 22UF M
C307 24693823 PLASTIC FILM CQ921 M 100V 0.082MF J
C308 24668221 ELECTROLYTIC, 35V 220UF M 3A
C309 24212101 CERAMIC DISC, 50V B 100PF K
C310 24667102 ELECTROLYTIC, 25V 1000UF M 3A
C311 24214152 CERAMIC DISC, 500V B 1500PF K
C313 24082057 PLASTIC FILM, 100V 0.22UF J
C314 24591563 PLASTIC FILM, 50V 0.056UF J
C320 24667221 ELECTROLYTIC, 25V 220UF M 3A
C322 24539105 PLASTIC FILM, 50V 1UF J
C323 24539105 PLASTIC FILM, 50V 1UF J
C325 24591203 PLASTIC FILM, 50V 0.02UF J
C326 24669010 ELECTROLYTIC, 50V 1UF M 3A
C327 24073041 ELECTROLYTIC, 16V 470UF M 3A
C331 24667102 ELECTROLYTIC, 25V 1000UF M 3A
C332 24591562 PLASTIC FILM, 50V 5600PF J
C333 24109332 CERAMIC CHIP, 50V B 3300PF K
C362 24591123 PLASTIC FILM, 50V 0.012MF J
C370 24666100 ELECTROLYTIC, 10V 10UF M 3A
C402 24092463 CERAMIC CHIP, 16V B 0.22UF K
C404 24669229 ELECTROLYTIC, 50V 2.2UF M 3A
C406 24109223 CERAMIC CHIP, 25V B 0.022UF K
C410 24109221 CERAMIC CHIP, 50V B 220PF K
C413 24214392 CERAMIC DISC, 500V B 3900PF K
C416 24676330 ELECTROLYTIC, 100V 33UF M 3A
C417 24214391 CERAMIC DISC, 500V B 390PF K
C418 24667221 ELECTROLYTIC, 25V 220UF M 3A
C424 24763101 ELECTROLYTIC, 16V 100UF M
C425 24763101 ELECTROLYTIC, 16V 100UF M
*C428 24503192 PLASTIC FILM, 400V 0.15UF J
C432 24763101 ELECTROLYTIC, 16V 100UF M
C439 24503459 PLASTIC FILM, 400V 0.068UF J
*C442 24503190 PLASTIC FILM, 400V 0.12UF J
*C443 24503348 PLASTIC FILM, 1800VH 3900PF H
*C444 24503196 PLASTIC FILM CF92 T 1800VH 5600PF H
C445 24095804 PLASTIC FILM, 400V 0.056UF J
C446 24073120 ELECTRPLYTIC, 250V 33UF, 250YXF33M
C448 24073118 ELECTROLYTIC, 160V 33UF M
C449 24667102 ELECTROLYTIC, 25V 1000UF M 3A
C450 24092341 CERAMIC DISC, 2KV R 470PF K
C451 24092341 CERAMIC DISC, 2KV R 470PF K
C452 24820103 PLASTIC FILM, 630V 0.01UF J
*C461 24820123 PLASTIC FILM, 630V 0.012UF J
C464 24503149 PLASTIC FILM, 250V 3.3UF
C465 24591183 PLASTIC FILM, 50V 0.018UF J
C466 24679220 ELECTROLYTIC, 250V 22UF M 3A
*C467 24820123 PLASTIC FILM, 630V 0.012UF J
C468 24591823 PLASTIC FILM, 50V 0.082UF J
C469 24591122 PLASTIC FILM, 50V 1200PF J
C470 24766220 ELECTROLYTIC, 50V 22UF M
C471 24766479 ELECTROLYTIC, 50V 4.7UF M
C472 24539474 PLASTIC FILM, 50V 0.47UF J
C476 24214471 CERAMIC DISC, 500V B 470PF K
C477 24666220 ELECTROLYTIC, 16V 22UF M 3A
C482 24109122 CERAMIC CHIP, 50V B 1200PF K
C488 24666100 ELECTROLYTIC, 10V 10UF M 3A
C502 24092730 CERAMIC CHIP, 16V B 0.1UF K
C503 24666471 ELECTROLYTIC, 16V 470UF M 3A
C508 24092730 CERAMIC CHIP, 16V B 0.1UF K
C509 24666101 ELECTROLYTIC, 16V 100UF M 3A
C513 24109103 CERAMIC CHIP, 50V B 0.01UF K
C515 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C520 24567334 PLASTIC FILM, 50V 0.33UF J
C524 24109103 CERAMIC CHIP, 50V B 0.01UF K
C525 24109103 CERAMIC CHIP, 50V B 0.01UF K
C526 24109103 CERAMIC CHIP, 50V B 0.01UF K
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the
safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with * mark is no longer available after the end of the production.
Model : 34HF83
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CHASSIS AND CABINET REPLACEMENT PARTS LIST

–17 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
C527 24109103 CERAMIC CHIP, 50V B 0.01UF K
C528 24109103 CERAMIC CHIP, 50V B 0.01UF K
C529 24109103 CERAMIC CHIP, 50V B 0.01UF K
C533 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C534 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C535 24109103 CERAMIC CHIP, 50V B 0.01UF K
C536 24109103 CERAMIC CHIP, 50V B 0.01UF K
C537 24109103 CERAMIC CHIP, 50V B 0.01UF K
C538 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C540 24092538 CERAMIC CHIP, 10V F 1UF Z
C541 24092538 CERAMIC CHIP, 10V F 1UF Z
C542 24092538 CERAMIC CHIP, 10V F 1UF Z
C547 24109103 CERAMIC CHIP, 50V B 0.01UF K
C563 24797010 ELECTROLYTIC, 50V 1UF M
C564 24797229 ELECTROLYTIC, 50V 2.2UF M
C568 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C571 24109103 CERAMIC CHIP, 50V B 0.01UF K
C582 24761102 ELECTROLYTIC, 6.3V 1000UF M
C583 24761102 ELECTROLYTIC, 6.3V 1000UF M
C584 24797010 ELECTROLYTIC, 50V 1UF M
C585 24109103 CERAMIC CHIP, 50V B 0.01UF K
C586 24761102 ELECTROLYTIC, 6.3V 1000UF M
C612 24668101 ELECTROLYTIC, 35V 100UF M 3A
C613 24109103 CERAMIC CHIP, 50V B 0.01UF K
C617 24073034 ELECTROLYTIC, 16V 10UF M 3A
C661 24109122 CERAMIC CHIP, 50V B 1200PF K
C662 24109122 CERAMIC CHIP, 50V B 1200PF K
C664 24073035 ELECTROLYTIC, 16V 22UF M 3A
C665 24794100 ELECTROLYTIC, 16V 10UF M
C671 24669100 ELECTROLYTIC, 50V 10UF M 3A
C672 24669479 ELECTROLYTIC, 50V 4.7UF M 3A
C673 24073084 ELECTROLYTIC, 50V 4.7UF M 3A
C676 24503041 PLASTIC FILM , 63V 0.1UF J
C677 24503041 PLASTIC FILM , 63V 0.1UF J
C678 24073084 ELECTROLYTIC, 50V 4.7UF M 3A
C679 24667470 ELECTROLYTIC, 25V 47UF M 3A
C680 24109333 CERAMIC CHIP CK73B 25V 33000PFK
C681 24668471 ELECTROLYTIC, 35V 470UF M 3A
C682 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C683 24668471 ELECTROLYTIC, 35V 470UF M 3A
C684 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C686 24503041 PLASTIC FILM , 63V 0.1UF J
C704 24591822 PLASTIC FILM, 50V 8200PF J
C705 24232103 CERAMIC DISC, 50V F 0.01UF Z
C707 24794470 ELECTORLYTIC, 16V 47UF M
C712 24666470 ELECTORLYTIC, 16V 47UF M 3A
C713 24709100 ELECTROLYTIC, 200V 10UF M
C714 24436101 CERAMIC DISC, 50V SL 100PF J
C715 24214472 CERAMIC DISC, 500V B 4700PF K
C716 24436101 CERAMIC DISC, 50V SL 100PF J
C717 24214472 CERAMIC DISC, 500V B 4700PF K
C718 24766470 ELECTROLYTIC, 50V 47UF M
C719 24435560 CERAMIC DISC, 500V SL 56PF J
C720 24709100 ELECTROLYTIC, 200V 10UF M
C721 24797470 ELECTROLYTIC, 50V 47UF M
C726 24212102 CERAMIC DISC, 50V B 1000PF K
*C801 24503002 PLASTIC FILM, AC275V 0.22UF M
*C802 24503001 PLASTIC FILM, AC275V 0.1UF M
C805 24092623 CERAMIC DISC, 250V F 0.01UF Z
C806 24092623 CERAMIC DISC, 250V F 0.01UF Z
C807 24214103 CERAMIC DISC, 500V B 0.01UF K
C808 24214103 CERAMIC DISC, 500V B 0.01UF K
C810 24086062 ELECTROLYTIC, 200V 1000UF M 3F
C810A 23960136 ADHESIVE, SILICONE, TSE3843-W
*C811 24092583 CERAMIC DISC, AC250V E 2200PF M
*C812 24092583 CERAMIC DISC, AC250V E 2200PF M
*C815 24092591 CERAMIC DISC, AC250V B 470PF K
C817 24590102 PLASTIC FILM, 50V 1000PF J
C818 24539104 PLASTIC FILM, 50V 0.1UF J
C821 24794102 ELECTROLYTIC, 16V 1000UF M
C828 24503047 PLASTIC FILM, 63V 0.33UF J
C829 24794101 ELECTROLYTIC, 16V 100UF M
C830 24503047 PLASTIC FILM, 63V 0.33UF J
C831 24795470 ELECTROLYTIC, 25V 47UF M
C832 24794101 ELECTROLYTIC, 16V 100UF M
C833 24794101 ELECTROLYTIC, 16V 100UF M
C833 24503041 PLASTIC FILM , 63V 0.1UF J
C834 24503041 PLASTIC FILM , 63V 0.1UF J
C835 24214331 CERAMIC DISC, 500V B 330PF K
C835 24795470 ELECTROLYTIC, 25V 47UF M
C837 24503041 PLASTIC FILM , 63V 0.1UF J
C838 24617040 ELECTROLYTIC, 25V 1000UF M 3D
C839 24503047 PLASTIC FILM, 63V 0.33UF J
C840 24679220 ELECTROLYTIC, 250V 22UF M 3A
C841 24073043 ELECTROLYTIC, 16V 2200UF M 3A
C842 24503041 PLASTIC FILM , 63V 0.1UF J
C843 24092469 CERAMIC DISC, 2KV B 100PF K
C844 24793221 ELECTROLYTIC, 10V 220UF M
C845 24073082 ELECTROLYTIC, 50V 2.2UF M 3A
C847 24795470 ELECTROLYTIC, 25V 47UF M
C848 24796222 ELECTROLYTIC, 35V 2200UF M
C849 24794222 ELECTROLYTIC, 16V 2200UF M
C860 24214103 CERAMIC DISC, 500V B 0.01UF K
C862 24435221 CERAMIC DISC, 500V SL 220PF J
C863 24503041 PLASTIC FILM , 63V 0.1UF J
C864 24092347 CERAMIC DISC, 2KV R 1500PF K
C865 24092347 CERAMIC DISC, 2KV R 1500PF K
C866 24669010 ELECTROLYTIC, 50V 1UF M 3A
C867 24591682 PLASTIC FILM, 50V 6800PF J
C868 24668470 ELECTROLYTIC, 35V 47UF M 3A
C869 24678229 ELECTROLYTIC, 200V 2.2UF M 3A
C870 24503208 PLASTIC FILM, 400V 0.24UF J
C871 24092347 CERAMIC DISC, 2KV R 1500PF K
C873 24503045 PLASTIC FILM, 63V 0.22UF J
C874 24435221 CERAMIC DISC, 500V SL 220PF J
C876 24503041 PLASTIC FILM , 63V 0.1UF J
C877 24092347 CERAMIC DISC, 2KV R 1500PF K
C879 24212101 CERAMIC DISC, 50V B 100PF K
C881 24214471 CERAMIC DISC, 500V B 470PF K
C882 24214471 CERAMIC DISC, 500V B 470PF K
C884 24640019 ELECTROLYTIC, 160V 220UF M H-R
C885 24214471 CERAMIC DISC, 500V B 470PF K
C886 24214471 CERAMIC DISC, 500V B 470PF K
C889 24796332 ELECTROLYTIC, 35V 3300UF M
C891 24082227 PLASTIC FILM, 250V 0.068UF K
C893 24092333 CERAMIC DISC, 2KV 100PF K
C894 24092333 CERAMIC DISC, 2KV 100PF K
C895 24794222 ELECTROLYTIC, 16V 2200UF M
C896 24214471 CERAMIC DISC, 500V B 470PF K
C897 24796102 ELECTROLYTIC, 35V 1000UF M
C898 24503047 PLASTIC FILM, 63V 0.33UF J
C899 24214471 CERAMIC DISC, 500V B 470PF K
C902 24092353 CERAMIC DISC, 2KV 4700PF K
C904 24436471 CERAMIC DISC, 50V SL 470PF J
C905 24436391 CERAMIC DISC, 50V SL 390PF J
C907 24436561 CERAMIC DISC, 50V SL 560PF J
C909 24679220 ELECTROLYTIC, 250V 22UF M 3A
C910 24669478 ELECTROLYTIC, 50V 0.47UF M 3A
C911 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
C912 24073042 ELECTROLYTIC, 16V 1000UF M 3A

–18 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
C913 24666102 ELECTROLYTIC, 16V 1000UF M 3A
C914 24232103 CERAMIC DISC, 50V F 0.01UF Z
C918 24503041 PLASTIC FILM , 63V 0.1UF J
C919 24503041 PLASTIC FILM , 63V 0.1UF J
C920 24503041 PLASTIC FILM , 63V 0.1UF J
C921 24503041 PLASTIC FILM , 63V 0.1UF J
C922 24436390 CERAMIC DISC, 50V SL 39PFJ
C931 24214101 CERAMIC DISC, 500V B 100PF K
C2020 24109103 CERAMIC CHIP, 50V B 0.01UF K
C2102 24108100 CERAMIC CHIP, 50V SL 10PF D
C2103 24108100 CERAMIC CHIP, 50V SL 10PF D
C2104 24108100 CERAMIC CHIP, 50V SL 10PF D
C2110 24109103 CERAMIC CHIP, 50V B 0.01UF K
C2112 24109103 CERAMIC CHIP, 50V B 0.01UF K
C2113 24092731 CERAMIC CHIP, 16V B 1UF K
C3100 24667102 ELECTROLYTIC, 25V 1000UF M 3A
C3103 24105330 CERAMIC CHIP, 50V CH 33PF J
C3110 24092730 CERAMIC CHIP, 16V B 0.1UF K
C3150 24669229 ELECTROLYTIC, 50V 2.2UF M 3A
C4010 24109331 CERAMIC CHIP, 50V B 330PF K
C4401 24073039 ELECTROLYTIC, 16V 220UF M 3A
C4402 24109103 CERAMIC CHIP, 50V B 0.01UF K
C4403 24766010 ELECTROLYTIC, 50V 1UF M
C4404 24109103 CERAMIC CHIP, 50V B 0.01UF K
C4405 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C4406 24109103 CERAMIC CHIP, 50V B 0.01UF K
C4407 24763221 ELECTROLYTIC, 16V 220UF M
C4410 24109122 CERAMIC CHIP, 50V B 1200PF K
C4420 24109103 CERAMIC CHIP, 50V B 0.01UF K
C4427 24092538 CERAMIC CHIP, 10V F 1UF Z
C4460 24539224 PLASTIC FILM, 50V 0.22UF J
C4461 24539224 PLASTIC FILM, 50V 0.22UF J
C4690 24109103 CERAMIC CHIP, 50V B 0.01UF K
C4691 24109822 CERAMIC CHIP, 50V B 8200PF K
C4693 24591473 PLASTIC FILM, 50V 0.047UF J
C4699 24668222 ELECTROLYTIC, 35V 2200UF M 3A
C4811 24567474 PLASTIC FILM, 50V 0.47UF J
C4816 24669010 ELECTROLYTIC, 50V 1UF M 3A
C4819 24567684 PLASTIC FILM, 50V 0.68UF J
C5020 24109103 CERAMIC CHIP, 50V B 0.01UF K
C5030 24763101 ELECTROLYTIC, 16V 100UF M
C5080 24797010 ELECTROLYTIC, 50V 1UF M
C5090 24763101 ELECTROLYTIC, 16V 100UF M
CA04 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA05 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA06 24109392 CERAMIC CHIP, 50V B 3900PF K
CA07 24109392 CERAMIC CHIP, 50V B 3900PF K
CA09 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA15 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA22 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA23 24105101 CERAMIC CHIP, 50V CH 100PF J
CA25 24100103 CERAMIC CHIP, 50V F 0.01UF Z
CA27 24092538 CERAMIC CHIP, 10V F 1UF Z
CA28 24085970 ELECTROLYTIC, NONPOLAR, 16V 10UF M 7L
CA30 24085970 ELECTROLYTIC, NONPOLAR, 16V 10UF M 7L
CA31 24092538 CERAMIC CHIP, 10V F 1UF Z
CA33 24100103 CERAMIC CHIP, 50V F 0.01UF Z
CA34 24092538 CERAMIC CHIP, 10V F 1UF Z
CA37 24105101 CERAMIC CHIP, 50V CH 100PF J
CA38 24105101 CERAMIC CHIP, 50V CH 100PF J
CA39 24105101 CERAMIC CHIP, 50V CH 100PF J
CA42 24109392 CERAMIC CHIP, 50V B 3900PF K
CA45 24105471 CERAMIC CHIP, 50V CH 470PF J
CA46 24105471 CERAMIC CHIP, 50V CH 470PF J
CA49 24105101 CERAMIC CHIP, 50V CH 100PF J
CA52 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA54 24092730 CERAMIC CHIP, 16V B 0.1UF K
CA55 24105101 CERAMIC CHIP, 50V CH 100PF J
CA59 24105101 CERAMIC CHIP, 50V CH 100PF J
CA60 24105101 CERAMIC CHIP, 50V CH 100PF J
CA61 24666220 ELECTROLYTIC, 16V 22UF M 3A
CA68 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA69 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA71 24105331 CERAMIC CHIP, 50V CH 330PF J
CA72 24085970 ELECTROLYTIC, NONPOLAR, 16V 10UF M 7L
CA73 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA80 24503041 PLASTIC FILM , 63V 0.1UF J
CA81 24073015 ELECTROLYTIC, 10V 47UF M 3A
CA82 24503049 PLASTIC FILM, 63V 0.47UF J
CA95 24100103 CERAMIC CHIP, 50V F 0.01UF Z
CA251 24073015 ELECTROLYTIC, 10V 47UF M 3A
CA331 24073015 ELECTROLYTIC, 10V 47UF M 3A
CA371 24105820 CERAMIC CHIP, 50V CH 82PF J
CA381 24105820 CERAMIC CHIP, 50V CH 82PF J
CA391 24105820 CERAMIC CHIP, 50V CH 82PF J
CA611 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA701 24092538 CERAMIC CHIP, 10V F 1UF Z
CA705 24666100 ELECTROLYTIC, 10V 10UF M 3A
CB01 24794470 ELECTORLYTIC, 16V 47UF M
CB05 24666100 ELECTROLYTIC, 10V 10UF M 3A
CB13 24085970 ELECTROLYTIC, NONPOLAR, 16V 10UF M 7L
CB14 24105331 CERAMIC CHIP, 50V CH 330PF J
CB15 24794100 ELECTROLYTIC, 16V 10UF M
CB40 24092538 CERAMIC CHIP, 10V F 1UF Z
CB41 24109222 CERAMIC CHIP, 50V B 2200PF K
CB42 24105561 CERAMIC CHIP, 50V CH 560PF J
CB43 24109332 CERAMIC CHIP, 50V B 3300PF K
CB62 24105331 CERAMIC CHIP, 50V CH 330PF J
CB90 24109103 CERAMIC CHIP, 50V B 0.01UF K
CB91 24666100 ELECTROLYTIC, 10V 10UF M 3A
CC01 24109102 CERAMIC CHIP, 50V B 1000PF K
CC02 24109102 CERAMIC CHIP, 50V B 1000PF K
CC03 24109102 CERAMIC CHIP, 50V B 1000PF K
CC04 24109102 CERAMIC CHIP, 50V B 1000PF K
CC05 24109102 CERAMIC CHIP, 50V B 1000PF K
CC06 24109102 CERAMIC CHIP, 50V B 1000PF K
CC07 24109102 CERAMIC CHIP, 50V B 1000PF K
CC08 24109102 CERAMIC CHIP, 50V B 1000PF K
CC11 24109102 CERAMIC CHIP, 50V B 1000PF K
CC12 24109102 CERAMIC CHIP, 50V B 1000PF K
CC15 24109102 CERAMIC CHIP, 50V B 1000PF K
CC16 24109102 CERAMIC CHIP, 50V B 1000PF K
CI01 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI02 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI03 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI04 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI05 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI07 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI08 24797010 ELECTROLYTIC, 50V 1UF M
CI09 24105470 CERAMIC CHIP, 50V CH 47PF J
CI10 24105180 CERAMIC CHIP, 50V CH 18PF J
CI11 24105270 CERAMIC CHIP, 50V CH 27PF J
CI12 24797478 ELECTROLYTIC, 50V 0.47UF M
CI13 24109102 CERAMIC CHIP, 50V B 1000PF K
CI14 24105470 CERAMIC CHIP, 50V CH 47PF J
CI15 24105390 CERAMIC CHIP, 50V CH 39PF J
CI16 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI17 24092726 CERAMIC CHIP CK733B 16V 2,200,000PFK
CI18 24105181 CERAMIC CHIP, 50V CH 180PF J
CI21 24109103 CERAMIC CHIP, 50V B 0.01UF K

–19 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
CI23 24109103 CERAMIC CHIP, 50V B 0.01UF K
CI25 24105240 CERAMIC CHIP, 50V CH 24PF J
CI51 24797220 ELECTROLYTIC, 50V 22UF M
CI52 24794101 ELECTROLYTIC, 16V 100UF M
CI53 24797339 ELECTROLYTIO, 50V 3.3UF M
CJ01 24567104 PLASTIC FILM, 50V 0.1UF J
CJ02 24666470 ELECTORLYTIC, 16V 47UF M 3A
CJ03 24567104 PLASTIC FILM, 50V 0.1UF J
CJ04 24666470 ELECTORLYTIC, 16V 47UF M 3A
CJ05 24794101 ELECTROLYTIC, 16V 100UF M
CS01 24797229 ELECTROLYTIC, 50V 2.2UF M
CS02 24797229 ELECTROLYTIC, 50V 2.2UF M
CS03 24797229 ELECTROLYTIC, 50V 2.2UF M
CS04 24797229 ELECTROLYTIC, 50V 2.2UF M
CS05 24797229 ELECTROLYTIC, 50V 2.2UF M
CS06 24797229 ELECTROLYTIC, 50V 2.2UF M
CS07 24797229 ELECTROLYTIC, 50V 2.2UF M
CS08 24797229 ELECTROLYTIC, 50V 2.2UF M
CS09 24797229 ELECTROLYTIC, 50V 2.2UF M
CS10 24797229 ELECTROLYTIC, 50V 2.2UF M
CS11 24797229 ELECTROLYTIC, 50V 2.2UF M
CS12 24797229 ELECTROLYTIC, 50V 2.2UF M
CS13 24794100 ELECTROLYTIC, 16V 10UF M
CS14 24794100 ELECTROLYTIC, 16V 10UF M
CS15 24797229 ELECTROLYTIC, 50V 2.2UF M
CS16 24797229 ELECTROLYTIC, 50V 2.2UF M
CS19 24797479 ELECTROLYTIC, 50V 4.7UF M
CS20 24797478 ELECTROLYTIC, 50V 0.47UF M
CS21 24797479 ELECTROLYTIC, 50V 4.7UF M
CS22 24797479 ELECTROLYTIC, 50V 4.7UF M
CS24 24797229 ELECTROLYTIC, 50V 2.2UF M
CS25 24794470 ELECTORLYTIC, 16V 47UF M
CS26 24085944 ELECTROLYTIC, NONPOLAR, 50V
2.2UF M 11L
CS27 24085944 ELECTROLYTIC, NONPOLAR, 50V
2.2UF M 11L
CS30 24797229 ELECTROLYTIC, 50V 2.2UF M
CS31 24797229 ELECTROLYTIC, 50V 2.2UF M
CS115 24797010 ELECTROLYTIC, 50V 1UF M
CS116 24797010 ELECTROLYTIC, 50V 1UF M
CS119 24797010 ELECTROLYTIC, 50V 1UF M
CS120 24109103 CERAMIC CHIP, 50V B 0.01UF K
CS121 24797010 ELECTROLYTIC, 50V 1UF M
CS122 24797101 ELECTROLYTIC, 50V 100UF M
CS123 24073089 ELECTROLYTIC, 50V 47UF M 3A
CS124 24797229 ELECTROLYTIC, 50V 2.2UF M
CS125 24590102 PLASTIC FILM, 50V 1000PF J
CV01 24092621 CERAMIC CHIP, 10V B 1UF K
CV02 24092621 CERAMIC CHIP, 10V B 1UF K
CV03 24092621 CERAMIC CHIP, 10V B 1UF K
CV04 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV05 24092621 CERAMIC CHIP, 10V B 1UF K
CV06 24092621 CERAMIC CHIP, 10V B 1UF K
CV07 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV08 24794101 ELECTROLYTIC, 16V 100UF M
CV09 24092621 CERAMIC CHIP, 10V B 1UF K
CV10 24794100 ELECTROLYTIC, 16V 10UF M
CV11 24092621 CERAMIC CHIP, 10V B 1UF K
CV12 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV13 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV14 24092621 CERAMIC CHIP, 10V B 1UF K
CV15 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV23 24794101 ELECTROLYTIC, 16V 100UF M
CV24 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV38 24109102 CERAMIC CHIP, 50V B 1000PF K
CV39 24109102 CERAMIC CHIP, 50V B 1000PF K
CV40 24794101 ELECTROLYTIC, 16V 100UF M
CV42 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV45 24092621 CERAMIC CHIP, 10V B 1UF K
CV46 24092621 CERAMIC CHIP, 10V B 1UF K
CV47 24092621 CERAMIC CHIP, 10V B 1UF K
CV64 24794471 ELECTROLYTIC, 16V 470UF M
CV65 24794101 ELECTROLYTIC, 16V 100UF M
CV66 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV67 24794100 ELECTROLYTIC, 16V 10UF M
CV68 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CV100 24794100 ELECTROLYTIC, 16V 10UF M
CV101 24232103 CERAMIC DISC, 50V F 0.01UF Z
CV102 24232103 CERAMIC DISC, 50V F 0.01UF Z
CV238 24109103 CERAMIC CHIP, 50V B 0.01UF K
CV244 24109103 CERAMIC CHIP, 50V B 0.01UF K
CV245 24092441 CERAMIC CHIP, 16V F 1UF Z
CV246 24092441 CERAMIC CHIP, 16V F 1UF Z
CV247 24092441 CERAMIC CHIP, 16V F 1UF Z
CV248 24109103 CERAMIC CHIP, 50V B 0.01UF K
CV249 24092441 CERAMIC CHIP, 16V F 1UF Z
CV250 24092441 CERAMIC CHIP, 16V F 1UF Z
CV251 24092441 CERAMIC CHIP, 16V F 1UF Z
CV252 24109103 CERAMIC CHIP, 50V B 0.01UF K
CV253 24092441 CERAMIC CHIP, 16V F 1UF Z
CV254 24092441 CERAMIC CHIP, 16V F 1UF Z
CV255 24092441 CERAMIC CHIP, 16V F 1UF Z
CV256 24109103 CERAMIC CHIP, 50V B 0.01UF K
CV257 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
CV258 24666471 ELECTROLYTIC, 16V 470UF M 3A
CV259 24109103 CERAMIC CHIP, 50V B 0.01UF K
CV261 24109103 CERAMIC CHIP, 50V B 0.01UF K
CV263 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY101 24092441 CERAMIC CHIP, 16V F 1UF Z
CY102 24794101 ELECTROLYTIC, 16V 100UF M
CY103 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CY104 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY105 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY106 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY107 24794100 ELECTROLYTIC, 16V 10UF M
CY108 24100104 CERAMIC CHIP, 25V F 0.1UF Z
CY109 24105101 CERAMIC CHIP, 50V CH 100PF J
CY111 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY112 24105181 CERAMIC CHIP, 50V CH 180PF J
CY113 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY114 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY115 24105390 CERAMIC CHIP, 50V CH 39PF J
CY116 24105470 CERAMIC CHIP, 50V CH 47PF J
CY117 24105180 CERAMIC CHIP, 50V CH 18PF J
CY501 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY502 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY504 24109222 CERAMIC CHIP, 50V B 2200PF K
CY505 24105120 CERAMIC CHIP, 50V CH 12PF J
CY506 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY508 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY512 24092463 CERAMIC CHIP, 16V B 0.22UF K
CY513 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY514 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY515 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY516 24109103 CERAMIC CHIP, 50V B 0.01UF K
CY517 24092731 CERAMIC CHIP, 16V B 1UF K
CY524 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY525 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY526 24092730 CERAMIC CHIP, 16V B 0.1UF K
CY538 24794222 ELECTROLYTIC, 16V 2200UF M

–20 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
CY539 24794470 ELECTORLYTIC, 16V 47UF M
CY582 24105101 CERAMIC CHIP, 50V CH 100PF J
RESISTORS
R101 24553223 OXIDE METAL FILM, 1W 22K OHM J
R150 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R151 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J
R152 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R173 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R174 24011273 CHIP, METAL FILM, 1/20W 27K OHM J
R217 24366103 CARBON FILM, 1/6W 10K OHM J
R218 24366333 CARBON FILM, 1/6W 33K OHM J
R227 24366273 CARBON FILM, 1/6W 27K OHM J
R228 24366562 CARBON FILM, 1/6W 5.6K OHM J
R232 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J
R245 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R264 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
R265 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
R266 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
R286 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
R287 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
R288 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
R303 24321109 OXIDE METAL FILM, 1/2W 1 OHM J
R305 24322918 OXIDE METAL FILM, 1W 0.91 OHM J
R309 24383271 OXIDE METAL FILM, 2W 270 OHM J
R315 24011274 CHIP, METAL FILM, 1/20W 270K OHM J
R316 24011823 CHIP, METAL FILM, 1/20W 82K OHM J
R318 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R319 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R320 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R321 24011224 CHIP, METAL FILM, 1/20W 220K OHM J
R322 24011274 CHIP, METAL FILM, 1/20W 270K OHM J
R324 24011394 CHIP, METAL FILM, 1/20W 390K OHM J
R326 24366102 CARBON FILM, 1/6W 1K OHM J
*R327 24338159 OXIDE METAL FILM, 1W 1.5 OHM J
*R328 24338159 OXIDE METAL FILM, 1W 1.5 OHM J
R329 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R331 24872823 CHIP, METAL FILM, 1/16W 82K OHM J
R332 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R333 24552103 OXIDE METAL FILM, 1/2W 10K OHM J
R334 24552103 OXIDE METAL FILM, 1/2W 10K OHM J
R336 24000824 CHIP JUMPER, 2125TYPE
R360 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R361 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R362 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R363 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J
R365 24011331 CHIP, METAL FILM, 1/20W 330 OHM J
R366 24011911 CHIP, METAL FILM, 1/20W 910 OHM J
R367 24011242 CHIP, METAL FILM, 1/20W 2.4K OHM J
R370 24872103 CHIP, METAL FILM, 1/16W 10K OHM J
R371 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R372 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R373 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R374 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R376 24011471 CHIP, METAL FILM, 1/20W 470 OHM J
R377 24366220 CARBON FILM, 1/6W 22 OHM J
R401 24011361 CHIP, METAL FILM, 1/20W 360 OHM J
R402 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R403 24011272 CHIP, METAL FILM, 1/20W 2.7K OHM J
R405 24553682 OXIDE METAL FILM, 1W 6.8K OHM J
R409 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R411 24366101 CARBON FILM, 1/6W 100 OHM J
R412 24323228 OXIDE METAL FILM, 2W 0.22 OHM J
R413 24011182 CHIP, METAL FILM, 1/20W 1.8K OHM J
R415 24383271 OXIDE METAL FILM, 2W 270 OHM J
R416 24383680 OXIDE METAL FILM, 2W 68 OHM J
R422 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J
R423 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R424 24011272 CHIP, METAL FILM, 1/20W 2.7K OHM J
R425 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R426 24366222 CARBON FILM, 1/6W 2.2K OHM J
R429 24553100 OXIDE METAL FILM, 1W 10 OHM J
R431 24546159 FUSIBLE, 1/2W 1.5 OHM J
R432 24552151 OXIDE METAL FILM, 1/2W 150 OHM J
R435 24327224 METAL FILM, 1/4W 220K OHM F
R441 24383331 OXIDE METAL FILM, 2W 330 OHM J
*R448 24321338 OXIDE METAL FILM, 1/2W 0.33 OHM J
R460 24366103 CARBON FILM, 1/6W 10K OHM J
R461 24366102 CARBON FILM, 1/6W 1K OHM J
R462 24366562 CARBON FILM, 1/6W 5.6K OHM J
R463 24366473 CARBON FILM, 1/6W 47K OHM J
R464 24366221 CARBON FILM, 1/6W 220 OHM J
*R465 24011271 CHIP, METAL FILM, 1/20W 270 OHM J
R466 24383220 OXIDE METAL FILM, 2W 22 OHM J
R467 24383220 OXIDE METAL FILM, 2W 22 OHM J
*R468 24000634 METAL FILM, 1/4W 11K OHM F
R469 24366823 CARBON FILM, 1/6W 82K OHM J
*R470 24339518 OXIDE METAL FILM, 2W 0.51 OHM J
R471 24381271 OXIDE METAL FILM, 1/2W 270 OHM J
R472 24381270 OXIDE METAL FILM, 1/2W 27 OHM J
R473 24000247 METAL FILM, 1/4W 39K OHM F
R474 24872472 CHIP, METAL FILM, 1/16W 4.7K OHM J
R475 24872912 CHIP, METAL FILM, 1/16W 9.1K OHM J
R476 24000221 METAL FILM, 1/4W 20K OHM F
R477 24366102 CARBON FILM, 1/6W 1K OHM J
*R478 24338109 OXIDE METAL FILM, 1W 1 OHM J
R479 24381131 OXIDE METAL FILM, 1/2W 130 OHM J
R481 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R482 24011182 CHIP, METAL FILM, 1/20W 1.8K OHM J
R483 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R486 24011622 CHIP, METAL FILM, 1/20W 6.2K OHM J
R487 24011474 CHIP, METAL FILM, 1/20W 470K OHM J
R488 24011154 CHIP, METAL FILM, 1/20W 150K OHM J
R489 24011563 CHIP, METAL FILM, 1/20W 56K OHM J
R494 24366184 CARBON FILM, 1/6W 18OK OHM J
R502 24000445 CHIP JUMPER, 1608TYPE
R513 24011104 CHIP, METAL FILM, 1/20W 100K OHM J
R514 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R515 24871103 CHIP, METAL FILM, 1/8W 10K OHM J
R520 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R521 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R526 24000445 CHIP JUMPER, 1608TYPE
R547 24011680 CHIP, METAL FILM, 1/20W 68 OHM J
R548 24011680 CHIP, METAL FILM, 1/20W 68 OHM J
R553 24011680 CHIP, METAL FILM, 1/20W 68 OHM J
R560 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R561 24552181 OXIDE METAL FILM, 1/2W 180 OHM J
R562 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R563 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J
R564 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R565 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R566 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R567 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R568 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R569 24011224 CHIP, METAL FILM, 1/20W 220K OHM J
R570 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R610 24871222 CHIP, METAL FILM, 1/8W 2.2K OHM J
R611 24871222 CHIP, METAL FILM, 1/8W 2.2K OHM J
R612 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R613 24871222 CHIP, METAL FILM, 1/8W 2.2K OHM J
