owner’s manual
colour television
TOSHIBA
67Z27B

2
SAFETY
For your safety
This equipment has been designed and manufactured to meet international safety standards but, like any electrical
equipment, care must be taken if you are to obtain the best results and safety is to be assured. So, please read the
points below for your own safety. They are of a general nature, intended to help you with all your electronic
consumer products and some points may not apply to the goods you have just purchased.
DON'T remove any fixed cover as this may expose
dangerous voltages.
DON'T obstruct the ventilation openings of the
equipment with items such as newspapers,
tablecloths, curtains, etc. Overheating will cause
damage and shorten the life of the equipment.
DON'T allow electrical equipment to be exposed to
dripping or splashing or objects filled with liquids,
such as vases, to be placed on the equipment.
DON’T place hot objects or naked flame sources,
such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and
lead to fires.
DON'T use makeshift stands and NEVER fix legs with
wood screws. To ensure complete safety, always fit the
manufacturer’s approved stand or legs with the fixings
provided according to the instructions.
DON'T listen to headphones at high volume, as such
use can permanently damage your hearing.
DON'T leave equipment switched on when it is
unattended, unless it is specifically stated that it is
designed for unattended operation or has a standby
mode. Switch off using the switch on the equipment
and make sure your family know how to do this.
Special arrangements may need to be made for
infirm or handicapped people.
DON'T continue to operate the equipment if you are
in any doubt about it working normally, or it is
damaged in any way – switch off, withdraw the mains
plug and consult your dealer.
ABOVE ALL – NEVER let anyone, especially
children, push anything into holes, slots or any
other openings in the case – this could result in a
fatal electric shock.
NEVER guess or take chances with electrical
equipment of any kind – it is better to be safe
than sorry.
Leave at least 10cm clearance around the television to
allow adequate ventilation. This will prevent the TV
from overheating and consequential possible damage
to the TV. Dusty places should also be avoided.
Damage may occur if you leave the TV in direct
sunlight or near a heater. Avoid places subject to
extremely high temperatures or humidity, or locations
where the temperature is likely to fall below 5°C (41°F).
The mains supply required for this equipment is 230v
AC 50Hz. Never connect to a DC supply or any other
power source. DO ensure that the TV is not standing
on the mains lead. DO NOT cut off the mains plug
from this equipment, this incorporates a special Radio
Interference Filter, the removal of which will impair its
performance. In the UK, the fuse fitted in this plug is
13A, and is approved by ASTA or BSI to BS1362. It
should only be replaced by a correctly rated and
approved type and the fuse cover must be
refitted. IF IN DOUBT PLEASE CONSULT A
COMPETENT ELECTRICIAN.
DO read the operating instructions before you
attempt to use the equipment.
DO ensure that all electrical connections (including
the mains plug, extension leads and inter-connections
between pieces of equipment) are properly made and
in accordance with the manufacturers’ instructions.
Switch off and withdraw the mains plug before
making or changing connections.
DO consult your dealer if you are ever in doubt about
the installation, operation or safety of your equipment.
DO be careful with glass panels or doors
on equipment.
Air Circulation… Do not…
Heat Damage…
Mains Supply…
Do…

Contents
TELETEXT
FOR YOUR GUIDANCE
OTHER INFORMATION
SAFETY
CONNECTING OTHER EQUIPMENT
SETTING UP
SPECIAL SOUND FEATURES
USING YOUR TV
ADDITIONAL FEATURES
3
For your safety –some DOs and DON’Ts for you to be aware of 2
Your new television’s remote control – an at-a-glance guide 4
Connecting the speakers 5
Connecting and turning on your new TV 6
Choosing the language 7
Auto tune 8
Manually tuning your TV – an alternative to Auto tune 9
Swapping programme positions and programme skip 10
General controls – selecting and changing programme position, sound control, bass/treble/balance 11
Picture adjustments – picture preferences, NR (noise reduction), blue screen 12
Widescreen viewing – Super Live, Cinema, Subtitle, Wide, 4:3 13
Picture size/position, Widescreen Signalling 14
Dolby Pro Logic – Surround Test Mode 15
Digital Surround Processor – Surround Sound features 16
Teletext – setting up 17
Teletext – Auto and List modes 18
Teletext – control buttons 19
Timer, time display and panel lock 20
Stereo and bilingual transmissions 20
AV connections and input selection – input and output sockets for connected equipment 21
Front connections and controls 22
Back connections 23
The Menus – a display of the main on-screen menus for your reference 24
Questions and Answers, care/disposal information 25
Notes – a page for you to record your own information 27
Index, Specifications and Accessories – information on your television 28

SETTING UP
4
Carefully slide the back cover downwards to reveal the battery compartment and make
sure you insert the batteries the right way round.
All Toshiba batteries are Cadmium and Mercury free. Suitable battery types for
this remote are R03 or AAA.
Do not throw your old batteries into a fire, dispose of them in a designated disposal
area. Do not combine a used, old battery with a new one or mix battery types.
The performance of the remote control will deteriorate beyond a distance of
five metres or outside an angle of 30 degrees from the centre of the TV.
Simple, at-a-glance reference of your remote control’s buttons…
For On/Standby mode
To display teletext
Selectable picture preferences
To mute the sound
To exit Menus
Bass Boost
To alter the volume
Surround Sound
Teletext control buttons
To change programme positions
and teletext pages
To bring up on-screen information and
for the teletext initial/index function
Widescreen format
selection
To select input from external sources
To change programme positions,
up and down
To alter the volume
When using menus the arrows move the
cursor on the screen up, down, left or
right. ENTER to confirm your selection.
Stereo/bilingual reception
On-screen Menus
Fbutton – use with the colour buttons
to select additional teletext features
and with the VTR buttons for a
TOSHIBA DVD player.
Number buttons
1 or 2 digit
programme selection
Please see
page 24 for
the main
on-screen
Menus
Your new television’s remote control
… For quick reference
to topics, please see
the INDEX at the end of
this manual.
These buttons will operate your
TOSHIBA VIDEO and DVD.
For the DVD you must press the
F button at the same time…
to switch ON/OFF, press
to STOP, press
to PLAY, press
to PAUSE, press
to FAST FORWARD/SKIP, press
to REWIND/SKIP, press
The batteries... and the effective range of the remote…
☛
It also increases the speed of most functions.

WOOFER
EXT INT
SURROUND
8
K
When connecting external speakers always make sure that the power is OFF.
5
SETTING UP
Connecting the speakers
When connecting external Hi-Fi speakers of
your choice, they must be 8 ohm,10W
minimum. These speakers should be
positioned either side of the TV and will
deliver the left and right sound. Simply press
the connector and insert the cable. You must
now set the switch to EXT as shown.
Main Speakers
Active Super Woofer
TV
WARNING: do not
attempt to
share
external speakers
with your Hi-Fi as
serious damage
may occur.
!
Always make sure
that the lead with the
stripe (or raised edge) is
connected to the RED
terminal and the other
(smooth) lead is
connected to the
BLACK terminal.
!
Surround Speakers
In order to enjoy the sensations of Surround
Sound TV it is necessary to connect the two
Surround Speakers. These speakers and cables
are included with the TV and should be sited
in line with the normal viewing position.
To connect the Surround Speakers simply press
the connector and insert the cable.
These are suggested
positions only.
Place your speakers to
suit and adjust the
balance as necessary.
Main
Speaker Main Speaker
Surround
Speaker Surround
Speaker
☛
Don’t
forget to set
the switch
to EXT.
☛
Don’t
forget to set
the switch
to EXT.
☛

Connect the aerial to the socket on the rear of the television. If you use a Set Top Box and/or a video recorder it is essential that the
aerial cable is connected through the Set Top Box and/or through the video recorder to the television.
DO NOT CONNECT SCART LEADS UNTIL THE TELEVISION IS FULLY TUNED.
EXT INT
K
KMAIN (8 )
SURROUND
(8 )
(AUDIO/VIDEO) (AUDIO/VIDEO)
PB/CB
PR/CR
Y
COMPONENT
VIDEO INPUT
AUDIO
EXT INT
K
KMAIN (8 )
SURROUND
(8 )
(AUDIO/VIDEO) (AUDIO/VIDEO)
PB/CB
PR/CR
Y
COMPONENT
VIDEO INPUT
AUDIO
To conserve energy it is best to turn your TV off and not to leave it in Standby, unless the timer has been set.
6
SETTING UP
The TV back connections…
…and switching your new TV on…
On the front of the TV…
If the red power-on light is unlit, press the POWER button on the front of
the TV to switch the set on and then press a number button on the remote
control to see the screen.
…and with the remote control:
Press the Standby Button i:
This allows you to put the set into
standby mode when leaving the TV
unattended for short periods of time. To
return to TV mode press the ibutton,
or any of the numbered buttons on the
remote control. The picture may take
a few seconds to appear. To conserve energy, do not leave the
set in Standby for long periods of time.
Aerial
Video Recorder
SET TOP BOX*
Aerial Cable Aerial Cable
Connecting and turning on
your new TV
*a SET TOP BOX could be:
Digital Satellite, Analogue
Satellite, or any other
compatible decoder.
ORANGE = Bilingual transmission
being received
GREEN = Stereo transmission being received
RED = Power On
GREEN = On Timer is set
the back of your TV
☛

7
Choosing the language
SETTING UP
The on-screen menus can be viewed in different languages.
Choosing your language
Press the MENU button, and use the
Rbutton to select FEATURE MENU
from the top bar.
Now repeatedly press the Qbutton until
Language is highlighted in the FEATURE
MENU’s options.
Press the SorRbutton to view the language
options available. As you view each language,
the wording on the menus will automatically
change for you.
To select your chosen language, simply view it
on the screen and then press the EXIT button.
All the on-screen displays will now all appear
in your chosen language.
Now you can run Auto tune.…
Which is explained on the next page…
P
P
VTR/DVD
VTR/DVD
1
2
3
4
FEATURE MENU
EXIT : To exit
FEATURE MENU



AV connection
Picture size/position
Teletext
Surround set up
Language ENGLISH
Panel lock OFF
WSS ON






AUTO TUNE
Prog. Station Channel
1 BBC1 22
BBC1 39
ENTER : To store
EXIT : To exit
8
Before running Auto tune turn on your Set Top Box and tune to a main channel. Also turn on the video
recorder and set it to Standby – this will enable your television to identify and allocate the necessary
programme positions.
You can now run Auto tune…
Auto tune
SETTING UP
P
P
1
2
3
SEARCHING
Channel : 21
Station : – – – – – – –
AUTO TUNE
    
Press the MENU button, and then the Sor R
button to select the SET UP option from the top bar.
Press the Qbutton to highlight Auto tune and R
to select.
You will be informed that all previous settings will
be lost.
Press the ENTER button on the remote control to
begin the search for available stations.
xxxxxxxxxx
will flash and each station found will
appear in succession on the screen.
Manual fine tuning should not
require alteration unless you
experience interference or a weak
signal – see
Questions and
Answers
, starting on page 25.
EXIT : To exit
Allow the
television to
complete the
search.
SET UP


Auto tune
Manual tune
Programme swap
Manual fine tuning
Programme skip OFF
EXIT : To exit

YOU MAY NOW CONNECT YOUR SCART LEADS
see page 23...
!
If no station name
appears, it can be
put in manually,
see Step 5 of
Manual Tune.
…Your TV may
display different
Channel numbers…
☛
SET UP

4
5
If more than one is shown press the Qor
Pbutton to highlight and view the choices.
Choose the best picture and sound.
Press the ENTER button to store BBC1 on
programme position 1.
Note: You can only choose one BBC1 station
at this stage.
Position 2 will appear showing the BBC2 choices.
Repeat the steps above to allocate the
required signal.
Repeat for all the remaining programme positions
you wish to tune including a Set Top Box, if
connected. If there are no signals for any
programme positions, simply press the ENTER
button to move on to the next one.
Press EXIT to finish and one of the numbered
buttons to view TV.
When the search is complete, the screen will
display a list of all the available BBC1 signals.
6
7

9
As an alternative to Auto tune, you can tune-in your Toshiba television manually using Manual tune.
For example, if you are unable to connect the TV to your video with a Scart lead.
Manual tune
Manually tuning your TV
SETTING UP
P
P
MANUAL TUNE

Back
Search
>>>
Programme no. 01
Channel 24
Station -------
RRR (Search) will flash and the television will
show the channel numbers whilst the search is
progressing.
On finding a station it will show on the television.
If you do not wish to store it, press the Rbutton to
continue the search. If you do wish to store it
press Qto highlight the Programme no.and if
necessary, press Sor Rto select the number you
wish to store it on (we suggest 0 for the video
recorder).
Press Qto highlight Station and Sor Rto select
a Station name if required.
Press ENTER if you wish to store the
broadcast displayed.
To repeat the process, highlight Search and press
the Rbutton to look for the next station.
Press EXIT when you have finished.
Press the Rbutton twice to start the search.
1
2
3
4
5
6
7
If you cannot connect your
television to the video recorder using a
Scart lead you will need to allocate a
programme position on the television
for the video recorder. Insert a pre-
recorded tape and press PLAY on the
remote control, then Manual tune…
From the top menu bar select SET UP and with
the Qbutton select Manual tune.
ENTER : To store
EXIT : To exit








☛
This TV has direct channel entry if
the channel numbers are known.
Select the
Manual tune
screen.
Enter the required programme position, then
enter the appropriate channel number.
Select the station name and press
ENTER
to store.
SET UP


Auto tune
Manual tune
Programme swap
Manual fine tuning
Programme skip OFF
EXIT : To exit


P
LEASE
N
OTE

P
P
10
SETTING UP
Swapping programme positions and
programme skip
After tuning if you want to swap the position of certain programmes you can. Program swap is an easy way of storing
each channel on the programme position of your choice. Program skip stops the viewing of certain channels.
To swap programme positions
Press the MENU button and then the Sor R
button to select the SET UP option from the top
bar.
Press Qto highlight Programme swap and Rto
select.
The list of stations is now showing. With
the Qor Pbutton highlight the station you want
to move and press ENTER to select. The station you
are moving will show on the bar at the bottom.
With the Qor Pbutton again, move through
the list to your preferred position.
Press ENTER again. You will see that the
programme positions have now been swapped.
Repeat as necessary and then press EXIT.
Skipping programmes
To prevent certain programmes from being viewed, for
example, a certain film by your children whilst your are
out for the evening, you can skip the programme
position and take the remote control with you. The
television will still function as normal using the controls
on the front of it, but the set will not show the skipped
programme position.
Using the remote, select the channel to
be skipped.
Select theSET UP menu, and then
Programme skip.
Press Rto turn Programme skip ON.
1
2
3
3
4
5
6
2
1
5
6
4

Programme swap
Manual fine tuning
Programme skip ON
ENTER : To swap EXIT : To exit
Prog. Station Channel
1 BBC1 22
2 BBC2 28
3 ITV 25
4 CH4 32
4 CH4 32




SET UP
Then press the EXIT button.
It is necessary to repeat from step 1 for all the
channels to be skipped. The skipped channels
cannot now be selected by the ePfbuttons or
by the controls on the front of the TV but can still
be accessed by the number buttons on the
remote control.
To turn Programme skip OFF, repeat the
procedure on the chosen channel.
An
*
on the screen indicates
a skipped programme position.
…Remember… each channel
has to be INDIVIDUALLY
selected and set with
Programme skip ON or OFF.
SET UP


Auto tune
Manual tune
Programme swap
Manual fine tuning
Programme skip OFF
EXIT : To exit

PROGRAMME SWAP


11
USING YOUR TV
Volume
Press the –j+
button or the Sand Rbuttons to adjust the volume.
Sound Mute
Press the
kbutton to turn the sound off.
Press it again and the sound will return.
Bass Boost – to enhance the depth of sound
Press the nbutton repeatedly to turn the Bass boost
on and off. Press the Sor Rbutton to adjust the effect.
Volume 00
Enter the desired programme position number using the
numbered buttons on the remote control.
For programme positions below 10, press the -/-- button
to select —on the screen then enter the desired
programme position number.
For programme positions above 9, press the -/-- button to
select — — then enter the desired two digit programme
position number.
You can also change the programme position by using the
ePfbutton or the Qand Pbuttons.
The programme position will be displayed on
the screen with the Stereo/Mono indicator,
described on page 20.
SOUND
Bass +01
Treble 00
Balance 00






Press the MENU button on the remote control, and the
Sor Rbutton to select the SOUND option from the top
bar.
Press the Qbutton to highlight Bass, Treble or Balance
from the SOUND menu and then the Sor Rbutton to
change the setting.
EXIT : To exit
Pressing the F
button at the same
time will speed up
most functions…
Selecting and changing programme position
Sound control
When an active
Super Woofer is
connected the
n
button will
control it.
Bass, treble and balance adjustments
2
BBC2
Stereo
P
P
VTR/DVD
VTR/DVD
General controls

Blue Screen
NR – Noise Reduction
12
USING YOUR TV
Picture adjustments
This television offers you the choice of personalising the picture style to suit your own preferences.
P
P
1
2
3
NR enables you to ‘soften’ thescreen
representation of a weak signal.
Select NR from the PICTURE
menu. Select between ON
and OFF to obtain the best picture.
The differences may not always be noticeable.
By pressing the mbutton you can view the
different picture styles available:
Picture mode-1 to 3for preset options and,
Picture mode-M is for your own settings:
So, to set your own, choose PICTURE from the
top menu bar.
1






EXIT : To exit
Picture preferences
Within this PICTUREmenu
you have the options to
adjust the Contrast,
Brightness, Colour, Tint
and Sharpness.
Using the Sor Rbuttons
alter to suit your taste.
1
When no signal is being received, the TV will
switch the screen to blue. After 20 minutes the TV
will switch to Standby mode.
In the FEATURE MENU select
Blue screen ON or OFF.
Contrast 100
Brightness 50
Colour 50
Tint 00
Sharpness 00
NR ON



…press the Qbutton to
access the second part of
the FEATURE MENU…
☛
EXIT : To exit
FEATURE MENU



AV connection
Picture size/position
Teletext
Surround set up
Language ENGLISH
Panel lock OFF
WSS ON




EXIT : To exit
Blue screen ON
The Tint can only be
adjusted on a signal
from an NTSC video
recorder or DVD player
when the television is in
AUTO or NTSC
colour mode.

13
USING YOUR TV
P
SUPER LIVE
SUPER LIVE
Press the SIZE
button repeatedly
to view the
options available.
This setting will enlarge the image
to fit the screen by stretching
the image horizontally, holding
the correct proportions at the
centre of the image.
Widescreen viewing
CINEMA
Experiment with
them all until you
find a style that
suits you…
CINEMA
When watching ‘letterbox format’
films/video tapes, this setting will
eliminate or reduce the black bars
at the top and bottom of the screen
by zooming in and selecting the
image without distortion.
WIDE
SUBTITLE
4:3
SUBTITLE
SUBTITLE
WIDE
4:3
When subtitles are included on a
letterbox format broadcast, this
setting will raise the picture to
ensure that all the text is
displayed.
Use this setting when watching a widescreen
DVD, widescreen video tape or a 16:9
broadcast (when available). Due to the range of
widescreen formats (16:9, 14:9, 20:9 etc.) you
may see black bars on the top and bottom of
the screen.
Use this setting to view a true 4:3 broadcast.
Whenever the
MENU
button is
pressed the picture size setting may
change while the menus are ON the
screen. This is to ensure the menus do not
overlap the edges of the viewable area.
!
This set is capable of showing broadcasts in a number
of formats. Depending on the type of broadcast being
transmitted you may select between SUPER LIVE,
CINEMA, SUBTITLE, WIDE and 4:3.

WSS – Widescreen Signalling
14
USING YOUR TV
Picture size/position and Widescreen Signalling
Adjustment to the horizontal and vertical position and height of the picture may be made to suit your viewing
preferences.
Picture size/position settings
Press the MENU button, and use theRbutton to
select FEATURE MENU.
Now repeatedly press the Qbutton until Picture
size/position is highlighted.
1
2
3
The options available to you when
in thePICTURE SIZE/POSITION screen
will vary depending upon the
widescreen format you have previously
chosen, as detailed on page 13.
!
Press the Rbutton to view the options available
and adjust the settings, depending upon the
picture type (SUPER LIVE, CINEMA etc...)
selected previously.
In SUPER LIVE:
2
3
1
FEATURE MENU
When this TV receives a true Widescreen picture and WSS is ON, it will automatically be displayed in Widescreen
format, irrespective of the TV’s previous setting.
Press the MENU button, and use theRbutton
to select the FEATURE MENU.
Use Qto move down to WSS.
Using the SorRbutton turn WSS ON
or OFF.
PICTURE SIZE/POSITION
EXIT : To exit
Back
Horizontal position
Horizontal width
Vertical position
Vertical height


EXIT : To exit
FEATURE MENU



AV connection
Picture size/position
Teletext
Surround set up
Language ENGLISH
Panel lock OFF
WSS ON


EXIT : To exit
FEATURE MENU





AV connection
Picture size/position
Teletext
Surround set up
Language ENGLISH
Panel lock OFF
WSS ON
FEATURE MENU

15
Dolby Pro Logic
Surround Test Mode
Dolby Pro Logic
Press the Mbutton to bring up the
SURROUND menu. With Dolby Pro Logic
selected, EXIT and go to the FEATURE MENU
to select SURROUND TEST from the
Surround set up menu.
Whilst each speaker is highlighted, use the
Sand Rbuttons to adjust.
1
2
Inserting the headphone jack will mute the sound from all
speakers and deliver a normal stereo left and right signal.
There are no Dolby Pro Logic or Surround effects available
when using headphones.
P
P
From the FEATURE MENU select Surround
set up.
Using the Sor Rbutton turn Rear speaker to
YES.
Sit in your usual viewing position.
Dolby Pro Logic – available on many TV broadcasts in addition to video tapes. Uses a combination of 4
speaker channels – front-left, centre, front-right and rear. If external front speakers are not connected, these
channels will be delivered through the speakers in the TV.
1
2
YES in the Rear
speaker option must
be chosen for the Test
Mode below to function…
If you cannot
connect rear speakers –
select Dolby 3 Stereo.
Remember… Check that Rear speakers are
connected and the Rear speaker option in the
Surround set up menu is set to YES.
!
SPECIAL SOUND FEATURES
The TEST will play a ‘white noise’ through
each speaker in turn. The display will show
you which speaker is in play, adjustments
may be made whilst it is highlighted.
EXIT : To exit
Left
Centre
Right
Rear


61


61
!
!
!
☛
EXIT : To exit
SURROUND TEST
SURROUND SET UP



Back
Rear speaker YES
Surround test

16
Digital Surround Processor
Please note: Hall, Theatre, Disco and Stadium effects are only available on a stereo signal. Pseudo
surround works on both mono and stereo signals. The Digital Surround mode works equally well with
either internal or external front speakers connected. All of the Digital surround modes are adjustable, the
method of adjustment being described below, is the same for all the Digital Surround effects.
Surround Sound Features
Surround Sound: Hall
To reproduce in the living
room the surround effects
similar to those
experienced in a large
concert hall. Ideal for TV
programmes or music
video tapes.
Surround Sound:
Theatre
To reproduce the
surround effects similar
to those experienced in
a movie theatre filled
with a rich warm sound.
Ideal for movies with
stereo sound. Surround Sound:
Disco
To create the
atmosphere of a
room so full of
music that it
seems to engulf
the listener. An ideal
sound mode for
listening to pop videos.
Surround
Sound: Stadium
To reproduce the
surround effects
similar to those
experienced in a
large football or
baseball stadium
packed for a live game.
Surround Sound:
Pseudo
To create a
synthetic sound
effect for movies
and TV shows
recorded in
mono.
Surround Sound: Off
Uses only the front left and right speakers. This mode can be
selected for watching news broadcasts and the like which
require no special sound features.
Press the Mbutton to bring up the
SURROUND menu.
Press the Por Qbutton repeatedly to select
the digital mode which best suits the type of
broadcast.
Then press the Rbutton to access the
adjustments screen and with the P,Q,SandR
buttons, adjust the levels as required.
SURROUND SOUND uses a
combination of 4 speakers – front-left,
front-right and rear speakers.
1
2
3
SPECIAL SOUND FEATURES
TV
…if you choose to
adjust one Digital
Surround mode,
you will not effect
the others.

17
TELETEXT
VTR/DVD
VTR/DVD
P
P
Teletext – setting up
Viewing mode and general information
About teletext
Selecting the mode
This TV offers two ways of viewing text – AUTO and LIST which are explained on the next page.
2
3
4
With the Sor Rbutton choose AUTO or LIST.
Press EXIT to finish.
From the FEATURE menu, use the Qbutton to
highlight Teletext and then the Rbutton to select.
Use the Qbutton highlight Mode.
Before using teletext you can choose whether you want to
use the LIST or AUTO mode, explained on the next
page, in which to view the service.
1
The TEXT TV button:
Pressing the TEXT TV button once will bring
up the teletext screen. Press again to
superimpose the teletext over a normal
broadcast picture. Press again to return to normal TV
mode. You need to return to normal viewing if you wish
to change channels.
When you first press the TEXT TV button to access the
text service, the first page you see will be the initial page.
In Auto mode this displays the main subjects available
and their relevant page numbers.
In List mode you will see your chosen INITIAL page
(explained on the next page).
To access any teletext page, enter the 3 digit page
number, using the numbered buttons on the remote
control, e.g. 430.
To advance to the next page of teletext, press the
P fbutton, to go back to the previous page press the
P ebutton.
TELETEXT



Back
Character CHARACTER-1
Mode AUTO
EXIT : To exit
On this TV
CHARACTER-1
and
CHARACTER-2
will give the same
teletext display.
!

Teletext continued
– Auto and List modes
Selecting pages
18
TELETEXT
P
P
VTR/DVD
VTR/DVD
The rest of the text control buttons are
explained on the next page...
There are two Modes: Auto will display FASTEXT, if
available. List will display your four favourite pages. In
either mode, as an alternative to the coloured buttons
you can access a page by entering a 3-digit number,
using the buttons on the remote control.
Press the TEXT TV button to access teletext.
In Auto mode, if FASTEXT,is available, you will see four
coloured titles at the base of the screen.
To access one of the four given subjects, press the
relevant coloured button on the remote control,
corresponding to the title.
For further information on your particular text system(s),
see the broadcast teletext index page or, consult your
local Toshiba dealer.
List
Auto
In LIST mode, the four choices at the bottom of the
screen are now numbers – e.g. 100, 200, 300 and 400,
which have been programmed into the TV’s memory.
They will flash until the pages have been found.
To view these pages use the coloured prompt buttons
e.g. press the GREEN button to view page 200.
If you want to change these stored pages press the
coloured button for the colour you want to change,
e.g. GREEN and enter the 3 digit number. This number
will change in the top left of the screen and in the
coloured highlight.
Now press and hold the ENTER button
to store your choice. The bottom of the
screen will turn white.
If you do not press ENTER to confirm
your change, you will not have stored
your choice and it will be forgotten
when you leave the teletext screen.
You may view other pages by simply
entering the 3 digit page number – but DO NOT press
ENTER or you will lose the favourite already stored.
Whenever you press
ENTER
all four
pages numbers
showing along the
bottom will be
stored and the
previous ones will
be lost.

Remember…
to use the teletext
buttons for these four
functions, you must
press the Fbutton at
the same time.
19
TELETEXT
Teletext continued
– control buttons
2
1
Using the buttons on the remote control
Now you have set up teletext, below is a guide to the remote control teletext buttons and their functions.
3
4
5
6
You must
cancel the
news flash
page before
changing
channels.
☛
To view a TV programme whilst
waiting for your text page:
When in teletext mode, if a page selection is made and then the F
and the tbuttons are pressed, a normal picture will be
displayed. The TV will indicate when the page is present by
displaying the title bar of the text page at the top of the screen.
Press the TEXT TV button to view the page.
To display news flashes:
To view news flashes as they are broadcast, select the news flash
page for the particular teletext service (see the index page of teletext
service). Press the F and the tbutton. The news flashes will be
displayed as and when they are broadcast. Press the Fand the
tbuttons to cancel the display.
t
To display an index/initial page:
In AUTO mode
Press the Tbutton to access index pages. The one displayed is
dependant on the broadcaster.
In LIST mode, press the Tbutton to return to your first chosen
page, i.e. the red choice at the bottom of the screen.
To hold a wanted page: and
At times it is convenient to hold a page of teletext. Press the Fand
the qbuttons and the word HOLD will appear in the top left of
the screen. Press qagain to release.
p
q
TEXT TV
1
2
To enlarge the teletext display size: and
Press the F and the
s
buttons once to enlarge the top half of the
page, press again to enlarge the bottom half of the page. Press
again to revert to the normal size.
5
3
6
4r
s
To display a page of teletext:
Press the TEXT TV button to display teletext.Press again to
superimpose the teletext over a normal broadcast picture. Press
again to return to normal TV mode. You cannot change
programmes until you return to normal TV.
To reveal concealed text: and
Some pages cover topics such as quizzes and jokes. To discover
the solutions press the F and the rbuttons.
and

ADDITIONAL FEATURES
20
The timer, time display, panel lock
and stereo/bilingual transmissions
1
Stereo …
1
… and Bilingual
Bilingual transmissions are rare.
If they are transmitted the word Dual will display.
If the word Dual does appear press the OI/II
button to select between Dual 1, Dual 2
and mono.
1
2
The Timer
Stereo and Bilingual transmissions…
Panel lock allows you to disable the buttons on the
front of the TV set. You can though, still use all of
the buttons on the remote control.
From the FEATURE MENU select Panel
lock and choose ON or OFF with the
Sor R
buttons.
If stereo or dual language broadcasts are transmitted
the lights on the front of the TV will be lit. The word
Stereo or Dual will appear on the screen,
disappearing after a few seconds.
The display will reappear each time you change programme
positions, provided that the broadcast is in stereo. If the
broadcast is not in stereo the word Mono will appear.
Choose the required programme number.
Press the OI/II button repeatedly, to select
between Stereo and Mono.
NICAM broadcasts can be
in either Stereo or Mono.
You can tell the TV to turn itself ON or
OFF after a certain time.
EXIT : To exit
Panel Lock
FEATURE MENU





Select the On timer (or the Off timer). If, for
example, you want the TV to turn ON (or OFF) in
one and a half hours time, enter 01:30 using the
numbered buttons on the remote control.
When setting the On timer, you must enter the
programme position number you want to watch.
You must put the set into Standby mode by
pressing the ibutton.
Any equipment connected with Scart leads must
also be put into Standby mode to prevent them
being displayed when the timer switches on.
When the On timer has been set, the GREEN On
timer indicator on the front of the TV will be lit
(see page 6).
If the On timer has been set, you do not have to wait to
watch the television. You can bring the set back to life by
pressing the
i
button. However, the GREEN timer light
will stay on until the set time period has passed, at which
point the TV will go to the chosen channel.
The time display facility allows you to see the
current time on the TV screen.
If you press the Fbutton and the tbutton on the
remote control whilst watching a normal TV broadcast
you will see a time display from the broadcaster.
It will remain on the screen for about 5 seconds.
Select the TIMER option from the top menu bar.
1
2
3
Off timer 00:00
On timer 01:30 P02
0-9 : To set
EXIT : To exit
TIMER
4
The Time Display
To cancel the On timer, enter zero in each
position including the programme position.
When Panel lock is ON, you will be reminded on the
screen when you press any of the front panel buttons.
Once the set has been switched off it can ONLY be
brought out of standby using the remote control.
AV connection
Picture size/position
Teletext
Surround set up
Language ENGLISH
Panel lock OFF
WSS ON
