Toshiba TWD-BH90W4H User manual

FRONT LOADING
WASHER DRYER
OWNER’S MANUAL
MODEL
TWD-BH90W4H
Read This Manual
Use all instrucons and explanaons of
the installaon before use. Follow the
instrucons carefully. Keep the operaon
instrucons handy for later use. If the
applicaon issoldorpassedonthenensure
that the new owner always receives those
operaon instrucons.
CAUTION: HOT SURFACE !
CAUTION: RISK OF FIRE !

1
CONTENTS
SAFETY INSTRUCTIONS
Safety Instructions ..................................................... 2
INSTALLATION
Product Description ................................................. 10
Installation ............................................................... 11
OPERATIONS
Quick Start ............................................................... 15
Before Each Washing................................................ 17
Detergent Dispenser ................................................ 18
Control Panel.............................................................. 19
Option...................................................................... 20
Other Functions ....................................................... 23
Programmes............................................................. 24
Washing Programmes Table......................................... 25
MAINTENANCES
Cleaning And Care .................................................... 26
Trouble Shooting ...................................................... 29
Technical Specifications ........................................... 30

2
SAFETY INSTRUCTIONS
SafetyInstructions
•This appliance is not intended for use by
persons(includingchildren) with reduced
physical,sensory or mental capabilities or lack of
experience and knowledge unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
•Ifthe supply cord isdamaged,itmust bereplaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• The new hose-sets supplied with the appliance are to
be used and that old hose-sets should not be reused.
• The openings must not be obstructed by a carpet.
• This appliance is intended to be used in household
and similar applications such as:
− staff kitchen areas in shops, offices and other
working environments;
− farm houses;
− by clients in hotels, motels and other residential type
environments;
− bed and breakfast type environments;
− areas for communal use inblocks offlats orin
launderettes.
• The maximum permissible inlet water pressure, 1 MPa,
for appliances intended to be connected to the water mains.
The minimum permissible inlet water pressure,0.05 MPa, if
this is necessary for the correct operation of the appliance.

3
SAFETY INSTRUCTIONS
SafetyInstructions
For your safety,the information in this manual must be followed
to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, personal injury or loss of life.
Explanation of the symbols:
！Warning!
•Ifthesupply cord isdamaged, itmust bereplaced bythe
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
！Warning!
This combination of symbol and signal word indicates a
potentially dangerous situation which may result in
death or serious injuries unless it’s avoided.
Caution!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries or damage to property and the
environment.
Note!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries.
The electric shock!

4
SAFETY INSTRUCTIONS
• The new hose-sets supplied with the appliance must
beusedandtheoldhose-setsmustnotbeused.
• Before maintenance, unplug the appliance.
•Always unplug the machine and turn off the water
supply after use. The standard inlet water pressure:
0.05MPa~1MPa.
•This appliance must be grounded. In the event of
malfunction or breakdown , grounding will reduce the
risk of electric shock by providing a path of least
resistance for electric current.
•This appliance is equipped with a cord having an
equipment-grounding conductor and grounding plug.
The plug must be plugged into an appropriate outlet that is
properly installed and grounded in accordance with all local
codes and ordinances.
• Improper connection for the appliance when using
not grounded outlet or when GND terminal of outlet
is not suitable with GND terminal of power plug, can
result in risk of electric shock.. Check with a qualified
electrician or service person if you are in doubt as to
whether the appliance is properly grounded.
•Do not modify the plug provided with the appliance. If it
does not fit the outlet ,have a proper outlet installed
by a qualifiedelectrician.
•Make sure that the water and electrical devices must
be connected by a qualified technician in accordance
with the manufacturer's instructions and local safety
regulations.

5
SAFETY INSTRUCTIONS
•Pulloutitsplugfromthepower socketbefore cleaningor
maintenance.
•Donot use any socket with rated current less than that of
appliance. Never pull out power plug with wet hand.
• Please remember to disconnect water and power supply
immediately after the clothes are washed.
•Theappliancecanbeusedbychildrenagedfrom 8years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• Children of less than 3years should be supervised to
ensure that they do not play with appliance.
• Animals and children may climb into the machine. Check
the machine before every operation.
•Childrenshouldbesupervised thatthey donot playwith
the appliance.
•Glass door may be very hot during the operation. Keep
children and pets far away from the machine during the
operation .
• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage may result.
• Plug must be accessible after installation.
Risk to children!

6
SAFETY INSTRUCTIONS
• Do not wash or dry articles that have beencleaned in,washed
in,soaked in,orspotted with combustible or explosive
substances( such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene,etc.) This may result in
fire orexplosion.
•Thewasherdryerisnottobeused ifindustrial chemicals
have been used for cleaning.
•Theexhaust air must not bedischarged into aflue which
isforexhausting fumes from appliances burning gas or
other fuels.
• Rinse the articles thoroughly by hand before putting them
in the appliance.
Caution!
• The appliance is for indoor use only.
•Itisn't intendedtobe built-inusing.
• The openings must not be obstructed by a carpet.
•The appliance shall not be installed in bath room or
very wet rooms aswell asinthe rooms with explosive
or explosive and corrosive gases.
•Theappliance with single inlet valveonly canbe
connected to the cold water supply.
• Plug must be accessible after installation.
•The appliance must not be installed behind a lockable
door,a sliding door oradoor with a hinge onthe opposite
side to that of the washer dryer.
•Theappliance shall not beinstalled atahumid place.
• The household appliance isn't intended to be built-in.
Risk of explosion!
Installing the product!

7
SAFETY INSTRUCTIONS
• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage may result.
•Yourproduct isonly forhome use and isonly designed
for the textiles suitable for machine washing.
•Donotclimb upand sit ontop cover ofthe machine.
• Do not lean against machine door.
• Cautions during Handling Machine:
1. Transport bolts shall be reinstalled to the machine by
a specialized person.
2. The accumulated water shall be drained out of the
machine.
3. Handle the machine carefully. Never hold each protruded
part on the machine while lifting. Machine door can
not be used as the handle during the conveyance.
4. This appliance is heavy. Transport with care.
5.That the hands shall not be inserted into running
water extracting tub.
•Please donotclose the door with excessive forces.Ifit
is found difficult to close the door,please check if the
clothes are put in or distributed well.
• It is forbidden to wash carpets.
•Before washing the clothes at first time, the product
shall be operated in one round of the whole procedures
without the clothes inside.The suggested program is
“DRUM CLEAN”.
• Flammable and explosive or toxic solvents are forbidden.
Gasoline and alcohol etc.Shall not be used as detergents.
Please only select the detergents suitable formachine
washing, especially for front load washing machine.
Risk of damaging appliance!
Operating the appliance!

8
SAFETY INSTRUCTIONS
• Make sure that all pockets are emptied. Sharp and rigid
items such as coin,brooch,nail,screw or stone etc. may
cause serious damages to this machine.
•Please check whether the water inside the drum has
been drained before opening its door.Please do not open
the door ifthere isanywatervisible.
• Be careful of burning when the product drains hot
washing water.
• Never refill the water by hand during washing.
• After the program is completed, Please wait for two
minutes to open the door.
•Ifitisunavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care
products. itbeplaced inatumble dryer they should first
be washed in hot water with extra detergent ,this will
reduce, but not eliminate, the hazard.
•Adequate ventilation has to beprovided toavoid the back
flow of gases into the room from appliances burning other
fuels, including open fires.
• Do not dry unwashed items in the appliance.
Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should
be washed in hot with an extra amount of detergent
before being dried in the appliance.
• Items such as foam rubber (latex foam), shower caps, water
proof textiles, rubber backed articles and clothes or pillows
fitted with foam rubber pads should not be dried in the
machine.

9
SAFETY INSTRUCTIONS
• Fabric softeners, or similar products, should be used
as specified by the fabric softener instructions.
• The machine whose lid can be opened during water
extraction ,that ittakes 15s ormore for complete
stop of water extracting chamber tub.
•The final part of a washer dryer cycle occurs
without heat (cool down cycle) to ensure that the
items are left atatemperature that ensures that
the items will not be damaged.
• Remove all objects from pockets such as lighters
and matches before use the appliance.
•WARNING:Never stop awasher dryer before the
endofthe drying cycle unless all items are quickly
removed and spread out so that the heat is
dissipated.
Packaging / Oldappliance
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU . To prevent possible harm to the environment or
human health from uncontrolled waste disposal,recycle it
responsibly to promote the sustainable reuse of
material resources . To return your used device, please use
the collection systems or contact the retailer where the
product was purchased. They return and can take this
product for environmental safe recycling.

INSTALLATION
10
Product Description
Accessories
Transport
hole plug
Supplyhose
cold water
Drain hose
support
(optional)
Owner’s manual Rat resistance
panel(optional)
Spanner assembly
(optional)
Screw(optional)
Top cover
Water supply hose
Control panel
Detergent dispenser
Power supply cord
Drum
Door
Drain pump filter
Drain hose
Note!
• The product line chart is for reference only, please refer to real product as
standard.

INSTALLATION
11
Installation
Installation area
Before installing the machine, the location characterized
as follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4. Room temperature is above 0 ° C
5. Keepfarawayfromtheheatresourcessuchascoalorgas.
Unpacking the washing machine
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.Make sure the small triangle
foam isremoved with the bottom one together. If not, lay the unit down with side
surface, then remove the small foam from the unit bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Remove transport bolts
！Warning!
• Stability is important to prevent the product from
wandering!
•Make surethat theproduct should not stand on
the power cord.
w
W> 20mm
w
！Warning!
• Packaging material (e.g. Films, Styrofoam) can be
dangerous for children.
•There is a risk of suffocation ! Keep all packaging
well away from children.
！Warning!
• You must remove the transport bolts from the backside before using the product.
• You’ll need the transport bolts again ifyou move the product ,somakesure
you keepthem in asafe place.
Please take the following steps to remove the bolts:
1.Loosen 4 bolts with spanner and then remove them.
2.Cover the hole with transport hole plugs.
3.Keep the transport bolts properly for future use.

INSTALLATION
12
2
Levelling the washing machine
1. If it’s balanced from leto right
•Take a long sck, and e a rope at the end of it.
Bind a heavy object at the end of the rope.
•Hang the rope from the top cover of the
machine. Adjust the legs ll the difference
between ‘a’ and ‘b’ is less than 1cm.
2. If it’s balanced from front toback
•Put the sck at the middle of the control panel, and hang the rope in front of the
machine.
•Keep 13cm away from the rope end to the control panel edge( c ). Adjust the legs
ll ‘d’ is 5.5-6.5cm (‘d’ is the distance from rope to boom of front cover).
！
Warning!
• Check with the gradienter if the machine placement is balanced and steady.
• If there is no gradienter, check the balance as per the following method.
c
Control Panel
d
Front Cover
a
b

INSTALLATION
13
3
Levelling the washing machine
1. Check if the legs are closely aached to the cabinet. If not, please turn them to
their original posions ghten the nuts.
2. Loosen the lock nut turn the feet unl it closely contacts with the floor.
3.Adjust the legs and lock them with a spanner, make sure the machine is steady.
Connect Water Supply Hose
Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1. Connecon between ordinary tap and inlet hose.
Loosen clamp nut and
four bolts
Press the tap end
ghtly to the rubber
ring insidetheclamp,
and then, ghtenthe
4 bolts
Press slide bushing,
insert inlet hose into
connecng base
Connecon finished
2. Connecon between screw tap and inlet hose.
Tap with threads and inlet hose
Special tap for washing machine
1 2
slide bushing 3
4
clamp nut
！
Warning!
•To prevent leakage or water damage, follow the instrucons in this chapter!
•Do not kink, crush, modify or sever water inlet hose.
！
Warning!
• The lock nuts on all four feet must be screwed ghtly against the housing.
1
2
3
4
Raise
Lower
Lock nu
t
foot
slide bushing

INSTALLATION
14
4
！
Warning!
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe ghtly clockwise.
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the drain port. 2.Connect it to the branch drain pipe of
the trough.
！
Warning!
• When installing drainhose,fix it properly with a rope.
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
！
Warning!
•Do not kink or protract the drain hose.
•Posiondrainhoseproperly,otherwisedamagemightresultofwaterleakage.
water Inlet valve
water supply hose
Drain port
Note!
•If the machine has drain hose support, please install it like the following .
Trough
Hose Retainer
Max.100cm
Min.60cm
M
ax
.
100
c
m
M
i
n
.
60
c
m
Min.60 c
m
Ma
x
.100c
m

15
5
OPERATIONS
Quick Start
1. Before Washing
Plugin Opentap Load
Close door
Add detergent
2. Washing
1
2
3
4
Power On Select Programme Select funcon or
default(see next page
for details)
Start up
3. Aer Washing
Buzzer beep or “END” on display.
Note!
•Ifdefaultisselected,step3canbeskipped.
•Whenthemachineisworking,youcanslidethesensebartolightenthescreen
and lamp.
Note!
•Add detergent orsoener when the display shows notelikethis“Detergent
and Soener have run out, please add!”
1 2 3 4 5
DETERGENT SOFTENER
Caution!
• Before washing, please make sure it’s installed properly.
• Before washing at first me, the washing machine shall be operated in one
round of the whole procedures without clothes in as follows.The suggested
program is“DRUM CLEAN”.

16
6
OPERATIONS
Select func on or default
• TEMP./ SPIN/ RINSE/SENSEDOSE
Press the bu on (TEMP./ SPIN/ RINSE/SENSEDOSE) to adjust the parameter.
•
DELAY END/ FAST WASH/ DRYING
Op ons:
Step1: Press the bu on( DELAY END/ FAST WASH/
DRYING)
Step2: Slide and touch OK to select different level as
you need. A er selec ng, the display will highlight
corresponding icons.
Step3:To cancel a selected func on-Slide to CANCEL
and touch OK.
DELAY END (single choice):CANCEL, 1hour, 2hours, 3hours, 4hours, 5hours…24hours. FAST
WASH (single choice):CANCEL, FAST, FASTER, FASTEST.
DRYING (single choice):CANCEL, LESS, STANDARD, EXTRA.
• FUNCTION(mul ple choice)
Available fun ons: ECO, PREWASH,EASY IRON, SOAK, CONFIRM
Step1: Press the bu on (FUNCTION)
Step2: Slide and touch OK to select a func on. This step can be repeated to select several
fun ons. The selected fun ons will be highlighted.
Step3: To cancel a selected func on - Slide to a selected func on and touch O ll it’s not
highlighted.
Step4: A er selec ng, slide to CONFIRM and touch OK, the display will show corresponding
icons.
Note!
•The youselectinDELAYENDmustbemorethanthe ofthecurrent
program and the display will show the me that you can select.
•
If you press the same bu on (DELAY END/ FAST WASH/ DRYING/ FUNCTION) twice,
thedisplaywillswitchtotheprograminterface.Duringsele ng,ifyoupressother
bu on (DELAYEND/ FASTWASH/ DRYING/ FUNCTION), the display will switch to
other corresponding selec on interface.

OPERATIONS
17
Before Each Washing
•The working condion of the washer should be(0-40)°C.If used under 0°C,the
inlet valveand draining system may be damaged. If the machine is placed under
condion of 0°Cor less, then it should be transferred to normal ambient
temperature to ensure the water supply hose and drain hose are not frozen
before use.
•Please check the labelsand the explanaon of using detergent before wash.Use
non-foaming or less-foaming detergent suitable for machine washing properly.
Check the label
Put small clothes into the
pillow slip
Take out the items out of
the pockets
Turn easy-pilling and
long-pile fabric inside out
Knot the long strips,zip or
buon
Separate clothes with
different textures
！
Warning!
•When washing a single clothes, it may easily cause great imbalance and give
alarm. Therefore it is suggested to add one or two more clothes to be washed
together so that washing process can bedone smoothly.
•Don't wash the clothes soaked in kerosene, gasoline, alcohol and other
flammable materials.

OPERATIONS
18
Detergent Dispenser
Li qu i d d e t e r g e n t ( M A X : ≈ 810 m l )
S of t e n e r ( M A X : ≈ 440 m l )
If you want to use powder detergent
,you can add it directly into the drum
with clothes by using the container.
Please put the container on the top of
theload to make powderwelldissolved.
Don’t choose “Auto”or” ”in
SENSEDOSE, when using powder
detergent.
Pull out the dispenser
DOWN JACKET
SPORTSWEAR
ANTI-ALLERGY
WOOL
DELICATE
COLORALIVE
COTTON ECO
COTTON
SYNTHETIC
MIX
45' TO WEAR
10' SUPER FAST
BEDLINEN
AUTO DRY TIME
DRY
SPIN ONLY
DRUM CLEAN
Means must ○ Means oponal
Programme
Programme
Note!
• As for the agglomerated or ropy detergent or addive, before they are
poured into the detergent box, it is suggested to use some water for
diluon to prevent the inlet of detergent box from being blocked and
overflowing while filling water.
•Please choose suitable type of detergent for the various washing
temperature to get the best washing performance with less water and
energy consumpon.
•
Pay aenon to whether the detergent is dry, and clean the dispenser
regularly especially when the washing machine is not used for long
periods ofme.

OPERATIONS
1 9
Control Panel
Product is switched on or off.
Option
This allows you to select an addional
funcon and willlightwhenselected.
Press the buon to start or pause the
washing cycle.
Slider
Available to select orconfirm the
programme andfuncon
Display
The display shows the sengs, esmated me remaining, opons, and status messages
foryour washer.Thedisplay willremain onthrough thecycle.
B
1:18
C W
Cotton Fabric
m
ashing Progra
D
E
A
COTTON
A
B
PROGRAMME
WASH TIME
CPROGRAMME DESCRIPTION
D
E
WATER CONSUMPTION
POWER CONSUMPTION
2
S t ar t
/
P a u s e
1
On / O ff
1:18
MEMORY
COLORALIVE
COTTON ECO
Cotton Fabric
Washing Program
COTTON
SYNTHETIC
MIX
45' TO WEAR
3
5 4 2 1
Note!
• The chart is for reference only, Please refer to real product as standard.
3
4
5
