Toshiba TWD-BL160D4 Series User manual

OWNER’S MANUAL
DUAL DRUMWASHER DRYER
Read this manual
Use all instructions and explanations of
The installation before use. Follow the
Instructions carefully. Keep the operation
Instructions handy for later use. If the
Application is sold or passed on then ensure
That the new owner always receives those
Operation instructions.
CAUTION: HOT SURFACE !
CAUTION: RISK OF FIRE !
CAUTION: READ THE INSTRUCTIONS!
MODEL:
TWD-BL160D4 Series

SAFETY INSTRUCTIONS
INSTALLATION
Product Description ..................................................
Installation .................................................................
OPERATIONS
Quick Start ...................................................................
Before Each Washing .................................................
Detergent Dispenser .................................................
Control Panel ..............................................................
Option...........................................................................
Programmes.................................................................
Washing Programmes Table .....................................
MAINTENANCES
Cleaning And Care .....................................................
Trouble Shooting ........................................................
Technical Specifications ..........................................
Safety Instructions .....................................................
Setting guide...............................................................
2
10
12
16
17
18
19
20
23
26
28
31
34
35
CONTENTS
1

SAFETY INSTRUCTIONS
Safety Instructions
• This appliance is not intended for use by persons
(includingchildren) with reduced physical,sensory or mental
capabilities or lack of experience and knowledge unless they
have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
• The new hose-sets supplied with the appliance are to be used
and that old hose-sets should not be reused.
• The openings must not be obstructed by a carpet.
• This appliance is intended to be used in household and similar
applications such as:
− staff kitchen areas in shops, offices and other working
environments;
− farm houses;
− by clients in hotels, motels and other residential type
environments;
− bed and breakfast type environments;
− areas for communal use in blocks of flats or in launderettes.
• The maximum permissible inlet water pressure, 1 MPa,
for appliances intended to be connected to the water mains.
The minimum permissible inlet water pressure,0.05 MPa, if
this is necessary for the correct operation of the appliance.
2

SAFETY INSTRUCTIONS
Safety Instructions
For your safety,the information in this manual must be followed
to minimize the risk of fire or explosion, electric shock, or to
prevent property damage, personal injury or loss of life.
Explanation of the symbols:
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• If the supply cord is damaged, it must be replaced by the
The electric shock!
a potentially dangerous situation which may result in
death or serious injuries unless it’s avoided.
This combination of symbol and signal word indicates
Warning!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries.
Note!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries or damage to property and the
environment.
Caution!
Warning!
3

• The new hose-sets supplied with the appliance must
be used and the old hose-sets must not be used.
• Before maintenance, unplug the appliance.
• Always unplug the machine and turn off the water
supply after use. The standard inlet water pressure:
0.05MPa~1MPa.
• This appliance must be grounded. In the event of
malfunction or breakdown , grounding will reduce the
risk of electric shock by providing a path of least
resistance for electric current.
• This appliance is equipped with a cord having an
equipment-grounding conductor and grounding plug.
The plug must be plugged into an appropriate outlet that
is properly installed and grounded in accordance with all
local codes and ordinances.
SAFETY INSTRUCTIONS
• Improper connection for the appliance when using
not grounded outlet or when GND terminal of outlet
is not suitable with GND terminal of power plug, can
result in risk of electric shock.. Check with a qualified
electrician or service person if you are in doubt as to
whether the appliance is properly grounded.
• Do not modify the plug provided with the appliance. If it
does not fit the outlet , have a proper outlet installed
by a qualified electrician.
• Make sure that the water and electrical devices must
be connected by a qualified technician in accordance
with the manufacturer's instructions and local safety
regulations.
4

SAFETY INSTRUCTIONS
Risk to children!
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
• Children of less than 3years should be supervised to
ensure that they do not play with appliance.
• Animals and children may climb into the machine. Check
the machine before every operation.
• Children should be supervised that they do not play with
the appliance.
• The appliance can be used by children aged from 8 years
Risk to children!
•
maintenance.
• Do not use any socket with rated current less than that of
appliance. Never pull out power plug with wet hand.
• Please remember to disconnect water and power supply
immediately after the clothes are washed.
Pull out its plug from the power socket before cleaning or
• Glass door may be very hot during the operation. Keep
children and pets far away from the machine during the
operation .
• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage may result.
• Plug must be accessible after installation.
5

Risk of explosion!
•
in, soaked in, or spotted with combustible or explosive
substances( such as wax, oil, paint, gasoline, degreasers,
dry-cleaning solvents, kerosene, etc.) This may result in
fire or explosion.
• The washer dryer is not to be used if industrial chemicals
have been used for cleaning.
• The exhaust air must not be discharged into a flue which
is for exhausting fumes from appliances burning gas or
other fuels.
• Rinse the articles thoroughly by hand before putting them
in the appliance.
Do not wash or dry articles that have been cleaned in, washed
• The appliance is for indoor use only.
• It isn't intended to be built-in using.
• The openings must not be obstructed by a carpet.
• The appliance shall not be installed in bath room or
very wet rooms as well as in the rooms with explosive
or explosive and corrosive gases.
• The appliance with single inlet valve only can be
connected to the cold water supply.
• Plug must be accessible after installation.
• The appliance must not be installed behind a lockable
door, a sliding door or a door with a hinge on the opposite
side to that of the washer dryer.
• The appliance shall not be installed at a humid place.
• The household appliance isn't intended to be built-in.
Installing the product!
SAFETY INSTRUCTIONS
Caution!
6

• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage may result.
Risk of damaging appliance!
• Your product is only for home use and is only designed
for the textiles suitable for machine washing.
• Do not climb up and sit on top cover of the machine.
• Do not lean against machine door.
• Cautions during Handling Machine:
1.Transport bolts shall be reinstalled to the machine by
a specialized person.
2.The accumulated water shall be drained out of the machine.
3.Handle the machine carefully. Never hold each protruded
part on the machine while lifting. Machine door can
not be used as the handle during the conveyance.
4.This appliance is heavy. Transport with care.
5.That the hands shall not be inserted into running
water extracting tub.
• Please do not close the door with excessive forces. If it
is found difficult to close the door, please check if the
clothes are put in or distributed well.
• It is forbidden to wash carpets.
Operating the appliance!
• Before washing the clothes at first time, the product
shall be operated in one round of the whole procedures
without the clothes inside.The suggested program is
“DRUM CLEAN”.
• Flammable and explosive or toxic solvents are forbidden.
Gasoline and alcohol etc.Shall not be used as detergents.
Please only select the detergents suitable for machine
washing, especially for front load washing machine.
SAFETY INSTRUCTIONS
7

• Make sure that all pockets are emptied. Sharp and rigid
items such as coin,brooch,nail,screw or stone etc. may
cause serious damages to this machine.
• Please check whether the water inside the drum has
been drained before opening its door.Please do not open
the door if there is any water visible.
• Be careful of burning when the product drains hot
washing water.
• Never refill the water by hand during washing.
• After the program is completed, Please wait for two
minutes to open the door.
• If it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care
products. it be placed in a tumble dryer they should first
be washed in hot water with extra detergent , this will
reduce, but not eliminate, the hazard.
• Adequate ventilation has to be provided to avoid the back
flow of gases into the room from appliances burning other
fuels, including open fires.
• Do not dry unwashed items in the appliance.
Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers should
be washed in hot with an extra amount of detergent
before being dried in the appliance.
• Items such as foam rubber (latex foam), shower caps, water
proof textiles, rubber backed articles and clothes or pillows
fitted with foam rubber pads should not be dried in the
machine.
SAFETY INSTRUCTIONS
8

SAFETY INSTRUCTIONS
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU.To prevent possible harm to the environment or
human health from uncontrolled waste disposal,recycle
it responsibly to promote the sustainable reuse of
material resources.To return your used device, please use
the collection systems or contact the retailer where the
product was purchased. They return and can take this
product for environmental safe recycling.
Packaging/Old appliance
•
as specified by the fabric softener instructions.
• The final part of a washer dryer cycle occurs without heat
(cool down cycle) to ensure that the items are left at a
temperature that ensures that the items will not be damaged.
• Remove all objects from pockets such as lighters and matches
before use the appliance.
• Lint must not to be allowed to accumulate around the
tumble dryer
• WARNING: Never stop a washer dryer before the end of the
drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
• WARNING: The appliance must not besupplied through an
external switching device, such as a timer, or connected to a
circuit that is regularly switched on and off by a utility.
Fabric softeners, or similar products, should be used
9

Accessories
Product Description
• The product line chart is for reference only, please refer to real product as
standard.
Note!
INSTALLATION
Transport
hole plug
(9 plugs)
Supply hose
cold water
Drain hose
connect
Owner’s manual Screw(optional) Rat resistance
panel(optional)
Spanner assembly
(optional)
Power
supply cord
Upper drum
Detergent
dispenser
Under drum
Drain
pump filter
Under door
Upper door
10
Container
Extended
drain hose
Drain hose

INSTALLATION
Transport Bolt-1
Transport Bolt-3
Transport Bolt-6
Transport Bolt-7
Transport Bolt-2Transport Bolt-4
Transport Bolt-5
Transport Bolt-8
Transport Bolt-9
Adjustable Legs
Power supply cord
Drain Hose
Inlet valve
• The product line chart is for reference only, please refer to real product as
standard.
Note!
11

INSTALLATION
Installation
Before installing the machine, the location characterized
as follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0°C
5.Keep far away from the heat resources such as coal or gas.
Please take the following steps to remove the bolts:
1.Loosen 9 bolts with spanner and then remove them.
2.Cover the hole with transport hole plugs.
3.Keep the transport bolts properly for future use.
Installthe rat resistance panel &Remove transport bolts
• Stability is important to prevent the product from
wandering!
• Make sure that the product should not stand on
the power cord.
Warning!
• You must remove the transport bolts from the backside before using the product.
• You’ll need the transport bolts again if you move the product , so make sure
you keep them in a safe place.
Warning!
w
w
W> 20mm
Installation area
12
Install the rat resistance panel
Remove transport bolts (9unites)
Screwed the rat resistance panel
to the bottom of machine

INSTALLATION
Levelling the washing machine
• Check with the gradienter if the machine placement is balanced and steady.
• If there is no gradienter, check the balance as per the following method.
Warning!
b
a
dFront Cover
1.Whether it’s balanced from left to right
• Take a long stick, and tie a rope at the end of it.
Bind a heavy object at the end of the rope.
• Hang the rope from the top cover of the
machine. Adjust the legs till the difference
between ‘a’ and ‘b’ is less than 1cm.
2. it’s balanced from front to backWhether
• Put the stick at the middle of the Front cover, and hang the rope in front
of the machine.
• Keep 13cm away from the rope end to the Front cover edge( c ). Adjust the
legs till ‘d’ is 5.5-6.5cm (‘d’ is the distance from rope to Under door).
c
13

INSTALLATION
1.Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions tighten the nuts.
2.Loosen the lock nut turn the feet until it closely contacts with the floor.
3.Adjust the legs and lock them with a spanner, make sure the machine is steady.
Levelling the washing machine
• The lock nuts on all four feet must be screwed tightly against the housing.
Connect Water Supply Hose
Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1.Connection between ordinary tap and inlet hose.
• To prevent leakage or water damage, follow the instructions in this chapter
• Do not kink, crush, modify or sever water inlet hose.
!
234 1
Raise Lower
Lock nut
foot
Warning!
Warning!
Loosen clamp nut
and four bolts
Press the tap end
tightly to the rubber
ring inside the clamp,
and then, tighten the
4 bolts
Press slide bushing,
insert inlet hose into
connecting base
slide bushing
2341
Connection finished
clamp nut
Tap with threads and inlet hose Special tap for washing machine
2.Connection between screw tap and inlet hose.
slide bushing
14

INSTALLATION
Drain Hose
There are two ways to place the end of drain hose:
1.Put it into the drain port. 2.Connect it to the branch drain pipe of
the trough.
•
• Position drain hose properly ,otherwise damage might result of water leakage.
Do not kink or protract the drain hose.
Warning!
water supply hose
water Inlet valve
Connect the other end of inlet pipe to the inlet valve at the backside of product
and fasten the pipe tightly clockwise.
500mm
MAX
15
Installthe drain hose
with the clamp tightly.
Firstly install the drain hose to the
back side of machine.
Then hold the drain hose with the
clamp.

• Before washing, please make sure it’s installed properly.
• Before washing at first time, the washing machine shall be operated in one
round of the whole procedures without clothes in as follows.The suggested
program is “DRUM CLEAN”.
1. Before Washing
Buzzer beep or “END” on display.
Open tap
Load
Close door
Plug in
Add detergent
Quick Start
3. After Washing
1 2 3 4
2. Washing
Power On
Select Drum Start up
1 2 3 4
Caution!
OPERATIONS
Select Program and
function or default
5
• Add detergent or softener when the display shows note like this “Detergent
and Softener have run out, please add!”
Note!
•
• When the machine is working ,you can touch the display to lighten the
display screen and drum lamp.
You can operate Upper & Under drum at the same time.
Note!
DETERGENTSOFTENER
16
MIX
1:10

Knot the long strips,zip or
button
• When washing a single clothes, it may easily cause great imbalance and give
alarm. Therefore it is suggested to add one or two more clothes to be washed
together so that washing process can be done smoothly.
• Don't wash the clothes soaked in kerosene, gasoline, alcohol and other
flammable materials.
• The working condition of the washer should be(0-40)°C.If used under 0°C,the
inlet valve and draining system may be damaged. If the machine is placed under
condition of 0°Cor less, then it should be transferred to normal ambient
temperature to ensure the water supply hose and drain hose are not frozen
before use.
• Please check the labels and the explanation of using detergent before wash. Use
non-foaming or less-foaming detergent suitable for machine washing properly.
Take out the items out of
the pockets
Put small clothes into the
pillow slip
Check the label
Before Each Washing
Turn easy-pilling and
long-pile fabric inside out
Separate clothes with
different textures
Warning!
OPERATIONS
17

Detergent Dispenser
Liquid detergent
Softener
Pull out the dispenser
• As for the agglomerated or ropy detergent or additive, before they are
poured into the detergent box, it is suggested to use some water for
dilution to prevent the inlet of detergent box from being blocked and
overflowing while filling water.
• Please choose suitable type of detergent for the various washing
temperature to get the best washing performance with less water and
energy consumption.
• Pay attention to whether the detergent is dry, and clean the dispenser
regularly especially when the washing machine is not used for long
periods of time.
Note!
OPERATIONS
If you want to use powder detergent
,you can add it directly into the drum
with clothes by using the container.
Please put the container on the top of
the load to make powder well
dissolved.
Please make sure there is no liquid
detergent in the dispenser , when
using powder detergent.
Add Detergent & softener
18
Softener level Detergent level
Softener addition Detergent addition
Handle

Control Panel
OPERATIONS
Turn on the Machine , The display show UPPER”&”UNDER”Mode.
You can touch the screen to select "UPPER” or "UNDER”Drum.
"
" "
choose program and option.
UPPER”and UNDER”Drum operation display, you can touch and slide to
1
2
3
4
5
7
6
8 8 7
6
4
5
1
2
3
1
2
3
4
5
6
7
8
Program
Option
Display time
Return button
Start / Pause
Setting button
Memory function
Function icon
(Wi-Fi , time , remote control)
• The chart is for reference only, Please refer to real product as standard.
Note!
UPPER drum
19
UNDER drum
MIX
1:10
MIX
1:10
