Toshiba AW-J800APH1 User manual

OWNER’S MANUAL
Fully Automatic
Washing Machine
Model:
AW-J800APH1
AW-J900DPH1
6348363701
16138000013181

20
12
1
CONTENTS
SAFETY INSTRUCTIONS
Safety instructions .................................................................
INSTALLATION
Product description .............................................................
Installation area .....................................................................
Unpacking the washing machine ...................................
Levelling the washing machine .......................................
Selection of tap .....................................................................
Connection of inlet hose, tap and washing machine
Preparation before washing...............................................
Washing ....................................................................................
After washing...........................................................................
Washing matters needing attention ..............................
The usage of detergent and washing powder...........
Control panel ...............................................................................
Option.........................................................................................
Personalized setting of washing ........................course
Operations of washing process........................................
Washing table ..........................................................course
Maintenance
Cleaning and care ......................................................................
Cleaning the cabinet..................................................................
Trouble shooting.........................................................................
Technical .............................................................specifications
2
8
9
9
10
11
11
12
12
13
13
14
15
16
16
17
19
19
21
OPERATION
Cleaning inlet filter ............................................................the 19
18
Recommended detergent amount................................

2
SAFETY INSTRUCTIONS
For your safety, the information in this manual must be
followed to minimize the risk of fire or explosion, electric
shock, or to prevent property damage, personal injury or
loss of life.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• The new hose-sets supplied with the appliance are to
be used and that old hose-sets should not be reused.
• The openings must not be obstructed by a carpet.
• This appliance is intended to be used in household .

SAFETY INSTRUCTIONS
3

4
SAFETY INSTRUCTIONS
The electric shock!
Warning!
• washing machine
• Do not put this washing machine in a humid place.
• Hands should not be inserted into the rotating drum.
• Before doing any maintenance the unit, unplug the
appliance from the electrical source.
• Always unplug the machine andturn off the water supply
after use. Be aware of the maximum andminimum inlet
water pressure which is in megapascals .
•
• Make sure that the water andelectrical devices provisions
are connectedby a qualifiedtechnician in accordance with
the manufacturer's instructions andlocal safety regulations
This is for indoor use only.
(0.03-0.8Mpa)
This appliance must begrounded. In the event of
malfunction or breakdown , grounding will reduce the
risk of electric shock byproviding apath of least resistance
for electric current.

5
SAFETY INSTRUCTIONS
Risk to children!
•
•
•
•
The appliance can be used by children aged from 8
years and above and persons with reduced physical，
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved． Children shall not play
with the appliance． Cleaning and user maintenance shall
not be made by children without supervision．
Children of less than 3years should be supervised to
ensure that they do not play with appliance.
Animals and children may climb into the machine.
Check the machine before every operation.
Children should be supervised that they do not play
with the appliance.
Risk of explosion!
•
washed in, soaked in, or dabbed with combustible or
explosive substances( such as wax, oil, paint, gasoline,
degreasers, dry-cleaning solvents, kerosene, etc.) .This may
result in fire or explosion.
• Rinse the clothes or wash articles thoroughly by hand
before putting them in the appliance .
Do not wash or dry articles that have been cleaned in,

• This washing machine is for indoor use only.
• It is not intended for built-in using.
• The openings must not be obstructed by a carpet.
• The washing machine shall not be installed in bath rooms
or very wet rooms as well as in the rooms with explosive
or caustic gases.
• Remove all packaging materials before using
Otherwise, serious damage may result.
the appliance.
• The washing machine with single inlet valve may only
connected to a cold water supply. be
• The plug must be accessible after installation.
• Avoid place where the machine is exposed to direct
sunlight .Plastic parts may become deformed or discolored .
Avoid place where the machine may become frozen
during cold weather.
Risk of damaging appliance!
6
SAFETY INSTRUCTIONS
Caution
Installing the product!
• Your product is only for home use and is only designed
for textiles suitable for machine washing.
• Do not climb up and sit on the top cover of the machine.
• Cautions during Machine Handling and transport:
1.The accumulated water shall be drained out of the
machine.
2.Handle the machine carefully. Never hold protruding
parts of the machine while lifting.
3.This appliance is heavy, it should be transported carefully.
• Please do not close the top lid with excessive force.
• It is forbidden to wash carpets.

Operating the appliance!
• Before washing the clothes for the first time, the product
shall be operated without clothes using tub clean as the
recommended program
• Flammable and explosive or toxic solvents are forbidden.
Gasoline and alcohol etc. Shall not be used as detergents.
Please only select the detergents suitable for machine
washing, especially for top-loading fully automatic washing
machines.
• Make sure that all pockets are emptied. Sharp and rigid
items such as coins, brooches, nails, screws or ston s etc.
may cause serious damage to this machine.
e
• Never refill the water by hand during washing.
7
SAFETY INSTRUCTIONS

INSTALLATION
Product description
• All illustrations in this manual are for reference only.
Please refer to the product ,for actual appearance of the parts.
Note!
8
Accessories
Inlet hose assy manual screw cabinet baseboard
Adjustable foot knob
Glass lid
Drum
Frame
Control panel
Cabinet
Water inlet valve
Power and plugcord
Handle
Drain hose

Installation Area
Before installing the machine, the location characterized
as follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0 C
5.Keep far away from fuel sources such as coal or gas
Unpacking The Washing Machine
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.
3. Remove the tape securing the power supply cord and
drain hose.
4. Pick up the inlet hose from the drum.
• Stability is important to prevent the product
from moving!
• Make sure that the product does not stand on
the power cord.
Warning!
•
be
•
Packaging material (e.g. Films, Styrofoam) can
dangerous for children.
There is arisk of suffocation ! Keep all packaging
well away from children.materials
Warning!
9
INSTALLATION
w
w
W> 20mm
Note:
with the unit. It will cause damage to the machine.
Do not operate the washing machina with the base packing still intact
Note!

9
10
•
• Position the drain hose properly, otherwise , improper position may
result in water leakage.
• If drain hose is too long, do not force it into washing machine as this will
cause abnormal noises.
Do not kink, crash, modify or sever the drain hose.
Warning!
• The lock nuts on all four feet must be screwed tightly against the housing.
Levelling the washing machine
Warning!
INSTALLATION
Trough
Hose
Retainer
Bind
Min.86cm
Max.100cm
Min.86cm
Max.100cm
1. Check alignment of the product with a
leveler and do the succeeding steps if
necessary.
2. Loosen the lock nut and rotate the foot
either clockwise or counter clockwise ,
until it closely contacts with the floor.
3 Assure that the lock is secure and then
alternately press the four top corners of the
machine, to check if the proper adjustment
has been done.
• The lock nuts on all four feet must be screwed tightly against the housing.
• Only two feet in front of the machine can be adjusted.
Levelling the washing machine
Warning!
Lock nut foot
Raise Lower
lockloosen
right
wrong
The way to place the endof drain hose.

11
Wall
Slide bushing
1:Connection between ordinary tap and inlet hose.
2:Connection between screw tap and inlet hose.
• To prevent leakage or water damage, follow the instructions
•Do not kink, crush, modify or cut the water inlet hose.
above-mentioned !
Warning!
Selection of tap
Please select
tap.
appropriate
Connection of inlet hose, tap and washing machine
clamp nut
tap
1.Loosen clamp nut
to show 5mm groove
2.Loosen four
screws
3.Set connecting base
on tap and tighten
screws evenly
4.Tighten clamp nut
inlet valve
inlet hose
slide bushing
5.Press slide bushing,
insertinlethoseinto
connecting base
6. onnection finishedC7.After connection and installation,
check if there is water leakage
tap with threads and inlet hose special tap for washing machine
Screw tap Special washing
machine tap
Ordinary tap
INSTALLATION
5mm

Caution!
Before washing, please make sure installed properly.
Before washing first time, the washing machine shall be operated
•
•
that the unit is
for the
without clothes using tub clean as the recommended course.
Open tap
Plug in Add detergent
After Washing
1 2 3 4
Washing
Power On Start up
1
10
12
load and Close lid
The buzzer will beep after washing finished and the power supply will be cut off
automatically . unload the laundry.
At this point , you may
3
Preparation Before Washing
OPERATION
A complete cycle is as shown below
2
• Water level can be selected manually .
Note!
Select Course
• In the case of Liquid det rgent , t is used by this case .e i
Note!
Liquid detargent Case

Tie tassels into Knot, fasten
zippers and buttons
• Washing a single piece of clothing may cause , severe unbalance and
consequently sound an alarm. In this case, it is suggested to add one or two
more pieces of clothing to the wash load that will also make spinning smoother.
•Do not wash clothes stained with kerosene ,touching gasoline, alcohol and
other flammable materials.
•Before washing ,please check the clothes labels and the detergent usage
instructions. Use low-density detergent before wash suitable for washing
machines .
Take items out
of the pockets
Put small clothes into a
laundry net
Check the label
Washing matters needing attention
Turn the following clothes
inside out those that easily
form fiber on its surface and
thosewith longstrands offiber
Segregate clothes with
varying textures or materials
Warning!
10
13
The usage of detergent and washing powder
OPERATION
• As for powder detergent that can form into clusters or masses, it is suggested
to dilute the detergent with some water ,before pouring into the detergent
box, this will prevent the inlet of the detergent box from clogging and water
from over flowing during the filling process.
• Choose the type
to get the best washing effect with less water and energy consumption.
of detergent suitable with top loading WM.

長亮/閃爍
水位 預設 設定 程序 行程選擇
兒童安全裝置
浸泡
洗衣
沖洗
脫水
快洗
柔洗
記憶設定
清潔水槽
普通
牛仔褲
毛毯
強力洗衣 電源
(自動斷電)
開/關
預設( 小時 )
剩餘時間( 分鐘 ) 啟動
暫停
Control Panel
10
14
OPERATION
On/Off Start/Hold
Available according to the
laundry type.
Option
Note!
• This illustration is for reference only. Please refer to the product ,for
actual appearance.
1
1
4
1
2
3
5
1
2
4
The washing machine will select the water level automatically according
to the load weight.
1. When there's water in the tub, this function is not available;
2. Before pressing [Start/Hold] button, if the user selected the water level,
there will be no fuzzy weighing function;
3. After pressing [Start/Hold] button, the washing machine will run the
fuzzy weighing function.
54 4 4
4
6
6Fuzzy
Display
Course
Turns the unit on and off. Press this button to start or Hold
the washing cycle.
Note!
REGULAR ,JEANS ,MEMORY, HEAVY WASH course has fuzzy function.
The display shows the settings, estimated for your washer.
The display will remain on the cycle.
remaining
throughout
time etc.
Additional functions are available
according to the users’ preferences.
3
4

Option
15
OPERATION
Users can manually select the water level according to the clothing categories,
weight and washing preferences.
To select the soaking time, washing time, number of rinses spinning
time
and
.
To select one of the following functions, soak , wash, rinse or spin.
Only for models having these functions.
Start The GREATWAVES lit On
1. Select a course.
2.Press the button to choose the time before operation startsPreset start .
3.Press [Start/ ] to commence the operationHold Preset
Choose the course Start
On Setting preset time
Press the [ ] button repeatedly , to see time choices ,the time
should be set before starting the course. If you want to set the Preset time ,
after the course has already started, the on/off button should be pressed to
reset the course
Preset Preset Preset
Caution!
If there is any interruption in the power supply while the machine is operating,
a special memory stores the selected program and recalls the memory setting
when the power is restarted.
GREATWAVES is able to shorten wash time by special rhythm and
water flow.
CHILD PROOF
To avoid mis operation by children.
Start To activate press
the two buttons at the same
time
CHILD PROOF
and hold about 3 sec."
•
• The “ CHILD ” will lock all buttons except [ On/Off ].
If this mode is set to ON and the lid opened during operation, the buzzer beeps ,
the washer stops water supply and stops wash/spin operation, and drains water from
wash tub approximately 20 seconds of the lid opening.
PROOF
Caution!
On
The digital tube is
displayed as”CL”
.

16
OPERATION
Water Level
Course
Personalized setting of washing course
The user can personalize the settings ( )
according to the actual needs.
course/water level /preset time etc.
The user
according to the need. Detailed operations are as follows for different
models:
can set combinations of washing, rinsing and spinning freely
Operations of washing process
Wash
StartOn
+
Set Soak/Wash/Spin time
and number of rinse.
On Start
Preset
Soak
On
Press the PROCESS button
Start
Rinse
On Start
Press the SET button
Set soaking time
Press the PROCESS button Press the SET button
Set washing time
Press the PROCESS button Press the SET button
Set times of rinses
Spin
On Start
Press the PROCESS button Press the SET button
Set spinning time
Note: other process combinations are similarly set, as the above examples.
Note!
You can choose the following parameters : SOAK:0,10,20,30,40,50,60minutes
WASH 15 20minutes RINSE 1-4times SPIN:1 9minutes.: - : -
When pilot lamp besides of process selected flashes, press the SET button to
select time or number of cycles.

10
17
Washing TableCourse
OPERATION
Courses are available according to the laundry type.
Course
REGULAR: Standard fabric washing program
Washing is done once, twice for rinsing and the spin time is longer.
.
SPEED: Suitable to wash lightly- stained clothes .
MEMORY:
JEANS: Suitable to wash denim.
HEAVY WASH:
BLANKET:
heavily-stained/thick clothes.
The wash time is longer, the water action stronger, so the
washing effect is better.
DELICATE: Mid/High/Low water level selection, the tempo is soft, slow
washing and spinning speed, for minimal wear and deformation.
With intermittent spinning the dirt on the inner & outer surfaces
of the drum, as well as the are removed.pulsator
TUB CLEAN:
Memory is the setting last time user choose. To recall the memory ,
press Power on ,select the memory course and the stored cycle
will come up

OPERATION
Recommended Detergent Amount
10
18
Rated capacity(kg)
Manual Water
Level Setting Detergents Softener
Powder Liquid Normal
type
Concentrated
type
9kg
6kg
3kg
1kg
49L
40L
31L
17L
Approx. 90g
Approx. 50g
Approx. 30g
Approx. 11g
Approx. 45mL Approx. 70mL
Blanket
7kg 8kg
58L
49L
33L
18L
Approx. 30mL
Approx. 20mL
Approx. 10mL
Approx. 45mL Approx. 70mL
Approx. 18mL
Approx. 36mL
Approx. 55mL
Approx. 23mL
Approx. 9mL
Approx. 12mL
Approx. 18mL
Approx. 23mL
Note!
This is just for reference.
(2gear) (2gear)
(4gear) (4gear)
(6gear) (6gear)
(8gear) (8gear)

10
19
• Before your maintenance starts, please unplug the machine and close the tap.
Cleaning the cabinet
Proper maintenance the washing machine can extend its
working life. The surface can be cleaned with diluted
non-abrasive neutral detergents when necessary. If there is
any water overflow, use cloth to wipe it off immediately.
No sharp items are allowed.
of
a soft
Formic acid and its diluted solvents or equivalent are forbidden, such as
solvents or chemical products ,etc.
•
alcohol,
Warning!
Note!
Cleaning And Care
Cleaning the inlet filter
• Inlet filter must be cleaned if pressure of water from the inlet drops.
Washing the filter in washing machine:
1.Screw off the inlet pipe from the of the
machine.
4.Reconnect the inlet pipe.
the
back
2.Pull out the filter with ong nos
pliers and reinstall it back after being
washed.
a pair of l
3.Use to clean the filter.a brush
Note!
1.There is a built-in lint filter in your washer. It
can help to collect lint during washing cycle.
2.It is suggested to clean the lint filter every
10 cycles.
3.Take it out and clean the filter with water.
Then place it back into the washer.
Lint filter cleaning
MAINTENANCE
e
