Tosibox Lock 200 User manual

Lock 200
Quick Start Guide v1.5
Copyright © Tosibox Oy, 2017
Matching the Lock with the Key
Deploying into Broadband Networks
1. Connect an Internet-connected ethernet cable
to the Lock’s WAN port .
2. Plug the devices into the Lock’s LAN ports (LAN
1-3). If the devices have static IP addresses,
please see Deploying the Lock in the TOSIBOX®
user manual.
1
2a
TOSIBOX®Lock
TOSIBOX®Key
AC Adapter
Power 8-27V DC
1. Connect the AC adapter to the Lock and wait for 2 minutes.
2. Insert the Key into the USB port of the Lock. When the LED on the Key
turns off or the Info LED on Lock front panel stops blinking, (after approx.
10 seconds) the matching is complete and you can remove the Key from
the USB port.
3. Go to if deploying into broadband networks (ethernet) or if
deploying into mobile networks. If deploying Locks as DHCP client into
existing networks, please see the TOSIBOX®user manual.
Internet /xDSL router
WAN
2a 2b
VPN tunnel through Internet
PC
TOSIBOX®
Mobile
Client
TOSIBOX®
Key
W
A
N
L
A
N
Firewall
TOSIBOX®
Lock
HMI
PLC
Camera
PC

Deploying into Mobile Networks
2b
Using the Key
3
1. Connect a computer to the Lock’s service port with an ethernet cable.
2. Type http://172.17.17.17 into your browser’s address field to access the Lock’s user interface. Log in
using “admin” account. The password can be found on the bottom of the Lock. Select Network > USB
modem and either use the Automatic APN setting or fill in the APN according to your mobile operator
settings. Enter PIN code if necessary. Click Save.
3. Plug a supported USB Modem into the USB port of the Lock.
4. Plug network devices into the Lock’s LAN ports (LAN 1-3). See Deploying the Lock in the user manual for
static IP configurations.
5. Verify on the status page of the Lock user interface that Internet connection is OK.
For more information and latest supported modem models visit: www.tosibox.com/support
USB modem
Insert the TOSIBOX®Key into the USB port of your computer to install the Key software.
The TOSIBOX®Key user interface illustrated above shows all Lock devices serialized to the Key and the network
devices connected to them. For more options click or icon.
The Lock is connected to the Internet and the Key has a remote connection to the Lock.
TOSIBOX®Quick Start Guide v1.5 www.tosibox.com [email protected]
The Lock is not connected to the Internet.
The Lock is connected to the Internet, but the Key doesn’t have a remote connection to the Lock.
www.tosibox.com/support/
Download TOSIBOX®user manual
www.tosibox.com/
Lock_200_manual_en.pdf
This product is CE marked and compliant with the Directive 2014/35/EU and
2014/30/EU. The relevant Declaration of Conformity is available at:
www.tosibox.com/product/lock-200/EU-DoC
Federal Communication Commission
Interference Statement
This device complies with FCC part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user´s authority to operate
this equipment.
This device is UL listed in USA and Canada with UL file number E474664.
In Oulu, 02-May-2017
Tosibox Oy
Tero Lepistö, CEO
TOSIBOX®Mobile Client
Declarations of Conformity
Proc. Cont. Eq
E474664
US Patents: US8831020.
Patents pending: US14/119753,
US14/370872, US14/390153
