Totevision LCD-1901HDL User manual

Display:
Back Light:
Input Signal:
PC compatibility:
Dot Pitch:
Colors:
Number of Pixels:
Viewing angle L/R/T/B:
Pixel Configuration:
Input Signal Level:
Speakers:
Speaker Amplifier:
LCD-1901HDR: Dimensions (WHD):
Actual visible screen size (WH):
Operating temperature:
Power Requirement:
Power Consumption:
Includes switching power supply:
Rear Terminal Connections:
LCD-1901HDL: Weight:
LCD-1901HDR: Weight:
19" TFT LCD active matrix
Built-in CCFT
Composite NTSC/PAL (auto switching),
S-Video, Analog RGB, component
XGA, SVGA, VGA, MAC II
0.25875 (H) x 0.25875(V)mm
6-bit, 262, 144
1,024,00 dots
65/65/50/50
Stripe
1.0V P-P (positive) 75 Ohm
8 ohms, 2 W, 28 x 40mm oval type x 2
2 W x 2 @ 10% THD, 100 mV
19" x 12.3" x 12.1 (Occupies 7 RU)
412 x 258mm / 16.2" x 10.1"
32~122°F or 0~50°C
Regulated 12VDC, 3A, negative ground
Part No. DC-1500 required for use in vehicles
9.6 W (max)
100 ~ 240VAC, 47 ~63Hz
BNC video IN/OUT, S-Video jack
3 RCA IN jacks (composite, audio L/R),
3.5 stereo audio OUT jack, 2.1mm DC IN jack
15-pin mini D-sub (female), RCA y/Pb/Pr jacks,
external IR jack, RCA video OUT jack for video 1 or 2
9-pin RS-232 jack
Net: 4.9 kg. /10.9 lbs Gross: 6.1 kg. /13.5 lbs.
Net: 4.9 kg. /10.9 lbs Gross: 6.1 kg. /13.5 lbs.
LCD-1901HD
LCD-1901HDL
LCD-1901HDR
• Displays 16:9 and 4:3
• Front controls for power menu, up/down, select
• On-screen display for: brightness, contrast, back light, hue, volume
• IR remote control
• Composite x 2, S-Video, component, and PC capability
• Active matrix technology allows wide viewing angle & eliminates distortion
• Anti-glare surface treatment provides enhanced viewing pleasure
• Case made of durable metal
• Built-in removable desk stand included
• Response Time: 16mS
Active Matrix 19" Color LCD Monitors
The Biggest Thing
in HD LCD Monitors
1319 Dexter Ave. N. • Ste. 020 • Seattle, WA 98109
Tel: [phone] • FAX: [phone]
E-mail: [email protected]
http://www.totevision.com
Specifications subject to change without notice ©2008S ToteVision
• HD compatible (supports 480p/i, 720p, 1080p/i)
• RS-232 feature allows external devices to
control the monitor through the serial port.
• Underscan capability
Resolution:
Brightness rating:
Contrast Ratio:
1440 (H) x 900 (V) dots
300 cd/m² (Nit)
800:1
LCD-1901HDR Rack Mount Unit
LCD-1901HDL Unit in Flush Mount Kit
Dimensions (WHD): 19-3/8" x 13-5/16" x 2-5/16"
Installers Cut-Out (WH): 18" x 12-1/16"
LCD-1901HDL Flush Mount Unit
