Toto TBW01004U4 Installation instructions

TBW01004U4
Round Showerhead 2 Mode
FEATURES
• WaterSense®certified high-efficiency
1.75 gpm (6.6 lpm)
• Balanced Comfort Wave™ technology with wide
coverage rinse & wash
• Bathing shower Warm Spa™ Technology
• 8.5" (220 mm) diameter spray face
• Rubber nozzles to prevent lime scale build up
• Meets 2018 California water efficiency appliance
CEC regulations
• Includes matching escutcheon
• Shower arm sold separately
CODES/STANDARDS
PRODUCT SPECIFICATION
COLORS/FINISHES
#CP Polished Chrome
COMPATIBLE COMPONENT (Sold Separately)
Product shall be TOTO Model TBW01004U4#___.
Product shall have a maximum flow rate of 1.75 gpm
(6.6 lpm). Product shall have 2 shower modes: Comfort
Wave and Warm Spa. Product shall have 8.5" (220
mm) diameter spray face. Product shall have rubber
nozzles to prevent lime scale build up. Product shall
have meet 2018 California water efficiency appliance
CEC regulations. Product shall include matching
escutcheon. Product shower arm sold separately.
• Meets or exceeds ASME A112.18.1/CSA B125.1
• Certifications: IAPMO(cUPC), State of
Massachusetts, EPA WaterSense, and others
• Code Compliance: UPC, IPC, NSPC, NPC Canada,
CEC, DoE, and others
• Complies with CA Prop 65 warning requirements
TS110MW16: Rain Shower Arm Wall Mount 16"
TS110MC6: Rain Shower Arm Ceiling Mount 6"
Please note the following components
are sold separately
TS110MW16: Rain Shower Arm Wall Mount 16"
TS110MC6: Rain Shower Arm Ceiling Mount 6"
Certified by
IAPMO R&T
Comfort Wave Warm Spa
WARM SPA COMFORT WAVE ACTIVE WAVE SOFT FLOW ZERO DIMENSION
WARM SPA COMFORT WAVE ACTIVE WAVE SOFT FLOW ZERO DIMENSION

SPECIFICATIONS
TBW01004U4
INSTALLATION NOTES
Ph: [phone] | Fax: [phone] | www.totousa.com | © TOTO USA #SS-01359 v.01
Round Showerhead 2 Mode
Material ABS & POM
Maximum
Flow Rate 1.75 gpm (6.6 lpm)
Warranty Limited Lifetime for Residential Use
One Year for Commercial Use
Shipping Weight 4.45 lbs
Shipping
Dimensions 14-1/4"L x 10-3/4"W x 7"H
Use with TS110MW16: Rain Shower Arm Wall Mount 16"
or TS110MC6: Rain Shower Arm Ceiling Mount 6"
(Sold separately)
DIMENSIONS
TBW01004U *
Finished wall
surface
Note: The unit of above dimension is inch (mm); the dimension in [ ] is for reference only.
Shower arm and mounting bracket are not included.
1/2"NPT
Φ8-11/16"(Φ220mm)
16-1/8"(409mm)
15-9/16"~15-15/16"(395mm~405mm)
[2-3/8"(60mm)]
[4-5/16"(110mm)]
[5-13/16"(147mm)]
13/16"(20mm)
Φ3-1/8"(Φ80mm)
0 100 200 300 400 500 600
0.0
0.8
1.5
2.3
3.0
3.8
4.5
5.3
6.1
6.8
7.6
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2
0 10 20 30 40 50 60 70 80 90
Pressure(kPa)
FlowRate(lpm)
FlowRate(gpm)
Pressure(psi)
ComfortWave,
WarmSpa

TS362P
Oberon®Round Pressure Balance Valve Trim
FEATURES
• Clean & simple design trim made of durable brass
in a reflective chrome finish
• Lever handle
• ADA Compliant/Universal Design
• For use with Pressure Balance Valve model TSPTM
CODES/STANDARDS
• Meets or exceeds ASME A112.18.1/CSA B125.1
• Certifications: IAPMO(cUPC), State of
Massachusetts , City of Los Angeles, and others
• Code compliance: UPC, IPC, NSPC, NPC Canada,
and others
• ADA compliant
PRODUCT SPECIFICATION
COLORS/FINISHES
#CP Polished Chrome
Pressure balance valve trim shall have a lever handle.
Product shall be TOTO Model TS362P#CP and
required valve shall be TSPTM (sold separately).
OPTIONAL ACCESSORIES
• THP5108 - Extension Kit Oberon

SPECIFICATIONS
TS362P
INSTALLATION NOTES
VALVE REQUIRED: Pressure balancing valve model
TSPTM (sold separately).
Ph: [phone] | Fax: [phone] | www.totousa.com | © TOTO USA #SS-01240 v.02
Oberon®Round Pressure Balance Valve Trim
Material Brass & Zinc
Warranty Limited Lifetime for Residential Use
One Year for Commercial Use
Shipping Weight 3 lbs
Shipping
Dimensions 8-1/2"L x 7-1/2"W x 5-1/2"H
DIMENSIONS
Min: 1-⁄" [49mm]
Max: 2-⁄" [68mm]
3-⁄"80mm
3-⁄"80mm
Finished
Wall Surface
Valve port
C
L
59mm2-⁄"
⁄"9mm
Finished
Wall Surface
Valve port
C
L
2-⁄"59mm
⁄"9mm
7-⁄"180mm
7-⁄"180mm
7-⁄"180mm
Min: 1-⁄" [49mm]
Max: 2-⁄" [68mm]

TSPTM
Pressure Balancing Valve
FEATURES
• Corrosion resistant
• Anti-scald valve
• Adjustable temperature limit stop
• Tub port for use with diverter tub spout
• Integral shut-offs / check valves
• 1/2” NPT / sweat connections
• Back-to-back installation compatible without
cross-over piping
• Optimized for minimum flow rate of 1.5 gpm (5.7 lpm)
CODES/STANDARDS
PRODUCT SPECIFICATION
• Meets or exceeds ASME A112.18.1/CSA B125.1,
ASSE 1016
• Certifications: IAPMO(cUPC), State of
Massachusetts, City of Los Angeles, and others
• Code Compliance: UPC, IPC, NSPC, NPC Canada,
and others
Pressure balancing valve shall have anti-scald protection
and an adjustable temperature limit stop. Valve shall
have tub port for use with diverter tub spout. Valve shall
have integral shut-offs / check valve. Valve shall have
1/2” NPT / sweat connections. Valve model shall be
TSPTM. Requires pressure balance trim.

TSPTM
Pressure Balancing Valve
#SS-00865, v.03Ph: [phone] | Fax: [phone] | www.totousa.com | © TOTO USA
These dimensions and specifications are subject to change without notice
*Measured with tub spout TS210EV
SPECIFICATIONS
• Recommended
Operating Pressure 20 psi - 80 psi
• Warranty Lifetime Limited Warranty
(Residential Use)
One Year (Commercial Use)
• Material Brass
• Shipping Weight 2.6 lbs.
• Shipping Dimensions 5”L x 5”W x 4-7/8”W
5-1/16" (129mm)
3-3/4" (95mm)
Tub Outlet
Plug (not included)
If Unused
Shower Outlet
Cold Inlet Hot Inlet
ø5" (127mm)
Required Hole
4-11/16" (119mm)
Max: 2-11/16 (68mm)
Min: 1-11/16" (43mm)
Valve Port
C
L
Finished
Wall Surface
Valve shown with plaster guard removed
All Ports 1/2" NPT/Sweat Combination
0.0
3.8
7.6
11.4
15.1
18.9
0 100 200 300 400 500
0.0
1.0
2.0
3.0
4.0
5.0
6.0
0 20 40 60 80
Flow rate (lpm)
Pressure (kPa)
Flow rate (gpm)
Pressure (psi)
TRIM REQUIRED:
Pressure balance trim sold separately.
Tub spout must be installed 12" ± 1" below
valve center.
The showerhead must be installed 40" or more
above valve center.
INSTALLATION NOTES
12" ± 1”
305 mm ±
25 mm
~4-6" [~102-152"]
~78-82"
[~1920-2080 mm]
Tub Rim
Tub And Shower Installation
Dashed Pipework and Components Not Included
Tub Floor
40” or more
1016 mm
or more

Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
[phone] or [phone] when calling from outside of U.S.A.
Installation and Owner’s Manual
Manual de Instrucciones y del Propietario
Manuel d’Installation et d’Utilisation
16” Shower Arm (Wall Mount)
Brazo de la ducha de 16 in (montage de techo)
Bras de douche de 16 po (41 cm) (montage mural)
TS110MW16

2
ENGLISH
TABLE OF CONTENTS
THANKS FOR CHOOSING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Thanks for Choosing TOTO! .............................................................................. 2
Warnings............................................................................................................... 2
Common Tools Needed...................................................................................... 2
Before Installation................................................................................................ 3
Care & Cleaning................................................................................................... 3
Installation Procedure.......................................................................................... 4
Warranty................................................................................................................ 5
Rough-In Dimensions ....................................................................................... 14
WARNINGS
COMMON TOOLS NEEDED
For safe operation, please observe the following:
Recommended operating pressure:
Minimum pressure.........20 psi (0.14 MPA), dynamic
Maximum pressure........80 psi (0.55 MPA), static
Hot water supply temperature should not exceed 160°F (71°C).
Do not use steam for the water supply.
Do not use the product at an ambient temperature below 32°F (0°C).
Pipe Tape Adjustable
Wrench
Phillips (2 “1”)
Screwdriver

3
ENGLISH
BEFORE INSTALLATION
CARE & CLEANING
Your new shower arm is designed for years of trouble-free performance. Keep
it looking new by cleaning it periodically with mild soap, rinsing thoroughly
with warm water and drying with a clean, soft cloth. Do not use abrasive
cleaners, steel wool or harsh chemicals, as these will dull the finish. Failure to
follow these instructions may void your warranty.
Observe all local plumbing codes.
Make sure the water supply is shut off.
Read these instructions carefully to ensure proper installation.
Make sure there are adequate mounting supports.
TOTO reserves the right to update the product design without notice.
Check to make sure you have the following parts indicated below:
Shower Arm
Lag
Screws (4)
Washers (4)
Shower
Flange

4
ENGLISH
INSTALLATION PROCEDURE
CAUTION:
Product being installed onto shower arm is heavy. Make sure there is
adequate mounting support prior to installation.
Thoroughly clean and remove debris from the water supply pipe be-
fore installation to prevent clogging the spray outlet.
To avoid leakage, do not move the showerhead after installation.
1. Slide the shower flange onto the shower arm assembly.
2. Wrap the shower arm threads with pipe tape. Screw the shower arm
into the supply line.
3. Rotate flange as shown to avoid puncturing the supply line.
4. Drill four (4) 11/64” diameter pilot holes before fastening lag screws.
5. Secure the shower flange with the lag screws.
6. Secure the shower arm by tightening the shower flange nut.
Shower Arm
Flange
Supply Line
Lag Screws
Recommended
Mounting Support
Washers
Nut
Elbow
Shower
Flange
Supply
Line
Studs
2x6
Brace
7/8”-1”
Clearance
Hole
