tousek PULL T24 User manual

Mounting and installation manual
Sliding gate operators
PULL T24, -T24speed
V 2.6.004
Safety Sensor
b
y
T
Ü
V
-
S
ü
d
I
N
I
T
I
A
L
T
E
S
T
UNDER
EN 13241-1*)

- 2 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
This manual is the sole property of the TOUSEK Ges.m.b.H. and may not be made available to competitors. All rights reserved. No part of it may be reproduced without our prior
written permission. We will not accept liability for any claims resulting from misprints or errors. This edition of the manual replaces all earlier publications of the same.
Index
General warning and safety details.................................................................................................................. 3
1. Notes, general characteristics, function, technical data ................................................................................... 4
2. Mounting ........................................................................................................................................................ 5
Emergency release in case of power failure (note for the user) ................................................................ 8
3. Control unit, overview....................................................................................................................................... 9
Warnings - connection works ................................................................................................................... 10
Programming, Structure of the menu ................................................................................................. 11, 12
Connections and adjustments ................................................................................................................. 13
Button/switches................................................................................................................................... 13
Safety.................................................................................................................................................. 15
Motor................................................................................................................................................... 19
Operating mode .................................................................................................................................. 20
Lights/lamps........................................................................................................................................ 21
Diagnosis ............................................................................................................................................ 23
4. Connection of radio receiver ......................................................................................................................... 24
5. Initial operation .............................................................................................................................................. 25
5.1 Battery connection ................................................................................................................................... 27
6. Error diagnosis ............................................................................................................................................... 28
7. Cable plan ...................................................................................................................................................... 29
8. Dimensioned drawing .................................................................................................................................... 30
Declaration of incorporation .......................................................................................................................... 31

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 3 -
GENERAL WARNING AND SAFETY NOTES
• These installation and operating instructions form an integral part of the product “sliding gate operator”. They have been
specically written for professional installers trained and skilled in the trade and should be carefully read in their full length
before carrying out the installation. They describe the proper installation and operation of the sliding gate operator only,
not of the overall device “automatic gate”. After the installation this manual has to be handed over to the user.
• Installation, connection, adjustments, putting into operation, and servicing may only be carried out by trained profession-
als in full accordance with these installation- and operating instructions.
• Before carrying out works at the gate-system, the power supply has to be turned o󰀨.
• The EU Machine Directive, laws and rules concerning the prevention of accidents, and laws and standards which are in
force in the EU and in the individual countries have to be strictly followed.
• The TOUSEK Ges.m.b.H. cannot be held liable for any claims resulting from disregards of the laws and standards in
force during the installation and operation.
• The packaging materials (cardboard, plastic, EPS foam parts and lling material etc.) have to be properly disposed of
in accordance with the applying recycling- and environmental procection laws. They may be hazardous to children and
therefore have to be stored out of children´s reach.
• The product is not suitable for installation in explosion-hazardous areas.
• The product may only be used in accordance with its original purpose, for which it has been exclusively designed, and
which is described in these installation and operating instructions. The TOUSEK Ges.m.b.H. rejects any liability if the
product is used in any way not fully conforming to its original purpose as stated herein.
• Children have to be instructed, that the gate facility as well as the belonging parts may not be used improperly, e.g. for
playing. Furthermore handheld transmitters have to be kept in safe places and other impulse emitters as buttons and
switches have to be installed out of children‘s reach.
• Before beginning with the installation the installer has to make sure that all mechanical components of the gate facil-
ity, like carrier prole/rail, gate frame and panels, guiding elements etc. are su󰀩ciently supportive and resistant for the
purpose of gate automation.
• All electrical installations have to be made in full conformity with the applying rules and laws (e.g. using a fault current
circuit breaker, proper grounding etc.).
• An all-pole disconnecting main switch with a contact opening-gap of minimum 3 mm has to be foreseen.
• The electric motor heats up during operation. Therefore the device should only be touched after it has cooled o󰀨.
• After installation the proper function of the gate facility and the safety devices has to be checked!
• The TOUSEK Ges.m.b.H. rejects any liability for claims resulting from usage of the product in combination with compo-
nents or devices which do not fully conform to the applying safety laws and rules.
• Only original spare- and replacement parts may be used for repair of the product.
• The installer has to inform the user about all aspects of the automatic operation of the complete gate facility, as well as
about emergency operation. The installer further has to supply to the user all instructions relating to the safe operation
of the gate facility. The installation and operating instructions also have to be handed over to the user.
• Please notice that the warranty will not be applicable if the label with the engine number has been removed or
damaged.
Maintenance
• Maintenance works may only be carried out by qualied personnel.
• Check the proper sensitivity setting of the ARS safety reverse system once a month.
• Check the proper function of the emergency release mechanism periodically.
• Check if all mounting screws are securely fastened periodically.
• Remove dirt deposits from the operator and gear rack periodically.
• Maintenance and servicing of the complete gate facility has to be carried out according to the gate builder´s/
installer´s instructions.

- 4 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
Caractéristiques PULL T24, -T24speed
• Programmable control panel accessible from exterior with illuminated
display in english
• Direct connection of 8,2 kOhm contact barriers (safety sensing edges-
2-channels)
• Adjustable soft stop (no loss of force even with reduced revolution speed)
• Three operating modes (impulse, automatic and dead man)
• Adjustable partial opening
• Built in control board in separate housing
• Safety system ARS (automatic reversal system)
• Self locking worm gear
• Emergency release, lockable with prole half cylinder (3 keys included) -
changeable, thus incorporation into an existing house key system is possible.
• Backup battery can be integrated (optional)
• 24V Motor
• Drive unit (gearbox unit) made of steel and runs in an oil bath
• Worm gear and worm wheel made of tempered steel
• Permanently selearning force
• Current consumption in standby is minimal thanks to switch-mode power supply
•
1. General Sliding gate operator PULL T24, -T24speed
Technical data
Sliding gate operator PULL- T24 T24speed T24 T24speed
Control board intégrée Max. drive distance 30m
Power supply
Motor tension
230Va.c. 50Hz
24V d.c. Duty cycle (S3 mode) 40–80%
Max. current consumption (excl.
equipment) 1A Ambient temperature -20° +40°C
Gear wheel Z16M4 Z20M4 Protection class IP44
Max. gate weight 600kg 400kg Speed sensor
Speed 13m/min 16m/min Article number 11110540 11110550
Torque 20Nm
Optional equipment
pluggable receiver • addtional module for courtyard lamp/control lamp • additional module for
evaluation of gate status • bracket with cap rail included • radio transmission system TX 310 •
inductive system TX 400i
*atlowtemperaturesor with rough running gates a reduction in speed ispossibledependingonsystem used (24V DC motor)!
Motor selection by using a spring scale T5 T8 T10 T15 T24 T24speed
Attach the spring scale to the gate at approx. the height of the rack. Then pull
horizontally and without rocking at motor speed. Compare the max. detected
tractive force with the guide values listed on the right.
up to
20kg
up to
30kg
up to
40kg
up to
60kg
up to
25kg
up to
20kg
General
During the development of the new operator generation Tousek PULL T24, -T24speed special attention has been paid to a quick and simple
installation and a troublefree operation, together with the proven quality and reliability. Accordingly, many clever details have been built into
the operator - from the automatic learning of gate end positions, to the control board with removable clamps an integrated safety sensing edge
analysis, to an easy programmable text display - which make it particularly user-friendly. The drive unit itself consists of an electric motor and
a worm gearing, accommodated in a robust aluminium housing, and - together with the integrated microprocessor control unit and the safety
reverse system ARS - forms a compact device with small overall dimensions. The safety reverse system ARS senses obstacles during open-
ing and closing of the gate and permits a continuous adjustment of the drive force. Following the Tousek tradition, all operator components have
been built in a particularly robust and resistant way to guarantee the safe and reliable operation even in the most adverse weather conditions.
Additional improvements are for example: control board with dispay is accesible from outside, the separate control board housing, which double pro-
tects this sensible part, or an oil bath which ensures that the motor/gearing components can move in an optimal way in all temperatures with perfect
lubrication and cooling e󰀨ect. The installation of the PULL T24, -T24speed is possible for new or already exsting sliding gates in a simple and fast way.
Functions
The integrated control board has three operation modes : impulse mode (with button/switch function open and close), automatic mode
(automatic closing) and dead-man mode (the gate moves as long as the button/switch is pressed)
Not only the possibility of connecting a button/switch OPEN / CLOSE / STOP, photocells and a safety device, but also a pedestrian entry
button/switch which enables the partial opening of the gate. The system has 230V output terminals, for connecting a signal lamp. Further it´s
equipped with slots for a pluggable radio receiver and an additional module (for courtyard lamp or for evaluating the gate state).

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 5 -
2
5a
11
Technical layout PULL T24, -T24speed
2. Installation Sliding gate operator PULL T24, -T24speed
3
1
4a
4
5
6
6a
6b
9
10
8
General installation notes
Before installing the Tousek PULL T24, -T24speed sliding gate operator we recommend checking the following points:
• Checking the gate structure:
On a gate which travels on oor rails please check the bottom rollers and the upper guide rollers and make
sure that there is no undue friction or jamming.
On a cantilever gate please check if the gate can be moved out of its end-positions without undue e󰀨ort.
• The gate must travel in a stable manner without lateral movements of the gate panel.
• Make sure that the gate travels in a regular way without undue friction or jamming along the whole travel length.
• Make sure that there are stoppers at both ends of the track, preventing the gate from running over its travel limit.
(5) Control board
(Display and control buttons)
(5a) Removable display cover
(6) Control housing
(6a) Cover for optional, pluggable
radio module
(6b) Indication for opt. additional module
(7) Sensor
(8) Motor condenser
(9) Motor-/gear unit
(10) Threaded hole for attachment of
motor cover
(11) Motor cover
(1) Lockable emergency release (PHZ)
(2) Gear wheel
(3) Cable ttings
(4) Ground plate
(4a) Slotted holes (4x) for mounting on
the foundation/ground
7
ATTENTION !
• ATTENTION: Mechanical limits are necessary!
• ATTENTION: the sliding gate operator PULL T24, -T24speed has been developed and designed for the auto-
mation of horizontally travelling sliding gates. Gates on sloping tracks (i.e. gates which follow an inclined,
non-horizontal, travel path) must not be automated without additional safety devices (which make sure that
the gate cannot start moving on its own from any gate position).

- 6 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
NOTE concerning cable laying
• The electric cables have to be laid in insulating sleeves which are suitable for underground usage. The insulat-
ing sleeves have to be lead into the inner of the operator housing (see picture).
• 230V cables and control lines have to be laid in separate sleeves.
• Only double-insulated cables, which are suitable for underground usage (e.g. E-YY-J) may be used.
•
In case that special regulations require another type of cable, cables according to these regulations have to be used.
2.1 Installation of the motor Installation
(1) lockable emergency release (PHZ)
(2) gear wheel
(3) cable
(4) ground plate
(4a) slotted holes (4x) for connection on
the ground
(Z) steel gear rack
After installing the protection tubes (check cable exit of operator (3)) and having nished the concrete foundation, the
motor has to be bolted through the 4 slotted holes (4a) to the concrete foundation. It is particularly important that the
operator is mounted parallel to the gate panel, and that the measurements given in the drawing are kept.
63
22
121 (PULL T24speed) 113 (PULL T24)
25
2
Z
4
1
3,4
gear wheel:
PULL T24speed : Z20M4, r44
PULL T24
: Z16M4, r36
Foundation
43
4a
272
48,5
58,5
40
85
52
13,5
119,5
309
30,530,5
18,5 18,5
Dimensions in mm

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 7 -
approx.
1mm
Attention
• Do not weld the individual gear rack elements
together!
• Disengage the motor from the output drive pinion with
the emergency release lever (see emergency release for
instructions) and open the gate completely.
• Install the spacer tubes (D) with the help of the bolts and
washers on the rst meter of gear rack
• Make sure that the bolts/screws sit in the top end of the
vertical slots (L), then tighten them.
• Place the rst gear rack element on the drive pinion and
x it in place with a screw clamp.
• Move the gate by hand until reaching the end of the rst
gear rack element, then weld the rst, second, and third
spacer tube to the gate
• Proceed with the other gear rack elements in the same
manner.
• Before xing the second meter of gear rack it is es-
sential to place another gear rack element under the
rst and second gear rack elements, thereby making
sure that the gearing module between the two gear
rack elements will be exactly kept (see illustration).
• After installation of the gear rack please loosen the
fastening bolts slightly and rise the gear rack a little
along the vertical slots, creating a distance of approx.
1 mm between the ank of the drive pinion and the
gear rack.
• The gear rack elements can also be installed without
welding, i.e. by screwing them to the gate frame together
with the spacer tubes. Apart from that the gear rack
elements
2.2 Installation of the gear rack Installation
L
D

- 8 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
2.5 Dismantling
The dismantling of motor is made the other way around of mounting.
Before dismantling please plug o󰀨 power supply of motor !
Handle in picture shows unlocked position
In case of a power failure or other defect the drive pinion
can be disengaged from the gearmotor as follows:
• Switch o󰀨 power supply
• Slide key-cover (A) slightly to the front and turn it away.
Insert the key and turn it clockwise to its limit stop (the
emergency release mechanism can be key-locked both
in the engaged and in the disengaged position).
• Turn the handle 180° counter-clockwise (viewed from
above). The gate can now be manually opened or closed.
Re-engaging the emergency release mechanism:
To return to normal motor operation please turn the handle
back to its original position (i.e. 180° clockwise)
Important
• after the handle is back in normal position, slowly
move the gate manually in its travel direction until
you can hear that the gearing has re-engaged!
Then lock it again and remove the key.
With next command the motor searches the open position (a
new learning of end positions is not necessary).
H
A
• Remove the screw protection cap and turn out the
screw (S).
• Turn the cylinder protection cap down, insert the key,
turn it approx. 90° clockwise, and pull out the cylinder.
• To re-insert the cylinder please carry out the above
steps in the reverse order
S
40
30
Lock half cylinder (PHZ) with
3 keys (product code: 13300220)
2.4 Exchanging the lock half cylinder Sliding gate operator PULL T24, -T24speed
2.3 Emergency release in case of power failure (note for the user) PULL T24, -T24speed

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 9 -
ground
connection
Grounding
The grounding connection is made
on the operator housing with the
designated grounding screw!
K
F
FE ZM
S
D
Elements of control board
(K) Terminal blocks
(KE) Connector for battery 24Vd.c. (optional)
(KM) Motor clamps
(KN) Power supply low tension 24Vd.c.
(S) Sensor plug
(D) Display plug
(FE) Slot for optional radio receiver
(page 24 for connection)
(ZM) Connection slot for optional module
(page 22)
(F) Safety fuse T 4A
1918
KE
– + KM – + KN – +
3. Control board Sliding gate operator PULL T24, -T24speed
Attention
During connection, adjustment and
maintenance works please take care,
that the electronic circuit board won´t
be damaged by moisture (rain).
Important
The optional „tousek-connect“ or the
„tousek service interface“ must
be connected with socket (D)!
Overview of the control unit

- 10 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
signal lamp
230V, 100W
power supply 230V a.c.
violet
input switch-mode power supply
violet 230V a.c.
Contact for photocell
Common PHC-contact
Power supply photocell receiver
Power supply photocell transmitter
common photocell
Main safety sensing edge
Side safety sensing edge
common contact safety edge
Pedestrian-switch
CLOSE-switch
common
Impulse-switch
STOP-contact
3.1 Terminal assignment Sliding gate operator PULL T24, -T24speed
Attention
• Before taking o󰀨 the control cover, the
mains switch must be turned o󰀨!
• If the control is power supplied, its inner part is under
tension.
• In order to avoid electrical strokes, the safety regula-
tions have to be kept.
• The device may only be connected by trained profes-
sionals
• The product is not suitable for installation in explosion-
hazardous areas.
• An all-pole disconnecting mains switch with a contact
opening gap of min. 3 mm has to be foreseen. The
gate facility has to be secured according to the valid
safety regulations!
• IMPORTANT: The control lines (buttons, radio, pho-
tocells, etc.) have to be laid separately from the 230V
lines (supply line, motors, signal lamp).
grey
battery connection 24Vd.c. (optional)
yellow black
motor 24V
red blue Connection block supply and orange supply max. 24Vd.c., 5W (accessory)
pre-wired
40 4143 45 46 3137 32 30 33 34 525150
1
14 10
15 11
L
N
8.k2
8.k2
85
84
16
19
18
17
–
+
–
+
L
N
–
+
-
-
+
24V
=
24V
=
Terminals 40/41 and 40/43
in gate position CLOSE
(ready for use) are in eco
mode (= without tension).
Important: no external ac-
cessories are allowed on
these terminals!
N
The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide
the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation!
Safety sensing edges
Function main safety sensing edge (MCE):
Safety during closing
Function side safety sensing edges (SE):
Safety during opening
MCE
SE
CLOSE OPEN
If no stop switch is connected, termi-
nals 31/37 have to be wire-bridged.

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 11 -
A
T
• Before starting the programming, please choose the language. Use the buttons +or -to choose menu lan-
guage and conrm with .
•
Note: Language selection can also be chosen by pressing the ESC button ( ) for 5s, from any position in menu.
• The program menu is divided into “BASIC SETTINGS” and “MENU CONTROL”
The di󰀨erent menu points are indicated as follows:
= selectable setting = factory settings = status display
Gshows the menu points which are in the “ BASIC SETTINGS”
BASIC SETTINGS
• When entering the programming of the control unit for the rst time you will see the BASIC SETTINGS
• Here the necessary adjustments which are necessary for the use of the operator/gate can be set quickly.
• For advanced settings/programming please choose the menu point “menu (control)”.
MENU CONTROL
• For futher programming you will reach immediatly the MENU (CONTROL) (Basis settings are skipped)
• The menu control includes all kinds of settings.
Programming buttons Adjustment - overview
• For programming please remove cover (A) of control device
(loosen 2 bolts).
• The text display (T) informs you about operating status,
chosen menus and the adjustment of various parameters..
• The programming of the control is carried out with the help
of four buttons (+, -, (=Enter) and (=Escape).
• Scrolling through the available menu points (up/
down) or the adjustment of a parameter (value in-
crease/decrease) is carried out with buttons + and –.
AUTO-COUNT: when holding one of the buttons the value
changes automatically.
• When pressing the -button ea conrmation for entering
the shown menu point, resp. for accepting the shown value
of a parameter is given.
• When pressing the -button you return to the superior
menu point. Possibly changed adjustments of a parameter
are rejected with this button (the former values will remain).
• AUTO-EXIT: if no button is pressed during 1 min. then the
menu switches automatically to the “ready” menu (wihtout
saving changed parameters).
Programming menu Adjustment - overview
3.2 Adjustments - overview Sliding gate operator PULL T24, -T24speed

- 12 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
Main layer Sub layer Settings/adjustments
button/switches
page 13
impulse button  OPEN/STOP/CLOSE
 OPEN/CLOSE/OPEN
 OPEN
 DEAD MAN
*) if impulse button is
set to DEADMAN, then
the pedestrian and
close button are also
set automatically to
DEADMAN mode.
(not selectable under
„pedest.- button“)
)
pedestrian button  OPEN/STOP/CLOSE
 OPEN/CLOSE/OPEN
 OPEN
 Impulse OPEN
 DEAD MAN *)
safety
page 15
Gphotocell  active
 not active
Gmain safety edge  active
 radio edge TX
 TX 400
 not active
Gside safety edge  active
 radio edge TX
 TX 400
 not active
photoc.-function  when closing reverse
 stop - after release open
 during close stop, then close
PHC-pause time  no inuence of photocell
 abort of pause time
 re-start of pause time
 immediate close after opening
PHC-self test  active
 not active
motor
page 19
max. force  50...100% [increment 5 ] = 100%
ARS-response time  0,15...0,95s [increment 0,05] = 0,50s
speed  55...100% [increment 5] = 100%
soft stop way  0...2m [increment 0,1] = 0,5m
soft speed  10...50% [increment 5] = 40%
limit position OPEN  0...-30 [increment 1] = -5
limit position CLOSE  0...-30 [increment 1] = -5
operating mode
page 20
impulse mode  stop, start of pause time
 impulse suppression when opening
 pause time extension
Gopening direction  <<<–left
 –>>> right
Goperating mode  impulse mode
 aut. close 1...255s [increment 1]
partial opening  10...100% [increment 1] = 30%
automatic mode  complete/partial opening
 only complete opening
 only partial opening
pause time logic  no inuence
 always open in automatic mode
lights/lamps
page 21
prewarning OPEN  OFF, 1...30s = OFF
prewarning CLOSE  OFF, 1...30s = OFF
additional module  yard/control light
 status display 1
 status display 2
courtyard light 1)  OFF, 5...950s =
OFF
control lamp 1)  illuminates when opening/closing
 blinks slowly / illuminates / blinks
 illuminates in open position
diagnosis
page 23
status display  status display of all inputs
delete position  NO
 YES
factory setting  NO
 YES
software version  show software version
serial number  show serial number
protocol  show protocol notes
status sensor  show sensor
1) The menu points courtyard lamp and control lamp will only appear on display if in menu
„Additional module" courtyard lamp/control lamp is selected.
Menu structure Adjustments - overview
+
–
integr. control board for sliders PULL T24, -T24speed
ESC ENTER
Note: some adjustments regarding function or operating logic can only be executed if gate is closed and if the display shows „ready“.

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 13 -
• Before taking o󰀨 the control cover, the
mains switch must be turned o󰀨!
• If the control is power supplied, its inner part is under
tension.
• In order to avoid electrical strokes, the safety regula-
tions have to be kept.
• The device may only be connected by trained profes-
sionals.
• The product is not suitable for installation in explosion-
hazardous areas.
• An all-pole disconnecting mains switch with a contact
opening gap of min. 3 mm has to be foreseen. The
gate facility has to be secured according to the valid
safety regulations!
• IMPORTANT: The control lines (buttons, radio, pho-
tocells, etc.) have to be laid separately from the 230V
lines (supply line, motors, signal lamp).
Warning notes
• A general status display of all inputs can be found in the menu DIAGNOSIS / STATUS DISPLAY
3.3 Connections and adjustments Sliding gate operator PULL T24, -T24speed
The di󰀨erent menu points are indicated as follows:
= selectable setting = factory settings = status display
Gshows the menu points which are in the “ BASIC SETTINGS”
As impulse emitters pushbuttons or key switches as well as external radio receivers with potential free make
contacts can be used.
Impulse button (terminals 30/32) Buttons/switches
OPEN/ STOP / CLOSE impulse repetition (factory settings): After a command of the impulse switch the motor
starts an open or close movement. If the impulse switch is pressed again during this movement, the motor stops.
With the next command, the motor drives in the opposite direction of the last gate movement.
OPEN / CLOSE / OPEN impulse repetition: After a command of the impulse switch the motor starts an open or
close movement. If the impulse switch is pressed again during this movement, the motor reverses.
•In this operation mode it is not possible to stop the motor with the impulse switch – it always
travels until reaching an end position. (Opened or closed position).
• for the function OPEN/CLOSE/OPEN we strongly suggest the installation of a photocell!
OPEN: Only open commands are accepted of the impulse switch. Closing the gate with the impulse switch is not
possible.
DEAD-MAN: The motor opens as long as the impulse switch is pressed – closing the gate with the impulse switch
is not possible. As soon as the switch is released, the gate stops. If hold to run operating mode is selected, the radio
receiver slot (FE) is set out of order for reasons of safety.
IMPORTANT: Do not put into operation in dead man mode.
Select only after putting into operation (page 25), if desired.
Button/switches Connections and adjustments

- 14 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
As impulse emitters pushbuttons or key switches as well as external radio receivers with potential free make
contactscan be used.
Pedestrian button (terminals 30/34) Buttons / switches
OPEN/ STOP / CLOSE impulse repetition: An impulse through the pedestrian button-while the gate is in motion-
causes gate stopping. If the gate is within the pedestrian area, then an impulse through the pedestrian button causes
inversion of the direction.
If the gate is in complete open position an impulse through the pedestrian button causes a movement in CLOSE
direction and the gate stopps at pedestrian OPEN position.
OPEN / CLOSE / OPEN impulse repetition:
If the gate is within the pedestrian area, then an impulse through the
pedestrian button causes inversion of the direction.
If the gate is in complete open position an impulse through the pedestrian button causes a movement in CLOSE
direction and the gate stopps at pedestrian OPEN position.
•In this operation mode it is not possible to stop the motor with the pedestrian button – it always
travels until reaching an end position. (Opened or closed position).
• for the function OPEN/CLOSE/OPEN we strongly suggest the installation of a photocell!
OPEN: Only open commands are accepted of the pedestrian opening button. Closing the pedestrian entry with the
button is not possible.
Impulse OPEN: The contact at terminals 30/34 works as a second impulse button with the xed adjustment „OPEN“.
DEADMAN (not selectable): As soon as the Impulse button is set to DEADMEN, automatically the pedestrian- and the
CLOSE button are set to DEADMEN.
The motor opens as long as the pedestrian button is pressed – closing the gate with the pedestrian button is not
possible. As soon as the switch is released, the gate stops.
As CLOSE-buttons you may use pushbuttons or key switches as well as external radio receivers with potential
free make contacts can be used.
CLOSE-button (terminals 30/33) Buttons / switches
•A command with the CLOSE-switch engages closing of gate. In deadman mode the gate closes as long as the
CLOSE-switch is pressed/switched. As soon as switch is released the gate movement stops.
STOP-switch (terminals 31/37) Buttons / switches
• when pressing the stop switch the gate stops in any desired position.
As stop switch a break contact has to be used.
If no stop switch is connected, terminals 31/37 have to be wire-bridged.
37
31
The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide
the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation!

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 15 -
Important
• Jumper J of transmitter and receiver has to
be adjusted in the same way.
Photocells
• The control unit has a power supply connection for a 24V d.c. photocell (PHC):
supply PHC-transmitter: terminals 40/41 supply PHC-receiver: terminals 40/43.
Note: in „gate closed“ position the terminals 40/41 are being switched into energy saving mode (no current)
• The contact has to be closed when using powered and positioned photocells (opening contact).
Connection of the photocell contact: terminals 45/46
• When using two pairs of photocells please do not
install both photocell transmitters/receivers on the
same side (to eleminate interference between both) !
Exception: photocells with SYNC function allow the
installation of both photocell transmitters/receivers on
the same side without causing interference to each
other.
•
Self-monitoring of photocells: The control unit has a monitoring function for the connected photocells. A test will be
triggered by each impulse and will be checked if the receiver of the photocell responds to the signal from the photocell
transmitter. If there is no communication between the photocell receiver and transmitter the control unit responds with an error.
The deactivation of the self-test function is only permitted if the safety installations correspond to the
category 3 !
• The exact function of the photocells depend on the programming of the control unit.
Photocell function please see menu point SAFETY / photocell function or photocell with pause time (page 18)
• Youwillnddetailed information in the corresponding photocell manual.
Standard:
transmitter 1 receiver 1
receiver 2 transmitter 2
With SYNC-function:
transmitter 1 receiver 1
transmitter 2 receiver 2
GPhotocell (Contact: terminals 45/46) Safety
active: to be selected, if photocell should be triggered.
not active: to be selected, if photocell should not be triggered.
Photocell - connection examples
Photocell Tousek LS 26
as safety device
Safety Connections and adjustments
46
45
43
41
40
+
~
-
~
12/24V
J
+
~
-
~
12/24V
NC C NO
J
transmitter receiver
-
-
+

- 16 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
1 2
+ -
~ ~
12/24V
1 2 3 4 5
+ -
~ ~
12/24V
1 2
+ -
~ ~
12/24V
1 2 3 4 5
+ -
~ ~
12/24V
46
45
43
41
40
transmitter 1 receiver 1
receiver 2 transmitter 2
-
-
+
NO NC COM
NO NC COM
Deactivation of SYNC function
• The SYNC function with LS41 is
not possible with this control unit.
For deactivation of SYNC function,
the jumpers J of both transmitters
have to be connected (see picture).
(see manual LS41)
SYNC
J
2 Photocells Tousek LS 41 as safety device
transmitter 1 receiver 1
receiver 2 transmitter 2
Photocell Tousek LS 41 as safety device
transmitter receiver
2 Photocells Tousek LS 45/2 as safety device Photocells Tousek RLS 610 as safety device
-
-
+
46
45
43
41
40
24–230V
a.c./d.c.
24Vd.c.
COM
NO
NC
COM
-
-
+
N.O. COM N.C.
46
45
43
41
40
N.O. COM N.C.
-
-
+
N.O. COM N.C.
46
45
43
41
40

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 17 -
• Connection and detailed information of radio transmission system TX 310 see according manual.
• Connection and detailed information of inductive system TX 400i see according manual.
GMain safety edge (terminals 50/52) Safety
active: to be selected if the contact strip (8,2kOhm) of main safety sensing edge should be evaluated.
radio edge TX: to be selected if safety sensing edge (8,2kΩ) of main entrance edge should be evaluated with the
radio transmission system TX 310.
TX 400: to be selected if safety sensing edge (8,2kΩ) of main entrance edge should be evaluated with the system
TX 400i.
not active: to be selected if the contact strip of main safety sensing edge should NOT be evaluated
GSide safety edge (terminals 50/51) Safety
active: to be selected if the contact strip (8,2kOhm) of side safety sensing edge should be evaluated.
radio edge TX: to be selected if safety sensing edge (8,2kΩ) of side entrance edge should be evaluated with the
radio transmission system TX 310.
TX 400: to be selected if safety sensing edge (8,2kΩ) of side entrance edge should be evaluated with the system
TX 400i.
not active: to be selected if the contact strip of side safety sensing edge should NOT be evaluated.
Safety sensing edges (main and side edge)
• OBSTACLE DETECTION: when a contact strip is
triggered/activated then a change of direction is
e󰀨ected for 1 second. Then the gate stops.
Hence if: safety edges that have to react on obstacles in closing movement have to be serially connected
to the terminals of the main safety edge.
Safety edges that have to react on obstacles in opening movement have to be serially connected
to the terminals of the side safety edge.
Example: W 8,2kΩ nal resistance
1 nal edge
2+3 passage edge
S to control board
When connecting one safety edge a nal edge (1) has to be used.
Side safety sensing edge
Function:
safety during opening
Main safety sensing edge
Function:
Safety during closing
1
W
2 3 S
50
52
50
51
Main safety sensing edge Side safety sensing edge
Important
• After giving the impulse to program the end positions, no other impulse must be given. Also the safety devices
mustn´t be triggered. This would lead to an interruption of the programming process.
• Therefore, the mechanical stops must be set so that the existing contact strips cannot be triggered.

- 18 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
Photocell function Safety
when closing reverse: an interruption of the photocell during closing makes the gate reverse (open). In automatic
mode the gate closes as soon as the pause time has run out. In impulse operation another closing command has to
be given.
stop - after release open: an interruption of the photocell beam during opening or closing makes the motor stop as
long as the photocell stays interrupted. After release of the photocell, the gate opens. In automatic mode the gate closes
as soon as the pause time has run out, in impulse operation another closing command has to be given.
during close stop, then close: an interruption of the photocell during closing makes the motor stop as long as the
photocell stays interrupted. After release of the photocell, the gate opens.
PHC-pause time Safety
no inuence of photocell: the photocell doesn’t have any inuence on the pause time in automatic mode..
abort of pause time: in automatic mode an interruption of the photocell during pause time shortens the pause time.
After release of the photocell the gate starts closing.
re-start of pause time: in automatic mode an interruption of the outer photocell during pause time, restarts the pause
time. As soon as the pause time has run out, the gate closes.
immediate close after opening: If the photocell is interrupted during the opening movement, the gate starts closing
as soon as it reached end position open after release of the photocell.
PHC-self test Safety
active: photocell self-test is executed with an opening impulse (switch, button) in gate position „closed“.
not active: photocell self-test is not executed.
Attention
• The photocell self-test can only be deactivated by selecting „not active“.
• The deactivation of the self-test function is only permittedif the safety installations correspond to the
category 3 !

tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019 - 19 -
Attention
At force adjustment the valid safety regulations and standards have to be strictly followed !
max. force 100% (factory setting) Motor
50–100% adjustable [increment 5]: determines the max. possible motor force.
ARS response time 0,50s (factory setting) Motor
0,15–0,95s adjustable [increment 0,05]: determines, in which time the AR-System responds. The lower the value,
the more sensitive the sensor will react.
speed 100% (factory setting) Motor
55–100% adjustable [increment 5]: determines the speed of motor.
soft stop way 0,5m (factory setting) Motor
0–2m adjustable [increment 0,1]: determines the distance of soft run.
soft speed 40% (factory setting) Motor
10–50% adjustable [increment 5]: determines the speed during soft run.
limit position OPEN -5 (factory setting) Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected OPEN limit position of gate (e.g. for
safety sensing barriers). With adjustment 0 the motor runs to the previously learned open position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
By deleting the limit positions in the menu „DIAGNOSIS / delete positions“ the adjusted value for „limit position OPEN“ will
be deleted as well. The factory setting -5 will be saved.
limit position CLOSE -5 (factory setting) Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected CLOSE limit position of gate (e.g.
for safety sensing barriers). With adjustment 0 the motor runs to the previously learned close position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
By deleting the limit positions in the menu „DIAGNOSIS / delete positions“ the adjusted value for „limit position OPEN“ will
be deleted as well. The factory setting -5 will be saved.
Motor Connections and adjustments

- 20 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
Impulse mode Operating mode
stop, start of pause time: An impulse during the opening movement stops the gate and starts pause time in automatic
operation. When the pause time has run out, the gate closes automatically.
impulse suppression when opening: Commands received during the opening movement are suppressed,
commands during closing are accepted.
pause time extension: A command during pause time restarts the pause time. If this menu point is chosen, an impulse
suppression during opening is active at the same time.
GOpening direction Operating mode
<<<–left: gate opens to the left side (seen from inside)
–>>> right: gate opens to the right side (seen from inside)
This adjustment is ONLY adopted in CLOSED-position.
GOperating mode Operating mode
Impulse mode: Impulse through impulse switch/button or CLOSE-button to start closing of gate.
aut. close 1-255s adjustable [increment 1]: gate closes automatically after the adjusted pause time
(Exception: see adjustment „Automatic mode“ / „only complete opening“).
Partial opening 30% (factory setting) Operating mode
10–100% adjustable [increment 1]: value denes the partial opening of the total opening.
This adjustment is ONLY adopted in CLOSED-position
Automatic mode Operating mode
complete/partial opening: either with complete as well as partial opening, the gate closes automatically after the
adjusted pause time.
only complete opening: only after complete opening, the gate closes automatically after the adjusted pause time.
Exception: If the gate is in partial open position and an impulse for complete opening arrives then the gate opens
completely and after the pause time it returns to partial opening position.
only partial opening: only after partial opening the gate closes automatically after the the adjusted pause time.
Pause time logic Operating mode
no inuence
always open in automatic mode: If “always open in automatic mode” and “pause time” are simultaneaus activated
the automatic mode can be deactivated. An impulse in complete open position causes a switch into “impulse mode”
but only for hte current cycle. So the gate stays in OPEN position. The next impulse closes the gate an the control unit
switched to “automaitc mode” again. This function allows that the entrance of a company site stays open during the day
(rst impulse in complete open position). The gate can be closed with the second impulse e.g. in the evening (second
impulse - for closing the gate and switching to the “automatic mode”). The control unit switches to the “automatic mode”
again (automatic opening and closing of the gate).
Note: An impulse through the pedestrian button in the complete open position doesn´t start the “always open” function.
This action causes a movement in CLOSE direction and the gate stopps at pedestrian OPEN position.
If the gate is in partial open position and „permanent open in automatic mode“ is selected, so it is possible to adjust
permanent partial open for this cycle by giving an impulse via pedestrian button. Permanent partial open can be
nished analogous to the above described method.
left opening
right opening
Operating mode Connections and adjustments
