Tow Tuff TTF-1953SC User manual

Compact Cargo Carrier
OWNER’S MANUAL
WARNING:
Carefully read and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
10092015
Model # TTF-1953SC

Page of 6
2
Thank you very much for choosing this product! For future reference, please complete the owner’s
record below:
Model: TTF-1953SC Purchase Date: _______________
Save the receipt, warranty, and these instructions. It is important that you read the entire manual to
become familiar with this product before you begin using it.
This product is designed for certain applications only. The manufacturer cannot be responsible for
issues arising from modification. We strongly recommend that this product not be modified and/or
used for any application other than that for which it was designed. If you have any questions relative
to a particular application, DO NOT use the product until you have first contacted us to determine if
it can, or should, be performed on the product.
For technical questions, please call 1-218-943-6296.
INTENDED USE
This compact cargo carrier has a 500 lb. load capacity. It is great for hauling sporting goods,
coolers, and much more. It fits 2” x 2” Class III or IV hitch receivers.
TECHNICAL SPECIFICATIONS
Item
Description
Capacity
500 lbs.
Dimensions
53” x 19” x 4”
Construction
Heavy-duty, all steel construction
Hitch receivers
Fits 2” x 2” Class III or IV hitch receivers
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this cargo carrier until they
have read this manual and have developed a thorough understanding of how the cargo
carrier works.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors that cannot be built into this
product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS

Page of 6
3
WORK AREA
•Keep work area clean, free of clutter, and well-lit. Cluttered and dark work areas can cause
accidents.
•Keep children and bystanders away while operating a cargo carrier. Distractions can cause
you to lose control, so visitors should remain at a safe distance from the work area.
•Be alert of your surroundings. Using a cargo carrier in confined work areas may put you
dangerously close to sharp tools and rotating parts.
PERSONAL SAFETY
•Stay alert, watch what you are doing, and use common sense when using a cargo carrier. Do
not use a cargo carrier while you are tired or under the influence of drugs, alcohol, or medication.
A moment of inattention while operating a cargo carrier may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair,
clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught
in moving parts.
COMPACT CARGO CARRIER USE AND CARE
•Do not modify the cargo carrier in any way. Unauthorized modification may impair the
function and/or safety and could affect the life of the equipment. There are specific applications
for which the cargo carrier was designed.
•Always check for damaged or worn-out parts before using the cargo carrier. Broken parts
will affect the cargo carrier operation. Replace or repair damaged or worn parts immediately.
•Do not exceed the cargo carrier load capacity of 500 lbs.
•Distribute the load evenly. Uneven loads may cause the cargo carrier to tip, resulting in
personal injury to the operator or others.
•Use the cargo carrier on flat and level surfaces capable of supporting the cargo carrier and
its maximum load. Pulling or pushing a load on a slanted or uneven surface can result in loss of
control.
•Store idle cargo carrier. When cargo carrier is not in use, store it in a secure place out of the
reach of children. Inspect it for good working condition prior to storage and before re-use.
•Only use the cargo carrier with a properly installed 2” hitch receiver capable of
supporting the cargo carrier and its load.
•Do not allow children to play on, stand upon, or climb into the cargo carrier. The cargo
carrier is not for carrying people or animals.
•Always check hardware and assembled parts after assembling. All connections and
hardware should be tight.
•Be aware of dynamic loading! Suddenly dropping or bouncing a load on the cargo carrier may
create, for a brief instant, an excess load, which may result in damage to the product and/or
personal injury. Additionally, if the vehicle hits bump, a slight play in the receiving hitch or a
movement in the load, could result in a momentary dynamic loading effect that could dramically
increase the actual weight load. Check the hitch-to-carrier connection for any looseness. This
momentary dynamic loading effect could result in damage to the cargo carrier, damage tothe
load, and possible injury.

Page of 6
4
•WARNING: Be aware of the possible risk of fire and damage to property resulting from
the vehicle’s exhaust system pointing at or running near the cargo loaded on the cargo carrier.
Before installing the cargo carrier, check to make sure that the exhaust pipe is not pointing in
the direction of the cargo. Flammable cargo can ignite from exposure to heat. Other cargo can
be damaged from the heat. Always be aware of this potential danger, and never use the cargo
carrier if the risk exists.
•Follow DOT guidelines for installation and use.
•Do not exceed 65 MPH while carrier is attached.
WARNING: The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors which cannot be
built into this product, but must be supplied by the operator.
ASSEMBLY
It is important that you read the entire manual to become familiar with the product BEFORE
you assemble and use the cargo carrier. Before assembling and operating the cargo carrier,
be sure that you have all parts described in the Parts List and Assembly Diagram located on
the last page of this manual.
See Parts Diagram for reference:
1. Align the mounting holes on the ends of the Right Frame (2) and Left Frame (3) with the
mounting holes along the sides of the Post (1).
2. With a wrench (not included), fasten the Frames (2,3) to the Post (1) by using four Connecting
Bolts (10), four Flat Washers (11), four Spring Washers (12) and four Nuts (13).
3. Set the Cross Braces (6) over the Frames (2,3) and fasten the Cross Braces to the Frames by
using four Bolts (7), eight Flat Washers (8), and four Lock Nuts (9).
4. Make sure all connections are tightened securely.
OPERATING INSTRUCTIONS
WARNING: The load weight must be centered or evenly distributed across the carrier
platform. Always use appropriate tie-down restraints to securely attach any cargo loaded
onto the cargo carrier before moving your vehicle any distance. Do not leave loose items on
the platform while operating the vehicle. Always use reflectors. Make certain to use the
appropriate red flags when moving a load. Check with your local traffic enforcement agency
to make certain that you are correctly following all local laws.
a) Have another adult to help lift the cargo carrier.
b) Lift the cargo carrier and place the Post (1) into the 2”hitch receiver mounted to your vehicle.
c) Line up the hole in the Post (1) with the hole in your hitch. With the holes lined up, slide a Hitch
Pin (5) through the holes and insert a Cotter Pin (4).
WARNING: Your cargo carrier can be loaded with up to 500 lbs. of evenly distributed
cargo if an appropriately rated hitch is used.

Page of 6
5
WARNING: The load weight must be centered or evenly distributed across the carrier
platform. Always use appropriate tie-down restraints to securely attach any cargo loaded
onto the cargo carrier before moving your vehicle any distance. Do not leave loose
items on the platform while operating the vehicle.
Note: Any load over 320 lbs. requires a Class 3 hitch on the vehicle.
(Class 2 Hitch = 350 lb. maximum tongue weight, add carrier weight of about 30 lb.)
(Class 3 Hitch = 500 lb. maximum tongue weight)
Always use reflectors. Make certain to use the appropriate red flags when
moving a load. Check with your local traffic enforcement agency to make
certain that you are correctly following all local laws.
MAINTENANCE
•Maintain your cargo carrier. It is recommended that the general condition of any cargo carrier
be examined before it is used. Keep your cargo carrier in good repair by adopting a program of
conscientious repair and maintenance. If any abnormal vibrations or noise occurs, have the
problem corrected before further use. Have necessary repairs made by qualified service
personnel.

Page of 6
6
DIAGRAM & PARTS LIST
Part#
Description
Qty.
Part#
Description
Qty.
1
Post
1
8
Flat Washer M8
8
2
Right Frame
1
9
Lock Nut M8
4
3
Left Frame
1
10
Connecting Bolt
(M10x1.5x80)
4
4
Cotter Pin
1
11
Flat Washer M10
4
5
Hitch Pin, 5/8”
1
12
Spring Washer M10
4
6
Cross Brace
2
13
Nut M10
4
7
Bolt (M8x1.25x35)
4
For replacement parts and technical questions, please call 1-218-943-6296.
WARRANTY
One-year limited parts warranty.
TG
PO BOX 203
Miltona, MN 56354
