Tow Tuff TMD-600 User manual

600LB TRAILER DOLLY
OWNER’S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
01182017
Item# TMD-600

Page of 5
2
Thank you very much for choosing this product! For future reference, please complete the
owner’s record below:
Model: __TMD-600_____________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This product is designed for certain applications only. The manufacturer cannot be responsible
for issues arising from modification. We strongly recommend this product not be modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the product until you have first contacted us to
determine if it can or should be performed on the product.
For technical questions please call 1-218-943-6296.
.
TECHNICAL SPECIFICATIONS
Item
Description
Capacity
600 lbs
Tires
10” Pneumatic
Construction
Steel
Dimensions
42” x 28” x 30”
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions listed
below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this trailer dolly until they
have read this manual and have developed a thorough understanding of how the trailer dolly
works.
WARNING: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions or situations that could occur. It must be
understood by the operator that common sense and caution are factors which cannot be built into
this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS

Page of 5
3
WORK AREA
•Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause
accidents.
•Keep children and bystanders away while operating a trailer dolly.
•Be alert of your surroundings. Using a trailer dolly in confined work areas may put you
dangerous situations.
PERSONAL SAFETY
•Stay alert, watch what you are doing and use common sense when using a trailer dolly. Do not
use a trailer dolly while you are tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating a trailer dolly may result in serious personal injury.
•Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving
parts.
•Use safety apparel and equipment. Use safety goggles or safety glasses with side shields
which comply with current national standards, or when needed, a face shield.Also use non-skid
safety shoes, and gloves when appropriate.
TRAILER DOLLY USE AND CARE
•Do not modify the trailer dolly in any way. Unauthorized modification may impair the function
and/or safety and could affect the life of the equipment. There are specific applications for which
the trailer dolly was designed.
•Always check for damaged or worn out parts before using the trailer dolly. Broken parts will
affect the trailer dolly operation. Replace or repair damaged or worn parts immediately.
•Do not exceed the trailer dolly load capacity.
•Distribute the load evenly. Uneven loads may cause the trailer dolly to tip, resulting in personal
injury to the operator or others.
•Use the trailer dolly on flat and level surfaces capable of supporting the trailer dolly and its
maximum load. Pulling or pushing a load on a slanted or uneven surface can result in loss of
control.
•Store idle trailer dolly. When trailer dolly is not in use, store it in a secure place out of the reach
of children. Inspect it for good working condition prior to storage and before re-use.
WARNING
•Never inflate over max rating.
•Max pressure is 30 psi from regulated air source.
•Over inflating can result in serious injury or death.

Page of 5
4
ASSEMBLY
(See parts diagram on page 5)
1. Attach one side of brace (#4) to axle assembly (#12) using bolt (#16), flat washer (#17), ,
lock washer (#18) and nut (#19).
2. Connect brace (#4), T-Bar handle (#2) and V support (#5) together using bolts (#3), flat
washer (#6), lock washers (#7) and nuts (#8).
3. Install ball coupler (#15) onto the top of axle assembly (#12) using bolt (#13) and lock
washer (#14).
4. Assemble two wheels (#9) to axle assembly and secure them with big flat washers (#10) and
cotter pins (#11).
5. Check and tighten all fasteners as needed.
OPERATION
Design load limit is 600lbs. For the Trailer Dolly alone, not including load supported by
trailer wheels. Do not exceed the rated capacity.
Always wear approved safety goggles when working with tools and equipment.
Always keep arms, feet, and legs, etc. out from under the trailer tongue while hitching,
unhitching or moving the trailer. Children should always be kept at a safe distance.
Always make sure any loaded trailer is blocked properly while the Trailer Dolly is being
moved into place.
Make sure the trailer tongue is securely connected to the Trailer Dolly coupler ball before
attempting to unblock and move the trailer.
Take precautions to prevent uncontrolled movement of the trailer once it is connected to the
Trailer Dolly. Remember, the slope of a roadbed surface is difficult to judge, and the pull of
gravity can result in a dangerously out of control trailer.
If the Trailer Dolly is being connected to a trailer which is being stored over a lengthy period
of time, make sure both the trailer and the Trailer Dolly are blocked properly.
Keep the Trailer Dolly clean and free of road dirt. Inspect the Trailer Dolly before each use
to make sure all parts are securely in place and in working order. Periodically lubricate moving
parts.
WARNING: FAILURE TO FOLLOW THESE INSTRUCTIONS COULD
RESULT IN LOSS OF LOAD AND/OR PERSONAL INJURY OR DAMAGE TO
PROPERTY.
MAINTENANCE
•Maintain your trailer dolly. It is recommended that the general condition of any trailer dolly be
examined before it is used. Keep your trailer dolly in good repair by adopting a program of
conscientious repair and maintenance. Have necessary repairs made by qualified service
personnel.

Page of 5
5
DIAGRAM & PARTS LIST
Ref #
Description
Qty
Ref #
Description
Qty
1
support frame
1
11
bolt M10X25
2
2
handle
1
12
spring washer 18
1
3
link bar
1
13
nut M18
1
4
handle bracket
1
14
M12X30
1
5
triangle stand
1
15
flat washer 12
1
6
hitch ball,1-7/8"
1
16
nut M12
1
7
washer
2
17
flat washer 10
5
8
split pin
2
18
nut M10
5
9
bolt M10*50
2
19
wheel
2
10
bolt M10X60
1
20
grip
2
For replacement parts and technical questions, please call 1-218-943-6296.
WARRANTY
One-year limited warranty
TG
PO BOX 203
Miltona, MN 56354
Made in China
