TP-Link Archer T4UHP User manual

AC1300 High Power
Wireless Dual Band USB Adapter
7106506350 REV1.0.0
Quick
Installation
Guide
MODEL NO. Archer T4UHP
Connect to a Computer
1 2 Install Driver and Utility
Insert the CD.
Browse the CD, go to Archer T4UHP > Mac
OS X Driver, unzip the Mac OS X version.zip
file and run the Installer.
3Join a Wireless Network
For Mac OS X
uninstall.commandInstaller.pkg
SHELL
Follow the wizard to complete the installation.
b.
a.
c.
Note: You can also download the driver and
utility at www.tp-link.com.
Option 1: Via TP-LINK Utility Option 2: Via Wi-Fi Protected Setup (WPS)
a. Click (TP-LINK Wireless Configuration
Utility) on the menu bar.
b. Select your Wi-Fi network and enter the Wi-Fi
password when prompted.
a. Press the WPS button on your router.
b. In 2 minutes, press and hold the WPS button on
the adapter until the WPS progress screen appears.
c. When you are prompted“WPS Protocol Finished!”,
click OK.
Fri 5:14 PM
TP-LINK_TEST_Device
TP-LINK_0001
TP-LINK_0969
TP-LINK_XXXX
Join Other Network
WPS
Open Wireless Utility
USB-WiFi: On
Turn USB-WiFi Off
Connect the adapter to a USB port on your
computer using the USB cable provided.

Connect to a Computer
1
For Windows
Note:
In Windows XP, a Found New Hardware Wizard window
will appear when the adapter is detected. Please click
Cancel.
This USB Adapter can only be powered by computers that comply with
Limited Power Source (LPS).
2Install Driver and Utility
Insert the CD and run the Autorun.exe
from the pop-up Autoplay window.
Setup Wizard
Browse CD EXIT
Archer T4UHP
Install Driver
User Guide
Select Archer T4UHP and click Install Driver,
then follow the InstallShield Wizard to
complete the installation.
Notes:
1. You can also download the driver and utility at
www.tp-link.com.
2. In some operating systems, the CD screen will pop
up automatically. Otherwise, run the CD manually.
a.
b.
3Join a Wireless Network
Connect the adapter to a USB port on your
computer using the USB cable provided.
Option 2: Via TP-LINK Utility
Select your Wi-Fi network from the utility window and
click Connect. The symbol indicates a successful
connection.
Network Name(SSID)
Channel
Signal
Security
2 (2.4G)
149 (5G)
None
WPA/WPA2-Personal TP-LINK_0969
TP-LINK_TEST_Device
6 (2.4G) TP-LINK_XXXX
Connect automatically
WPA/WPA2-Personal
Connect
Status WPS Profile AdvancedNetwork
TP-LINK_0001
Network Na
TP-LINK_XXXX
Option 3: Via Wi-Fi Protected Setup (WPS)
a. Press the WPS button on your router.
c. When you are prompted“Successfully connected
to the network by WPS!”, click OK.
b. In 2 minutes, press and hold the WPS button on
the adapter until the configuring screen appears.
For more information, please visit our website
http://www.tp-link.com
©2016 TP-LINK
Click or ( Network icon) on the task bar,
select your Wi-Fi network, and click Connect.
Note: In Windows XP, you need to close the TP-LINK Utility
before using the Windows Wireless Utility.
Option 1: Via Windows Wireless Utility
Networks
Connect automatically Connect
√
Wi-Fi
TP-LINK_XXXX
TP-LINK_TEST_Device
TP-LINK_0969
