TP-Link TL-WPA4220T User manual

www.tp-link.com
TL-WPA4220T KIT
Features：
Description
：
Wi-Fi Clone Button simplies your Wi-Fi conguration
and helps build a seamless unied home network
HomePlug AV standard providing up to 500Mbps high
speed data transmission over a home’s existing electrical
wiring, ideal for lag-free HD or 3D video streaming and
online gaming
Extend 300Mbps Wireless connections to previously
hard-to-reach areas of your home and oce
Two Ethernet ports allow your TVs, game consoles, or PCs
connect to the Internet
Up to 300-meter range over the household power circuit
Easy-to-install, just plug in, pair and play
128-bit AES encryption easily at a push of "Pair" Button
Supports IGMP managed multicast IP transmission,
optimizing IPTV streaming
TP-LINK 300Mbps AV500 Powerline Universal WiFi Range Extender, 2 Ethernet Ports, Network Kit TL-WPA4220T KIT extends your
Internet connection to every room of the house through your home’s existing electrical circuitry. The TL-WPA4220 features a
Wi-Fi Clone Button enabling Super Range Extension, which means it can automatically copy the SSID and Password of your
router. In this way, TL-WPA4220T KIT simplies your Wi-Fi conguration and allows for seamless roaming within your home
network.
HomePlug AV standard providing up to 500Mbps high
speed data transmission over a home’s existing electrical
wiring, ideal for lag-free HD or 3D video streaming and
Extend 300Mbps Wireless connections to previously
Two Ethernet ports allow your TVs, game consoles, or PCs
Up to 300-meter range over the household power circuit
128-bit AES encryption easily at a push of "Pair" Button
Supports IGMP managed multicast IP transmission,
AV500 Powerline
Universal WiFi Range Extender
2 Ethernet Ports, Network Kit

Package:
300Mbps AV500 WiFi Powerline Extender Starter Kit
TL-WPA4220 *2 & TL-PA4010 *1
2-meter RJ-45 Ethernet Cable * 2
Quick Installation Guide
Resource CD
www.tp-link.com
Specifications：
Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are
trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any
Diagram:
Hardware Features
Standards and Protocols
Interface
Plug Type
Button
LED Indicator
Dimensions ( W x D x H )
Power Consumption
Range
Software Features
Modulation Technology
Encryption
Others
Certications
System Requirements
Environment
HomePlug AV, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n
10/100Mbps Ethernet Ports
EU, UK
Pair, Reset, Wi-Fi/Wi-Fi Clone
PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone
3.7 x 2.1 x 1.6 in. (94 × 54 × 40mm)
<6W
300 Meters over electrical circuit
OFDM (PLC)
Powerline Security:
128-bit AES
Wireless Security:
WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Encryption
CE, FCC, RoHS
Windows 8/7/Vista/XP/2000, Mac OS, Linux*
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
* Utility supports Windows 8/7/Vista/XP/2000 operating system for the present.
PLUG & PLAY WITH TP-LINK WI-FI CLONE!
> Plug in TL-WPA4220 near your router.
> Press the Wi-Fi Clone button on TL-WPA4220.
> Press the WPS button on the router.
That’s it! Now TL-WPA4220 has copied your router’s SSID and
Password and you can enjoy a unied home network!
PASSWORD
SSID
PASSWORD
PASSWORD
PASSWORD
SSID
PASSWORD
SSID
PASSWORD
SSID
PASSWORD
PASSWORD
SSID
> Plug in TL-WPA4220 near your router.
PASSWORD
WPS
TL-WPA4220T KIT
AV500 Powerline Universal WiFi Range Extender
2 Ethernet Ports, Network Kit
