TP-Link TL-MR3020 User manual

Quick Installation Guide
3G/4G Wireless N Router
7106506987 REV2.0.0
www.tp-link.com
Specificaons are subject to change without noce. is a registered trademark of TP-Link Technologies Co., Ltd. Other
brands and product names are trademarks or registered trademarks of their respecve holders.
No part of the specificaons may be reproduced in any form or by any means or used to make any derivave such as
translaon, transformaon, or adaptaon without permission from TP-Link Technologies Co., Ltd.
Copyright © 2016 TP-Link Technologies Co., Ltd. All rights reserved.

01 / English
07 / Български
13 / Čeština
19 / Eesti
25 / Қазақша
31 / Latviešu
37 / Lietuvių
43 / Magyar
49 / Polski
55 / Русский язык
61 / Română
67 / Slovenčina
73 / Srpski jezik/Српски језик
CONTENTS

1
English
Determine Operation Mode
Refer to the following table to determine an appropriate operation mode as
needed.
Mode
Switch
Operation
Mode Scenario
3G/4G 3G/4G
Router I want to share the 3G/4G network with my local devices.
WISP WISP Client
Router
I want to have internet access from a Wireless Internet Service
Provider (WISP), and share internet with local devices.
AP Access
Point
I want to access internet wirelessly, but only a wired network is
available.
Connect the Hardware
1. Switch the operation mode to the determined one.
Note: By setting the router to AP Mode, you can also access the other four modes:
Repeater, Bridge, Client and Multi-SSID. For details, please refer to the User Guide at

2
English
www.tp-link.com.
2. Connect the hardware according to the diagram below.
■3G/4G Router
A
B
C
3G/4G USB Modem

3
English
■WISP Client Router
A B
■Access Point
B
CD
A
Wired Router
Internet

4
English
Congure the Router
1. Connect your device to the router wirelessly. The SSID (wireless network
name) and password are printed on the router’s label.
2. Launch a web browser and type http://tplinkwifi.net in the address bar.
Enter admin for both username and password to log in.
3. Go to Quick Setup and click Next to start.
4. Follow the step-by-step instructions to complete the initial
configuration.
Enjoy internet!
Note: If you have changed the default SSID and password, you have to reconnect your
wireless devices to the new Wi-Fi network.
FAQ (Frequently Asked Questions)
Q1. What can I do if I forgot my web management password?
• Refer to FAQ > Q3 to reset the router, and then use the default admin (all

5
English
lowercase) for both username and password to log in.
Q2. What can I do if I cannot log in to the web management page?
• If the computer is set to a static or xed IP address, change the setting to obtain
an IP address automatically.
• Verify that http://tplinkwi.net is correctly entered in the web browser. Alternatively,
check spacing and enter http://192.168.0.254 in the web browser.
• Use another web browser and try again.
• Reset your router to its factory default settings ( FAQ > Q3) and try again.
• Disable and then enable the network adapter in use.
Q3. How do I restore the router to its factory default settings?
• With the router powered on, press and hold the WPS/Reset button for 8 to 10
seconds and then release the button.
Q4. What can I do if I cannot access internet with an identied 3G/4G
USB modem?
• Insert a suited SIM/UIM card into the 3G/4G USB modem correctly.
• Plug your 3G/4G USB modem directly into your PC and disable the PIN verication
via the modem utility.
• Verify that the 3G/4G USB modem works well on your PC.
• Consult your ISP for the latest dial number and APN (Access Point Name), and

6
English
correct the preset information manually.
Q5. What can I do if the "Unknown Modem" message displays?
• Launch a web browser, enter www.tp-link.com in the address bar and go to
Support > Compatibility List. And check whether your 3G/4G USB modem is on
the 3G/4G Compatibility List. If the latest rmware or bin le doesn't support your
modem, please contact our technical support.
Q6. How to update the rmware of the router?
1. Go to the router's product page at www.tp-link.com, and download the latest
rmware.
2. Connect your computer to the router via an Ethernet cable (recommended) or
wirelessly.
3. Log in to the web management page and go to System Tools > Firmware Upgrade
to update the router.

7
Български
Определяне на режима на работа
Разгледайте следната таблица, за да определите подходящия режим
на работа според нуждите.
Превключвател
на режима
Режим на
работа Сценарий
3G/4G 3G/4G
рутер
Искам да споделям 3G/4G мрежата с моите локални
устройства
WISP
WISP
клиент
рутер
Искам да получавам достъп до интернет от
доставчик на безжични интернет услуги (Wireless
Internet Service Provider (WISP)), и да споделям
интернета с локални устройства.
AP Точка за
достъп
Искам безжичен достъп до интернет, но има само
кабелна мрежа
Свързване на хардуера
1. Превключете режима на работа на този, който сте определили.
Забележка: Като поставите рутера в режим "Точка за достъп", вие също така

8
Български
имате достъп и до останалите четири режима: Повторител, Мост, Клиент и
Мулти-SSID. За подробности, вижте Ръководството за потребителя на
www.tp-link.com.
2. Свържете хардуера съгласно схемата по-долу.
■ 3G/4G рутер
A
B
C
3G/4G USB модем
