Description：
The TL-WR841ND Wireless N Router is a combined wired/wireless network connection device designed specically for small business,
oce and home networking requirements. It provides a simple, very fast, pleasing way to access internet or Ethernet without cables
for work or fun. It complies with the IEEE 802.11n standard with wireless transmission speeds of up to 300Mbps. The router features
4 10/100M switch ports to achieve the most eective data transmission. TL-WR841ND adopts MIMO technologies, has two external
detachable Omni directional antennas providing even better wireless performance, transmission rates, stability and coverage. CCA™
technology automatically avoids channel conicts using its channel selection feature. It also works well with other 11g and 11n
protocol wireless products. TL-WR841ND also provides easy and quick security setup with WPS (WiFi Protected Setup) standard, get
network safety at the push of a button.
TL-WR841ND
300Mbps Wireless N Router
300Mbps wireless transmission rate
with 2 antennas, brings
smooth wireless N experience
MIMO, CCA™ technology, brings
competitive performance
in 11n routers
QSS, Quick Secure Setup
at a push of button

300M wireless transmission rate, adopts
MIMO, CCA™ technology, allows for faster
speed, further wireless coverage, more
stable performance
For home and oce use, Supports PPPoE,
Dynamic IP, and static IP broadband access
and various kind of dialing requirements
Supports UPnP, DDNS, static routing, VPN
Pass-through, and data forwarding
Built-in rewall features IP, MAC, URL
ltering which exibly controls online
access and time
Supports QSS (Quick Secure Setup),
Provides 64/128/152-bit WEP encryption,
supports WPA/WPA2, WPA-PSK/WPA2-PSK
authentication
User interface supports free WEB software
updates
Sleek exterior, can be mounted on a wall or
placed horizontally on a table or desk
2 detachable Antennas
www.tp-link.com
Features：Specifications：
Standards
Interface
Wireless Signal Rates
With Automatic Fallback
Frequency Range
Wireless Transmit Power (MAX)
Antenna
Modulation Technology
Receiver Sensitivity
Power Supply Unit
Operating Temperature
Storage Temperature
Relative Humidity
Storage Humidity
Dimensions
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
4 10/100M auto-sensing LAN Port(Auto MDI/MDIX)
1 10/100M auto-sensing WAN Port(Auto MDI/MDIX)
11n: 270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps
11g: 54/48/36/24/18/12/9/6M(dynamic)
11b: 11/5.5/2/1M(dynamic)
2.4-2.4835GHz
20dBm
3dBi detachable Omni directional antenna x 2
DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
270M: -68dBm@10% PER;
130M: -68dBm@10% PER
108M: -68dBm@10% PER;
54M: -68dBm@10% PER
11M: -85dBm@8% PER;
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Input: localized to country of sale
Output: 9VDC/0.6A switching PSU
0°C~40°C (32°F~104°F)
-40°C~70°C (-40°F~158°F)
10% ~ 90%, non condensation
5%~95% non-condensing
7.6 x 5.1 x 1.3 in.(192 x 130 x 33 mm)
-
-
-
-
Related Products:
Wireless N PCI Adapter TL-WN851N
Wireless N USB Adapter TL-WN821N
SOHO Cable/DSL Router TL-R460
10/100M Desktop Switch TL-SF1005
Diagram:
Wireless N Cardbus Adapter
Wireless N PCI Adapter
TL-WN851N
TL-WN811N
Internet
Wireless N USB Adapter
TL-WN821N
300Mbps Wireless N Router
TL-WR841ND
ADSL2+ Router
TD-8810
Specifications are subject to change without notice. TP-LINK is a
registered trademark of TP-LINK Technologies Co., Ltd. Other brands
and product names are trademarks or registered trademarks of their
respective holders. No part of the specificationsmay be reproduced
in any form or by any means or used to make any derivative such as
translation, transformation, or adaptation without permission from
TP-LINK Technologies Co., Ltd.
Wired
Wireless
Copyright © 2010 TP-LINK Technologies Co., Ltd. All rights reserved.
-
-
-
-
Package:
Wireless N Router TL-WR841ND
Power supply unit
(localized to country of sale)
Resource CD
Quick Setup Guide
