TP-Link TL-WR843N User manual

TL-WR843N
300Mbps Wireless AP/Client Router
Rev: 2.0.0
1910011335

COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice. is a registered
trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are
trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from TP-LINK
TECHNOLOGIES CO., LTD. Copyright © 2015 TP-LINK TECHNOLOGIES CO., LTD. All rights
reserved.
http://www.tp-link.com

FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the
equipment.

FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna must not be co-located or operating in conjunction with
any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile
Configurations. The antennas used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating in conjunction
with any other antenna or transmitter.”
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference,
in which case the user may be required to take adequate measures.
Canadian Compliance Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference, and
(2)This device must accept any interference, including interference that may cause undesired
operation of the device.
Cet appareil est conforme aux norms CNR exemptes de licence d’Industrie Canada. Le
fonctionnement est soumis aux deux conditions suivantes:
(1) cet appareil ne doit pas provoquer d’interférences et
(2) cet appareil doit accepter toute interférence, y compris celles susceptibles de provoquer un
fonctionnement non souhaité de l’appareil.
This device has been designed to operate with the antennas listed below, and having a maximum
gain of 5 dBi. Antennas not included in this list or having a gain greater than 5 dBi are strictly
prohibited for use with this device. The required antenna impedance is 50 ohms.
Industry Canada Statement
Complies with the Canadian ICES-003 Class B specifications.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device complies with RSS 210 of Industry Canada. This Class B device meets all the
requirements of the Canadian interference-causing equipment regulations.

Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Korea Warning Statements
당해 무선설비는 운용중 전파혼신 가능성이 있음.
NCC Notice & BSMI Notice
注意！
依據 低功率電波輻射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、
加大功率或變更原設計之特性或功能。
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通行；經發現有干擾現象時，應立即
停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信規定作業之無線電信。低功率射
頻電機需忍受合法通信或工業、科學以及醫療用電波輻射性電機設備之干擾。
減少電磁波影響，請妥適使用。
安全諮詢及注意事項
●請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
●清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。
●注意防潮，請勿將水或其他液體潑灑到本產品上。
●插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。
●請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。
●請不要私自打開機殼，不要嘗試自行維修本產品，請由授權的專業人士進行此項工作。
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам
нормативних документів та вимогам, що передбачені чинними законодавчими актами
України.

Safety Information
When product has power button, the power button is one of the way to shut off the product;
when there is no power button, the only way to completely shut off power is to disconnect the
product or the power adapter from the power source.
Don’t disassemble the product, or make repairs yourself. You run the risk of electric shock and
voiding the limited warranty. If you need service, please contact us.
Avoid water and wet locations.
This product can be used in the following countries:
AT BG BY CA CZ DE DK EE
ES FI FR GB GR HU IE IT
LT LV MT NL NO PL PT RO
RU SE SK TR UA US

TP-LINK TECHNOLOGIES CO., LTD
TP-LINK TECHNOLOGIES CO., LTD.
Building 24 (floors 1, 3, 4, 5), and 28 (floors 1-4) Central Science and Technology Park,
Shennan Rd, Nanshan, Shenzhen, China
DECLARATION OF CONFORMITY
For the following equipment:
Product Description: 300Mbps Wireless AP/Client Router
Model No.: TL-WR843N
Trademark: TP-LINK
We declare under our own responsibility that the above products satisfy all the technical regulations
applicable to the product within the scope of Council Directives:
Directives 1999/5/EC, Directives 2004/108/EC, Directives 2006/95/EC, Directives 1999/519/EC,
Directives 2011/65/EU
The above product is in conformity with the following standards or other normative documents
EN 300 328 V1.8.1
EN 301 489-1 V1.8.1:2008 & EN 301 489-17 V2.2.1
EN 55022:2010
EN 55024:2010
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-3:2008
EN60950-1:2006+A11
：
2009+A1:2010+A12:2011
EN62311:2008
The product carries the CE Mark:
Person is responsible for marking this declaration:
Yang Hongliang
Product Manager of International Business
Date of issue: 2015

- I -
CONTENTS
Package Contents ....................................................................................................1
Chapter 1. Introduction.........................................................................................2
1.1 Overview of the Router.................................................................................................2
1.2 Conventions..................................................................................................................3
1.3 Main Features...............................................................................................................3
1.4 Panel Layout.................................................................................................................4
1.4.1 The Front Panel ................................................................................................4
1.4.2 The Rear Panel.................................................................................................5
Chapter 2. Connecting the Router .......................................................................7
2.1 System Requirements ..................................................................................................7
2.2 Installation Environment Requirements........................................................................7
2.3 Connecting the Router..................................................................................................7
Chapter 3. Quick Installation Guide...................................................................10
3.1 TCP/IP Configuration..................................................................................................10
3.2 Quick Installation Guide..............................................................................................12
3.2.1 Configuration for Router Mode .......................................................................14
3.2.2 Configuration for Client Router Mode.............................................................18
Chapter 4. Configuring the Router ....................................................................24
4.1 Login ...........................................................................................................................24
4.2 Status..........................................................................................................................24
4.3 Quick Setup ................................................................................................................25
4.4 WPS ............................................................................................................................25
4.5 Working Mode.............................................................................................................28
4.6 Network.......................................................................................................................28
4.6.1 WAN ................................................................................................................29
4.6.2 MAC Clone......................................................................................................38
4.6.3 LAN .................................................................................................................39
4.7 Wireless ......................................................................................................................40
4.7.1 Wireless Settings ............................................................................................40
4.7.2 Wireless Security ............................................................................................46
4.7.3 Wireless MAC Filtering ...................................................................................49
4.7.4 Wireless Advanced .........................................................................................51

- II -
4.7.5 Wireless Statistics...........................................................................................53
4.8 DHCP..........................................................................................................................55
4.8.1 DHCP Settings................................................................................................55
4.8.2 DHCP Client List .............................................................................................56
4.8.3 Address Reservation ......................................................................................56
4.9 Forwarding..................................................................................................................58
4.9.1 Virtual Servers ................................................................................................58
4.9.2 Port Triggering ................................................................................................60
4.9.3 DMZ ................................................................................................................61
4.9.4 UPnP...............................................................................................................62
4.10 Security .......................................................................................................................63
4.10.1 Basic Security .................................................................................................63
4.10.2 Advanced Security..........................................................................................65
4.10.3 Local Management .........................................................................................66
4.10.4 Remote Management .....................................................................................67
4.11 Parental Control..........................................................................................................68
4.12 Access Control............................................................................................................71
4.12.1 Rule.................................................................................................................71
4.12.2 Host.................................................................................................................77
4.12.3 Target ..............................................................................................................78
4.12.4 Schedule .........................................................................................................81
4.13 Advanced Routing ......................................................................................................82
4.13.1 Static Routing..................................................................................................83
4.13.2 System Routing Table.....................................................................................84
4.14 Bandwidth Control ......................................................................................................84
4.14.1 Control Settings ..............................................................................................85
4.14.2 Rules List ........................................................................................................85
4.15 IP & MAC Binding .......................................................................................................86
4.15.1 Binding Settings..............................................................................................86
4.15.2 ARP List ..........................................................................................................88
4.16 Dynamic DNS .............................................................................................................89
4.16.1 Comexe.cn DDNS...........................................................................................89
4.16.2 Dyndns.org DDNS ..........................................................................................90
4.16.3 No-ip.com DDNS ............................................................................................91
4.17 System Tools.............................................................................................................101

- III -
4.17.1 Time Settings ................................................................................................101
4.17.2 Diagnostic .....................................................................................................103
4.17.3 Firmware Upgrade ........................................................................................104
4.17.4 Factory Defaults............................................................................................105
4.17.5 Backup & Restore.........................................................................................106
4.17.6 Reboot...........................................................................................................106
4.17.7 Password ......................................................................................................107
4.17.8 System Log ...................................................................................................107
4.17.9 Statistics........................................................................................................110
Appendix A: FAQ .................................................................................................. 112
Appendix B: Configuring the PC......................................................................... 117
Appendix C: Specifications .................................................................................121
Appendix D: Glossary ..........................................................................................122

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 1 -
Package Contents
The following items should be found in your package:
TL-WR843N 300Mbps Wireless AP/Client Router
Power Adapter for TL-WR843N 300Mbps Wireless AP/Client Router
Passive PoE Injector
Ethernet cable
Quick Installation Guide
Resource CD for TL-WR843N 300Mbps Wireless AP/Client Router, including:
•This Guide
•Other Helpful Information

Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact your distributor.

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 2 -
Chapter 1. Introduction
Overview of the Router
The TL-WR843N 300Mbps Wireless AP/Client Router integrates 4-port Switch, Firewall, NAT-Router
and Wireless AP. Powered by 2x2 MIMO technology, the 300Mbps Wireless AP/Client Router
delivers exceptional range and speed, which can fully meet the need of Small Office/Home Office
(SOHO) networks and the users demanding higher networking performance.
The TL-WR843N 300Mbps Wireless AP/Client Router provides up to 300Mbps wireless connection
with other 802.11n wireless clients. The incredible speed makes it ideal for handling multiple data
streams at the same time, which ensures your network stable and smooth. The performance of this
802.11n wireless Router will give you the unexpected networking experience at speed much faster than
802.11g. It is also compatible with all IEEE 802.11g and IEEE 802.11b products.
The TL-WR843N 300Mbps Wireless AP/Client Router supports two working modes. The WISP Client
Router mode allows the TL-WR843N to connect to the WISP and create a local area network via
wireless connection. The Standard Wireless Router mode enables the TL-WR843N to work as a
router for network sharing with high speed.
With multiple protection measures, including SSID broadcast control and wireless LAN 64/128/152-
bit WEP encryption, WiFi protected Access (WPA2- PSK, WPA- PSK), as well as advanced Firewall
protections, the TL-WR843N 300Mbps Wireless AP/Client Router provides complete data privacy.
The TL-WR843N 300Mbps Wireless AP/Client Router provides flexible access control, so that
parents or network administrators can establish restricted access policies for children or staff. It also
supports Virtual Server and DMZ host for Port Triggering, and then the network administrators can
manage and monitor the network in real time with the remote management function.
Multiple Security Protections
Incredible Speed
Multiple Working Modes
Flexible Access Control

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 3 -
Since the Router is compatible with virtually all the major operating systems, it is very easy to
manage. Quick Setup Wizard is supported and detailed instructions are provided step by step in
this user guide. Before installing the Router, please look through this guide to know all the Router’s
functions.
Conventions
The Router or TL-WR843N mentioned in this guide stands for TL-WR843N 300Mbps Wireless AP/Client
Router without any explanation.
Main Features
Complies with IEEE 802.11n to provide a wireless data rate of up to 300Mbps.
One 10/100M Auto-Negotiation RJ45 INTERNET port, supporting passive POE at AP Client
Router mode.
Four 10/100M Auto-Negotiation RJ45 LAN ports, supporting Auto MDI/MDIX.
Provides WPA/WPA2, WPA-PSK/WPA2-PSK authentication, TKIP/AES encryption security.
Shares data and Internet access for users, supporting Dynamic IP/Static IP/PPPoE Internet
access.
Supports Client Router mode for WISP Connection.
Supports Virtual Server, Special Application and DMZ host.
Supports UPnP, Dynamic DNS, Static Routing.
Provides Automatic-connection and Scheduled Connection on certain time to the Internet
Built-in NAT and DHCP server supporting static IP address distributing.
Supports Parental Control and Access Control.
Connects Internet on demand and disconnects from the Internet when idle for PPPoE.
Provides 64/128/152-bit WEP encryption security and wireless LAN ACL (Access Control List).
Supports Flow Statistics.
Supports firmware upgrade and Web management.
Simple Installation

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 4 -
Panel Layout
1.4.1 The Front Panel
Figure 1-1 Front Panel sketch
The Router’s LEDs are located on the front panel (View from left to right).
Name Status Indication
（Power）
Off
Power is off.
On Power is on.
(WLAN)
Off
The Wireless function is disabled.
Flashing The Wireless function is enabled.
(LAN 1-4)
Off There is no device linked to the corresponding port.
On There is a device linked to the corresponding port but there
is no activity.
Flashing There is an active device linked to the corresponding port.
(INTERNET)
Green The router is connected to the Internet.
Orange The INTERNET port is connected, but there is no Internet
connection.
Off The INTERNET port is not connected.
(WPS)
Slow Flash A wireless device is connecting to the network by WPS
function. This process will last in the first 2 minutes.
On A wireless device has been
successfully added to the
network by WPS function.
Quick Flash A wireless device failed to be added
to the network by
WPS function.
Table 1-1 The LEDs Description

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 5 -

Note:
After a device is successfully added to the network by WPS function, the WPS LED will keep on
for about 5 minutes and then turn off.
1.4.2 The Rear Panel
Figure 1-2 Rear Panel sketch
The following parts are located on the rear panel (View from left to right).
ON/OFF: The switch for the power.
POWER: The Power socket is where you will connect the power adapter. Please use the
power adapter provided with this TL-WR843N 300Mbps Wireless AP/Client Router.
INTERNET:This INTERNET port is where you will connect the DSL/cable Modem, or
Ethernet.
4,3,2,1 (LAN): These ports (4,3,2,1) connect the Router to the local PC(s).
ROUTER WISP:This switch is used to select working mode.
WPS/RESET: This button is used for both WPS and Reset function. To use the WPS function,
press it for less than five seconds; to use the RESET function, press it for more than five
seconds.
Used as RESET button:
There are two ways to reset to the Router's factory defaults:
1) Use the Factory Defaults function on System Tools →Factory Defaults page in the
Router's Web-based Utility.
2) Use the WPS/RESET button: With the Router powered on, press and hold the
WPS/RESET button (more than 5 seconds) until the SYS LED becomes quick-flash from
slow-flash. Then release the button and wait the Router to reboot to its factory default
settings.
Used as WPS button:

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 6 -
If you have client devices, such as wireless adapters, that support Wi-Fi Protected Setup,
then you can press this button to quickly establish a connection between the Router and client
devices and automatically configure wireless security for your wireless network.
Wireless antenna: To receive and transmit the wireless data.

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 7 -
Chapter 2. Connecting the Router
System Requirements
Broadband Internet Access Service (DSL/Cable/Ethernet)
One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the Router is
connected directly to the Ethernet.)
PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors
TCP/IP protocol on each PC
Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari
Installation Environment Requirements
Place the Router in a well ventilated place far from any heater or heating vent
Avoid direct irradiation of any strong light (such as sunlight)
Keep at least 2 inches (5 cm) of clear space around the Router
Operating Temperature: 0 ℃~40 ℃ (32℉ ~104℉)
Operating Humidity: 10%~90%RH, Non-condensing
Connecting the Router
To connect the Router, please follow the steps below:
1) Locate an optimum location for the Router. The best place is usually at the center of your
wireless network. The place must accord with the Installation Environment Requirements.
2) Adjust the direction of the antenna. Normally, upright is a good direction.
After finishing the steps above, please choose the working mode you need and carry out the
corresponding steps. There are two working mode supported by this router: WISP Client Router
and Standard Wireless Router.

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 8 -
a) WISP Client Router Mode
Figure 2-1 Hardware Installation of the TL-WR843N in WISP Client Router mode
1. Connect the notebook/PC to the LAN port of TL-WR843N router with an Ethernet cable.
2. Plug one end of the provided power adapter into the POWER jack of the router, and the other
end to a standard electrical wall socket.
3. Press the ON/OFF button of the router.
b) Standard Wireless Router Mode
Figure 2-2 Hardware Installation of the TL-WR843N in Router mode
1. Connect the PC(s)/Switch/Hub in your LAN to the LAN Ports on the Router.
2. Connect the DSL/Cable Modem to the INTERNET port on the Router.
3. Plug one end of the provided power adapter into the POWER jack of the router, and the other
end to a standard electrical wall socket.
4. Press the ON/OFF button of the router.

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 9 -
Figure 2-3 Wall-mount Install
Note: The diameter of the screw, 4mm<D<8mm, and the distance of two screws is 123mm. The
screw that project from the wall need around 4mm based, and the length of the screw need to be
at least 20mm to withstand the weight of the product.

TL-WR843N
300Mbps Wireless AP/Client Router User Guide
- 10 -
Chapter 3. Quick Installation Guide
This chapter will show you how to configure the basic functions of your TL-WR843N 300Mbps
Wireless AP/Client Router using Quick Setup Wizard within minutes.
TCP/IP Configuration
The default domain name of the TL-WR843N 300Mbps Wireless AP/Client Router is
http://tplinkwifi.net, the default IP address is 192.168.0.1, and the default Subnet Mask is
255.255.255.0. These values can be changed as you desire. In this guide, we use all the default
values for description.
Connect the local PC to the LAN ports of the Router. And then you can configure the IP address
for your PC in the following two ways.
Configure the IP address manually
1) Set up the TCP/IP Protocol for your PC. If you need instructions as to how to do this,
please refer to Appendix B: "Configuring the PC".
2) Configure the network parameters. The IP address is 192.168.0.xxx ("xxx" is any number
from 2 to 254), Subnet Mask is 255.255.255.0, and Gateway is 192.168.0.1 (The Router's
default IP address)
Obtain an IP address automatically
1) Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC.
If you need instructions as to how to do this, please refer to Appendix B: "Configuring the
PC”.
2) Then the built-in DHCP server will assign IP address for the PC.
Now, you can run the Ping command in the command prompt to verify the network connection
between your PC and the Router. The following example is in Windows XP.
Open a command prompt, and type ping 192.168.0.1, and then press Enter.
If the result displayed is similar to the Figure 3-1, it means the connection between your PC
and the Router has been established well.
