TPI Corporation FES-4548-3 User manual

ECO 1-7575 REV. LEVEL: D REV. DATE: 10-25-2019 FORM:8992 1 OF 5
MODEL FES-4548-3
MODEL FES-4557-3
MODEL FES-6048-3
MODEL FES-6057-3
PORTABLE ELECTRIC SALAMANDER
INSTALLATION
INSTRUCTIONS
IMPORTANT SAFETY INFORMATION INSIDE
• Serious injury or death possible.
• Read, understand, and follow all safety information and instructions in this manual before using or
servicing this product.
• Retain these instructions for future reference.
SPECIFICATIONS
Model Part Number kW Volts Ph Amps Fan
Output
Heat
Output
FES-4548-3 08722202 45 480 3 55.4 2200 CFM 153,585 BTU
FES-4557-3 04874002 45 575 3 46.2 2200 CFM 153,585 BTU
FES-6048-3 04915302 60 480 3 73.5 2500 CFM 204,780 BTU
FES-6057-3 04915402 60 575 3 61.3 2500 CFM 204,780 BTU
Description - Fostoria portable electric salamander heaters provide clean, odor-free, fan-forced heat. They are
designed to circulate room air continously; gradually heating a conned space. The best results will be obtained
when using these heaters in smaller, insulated spaces. Features include a safety-yellow enclosure with front and
rear safety screens; reliable steel nned heating elements; a high-limit temperature switch with manual reset;
an automatic thermostat control; fan switch; and a long-life motor and fan assembly with sealed bearings. The
portable (FES) models come mounted on a four-wheeled cart with wheels designed to be easily pushed or pulled
over uneven surfaces.

ECO 1-7575 REV. LEVEL: D REV. DATE: 10-25-2019 FORM:8992 2 OF 5
WIRING
THE PROPER SIZE SO- type feeder cable MUST BE USED for the electrical hook-up of this heater.
The proper cable size is shown in the table below (A.W.G./ # of conductors.)
Model Unit Rating Cable Size - Under
50ft. long
Cable Kit
Number
FES-4548-3 45kW, 480 Volt, 3-Ph 4/4 03164301
FES-4557-3 45kW, 575 Volt, 3-Ph 6/4 03164001
FES-6048-3 60kW, 480 Volt 3-Ph 2/4 04917302
FES-6057-3 60kW, 575 Volt 3-Ph 4/4 03164301
• Disconnect from electrical supply before installing feeder cable to these heaters.
• Feeder cable or cable kit assembly MUST BE made by licensed electricians ONLY.
• Service panel or receptacle used to supply power to these heaters MUST have a ground bus
or ground pole that is securely bonded to earth ground.
• Connect green ground conductor on feeder cable or cable kit to grounding lug on heaters.
• Comply with ALL local electrical codes and the National Electric Code (NFPA70) when
providing electrical power to these heaters.
FES-4548-3
WIRING DIAGRAMS
LTB
GRD
E
E
E
E
E
E
E
E
CC2
ELEMENTS
WIRED WYE
CAPACITOR
POWER SUPPLY
CONTACTOR
COILS
HTCO
XFMR
STAT
HEAT/FAN
SWITCH
FANHEAT
BLOWER
MOTOR
FUSESFUSES
CC2
CC1 FLANGED INLET RECEPT. ---------- FIR
LOCKING RECEPTICAL -------------- LR
PL
FAN
DELAY
OFF
3
1
H
H
CC1
ORANGE
BLACK
YELLOW
TRANSFORMER -------------------- XFM
R
CONTROL TERMINAL BLOCK ---- CTB
HTCO (Limit Control) ---------------
HEATING ELEMENT --------------------- E
BLOWER MOTOR ------------------------- B
CONTROLLING CONTACTOR ----- CC
FACTORY WIRING
FIELD WIRING
WIRING DIAGRAM LEGEND
THERMOSTAT ---------------------- STAT
BLOWER TERMINAL BLOCK ----- BTB
LINE TERMINAL BLOCK ------------ LTB
DISCONNECT SWITCH -------------- D
S
GROUND LUG ------------------------ GND
B
E

ECO 1-7575 REV. LEVEL: D REV. DATE: 10-25-2019 FORM:8992 3 OF 5
FES-4557-3
FES-6048-3
WIRING DIAGRAMS
FAN
HEAT
FAN
DELAY
OFF
3
1
H
H
TRANSFORMER -------------------- XFMR
CONTROL TERMINAL BLOCK ---- CTB
HTCO (Limit Control) ---------------
HEATING ELEMENT --------------------- E
BLOWER MOTOR ------------------------- B
CONTROLLING CONTACTOR ----- CC
FACTORY WIRING
WIRING DIAGRAM LEGEND
THERMOSTAT ---------------------- STAT
BLOWER TERMINAL BLOCK ----- BTB
LINE TERMINAL BLOCK ------------ LTB
GROUND LUG ------------------------ GND
480 VAC
ORANGE
BLACK
YELLOW
SPLICE
YELLOW
BLUE
GREEN
SPLICE
FAN
DELAY
OFF
3
1
H
H
BRN/WHT
BLACK
YELLOW
SPLICE
YELLOW
BLUE
GREEN
FLANGED INLET RECEPT. -------- FIR
MOTOR
CONTACTOR
SPLICE
POWER SUPPLY
BROWN
FAN
HEAT
TRANSFORMER ------------------- XFMR
CONTROL TERMINAL BLOCK --- CTB
HTCO (Limit Control) ---------------
HEATING ELEMENT -------------------- E
BLOWER MOTOR ------------------------ B
CONTROLLING CONTACTOR ---- CC
FACTORY WIRING
FIELD WIRING
WIRING DIAGRAM LEGEND
THERMOSTAT --------------------- STAT
LINE TERMINAL BLOCK ----------- LTB
DISCONNECT SWITCH ------------- DS
GROUND LUG ----------------------- GND

ECO 1-7575 REV. LEVEL: D REV. DATE: 10-25-2019 FORM:8992 4 OF 5
FES-6057-3
WIRING DIAGRAMS
HEAT/FAN SWITCH
E
B
BROWN
600 VAC
GREEN
MOTOR
CONTACTOR
FAN
HEAT
PL
FAN
DELAY
OFF
3
1
H
H
LTB
CC1
BRN/WHT
BLACK
WHITE
YELLOW
BLUE
TRANSFORMER -------------------- XFMR
CONTROL TERMINAL BLOCK ---- CT
B
HTCO (Limit Control) ---------------
HEATING ELEMENT --------------------- E
BLOWER MOTOR ------------------------- B
CONTROLLING CONTACTOR ----- CC
FACTORY WIRING
WIRING DIAGRAM LEGEND
THERMOSTAT ---------------------- STAT
BLOWER TERMINAL BLOCK ----- BTB
LINE TERMINAL BLOCK ------------ LTB
GROUND LUG ------------------------ GND
FUSES
CC1
E
E
E
E
E
E
E
E
E
E
E
ELEMENTS
WIRED WYE
CONTACTOR
COILS
CC2
CAPACITOR
XFMR
FUSES
GN
D
BLOWER MOTOR
STAT
HTCO
CC2

ECO 1-7575 REV. LEVEL: D REV. DATE: 10-25-2019 FORM:8992 5 OF 5
The FES series heaters are designed to circulate room air across its heating elements to gradually
increase room temperature. The best performance results will be obtained when using these heaters
in smaller, conned spaces with low ceilings.
Operation of these heaters is accomplished using the thermostat and fan switch.
You have the option to use the fan only*, or the fan and heating elements together. Position the fan
switch to the “fan” position to circulate room air with no heating. Move the switch into the “heat”
position for control of fan and elements with the thermostat. Maximum heating is obtained with knob
turned fully clockwise**.
This heater is equipped with an automatic fan purge that eliminates residual heat after the
heating cycle . Allow the heater to fully purge before disconnecting power to the heater. This will
eliminate the possibility of cycling the heater on the limit control.
*The thermostat has a preset range of 40oF, there will be no “fan only” function as the
thermostat is always calling for heat.
**Setting the thermostat to high heat versus low heat does not make the unit operate at a
higher temperature. It simply raises the temperature necessary to satisfy the thermostat.
The unit will run longer to try to satisfy a higher thermostat setting.
Note: ALL FES models are equipped with an internal over temperature limit designed to protect your
heater if a restricted airow condition occurs. This limit device will completely shut down the heating
elements if the temperature limit is reached. The limit must be manually reset when the unit cools.
The reset button is marked and located on the side of the control box near the thermostat knob
on the 45kW models and the opposite side for the 60 kW models.
WARNING:
• Do not use outdoors or where ammable gases or liquids are stored.
• Do not use as a residential comfort heater.
• Keep portable heater 3ft. minimum from all combustible materials at all times.
• Do not modify heater in any way.
• Do not provide power to heater when unit is near standing water.
• Only use handle to move heater.
• Do not touch heater housing when in use.
• Do not allow feeder cable to contact combustible materials.
OPERATING INSTRUCTIONS
