OWNER’S MANUAL
PRODUCT CODE: 6003T
450kg HYDRAULIC SCISSOR LIFT TROLLEY
Working
Load Limit
Maximum
Height
Minimum
Height
Table
Dimensions
Wheel
Diameter
Nett
Weight
450kg
875mm
280mm
810 x 500mm
125mm
55kg

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before
using or operating this equipment. Do not allow anyone to use or operate this equipment until
they have read this manual and have developed a thorough understanding of how this
equipment works. Failure to observe any of the instructions contained in the manual could
result in severe personal injury to the user or bystanders, or cause damage to the equipment
and property. Keep this manual in a convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual,
the TQB Brands Pty Ltd policy of continuous improvement determines the right to make
modifications without prior warning.
CONTENT
WARNING .............................................................................................................................. 2
CONTENT ............................................................................................................................... 2
SAFETY INSTRUCTIONS ........................................................................................................... 3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE .......................................................... 4
PARTS LIST ............................................................................................................................. 7
WARRANTY ............................................................................................................................ 9

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 3
Visit us at www.tqbbrands.com.au
SAFETY INSTRUCTIONS
SAFETY OPERATING INSTRUCTIONS
Save these instructions. For your safety, read, understand, and follow the information
provided with and on this hydraulic scissor lift trolley before use.
• This Hydraulic Scissor Lift Trolley should be used for lifting and lowering only.
• No person should get any part of the body under a load that is supported by this
Hydraulic Scissor Lift Trolley.
• Do not overload this hydraulic scissor lift trolley beyond its rated capacity.
• Overloading this Hydraulic Scissor Lift Trolley beyond its rated capacity can cause
damage to or failure of the Hydraulic Scissor Lift Trolley.
• Use only on hard level surfaces. Use on other than hard level surfaces can result in
Hydraulic Scissor Lift Trolley instability and wheel damage.
• Do not allow people to sit or ride on the Hydraulic Scissor Lift Trolley.
• Do not transport heavy loads in the raised position.
• Keep hands & feet clear of the Hydraulic Scissor Lift Trolley hinge mechanism &
ground contact area when lowering the load.
• Ensure castor brakes are engaged when loading and unloading.
• When servicing, use only TradeQuip identical replacement parts. Use of any other
parts will void the warranty.
• Use the right product for the job. There are certain applications for which the
Hydraulic Scissor Lift Trolley was designed. Do not modify the Hydraulic Scissor Lift
Trolley and do not use the Hydraulic Scissor Lift Trolley for a purpose for which it was
not intended.
• Failure to comply with the above warnings may result in personal injury and/or
property damage.

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 4
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
This TradeQuip Hydraulic Scissor Lift Trolley is widely used as a scissor lift table to
transport parts and materials around the workshop. This Hydraulic Scissor Lift Trolley can
be manually pumped to the required height through its hydraulic foot pump mechanism.
The foot pump raises and lowers the platform using a single scissor lift and hydraulic
cylinder. In addition, the TradeQuip 6003T can be used as a convenient mobile work
bench so you can work at different heights to reduce the risk of injury.
2. ASSEMBLY
1. The Hydraulic Scissor Lift Trolley has minimal assembly required.
2. Unfold the Handle by pulling it up and back into a vertical position. Lock the Handle
into position. Note: The Handle may be released and folded back down by pressing
down the Locking Bar.
3. Note: The Control Lever controls the operation of the Hydraulic Ram unit. To lower
the Ram and Table, squeeze the Control Lever. When the Control Lever is released,
the Ram and Table movement will stop and the table will remain stationary.
4. Your Hydraulic Scissor Lift Trolley is now ready for use.

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 5
Visit us at www.tqbbrands.com.au
3. BEFORE USE
Before using this Hydraulic Scissor Lift Trolley, the hydraulic ram must be purged of air
(called bleeding).
Housing Filler Bolt
1. Remove any load from the Table.
2. Release the Control Lever, then repeatedly pump the Foot Pedal.
3. When the table has been raised, remove the Filler Bolt from the Housing. Use a rag
to catch any fluid leaks.
4. Keeping hands and tools clear, squeeze the Control Lever while pumping the Foot
Pedal several times rapidly to lower the Table.
5. Release the Control Lever, and pump more slowly to raise the Table to its full height.
6. Add good quality hydraulic fluid into the opening in the Housing where the Filler Bolt
has been removed. Fill until the Housing will hold no more fluid.
7. Replace the Filler Bolt and its Seal Washer into the Housing, tighten, but do not
overtighten to avoid damaging the Washer.
8. Check the condition of the Hydraulic Lift Table before use. Raise and lower it several
times before adding any load. Be sure that all controls work properly.

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 6
Visit us at www.tqbbrands.com.au
4. OPERATION
1. Unfold the handle by lifting it up to a vertical position until it locks in place.
2. Before placing anything on the Hydraulic Scissor Lift Trolley, lock the back two
casters. The locking swivel castors can be locked by pressing the lever down into the
locked position with your foot. Test the cart operation using the Foot Pedal and
Control Lever. Make sure the table raises and lowers properly before adding weight
to the table.
3. Observing safe lifting procedures, move the workpiece onto the Hydraulic Scissor Lift
Trolley. If necessary, secure the item onto the Hydraulic Scissor Lift Trolley using tie-
downs or chocks to keep it stable while moving.
4. Release the locking swivel castors by moving the levers to the unlock position. Move
the workpiece to the desired location.
5. Always ensure castor wheel brakes are engaged prior to loading and unloading.
6. To raise the table, ensure that the control lever is in the released position. Press
repeatedly on the foot pedal to raise the table.
7. To lower the table squeeze the control lever. The Hydraulic Scissor Lift Trolley has a
2-speed valve. Squeeze the lever halfway for slowly lowering a load. Squeeze it fully
for quickly lowering the table when empty.
5. MAINTENANCE
Inspect the product for damage, wear, broken or missing parts and that all components
function before each use. Remove from service immediately if damaged in any
1. Periodically check the tightness of the mounting bolts.
2. Remove all dirt or corrosion with a clean cloth.
3. Check the movement and wear of wheels.
4. Inspect for hydraulic oil leakage and add oil as needed.
5. Lubricate the wheels to maintain smooth rolling.
6. Lubricate each friction point monthly with multi-purpose grease.

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 7
Visit us at www.tqbbrands.com.au
PARTS LIST

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 8
Visit us at www.tqbbrands.com.au
Part
#
Description
QTY
Part
#
Description
QTY
1
Handle
1
25
Handle Lock Pivot
2
2
Roll Pin
1
26
Spring
2
3
Control Lever
1
27
Pin
4
4
Hex Nut
13
28
Locking Bar
1
5
Bolt
1
29
Washer
2
6
Jacket
1
30
Spring Washer
12
7
Pull Rod
1
31
Locking Swivel Castor
2
8
Retaining Ring
6
32
Base
1
9
Pin
1
33
Lock Nut
2
10
Power Unit
1
34
Wheel
2
11
Pin
1
35
Bushing
2
12
Retaining Ring
2
36
Hex Bolt
2
13
Bushing
2
37
Bearing
4
14
Bushing
1
38
Washer
4
15
Cushion
1
39
Roller
2
16
Pump Lever
1
40
Washer
4
17
Cotter Pin
1
41
Pin
4
18
Pin
1
42
Bushing
2
19
Connecting Rod
1
43
Scissor Arm Assembly
1
20
Bolt
13
44
Bushing
2
21
Foot Pedal
1
45
Roller
2
22
Grip Seat
2
46
Protective Mat
1
23
Cotter Pin
6
47
Table
1
24
Washer
16

Jul-18 Product Code: 6003T
Made in China to TQB Brands Pty Ltd specifications Page 9
Visit us at www.tqbbrands.com.au
WARRANTY
TradeQuip products have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship for a period of 12 months
from the date of purchase except where tools are hired out when the guarantee period is
ninety days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your
nearest authorised warranty repair agent or contact TQB Brands Pty Ltd Warranty team –
[e-mail].
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee does not apply to
normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accident, or repairs attempted or made by any personnel other than the
authorised TQB Brands Pty Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a
dated receipt or invoice to verify your proof of purchase within the 12 month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
