Trader ARCTIC OWL OWPIROD 180 User manual

Power Source 220-240V/AC
Power Frequency 50Hz
Power Consumption 0.75W
Rated Load
1200W max Tungsten/Incandescent
300W max Fluorescent
100W LED (SBL)
Detection Angle 180°
Working Temperature -10°C ~ +40°C
Working Humidity <93%RH
Installation Height 1.8m~2.5m
Detection Motion Speed 0.6-1.5m/s
Weather Protection IP44
Time Delay
min:10sec±3sec
max: 10min±2min
Light-control : <3LUX- daylight
(adjustable) Detection

<ASwitched Active
8/08/2022 10:41:45
61
SIZE
87
SIZE
68
FIXING
41
FIXING
97
SIZE
LINE DRAWING
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH: AS IN NOTES
TOLERANCES:
LINEAR: X.XX = 0.1
ANGULAR: X.X = 0.1
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:1 SHEET 1 OF 1
A3
WEIGHT: 79.73
SD
8/08/2022
OWPIROD180
INFRARED SENSOR
OUTDOOR IP66 1800
142-144 Fullarton Road ROSE PARK,
South Australia, 5067
Tel [phone]; Fax [phone]
GSM ELECTRICAL (AUSTRALIA) PTY LTD; ACN 603 377 484
A A
B B
C C
D D
E E
F F
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
8/08/2022 10:41:45
61
SIZE
87
SIZE
68
FIXING
41
FIXING
97
SIZE
LINE DRAWING
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH: AS IN NOTES
TOLERANCES:
LINEAR: X.XX = 0.1
ANGULAR: X.X = 0.1
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:1:1 SHEET 1 OF 1
A3
WEIGHT: 79.73
SD
8/08/2022
OWPIROD180
INFRARED SENSOR
OUTDOOR IP66 1800
142-144 Fullarton Road ROSE PARK,
South Australia, 5067
Tel [phone]; Fax [phone]
GSM ELECTRICAL (AUSTRALIA) PTY LTD; ACN 603 377 484
A A
B B
C C
D D
E E
F F
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1

180°
4m
8m
12m
4m 8m 12m
2.5m

Problem Reason Solution
Unit will not operate
during daylight Sensor not in daylight operation mode. Rotate LUX control fully clockwise.
Sensor false triggering Unit may be suering from false
activation.
Cover sensor unit with a black cloth for a period of 5 min to
check that the light does not trigger. Occasionally,winds and
draughts may activate the sensor. Sometimes passages between
buildings etc. can cause a "wind tunnel’’ eect.
Ensure the unit is not positioned so as to allow detection
of cars/people using public thoroughfares adjacent to your
property Adjust the sensitivity control accordingly to decrease
range of sensor or adjust direction of sensor head.
Sensor not turning o Sensor re-triggering
during operation.
Stand well out of the detection range and wait (the
warm-up period should never exceed 1minute), check for any
extra sources of heat or movement within detection area such
as animals, trees, light globes, etc. Adjust sensor head and
controls accordingly.
PIR will not operate at
night Too much ambient light.
The level of ambient light in the area may be too bright to allow
operation. Adjust LUX level control accordingly and remove any
other sources of ambient light.
PIR sensor will not
operate at all No power. Check that the power is switched ON at the circuit-breaker or internal wall switch. Ensure that connections are not loose.
Unit activates during the
daytime
Low level of ambient
light or LUX level control set incorrectly.
The level of ambient light in the area may be too dark to allow
operation in Night-time only mode. Re-adjust the LUX control
accordingly.
