Trane Technologies Thermo King TriPac Evolution User manual

Revision B
October 2020 TTKK 5555771111--1199--OOPP--EENN
TriPac®Evolution
Operator’s Manual

2TK 55711-19-OP-EN
Introduction
This manual is published for informational purposes only and the
information furnished herein should not be considered as all-inclusi e or
meant to co er all contingencies. If more information is required, consult
your Thermo King Ser ice Directory for the location and telephone number
of the local dealer.
TThheerrmmoo KKiinngg’’ss wwaarrrraannttyy sshhaallll nnoott aappppllyy ttoo aannyy eeqquuiippmmeenntt wwhhiicchh hhaass
bbeeeenn ““ssoo iinnssttaalllleedd,, mmaaiinnttaaiinneedd,, rreeppaaiirreedd oorr aalltteerreedd aass,, iinn tthhee
mmaannuuffaaccttuurreerr’’ss jjuuddggmmeenntt,, ttoo aaffffeecctt iittss iinntteeggrriittyy..””
MMaannuuffaaccttuurreerr sshhaallll hhaavvee nnoo lliiaabbiilliittyy ttoo aannyy ppeerrssoonn oorr eennttiittyy ffoorr aannyy
ppeerrssoonnaall iinnjjuurryy,, pprrooppeerrttyy ddaammaaggee oorr aannyy ootthheerr ddiirreecctt,, iinnddiirreecctt,, ssppeecciiaall,,
oorr ccoonnsseeqquueennttiiaall ddaammaaggeess wwhhaattssooeevveerr,, aarriissiinngg oouutt ooff tthhee uussee ooff tthhiiss
mmaannuuaall oorr aannyy iinnffoorrmmaattiioonn,, rreeccoommmmeennddaattiioonnss oorr ddeessccrriippttiioonnss
ccoonnttaaiinneedd hheerreeiinn.. TThhee pprroocceedduurreess ddeessccrriibbeedd hheerreeiinn sshhoouulldd oonnllyy bbee
uunnddeerrttaakkeenn bbyy ssuuiittaabbllyy qquuaalliiffiieedd ppeerrssoonnnneell.. FFaaiilluurree ttoo iimmpplleemmeenntt tthheessee
pprroocceedduurreess ccoorrrreeccttllyy mmaayy ccaauussee ddaammaaggee ttoo tthhee TThheerrmmoo KKiinngg uunniitt oorr
ootthheerr pprrooppeerrttyy oorr ppeerrssoonnaall iinnjjuurryy..
There is nothing complicated about operating and maintaining your Thermo
King unit, but a few minutes studying this manual will be time well spent.
Performing pre-trip checks and enroute inspections on a regular basis will
minimize operating problems. A regular maintenance program will also help
to keep your unit in top operating condition. If factory recommended
procedures are followed, you will find that you ha e purchased the most
efficient and dependable temperature control system a ailable.
All ser ice requirements, major and minor, should be handled by a Thermo
King dealer for four ery important reasons:
• They are equipped with the factory recommended tools to perform all
ser ice functions
• They ha e factory trained and certified technicians
• They ha e genuine Thermo King replacement parts
• The warranty on your new unit is alid only when the repair and
replacement of component parts is performed by an authorized Thermo
King dealer

TK 55711-19-OP-EN 3
Customer Satisfaction Survey
Let your oice be heard!
Your feedback will help impro e our manuals. The sur ey is accessible
through any internet-connected de ice with a web browser.
Scan the Quick Response (QR) code or click or type the web address https://
tranetechnologies.iad1.qualtrics.com/jfe/form/SV_2octfSHoUJxsk6x?Q_
CHL=qr&Q_JFE=qdg to complete the sur ey.
IInnttrroodduuccttiioonn

4TK 55711-19-OP-EN
SSaaffeettyy................................................................................................................ 77
Danger, Warning, Caution, and Notice. . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Refrigerant Oil Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Refrigerant Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
FirstAid................................................... 10
Electrical Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Low Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Battery Installation and Cable Routing . . . . . . . . . . . . . . . . . . . . . . . 12
Safety Decals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
UUnniitt DDeessccrriippttiioonn.... .... ...... .................. ...... .......... ...... ........ ...... ...... ...... ...... .. 1144
TriPac Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
TriPac System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Auxiliary Power Unit (APU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Condenser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
E aporator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Heater................................................. 17
HMI Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Engine On/Off Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Control Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
TriPac Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Dri er Con enience Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Standby Truck Integration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Standby Truck Integration - with Dash-Mounted Selector
Switch ................................................ 20
Dual Remote Hour Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Remote Engine Hour Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Closed Loop Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table of Contents

TK 55711-19-OP-EN 5
High Output Heater. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Diesel Particulate Filter (DPF). . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
High Output Alternator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Arctic Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Appearance Package - Top Co er . . . . . . . . . . . . . . . . . . . . . . . . 21
Brushed Stainless Steel Condenser Co er . . . . . . . . . . . . . . . . 21
Exhaust Tube Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
MMaannuuaall PPrree--TTrriipp IInnssppeeccttiioonn........................ ...... ...... ...... ...... ...... ...... .... 2222
Before Starting the TriPac Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
OOppeerraattiinngg IInnssttrruuccttiioonnss .................. ...... .......... ...... ........ ...... ...... ...... ...... .. 2233
HMI Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
On/Off Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Mode Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Temperature Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Fan Speed Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
System Condition Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Clearing Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Operating Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cool Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Heat Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Fan Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Standby Mode (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Monitor Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Acti ate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Deacti ate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Engine Load Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Engine On/Off Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Alarm Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
TTaabbllee ooff CCoonntteennttss

6TK 55711-19-OP-EN
Alarm Notification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Clearing Alarm Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
PPoowweerr IInn eerrtteerr ((OOppttiioonn))........................................................................ 3366
In erter Operation Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
SSppeecciiffiiccaattiioonnss .. .................... ...... ........ ...... ...... ...... ...... ...... ...... ........ ...... ...... 3388
Engine.................................................... 38
Electrical Control System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Fuses..................................................... 39
Air Conditioning System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Truck Sleeper Compartment Heater . . . . . . . . . . . . . . . . . . . . . . . . . 40
MMaaiinntteennaannccee IInnssppeeccttiioonn SScchheedduullee .. ...... ...... ........ ...... ........ ...... ...... 4411
Engine.................................................... 41
Engine Oil Change Inter als . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Structural . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Air Conditioning System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Heater.................................................... 44
TTrriiPPaacc WWaarrrraannttyy .. ................ ...... ........ ...... .......... ...... ...... ...... ...... ...... ...... .... 4455
SSeerriiaall NNuummbbeerr LLooccaattiioonnss .. .... ...... ...... ...... ...... ...... ...... ...... ........ ...... ...... 4466
EEmmeerrggeennccyy CCoolldd LLiinnee ...... ...... ........ ...... .......... ...... ........ ...... ...... ...... ...... .. 4477
RReeccoo eerr RReeffrriiggeerraanntt.. ........ ...... ...... ...... ...... ...... ...... ........ ...... ........ ...... ...... 4488
CCAALLIIFFOORRNNIIAA PPrrooppoossiittiioonn 6655 WWaarrnniinngg ................ ...... ........ ...... ...... 4499
TTaabbllee ooff CCoonntteennttss

TK 55711-19-OP-EN 7
Safety
Dan er, Warnin , Caution, and Notice
Thermo King®recommends that all ser ice be performed by a Thermo King
dealer and to be aware of se eral general safety practices.
Safety ad isories appear throughout this manual as required (refer to
examples below). Your personal safety and the proper operation of this unit
depend upon the strict obser ance of these precautions.
DDAANNGGEERR
EExxaammppllee!!
Indicates an imminently hazardous situation which, if not a oided, will
result in death or serious injury.
WWAARRNNIINNGG
EExxaammppllee!!
Indicates a potentially hazardous situation which, if not a oided, could
result in death or serious injury.
CCAAUUTTIIOONN
EExxaammppllee!!
Indicates a potentially hazardous situation which, if not a oided, could
result in minor or moderate injury and unsafe practices.
NN TTIICCEE
EExxaammppllee!!
Indicates a situation that could result in equipment or property-damage
only accidents.

8TK 55711-19-OP-EN
Safety Precautions
Thermo King recommends all ser ices be performed by a Thermo King
dealer. Howe er, there are se eral general safety practices you should be
aware of:
DDAANNGGEERR
FFiirree HHaazzaarrdd!!
Always turn the TriPac system OFF at the HMI Control Panel On/Off button
while the truck is being refueled. Fuel apors could ignite if they come in
contact with TriPac electrical or heater components.
DDAANNGGEERR
RRiisskk ooff IInnjjuurryy!!
Keep your hands, clothing, and tools clear of mo ing parts when the unit is
operating or ehicle’s engine is running. Loose clothing can become
entangled in mo ing parts, causing serious injury or possible death.
WWAARRNNIINNGG
PPeerrssoonnaall PPrrootteeccttii ee EEqquuiippmmeenntt ((PPPPEE)) RReeqquuiirreedd!!
Always wear goggles or safety glasses when working with or around the
refrigeration system or battery. Refrigerant or battery acid can cause
permanent damage if it comes in contact with your eyes.
WWAARRNNIINNGG
EEqquuiippmmeenntt DDaammaaggee aanndd RRiisskk ooff IInnjjuurryy!!
Ne er drill holes into the unit unless instructed by Thermo King. Holes
drilled into high oltage cables could cause an electrical fire, se ere
personal injury, or e en death.
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
Turn the unit HMI Controller Off before opening the Battery Box or
inspecting any part of the unit.
CCAAUUTTIIOONN
SShhaarrpp EEddggeess!!
Exposed coil fins can cause lacerations. Ser ice work on the e aporator or
condenser coils is best left to a certified Thermo King technician.
SSaaffeettyy

TK 55711-19-OP-EN 9
Refri erant Oil Hazards
Obser e the following when working with or around refrigerant oil.
WWAARRNNIINNGG
PPeerrssoonnaall PPrrootteeccttii ee EEqquuiippmmeenntt ((PPPPEE)) RReeqquuiirreedd!!
Protect your eyes from contact with refrigerant oil. The oil can cause serious
eye injuries. Protect skin and clothing from prolonged or repeated contact
with refrigerant oil. To pre ent irritation, wash your hands and clothing
thoroughly after handling the oil. Rubber glo es are recommended.
Refri erant Hazards
Although fluorocarbon refrigerants (R-404A/R-452A and R-134a) are
classified as safe, obser e caution when working with refrigerants or around
areas where they are being used in the ser icing of your unit.
DDAANNGGEERR
HHaazzaarrddoouuss GGaasseess!!
Refrigerant in the presence of an open flame, spark, or electrical short
produces toxic gases that are se ere respiratory irritants which can cause
serious injury or possible death.
DDAANNGGEERR
RReeffrriiggeerraanntt VVaappoorr HHaazzaarrdd!!
Do not inhale refrigerant. Use caution when working with refrigerant or a
refrigeration system in any confined area with a limited air supply.
Refrigerant displaces air and can cause oxygen depletion, resulting in
suffocation and possible death.
WWAARRNNIINNGG
PPeerrssoonnaall PPrrootteeccttii ee EEqquuiippmmeenntt ((PPPPEE)) RReeqquuiirreedd!!
Refrigerant in a liquid state e aporates rapidly when exposed to the
atmosphere, freezing anything it contacts. Wear butyl lined glo es and
other clothing and eye wear when handling refrigerant to help pre ent
frostbite.
SSaaffeettyy

10 TK 55711-19-OP-EN
First Aid
RREEFFRRIIGGEERRAANNTT
•EEyyeess:: For contact with liquid, immediately flush eyes with large amounts
of water and get prompt medical attention.
•SSkkiinn:: Flush area with large amounts of warm water. Do not apply heat.
Remo e contaminated clothing and shoes. Wrap burns with dry, sterile,
bulky dressing to protect from infection. Get prompt medical attention.
Wash contaminated clothing before reuse.
•IInnhhaallaattiioonn:: Mo e ictim to fresh air and use Cardio Pulmonary
Resuscitation (CPR) or mouth-to-mouth resuscitation to restore
breathing, if necessary. Stay with ictim until emergency personnel
arri e.
•FFrroosstt BBiittee:: In the e ent of frost bite , the objecti es of First Aid are to
protect the frozen area from further injury, warm the affected area
rapidly, and to maintain respiration.
RREEFFRRIIGGEERRAANNTT OOIILL
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention.
•SSkkiinn:: Remo e contaminated clothing. Wash thoroughly with soap and
water. Get medical attention if irritation persists.
•IInnhhaallaattiioonn:: Mo e ictim to fresh air and use Cardio Pulmonary
Resuscitation (CPR) or mouth-to-mouth resuscitation to restore
breathing, if necessary. Stay with ictim until emergency personnel
arri e.
•IInnggeessttiioonn:: Do not induce omiting. Immediately contact local poison
control center or physician.
EENNGGIINNEE CCOOOOLLAANNTT
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention.
•SSkkiinn:: Remo e contaminated clothing. Wash thoroughly with soap and
water. Get medical attention if irritation persists.
•IInnggeessttiioonn:: Do not induce omiting. Immediately contact local poison
control center or physician.
BBAATTTTEERRYY AACCIIDD
•EEyyeess:: Immediately flush with large amounts of water for at least 15
minutes. Get prompt medical attention. Wash skin with soap and water.
EELLEECCTTRRIICCAALL SSHHOOCCKK
SSaaffeettyy

TK 55711-19-OP-EN 11
Take IMMEDIATE action after a person has recei ed an electrical shock. Get
quick medical assistance, if possible.
The source of the shock must be quickly stopped, by either shutting off the
power or remo ing the ictim. If the power cannot be shut off, the wire
should be cut with an non-conducti e tool, such as a wood-handle axe or
thickly insulated cable cutters. Rescuers should wear insulated glo es and
safety glasses, and a oid looking at wires being cut. The ensuing flash can
cause burns and blindness.
If the ictim must be remo ed from a li e circuit, pull the ictim away with a
non-conducti e material. Use wood, rope, a belt or coat to pull or push the
ictim away from the current. DO NOT TOUCH the ictim. You will recei e a
shock from current flowing through the ictim’s body. After separating the
ictim from power source, immediately check for signs of a pulse and
respiration. If no pulse is present, start Cardio Pulmonary Resuscitation
(CPR). If a pulse is present, respiration might be restored by using mouth-to-
mouth resuscitation. Call for emergency medical assistance.
AASSPPHHYYXXIIAATTIIOONN
Mo e ictim to fresh air and use Cardio Pulmonary Resuscitation (CPR) or
mouth-to-mouth resuscitation to restore breathing, if necessary. Stay with
ictim until emergency personnel arri e.
Electrical Hazards
Low Volta e
WWAARRNNIINNGG
LLii ee EElleeccttrriiccaall CCoommppoonneennttss!!
Control circuits used in the auxiliary power unit are low oltage (12 to 28
olts dc). This oltage potential is not considered dangerous, but the large
amount of amperage a ailable can cause se ere burns if shorted or
grounded. Do not wear jewelry, watches, or rings because they increase the
risk of shorting out electrical circuits and damaging equipment or causing
se ere burns.
CCAAUUTTIIOONN
RRiisskk ooff IInnjjuurryy!!
Always disconnect power at the battery before remo ing or repairing
electrical components. Failure to do so may result in personal injury or
damage to the equipment.
SSaaffeettyy

12 TK 55711-19-OP-EN
Battery Installation and Cable Routin
WWAARRNNIINNGG
HHaazzaarrdd ooff EExxpplloossiioonn!!
An improperly installed battery could result in a fire, explosion, or injury. A
Thermo King appro ed battery must be installed and properly secured to
the battery tray.
WWAARRNNIINNGG
HHaazzaarrdd ooff EExxpplloossiioonn!!
Improperly installed battery cables could result in a fire, explosion, or
injury. Battery cables must be installed, routed, and secured properly to
pre ent them from rubbing, chaffing, or making contact with hot, sharp, or
rotating components.
WWAARRNNIINNGG
FFiirree HHaazzaarrdd!!
Do not attach fuel lines to battery cables or electrical harnesses. This has
the potential to cause a fire and could cause serious injury or death.
WWAARRNNIINNGG
HHaazzaarrdd ooff EExxpplloossiioonn!!
Always co er battery terminals to pre ent them from making contact with
metal components during battery installation. Battery terminals grounding
against metal could cause the battery to explode.
CCAAUUTTIIOONN
HHaazzaarrddoouuss SSeerr iiccee PPrroocceedduurreess!!
Set all unit electrical controls to the OFF position before connecting battery
cables to the battery to pre ent unit from starting unexpectedly and causing
personal injury.
NN TTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
Do not connect other manufacturer’s equipment or accessories to the unit
unless appro ed by Thermo King. Failure to do so can result in se ere
damage to equipment and oid the warranty.
SSaaffeettyy

TK 55711-19-OP-EN 13
Safety Decals
Fi ure 1. Dan er Nameplate
Fi ure 2. Warnin Nameplate
Fi ure 3. Caution Nameplate
SSaaffeettyy

14 TK 55711-19-OP-EN
Unit Description
The Thermo King TriPac E olution APU (Auxiliary Power Unit) pro ides
auxiliary heating, cooling temperature management that allows dri ers to
reduce unnecessary truck engine idling, conser e diesel fuel and sa e
money. TriPac E olution pro ides truck engine preheating, battery charging
and truck cab sleeper compartment climate control.
By using TriPac, dri ers can reduce fuel cost, rest comfortably during stops
and comply with local, state and federal anti-idle laws. Reducing
unnecessary truck engine idling also reduces engine wear and extends
engine maintenance inter als. TriPac’s own diesel engine uses an automatic
start/stop feature for additional fuel efficiency.
TriPac’s two-cylinder diesel engine is EPA Tier 4 appro ed. An automoti e
type air conditioning compressor is used for sleeper compartment cooling. A
fuel-fired air heater pro ides sleeper compartment heat in cold conditions.
Voltage sensing automatically charges the truck batteries from TriPac’s 12-
olt alternator. Noise dampening construction assures quiet operation. Truck
engine preheating pro ides easier cold-climate starts by exchanging coolant
between TriPac and the truck engine. An optional in erter pro ides 120- olt
power to operate on-board appliances.
An optional Arctic package aids truck engine startups in cold weather by
sensing low coolant temperature. The TriPac is started automatically to heat
the coolant as required.
Fi ure 4. TriPac Evolution APU

TK 55711-19-OP-EN 15
TriPac Standard Features
• Easy to operate Human Machine Interface (HMI) Controller
• Truck cab sleeper compartment cooling and heating for dri er comfort in
all climates
• Truck engine preheating for easy starts in cold climates
• Truck battery charging with automatic low oltage sensing
• 9.0 hp 2 cylinder diesel engine - EPA Tier 4
• Thermo King TK 15 compressor for air conditioning
• Diesel fuel-fired sleeper compartment air heater
• 65 amp alternator standard
• Noise-dampening construction for quiet operation
• Automatic start/stop operation for maximum fuel efficiency
TriPac System Components
• Auxiliary Power Unit (APU)
• Condenser
• E aporator
• Heater
• HMI Controller
• Engine On/Off Switch
• Control Box and Fuses
UUnniitt DDeessccrriippttiioonn

16 TK 55711-19-OP-EN
Auxiliary Power Unit (APU)
The TriPac E olution APU is mounted onto the side of the tractor’s frame
rails and contains the diesel engine, air conditioning compressor, alternator
and engine On/Off switch.
Fi ure 5. TriPac Evolution APU
Condenser
The Air Conditioning condenser is mounted on the back of the truck cab.
Fi ure 6. TriPac Condenser
UUnniitt DDeessccrriippttiioonn

TK 55711-19-OP-EN 17
Evaporator
The Air Conditioning e aporator is typically installed under the bunk in the
truck cab sleeper compartment. Air ducts from the E aporator carry
conditioned air to the sleeper compartment. The e aporator has a air filter
that can easily remo ed for cleaning.
Fi ure 7. TriPac Evaporator and Air Ducts
Heater
The TriPac heater is typically installed in the cargo compartment or under
the truck cab sleeper compartment. It draws fuel from the truck’s diesel fuel
tank and is powered by the truck’s batteries.
Fi ure 8. Heater
UUnniitt DDeessccrriippttiioonn

18 TK 55711-19-OP-EN
HMI Controller
DDAANNGGEERR
FFiirree HHaazzaarrdd!!
Always turn the TriPac system OFF at the HMI Control Panel On/Off button
while the truck is being refueled. Fuel apors could ignite if they come in
contact with TriPac electrical or heater components.
The TriPac HMI controller is installed in the truck cab, typically on a wall in
the sleeper compartment. It is easily accessible to the dri er and controls the
heating, cooling and fan operation of the TriPac. If necessary, system
operating parameters can be programmed by your Thermo King dealer.
Fi ure 9. HMI Controller
RAJ1007
En ine On/Off Switch
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
The unit may start automatically without warning if the Engine On/Off
Switch is in the On position.
WWAARRNNIINNGG
RRiisskk ooff IInnjjuurryy!!
Immediately stand clear when the preheat buzzer sounds. This indicates
that the engine is preheating. If the engine is hot, preheat time will only be a
few seconds.
The APU Engine On/Off Switch is located inside the TriPac APU housing on
the lower right side of the frame. This switch is used to disable the engine
when performing ser ice and maintenance on the TriPac system. The switch
is normally in the ON position to allow the TriPac system to operate.
UUnniitt DDeessccrriippttiioonn

TK 55711-19-OP-EN 19
Fi ure 10. En ine On/Off Switch
Control Box
The control box is typically located in the bunk area. The control box
contains the circuit board and operates on 12 Volt DC supplied by the truck
batteries.
The electrical system is protected by a number of fuses. Most of the fuses
are located inside the control box. Other fuses are located in fuse holders in
wire harnesses. Refer to (“Fuses,” p. 39).
Fi ure 11. Control Box
UUnniitt DDeessccrriippttiioonn

20 TK 55711-19-OP-EN
TriPac Options
Driver Convenience Packa e
Includes 1,800 watt in erter and two GFI receptacles. 120 amp alternator
pro ides quicker battery charging under hea y loads. Refer to the Operating
Instructions included with your in erter.
Standby Truck Inte ration
Pro ides seamless acti ation of the TriPac control system based on tractor
off / on indication.
Standby Truck Inte ration - with Dash-Mounted Selector
Switch
The switch allows the operator to disable the TriPac system without
accessing the HMI Control Panel in the sleeper.
Fi ure 12. Dash-Mounted Standby Switch
Dual Remote Hour Meter
Pro ides separate heater and TriPac engine time tracking for accurate and
effecti e maintenance/ Allows the technician to access and record hours of
operation without entering tractor cab.
Remote En ine Hour Meter
Pro ides engine time tracking for accurate and effecti e pre enti e
maintenance.
Closed Loop Coolin
Allows the TriPac to run independently of tractor coolant and allows “limp
home” capability in case of tractor alternator failure.
UUnniitt DDeessccrriippttiioonn
