Integration Guide
LonTalk®® Integration to Ascend™
Air-Cooled Chiller Model ACR
with Symbio™ 800 Controls

©2021 Trane BAS-SVP046A-EN
Introduction
Read this manual thoroughly before operating or servicing this unit
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as required Your personal safety and the
proper operation of this machine depend upon the strict observance of these precautions
The three types of advisories are defined as follows:
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAU TION
Indicates a potentially hazardous situation which, if not avoided, could result in
minor or moderate injury. It could also be used to alert against unsafe practices.
NOTICE
Indicates a situation that could result in equipment or property-damage only
accidents.
Important Environmental Concerns
Scientific research has shown that certain man-made chemicals can affect the earth’s naturally
occurring stratospheric ozone layer when released to the atmosphere In particular, several of the
identified chemicals that may affect the ozone layer are refrigerants that contain Chlorine,
Fluorine and Carbon (CFCs) and those containing Hydrogen, Chlorine, Fluorine and Carbon
(HCFCs) Not all refrigerants containing these compounds have the same potential impact to the
environment Trane advocates the responsible handling of all refrigerants-including industry
replacements for CFCs and HCFCs such as saturated or unsaturated HFCs and HCFCs
Important Responsi le Refrigerant Practices
Trane believes that responsible refrigerant practices are important to the environment, our
customers, and the air conditioning industry All technicians who handle refrigerants must be
certified according to local rules For the USA, the Federal Clean Air Act (Section 608) sets forth
the requirements for handling, reclaiming, recovering and recycling of certain refrigerants and
the equipment that is used in these service procedures In addition, some states or municipalities
may have additional requirements that must also be adhered to for responsible management of
refrigerants Know the applicable laws and follow them
WWAARRNNIINNGG
PPrrooppeerr FFiieelldd WWiirriinngg aanndd GGrroouunnddiinngg RReeqquuiirreedd!!
FFaaiilluurree ttoo ffoollllooww ccooddee ccoouulldd rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy
AAllll ffiieelldd wwiirriinngg MMUUSSTT bbee ppeerrffoorrmmeedd bbyy qquuaalliiffiieedd ppeerrssoonnnneell IImmpprrooppeerrllyy iinnssttaalllleedd aanndd
ggrroouunnddeedd ffiieelldd wwiirriinngg ppoosseess FFIIRREE aanndd EELLEECCTTRROOCCUUTTIIOONN hhaazzaarrddss TToo aavvooiidd tthheessee hhaazzaarrddss,,
yyoouu MMUUSSTT ffoollllooww rreeqquuiirreemmeennttss ffoorr ffiieelldd wwiirriinngg iinnssttaallllaattiioonn aanndd ggrroouunnddiinngg aass ddeessccrriibbeedd iinn
NNEECC aanndd yyoouurr llooccaall//ssttaattee//nnaattiioonnaall eelleeccttrriiccaall ccooddeess

BAS-SVP046A-EN 3
WWAARRNNIINNGG
PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE)) RReeqquuiirreedd!!
FFaaiilluurree ttoo wweeaarr pprrooppeerr PPPPEE ffoorr tthhee jjoobb bbeeiinngg uunnddeerrttaakkeenn ccoouulldd rreessuulltt iinn ddeeaatthh oorr sseerriioouuss
iinnjjuurryy
TTeecchhnniicciiaannss,, iinn oorrddeerr ttoo pprrootteecctt tthheemmsseellvveess ffrroomm ppootteennttiiaall eelleeccttrriiccaall,, mmeecchhaanniiccaall,, aanndd
cchheemmiiccaall hhaazzaarrddss,, MMUUSSTT ffoollllooww pprreeccaauuttiioonnss iinn tthhiiss mmaannuuaall aanndd oonn tthhee ttaaggss,, ssttiicckkeerrss,, aanndd
llaabbeellss,, aass wweellll aass tthhee iinnssttrruuccttiioonnss bbeellooww::
•• BBeeffoorree iinnssttaalllliinngg//sseerrvviicciinngg tthhiiss uunniitt,, tteecchhnniicciiaannss MMUUSSTT ppuutt oonn aallll PPPPEE rreeqquuiirreedd ffoorr
tthhee wwoorrkk bbeeiinngg uunnddeerrttaakkeenn ((EExxaammpplleess;; ccuutt rreessiissttaanntt gglloovveess//sslleeeevveess,, bbuuttyyll gglloovveess,,
ssaaffeettyy ggllaasssseess,, hhaarrdd hhaatt//bbuummpp ccaapp,, ffaallll pprrootteeccttiioonn,, eelleeccttrriiccaall PPPPEE aanndd aarrcc ffllaasshh
ccllootthhiinngg)) AALLWWAAYYSS rreeffeerr ttoo aapppprroopprriiaattee SSaaffeettyy DDaattaa SShheeeettss ((SSDDSS)) aanndd OOSSHHAA
gguuiiddeelliinneess ffoorr pprrooppeerr PPPPEE
•• WWhheenn wwoorrkkiinngg wwiitthh oorr aarroouunndd hhaazzaarrddoouuss cchheemmiiccaallss,, AALLWWAAYYSS rreeffeerr ttoo tthhee
aapppprroopprriiaattee SSDDSS aanndd OOSSHHAA//GGHHSS ((GGlloobbaall HHaarrmmoonniizzeedd SSyysstteemm ooff CCllaassssiiffiiccaattiioonn aanndd
LLaabbeelllliinngg ooff CChheemmiiccaallss)) gguuiiddeelliinneess ffoorr iinnffoorrmmaattiioonn oonn aalllloowwaabbllee ppeerrssoonnaall eexxppoossuurree
lleevveellss,, pprrooppeerr rreessppiirraattoorryy pprrootteeccttiioonn aanndd hhaannddlliinngg iinnssttrruuccttiioonnss
•• IIff tthheerree iiss aa rriisskk ooff eenneerrggiizzeedd eelleeccttrriiccaall ccoonnttaacctt,, aarrcc,, oorr ffllaasshh,, tteecchhnniicciiaannss MMUUSSTT ppuutt
oonn aallll PPPPEE iinn aaccccoorrddaannccee wwiitthh OOSSHHAA,, NNFFPPAA 7700EE,, oorr ootthheerr ccoouunnttrryy--ssppeecciiffiicc
rreeqquuiirreemmeennttss ffoorr aarrcc ffllaasshh pprrootteeccttiioonn,, PPRRIIOORR ttoo sseerrvviicciinngg tthhee uunniitt NNEEVVEERR PPEERRFFOORRMM
AANNYY SSWWIITTCCHHIINNGG,, DDIISSCCOONNNNEECCTTIINNGG,, OORR VVOOLLTTAAGGEE TTEESSTTIINNGG WWIITTHHOOUUTT PPRROOPPEERR
EELLEECCTTRRIICCAALL PPPPEE AANNDD AARRCC FFLLAASSHH CCLLOOTTHHIINNGG EENNSSUURREE EELLEECCTTRRIICCAALL MMEETTEERRSS AANNDD
EEQQUUIIPPMMEENNTT AARREE PPRROOPPEERRLLYY RRAATTEEDD FFOORR IINNTTEENNDDEEDD VVOOLLTTAAGGEE
WWAARRNNIINNGG
FFoollllooww EEHHSS PPoolliicciieess!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss bbeellooww ccoouulldd rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy
•• AAllll TTrraannee ppeerrssoonnnneell mmuusstt ffoollllooww tthhee ccoommppaannyy’’ss EEnnvviirroonnmmeennttaall,, HHeeaalltthh aanndd SSaaffeettyy
((EEHHSS)) ppoolliicciieess wwhheenn ppeerrffoorrmmiinngg wwoorrkk ssuucchh aass hhoott wwoorrkk,, eelleeccttrriiccaall,, ffaallll pprrootteeccttiioonn,,
lloocckkoouutt//ttaaggoouutt,, rreeffrriiggeerraanntt hhaannddlliinngg,, eettcc WWhheerree llooccaall rreegguullaattiioonnss aarree mmoorree
ssttrriinnggeenntt tthhaann tthheessee ppoolliicciieess,, tthhoossee rreegguullaattiioonnss ssuuppeerrsseeddee tthheessee ppoolliicciieess
•• NNoonn--TTrraannee ppeerrssoonnnneell sshhoouulldd aallwwaayyss ffoollllooww llooccaall rreegguullaattiioonnss
Copyright
This document and the information in it are the property of Trane, and may not be used or
reproduced in whole or in part without written permission Trane reserves the right to revise this
publication at any time, and to make changes to its content without obligation to notify any
person of such revision or change
Trademarks
All trademarks referenced in this document are the trademarks of their respective owners

4BAS-SVP046A-EN
Overview 5
Purpose 5
Symbio 800 Controller Overview 5
Communication Options 5
Units of Measure 5
Communication Setup and Configuration 6
Service Tool for Symbio™800 Configuration 6
Connecting to the Symbio™800 Web Interface 7
Protocol Configuration 8
LonTalk Protocol Settings 8
Profile Definition and Network Variables 10
ACRB 150–300 Tons Data Points 10
ACRB 350–500 Tons Data Points 13
Arbitration A–1
Symbio™800 Controller Display B–1
Ta le of Contents

BAS-SVP046A-EN 5
Overview
Purpose
The purpose of this document is to provide instructions for integrating the Symbio™800700
controller into Non-Trane building automation systems This document is targeted to system
integrators and controls contractors
Sym io 800 Controller Overview
The Trane Chiller includes the Symbio 800 controller The controller has been installed,
programmed, wired, commissioned, and tested in the factory prior to shipment While some
sensors and end devices are normally wired in the field, nearly all other wiring is factory-
provided Power for the controller is provided and connected from within the chiller control
panel
The chiller and associated controller can be applied as standalone or as part of a building
automation system
NNoottee:: For communicating applications to third-party control systems, network communication
wiring must be provided by others.
Communication Options
The Symbio™700800 controller supports the following communication protocol options for
integration to either Trane or Non-Trane control systems:
• BACnet MS/TP
• BACnet IP
• BACnet Zigbee (Air-Fi)™
• BACnet/IP
–Ethernet
–Wi-Fi
• Modbus RTU
• Modbus TCP
• LonTalk
For information pertaining to the integration of the Symbio™700800 controller using either
Modbus or LonTalk communication, refer to the integration guides specific to those applications
Units of Measure
The communicated data of the Symbio™800 controller will be passed in the factory-configured
units of measure, either inch-pound (I-P) or the International System of Units (SI) The units of
measure are selected as part of the unit order (the default selection is normally I-P) Should the
units of measure need to be changed in the field, contact your local Trane representative
The Symbio 800 controller provides a browser-based user interface for USB connection to the
controller One of the tools provided with that interface allows the user to change and customize
the Data Display Units Preferences
IImmppoorrttaanntt:: These adjustable settings are applied only to the units of measured displayed in the
web interface, not the communicated interface.
Regardless of the communicated (system) units of measure, the user may change the displayed
units of measure on their smart device These user preference units of measure are independent
of the communicated units

6BAS-SVP046A-EN
Communication Setup and Configuration
The Symbio™800 controller can be factory ordered with a specific protocol configuration and
rotary address setting If communication options were not specified, the Symbio™800 controller
will be setup for BACnet MS/TP communications at 76,800 bps with a rotary address setting of
000
Figure 1. Sym io™™ 800 rotary address and service tool port
Service Tool for Sym io™™ 800 Configuration
The service tool used to modify the Symbio™800 controller is a standard web browser The
Symbio™800 webpage is accessed by using a standard USB type A/B cable Connect the USB
cable between a laptop and the service tool port on the Symbio™800 controller (shown in Figure
1, p 6)

BAS-SVP046A-EN 7
Connecting to the Sym io™™ 800 We Interface
1 Connect a laptop to the Symbio™800 controller using a USB cable
2 On the laptop, open a web browser to http://198 80 18 1/
3 When the Symbio™800 page displays, click LLoogg IInn
Figure 2. Sym io™™ 800 log in screen
NNoottee:: The ymbio ™ 800 web interface can only be viewed using the U B connection. Ethernet
port 1 and Ethernet port 2 will not allow access to the ymbio
™ web server to meet IT
security requirements.
CCoommmmuunniiccaattiioonn SSeettuupp aanndd CCoonnffiigguurraattiioonn

8BAS-SVP046A-EN
Protocol Configuration
To access the Symbio 800 Protocol Configuration page:
1 Connect to the Symbio 800 web interface
2 On the left-hand navigation, click IInnssttaallllaattiioonn
3 Click IIddeennttiiffiiccaattiioonn aanndd CCoommmmuunniiccaattiioonnss
Figure 3. Identification and Communications
4 Click the PPrroottooccooll CCoonnffiigguurraattiioonn tab
Figure 4. Protocol Configuration
5 View the existing Protocol Configuration settings
NNoottee:: There are no LonTalk communication parameters to edit.
LonTalk Protocol Settings
The Symbio 800 controller supports LonTalk communications with the optional LonTalk module
The LonTalk module is din rail mounted and is connected to the Symbio 800 controller using
USB
NNoottee:: The ymbio 800 rotary addresses are not used with LonTalk communications.

BAS-SVP046A-EN 9
Figure 5. LonTalk protocol configuration
1 Verify the LonTalk adapter connection status is CCoonnnneecctteedd If the adapter connection status is
another state, verify the LonTalk adapter is connected to a Symbio 800 USB port
2 Verify the Link Status is OOnnlliinnee If the Link Status is set to a different state, LonTalk network
management software such as Trane’s Rover software is needed to set the Link status to
Online
3 The Service Pin button will send a service pin message to the LonTalk network A service pin
will broadcast the Neuron ID to the LonTalk network so a LonTalk network management tool
can find a device and set its Domain, Subnet, Node address
LonTalk communication wire is connected to the LonTalk adapter LonTalk does not require wire
polarity but it is recommended that wire polarity be observed Refer to the LonTalk standard for
detailed information on LonTalk wiring
All LonTalk devices must have a unique DSN address and must have the same Domain value
The Symbio 800 LonTalk adapter ships on the zero-length domain so it can be easily discovered
by LonTalk network managers and tools
PPrroottooccooll CCoonnffiigguurraattiioonn

10 BAS-SVP046A-EN
Profile Definition and Network Varia les
The following tables are sorted as follows:
• Tables are listed by unit/profile type and sorted by network variable number
• Tables are sorted by name and provide a complete list of names, types, values/ranges, and
descriptions
NNoottee:: Not all points are available to the user. The available data points are defined during
self-configuration and are dependent on the type of equipment.
ACRB 150–300 Tons Data Points
Ta le 1. ACRB 150–300 tons configuration parameters
nv Index Configuration
Variable Name Variable Type Variable description Point Name
2 nciChillerType UCPT_chiller_type Chiller Information
Model Information Enum list - See table in UNVT-UCPT.doc Model Information
Unit Capacity Capacity of Unit (in watts) Chiller Design Capacity
Cooling Type
0 = Water Cooled
1 = Air Cooled
2 to 254 = Unused
Cooling Type
Number of Circuits Number of Circuits on Unit Number Of Circuits
Number of Compressors – Crt 1 Number of Compressors on Circuit 1 Number Of Compressors, Circuit 1
Number of Compressors – Crt 2 Number of Compressors on Circuit 2 Number Of Compressors, Circuit 2
5nciMfgLocation UCPT_manufacturing_location Chiller Manufacturing Location Manufacture Location
6nciNoiseRdcnReq SNVT_switch Default for Noise Reduction Auto/On
Request Noise Reduction request
7nciRefrigerant UCPT_refrig_type Chiller Refrigerant Type Refrigerant Type
8nciCapacityLim SCPTCapacityLimit Capacity Limit Demand Limit Setpoint
9 nciChillerEnable SCPTChillerEnable Default Value for nviChillerEnable Chiller Enable
10 nciCoolsetpt SCPTCoolSetpoint Default Value for nviCoolSetpt Chiller water Setpoint
11 nciDefaults SCPTDefaultBehavior
Determines which set of values will be
used on power up and communications
failure, stated default values or a list of
manufacturer specified values
Default Values
12 nciDevMajVer SCPTdevMajVer The major version number for the device Software Major Version
13 nciDevMinVer SCPTdevMinVer The minor version number for the device Software Minor Version
15 nciLocation SCPTlocation Location Label Location Label
16 nciMinOutTm SCPTminSendTime Minimum Send Time Minimum Send Time
17 nciMode SCPTHVACmode Default Value for nviMode Chiller Mode
18 nciPwrup SCPTpwrUpDelay Power Up Delay Power Up Delay
19 nciRcvHrtBt SCPTmaxRcvTime Receive Heartbeat Time Receive Heartbeat
20 nciSndHrtBt SCPTmaxSendTime Send Heartbeat Time (nciMAXSendTime) Send Heartbeat
21 nciBuildNum U16 Device Build Number Manufacturer-defined
22 nciCRC UCPT_crc CRC calculation result Manufacturer-defined
23 nciDeviceConfig U16 Device Configuration Choices Manufacturer-defined

BAS-SVP046A-EN 11
Ta le 2. ACRB 150–300 tons network varia le inputs
Profile Index Network Variable
Name Variable Type Variable
description Recv HrtBt Point Name
24 nviChillerEnable SNVT_switch Request Start/Stop
Chiller ♥BAS Chiller Auto Stop Command
25 nviCoolSetpt SNVT_temp_p Desired Temp of Lvg
Chilled Wtr ♥BAS Chilled Water Setpoint
26 nviCapacityLim SNVT_lev_percent Capacity Limit of
Chiller ♥BAS Demand Limit Setpoint
28 nviMode SNVT_Hvac_mode Chiller Modes ♥BAS Chiller Mode Command
32 nviNoiseRdcnReq SNVT_switch (2-state) Noise Reduction Auto/
On Request ♥Noise Reduction Request BAS
35 nviRequest SNVT_obj_request Status Request Status Request Input
36 nviTraneVar2 UNVT_c5c Trane Comm 5
Command Input Manufacturer-defined
Ta le 3. ACRB 150–300 tons network varia le outputs
nv
Index
Configuration
Variable Name Variable Type Variable description Delta to Send
(Notes) SendHrdBt Point Name
37 nvoOnOff SNVT_switch Chiller On / Off run state any ♥Chiller Running State
38 nvoActiveSetpt SNVT_temp_p Active Cool or Heat Setpt 0.10 °C ♥Active Chilled Water Setpoint
39 nvoActualCapacity SNVT_lev_percent
Actual Running Capacity
of Unit 0.03 ♥Chiller Power
40 nvoCapacityLim SNVT_lev_percent
Current Capacity Limit
Setting of Chiller 0.01 ♥Active Demand Limit Setpoint
41 nvoLvgCHWTemp SNVT_temp_p
Leaving Chilled Water
Temp 0.10 °C ♥
Evaporator Leaving Water
Temperature
42 nvoEntCHWTemp SNVT_temp_p
Entering Chilled Water
Temp 0.10 °C ♥
Evaporator Entering Water
Temperature
44 nvoAlarmDescr SNVT_str_asc Alarm annunciation text N/A Diagnostic Last Message
45 nvoChillerstat
SNVT_chlr_stat Chiller States , modes any ♥
chiller_t (enum) Chiller Running Status
CHLR_OFF 00 = Chiller off
CHLR_START
01 = Chiller in start
mode
CHLR_RUN 02 = Chiller in run mode
CHLR_PRESHUTDN
03 = Chiller in pre-
shutdown mode
CHLR_SERVICE
04 = Chiller in service
mode
hvac_t (enum) Operating Mode
HVAC_COOL 03 = Cooling only
HVAC_ICE 0B = Ice-making mode
u8 (01234567)
in_alarm
bit 0 (MSB) = in alarm
mode Diagnostic Present
run_enabled bit 1 = run enabled Run Enable
local bit 2 = local Local Setpoint Control
limited bit 3 = limited Capacity Limited
chw_flow
bit 4 = evaporator water
flow Evaporator Water Flow Status
Not Defined bit 6 Not Defined Not defined
Not Defined bit 7 Not Defined Not defined
PPrrooffiillee DDeeffiinniittiioonn aanndd NNeettwwoorrkk VVaarriiaabblleess

12 BAS-SVP046A-EN
Ta le 3. ACRB 150–300 tons network varia le outputs (continued)
nv
Index
Configuration
Variable Name Variable Type Variable description Delta to Send
(Notes) SendHrdBt Point Name
46 nvoStatusOutputs
SNVT_state Status Outputs defined at element ♥
bits 0 – 7 Validity of bits 8 – 15 any Reserved
bit 8 Max Capacity any Maximum Capacity Relay
bit 12 Noise Reduction Active any Noise Reduction active
bit 15 (LSB) Not Defined Undefined Not defined
48 nvoCprsrsRunning
SNVT_state
Compressor Running
Outputs defined at element ♥
bits 0 – 7 Validity of bits 8 – 15 any Reserved
bit 8 Compressor A Running any Running Status Compressor 1A
bit 11 Compressor D Running any Running Status Compressor 2A
49 nvoEvapWtrPump SNVT_switch
Evaporator Water Pump
Request any ♥Evaporator Water Pump Command
50 nvoEvapWtrFlow SNVT_switch
Evaporator Water Flow
Status5 any ♥Evaporator Water Flow Status
53 nvoOutdoorTemp SNVT_temp_p Outdoor Air Temperature 1.00°C ♥Outdoor Air Temperature
54 nvoEvapWFlowRate SNVT_flow
Evaporator Water Flow
Rate defined at element ♥Evaporator Water Flow Rate
64 nvoEvapRfgtPrsC1 SNVT_press_f
Evaporator Refrigerant
Pressure - Circuit 1 5.0 kPa ♥
Evaporator Refrigerant Pressure
Ckt1
65 nvoEvapRfgtPrsC2 SNVT_press_f
Evaporator Refrigerant
Pressure - Circuit 2 5.0 kPa ♥
Evaporator Refrigerant Pressure
Ckt2
66 nvoEvapRfgtTmpC1 SNVT_temp_p
Evaporator Refrigerant
Temperature - Circuit 1 0.50°C ♥
Evaporator Saturated Rfgt Temp
Ckt1
67 nvoEvapRfgtTmpC2 SNVT_temp_p
Evaporator Refrigerant
Temperature - Circuit 2 0.50°C ♥
Evaporator Saturated Rfgt Temp
Ckt2
68 nvoCondRfgtPrsC1 SNVT_press_f
Condenser Refrigerant
Pressure - Circuit 1 30.0 kPa ♥
Condenser Refrigerant Pressure
Ckt1
69 nvoCondRfgtPrsC2 SNVT_press_f
Condenser Refrigerant
Pressure - Circuit 2 30.0 kPa ♥
Condenser Refrigerant Pressure
Ckt2
70
nvo-
CondRfgtTmpC1 SNVT_temp_p
Condenser Refrigerant
Temperature - Circuit 1 1.00°C or 3.00°C ♥
Condenser Saturated Rfgt Temp
Ckt1
71
nvo-
CondRfgtTmpC2 SNVT_temp_p
Condenser Refrigerant
Temperature - Circuit 2 1.00°C or 3.00°C ♥
Condenser Saturated Rfgt Temp
Ckt2
72 nvoAirFlowPctC1 SNVT_lev_percent
Air Flow Percent – Circuit
1 0.05 ♥Air Flow Ckt1
73 nvoAirFlowPctC2 SNVT_lev_percent
Air Flow Percent – Circuit
2 0.05 ♥Air Flow Ckt2
76 nvoHiSideOilPrsA SNVT_press_f
High Side Oil Pressure -
Compressor A 20.0 kPa ♥Oil Pressure - Compressor 1A
79 nvoHiSideOilPrsD SNVT_press_f
High Side Oil Pressure -
Compressor D 20.0 kPa ♥Oil Pressure - Compressor 2A
94 nvoRfgtDischTmpA SNVT_temp_p
Refrigerant Discharge
Temperature -
Compressor A 0.50°C ♥
Discharge Temperature
Compressor 1A
97 nvoRfgtDischTmpD SNVT_temp_p
Refrigerant Discharge
Temperature -
Compressor D 0.50°C ♥
Discharge Temperature
Compressor 2A
112 nvoStartsRunTmA
UNVT_starts_runtime
Starts and Run Time –
Compressor A defined at element ♥
SNVT_count_f Starts 1 Starts Compressor 1A
SNVT_time_f Run Time 360 sec Running Time Compressor 1A
115 nvoStartsRunTmD
UNVT_starts_runtime
Starts and Run Time –
Compressor D defined at element ♥
SNVT_count_f Starts 1 Starts Compressor 2A
SNVT_time_f Run Time 360 sec Running Time Compressor 2A
118 nvoUnitPower SNVT_power_f Unit Power Consumption Note 1 ♥Unit Power Consumption
133 nvoStatus SNVT_obj_status Status Response NA ♥Status Response
134
nvoTraneVar9 UNVT_c5s
Trane Comm 5 Status
Output Manufacturer-defined
nvoFileDirectory SNVT_address File Directory NA File Directory
PPrrooffiillee DDeeffiinniittiioonn aanndd NNeettwwoorrkk VVaarriiaabblleess

BAS-SVP046A-EN 13
ACRB 350–500 Tons Data Points
Ta le 4. ACRB 350–500 tons configuration parameters
nv Index Configuration
Variable Name Variable Type Variable description Point Name
2 nciChillerType UCPT_chiller_type Chiller Information
Model Information Enum list - See table in UNVT-UCPT.doc Model Information
Unit Capacity Capacity of Unit (in watts) Chiller Design Capacity
Cooling Type
0 = Water Cooled
1 = Air Cooled
2 to 254 = Unused
Cooling Type
Number of Circuits Number of Circuits on Unit Number Of Circuits
Number of Compressors – Crt 1 Number of Compressors on Circuit 1 Number Of Compressors,
Circuit 1
Number of Compressors – Crt 2 Number of Compressors on Circuit 2 Number Of Compressors,
Circuit 2
5nciMfgLocation UCPT_manufacturing_location Chiller Manufacturing Location Manufacture Location
6nciNoiseRdcnReq SNVT_switch Default for Noise Reduction Auto/On
Request Noise Reduction request
7nciRefrigerant UCPT_refrig_type Chiller Refrigerant Type Refrigerant Type
8nciCapacityLim SCPTCapacityLimit Capacity Limit Demand Limit Setpoint
9 nciChillerEnable SCPTChillerEnable Default Value for nviChillerEnable Chiller Enable
10 nciCoolsetpt SCPTCoolSetpoint Default Value for nviCoolSetpt Chiller water Setpoint
11 nciDefaults SCPTDefaultBehavior
Determines which set of values will be
used on power up and communications
failure, stated default values or a list of
manufacturer specified values
Default Values
12 nciDevMajVer SCPTdevMajVer The major version number for the device Software Major Version
13 nciDevMinVer SCPTdevMinVer The minor version number for the device Software Minor Version
15 nciLocation SCPTlocation Location Label Location Label
16 nciMinOutTm SCPTminSendTime Minimum Send Time Minimum Send Time
17 nciMode SCPTHVACmode Default Value for nviMode Chiller Mode
18 nciPwrup SCPTpwrUpDelay Power Up Delay Power Up Delay
19 nciRcvHrtBt SCPTmaxRcvTime Receive Heartbeat Time Receive Heartbeat
20 nciSndHrtBt SCPTmaxSendTime Send Heartbeat Time (nciMAXSendTime) Send Heartbeat
21 nciBuildNum U16 Device Build Number Manufacturer-defined
22 nciCRC UCPT_crc CRC calculation result Manufacturer-defined
23 nciDeviceConfig U16 Device Configuration Choices Manufacturer-defined
Ta le 5. ACRB 350–500 tons network varia le inputs
Profile Index Network Variable
Name Variable Type Variable
description Recv HrtBt Point Name
24 nviChillerEnable SNVT_switch Request Start/Stop
Chiller ♥BAS Chiller Auto Stop
Command
25 nviCoolSetpt SNVT_temp_p Desired Temp of Lvg
Chilled Wtr ♥BAS Chilled Water Setpoint
26 nviCapacityLim SNVT_lev_percent Capacity Limit of
Chiller ♥BAS Demand Limit Setpoint
28 nviMode SNVT_Hvac_mode Chiller Modes ♥BAS Chiller Mode Command
32 nviNoiseRdcnReq SNVT_switch (2-state) Noise Reduction Auto/
On Request ♥Noise Reduction Request BAS
35 nviRequest SNVT_obj_request Status Request Status Request Input
36 nviTraneVar2 UNVT_c5c Comm5 Status Manufacturer-defined
PPrrooffiillee DDeeffiinniittiioonn aanndd NNeettwwoorrkk VVaarriiaabblleess

14 BAS-SVP046A-EN
Ta le 6. ACRB 350–500 tons network varia le outputs
nv
Index
Configuration
Variable Name Variable Type Variable description Delta to Send
(Notes) SendHrdBt Point Name
37 nvoOnOff SNVT_switch Chiller On / Off run state any ♥Chiller Running State
38 nvoActiveSetpt SNVT_temp_p Active Cool or Heat Setpt 0.10 °C ♥Active Chilled Water
Setpoint
39 nvoActualCap SNVT_lev_percent Actual Running Capacity
of Unit 0.03 ♥Chiller Power
40 nvoCapacityLim SNVT_lev_percent Current Capacity Limit
Setting of Chiller 0.01 ♥Active Demand Limit
Setpoint
41 nvoLvgCHWTemp SNVT_temp_p Leaving Chilled Water
Temp 0.10 °C ♥Evaporator Leaving Water
Temperature
42 nvoEntCHWTemp SNVT_temp_p Entering Chilled Water
Temp 0.10 °C ♥Evaporator Entering Water
Temperature
44 nvoAlarmDescr SNVT_str_asc Alarm annunciation text N/A Diagnostic Last Message
45 nvoChillerstat
SNVT_chlr_stat Chiller States , modes any ♥
chiller_t (enum)
Chiller Running Status
CHLR_OFF 00 = Chiller off
CHLR_START 01 = Chiller in start
mode
CHLR_RUN 02 = Chiller in run mode
CHLR_PRESHUTDN 03 = Chiller in pre-
shutdown mode
CHLR_SERVICE 04 = Chiller in service
mode
hvac_t (enum)
Operating Mode
HVAC_COOL 03 = Cooling only
HVAC_FREE_COOL 0A = Cooling with
compressor not running
HVAC_ICE 0B = Ice-making mode
u8 (01234567)
in_alarm bit 0 (MSB) = in alarm
mode Diagnostic Present
run_enabled bit 1 = run enabled Run Enable
local bit 2 = local Local Setpoint Control
limited bit 3 = limited Capacity Limited
chw_flow bit 4 = evaporator water
flow
Evaporator Water Flow
Status
Not Defined bit 6 Not Defined Not Defined
Not Defined bit 7 Not Defined Not Defined
46 nvoStatusOutputs
SNVT_state Status Outputs defined at element ♥
bits 0 – 7 Validity of bits 8 – 15 any Reserved
bit 8 Max Capacity any Maximum Capacity Relay
bit 9 Head Relief Request any Head Relief Request
bit 12 Noise Reduction Active any Noise Reduction active
bit 15 (LSB) Not Defined Undefined Not Defined
48 nvoCprsrsRunning
SNVT_state Compressor Running
Outputs defined at element ♥
bits 0 – 7 Validity of bits 8 – 15 any Reserved
bit 8 Compressor A Running any Running Status
Compressor 1A
bit 9 Compressor B Running any Running Status
Compressor 1B
bit 11 Compressor D Running any Running Status
Compressor 2A
49 nvoEvapWtrPump SNVT_switch Evaporator Water Pump
Request any ♥Evaporator Water Pump
Command
50 nvoEvapWtrFlow SNVT_switch Evaporator Water Flow
Status5 any ♥Evaporator Water Flow Status
PPrrooffiillee DDeeffiinniittiioonn aanndd NNeettwwoorrkk VVaarriiaabblleess

BAS-SVP046A-EN 15
Ta le 6. ACRB 350–500 tons network varia le outputs (continued)
nv
Index
Configuration
Variable Name Variable Type Variable description Delta to Send
(Notes) SendHrdBt Point Name
53 nvoOutdoorTemp SNVT_temp_p Outdoor Air Temperature 1.00°C ♥Outdoor Air Temperature
58 nvoEvapAprchTmp SNVT_temp_diff_p Evaporator Approach
Temperature 0.50°C ♥Evaporator Approach Temperature
62 nvoUnitVoltage
UNVT_3phase_volt Unit Voltage Per Phase defined at element ♥
SNVT_volt_ac BC voltage Note 1 Starter Voltage Phase BC
SNVT_volt_ac CA voltage Note 1 Starter Voltage Phase CA
SNVT_volt_ac AB voltage Note 1 Starter Voltage Phase AB
64 nvoEvapRfgtPrsC1 SNVT_press_f Evaporator Refrigerant
Pressure - Circuit 1 5.0 kPa ♥Evaporator Refrigerant Pressure Ckt1
65 nvoEvapRfgtPrsC2 SNVT_press_f Evaporator Refrigerant
Pressure - Circuit 2 5.0 kPa ♥Evaporator Refrigerant
Pressure Ckt2
66 nvoEvapRfgtTmpC1 SNVT_temp_p Evaporator Refrigerant
Temperature - Circuit 1 0.50°C ♥Evaporator Saturated Rfgt Temp Ckt1
67 nvoEvapRfgtTmpC2 SNVT_temp_p Evaporator Refrigerant
Temperature - Circuit 2 0.50°C ♥Evaporator Saturated Rfgt Temp Ckt2
68 nvoCondRfgtPrsC1 SNVT_press_f Condenser Refrigerant
Pressure - Circuit 1 30 KPA ♥Condenser Refrigerant Pressure Ckt1
69 nvoCondRfgtPrsC2 SNVT_press_f Condenser Refrigerant
Pressure - Circuit 2 30 KPA ♥Condenser Refrigerant
Pressure Ckt2
70 nvo-
CondRfgtTmpC1 SNVT_temp_p Condenser Refrigerant
Temperature - Circuit 1
1.00°C or 3.00°C
6♥Condenser Saturated Rfgt
Temp Ckt1
71 nvo-
CondRfgtTmpC2 SNVT_temp_p Condenser Refrigerant
Temperature - Circuit 2
1.00°C or 3.00°C
6♥Condenser Saturated Rfgt
Temp Ckt2
72 nvoAirFlowPctC1 SNVT_lev_percent Air Flow Percent – Circuit
15.00% ♥Air Flow Ckt1
73 nvoAirFlowPctC2 SNVT_lev_percent Air Flow Percent – Circuit
25.00% ♥Air Flow Ckt2
76 nvoHiSideOilPrsA SNVT_press_f High Side Oil Pressure -
Compressor A 20.0 kPa ♥Oil Pressure - Compressor
1A
77 nvoHiSideOilPrsB SNVT_press_f High Side Oil Pressure -
Compressor B 20.0 kPa ♥Oil Pressure - Compressor
1B
79 nvoHiSideOilPrsD SNVT_press_f High Side Oil Pressure -
Compressor D 20.0 kPa ♥Oil Pressure - Compressor
2A
94 nvoRfgtDischTmpA SNVT_temp_p
Refrigerant Discharge
Temperature -
Compressor A
0.50°C ♥Discharge Temperature
Compressor 1A
95 nvoRfgtDischTmpB SNVT_temp_p
Refrigerant Discharge
Temperature -
Compressor B
0.50°C ♥Discharge Temperature
Compressor 1B
97 nvoRfgtDischTmpD SNVT_temp_p
Refrigerant Discharge
Temperature -
Compressor D
0.50°C ♥Discharge Temperature
Compressor 2A
100 nvoVoltageB
UNVT_3phase_volt Voltage Per Phase –
Compressor B defined at element ♥
SNVT_volt_ac BC phase voltage Note 1 Phase BC Voltage -
Compressor 1B
SNVT_volt_ac CA phase voltage Note 1 Phase CA Voltage -
Compressor 1B
SNVT_volt_ac AB phase voltage Note 1 Phase AB Voltage -
Compressor 1B
107 nvoCurrentB
UNVT_3phase_
current
Current Per Line –
Compressor B defined at element ♥
SNVT_amp_ac L1 current in Amps Note 2 Line 1 Current -
Compressor 1B
SNVT_amp_ac L2 current in Amps Note 2 Line 2 Current -
Compressor 1B
SNVT_amp_ac L3 current in Amps Note 2 Line 2 Current -
Compressor 1B
SNVT_lev_percent L1 current in %RLA 100% Line 1 Current RLA -
Compressor 1B
SNVT_lev_percent L2 current in %RLA 100% Line 2 Current RLA -
Compressor 1B
SNVT_lev_percent L3 current in %RLA 100% Line 3 Current RLA -
Compressor 1B
112 nvoStartsRunTmA
UNVT_starts_runtime Starts and Run Time –
Compressor A defined at element ♥
SNVT_count_f Starts 1 Starts Compressor 1A
SNVT_time_f Run Time 360 sec Running Time Compressor
1A
PPrrooffiillee DDeeffiinniittiioonn aanndd NNeettwwoorrkk VVaarriiaabblleess

16 BAS-SVP046A-EN
Ta le 6. ACRB 350–500 tons network varia le outputs (continued)
nv
Index
Configuration
Variable Name Variable Type Variable description Delta to Send
(Notes) SendHrdBt Point Name
113 nvoStartsRunTmB
UNVT_starts_runtime Starts and Run Time –
Compressor B defined at element ♥
SNVT_count_f Starts 1 Starts Compressor 1B
SNVT_time_f Run Time 360 sec Running Time Compressor
1B
115 nvoStartsRunTmD
UNVT_starts_runtime Starts and Run Time –
Compressor D defined at element ♥
SNVT_count_f Starts 1 Starts Compressor 2A
SNVT_time_f Run Time 360 sec Running Time Compressor
2A
118 nvoUnitPower SNVT_power_f Unit Power Consumption Note 3 ♥Unit Power Consumption
133 nvoStatus SNVT_obj_status Status Response NA ♥Status Response
134
nvoTraneVar9 UNVT_c5s Trane Comm 5 Status
Output Manufacturer-defined
nvoFileDirectory SNVT_address File Directory NA File Directory
PPrrooffiillee DDeeffiinniittiioonn aanndd NNeettwwoorrkk VVaarriiaabblleess

BAS-SVP046A-EN A–1
Appendix A. Ar itration
The Symbio™800 controller includes arbitration logic for several points For each read/write
point designated as “BAS”, an associated “Arbitration” point determines the behavior of that
communicated data compared to the local hardwired (or wireless) sensor and a default value
As shown in Figure 6, p A–1, the arbitrator considers all possible sources of the provided data,
including Building Management Systems (BMS), local, and default Each potential source is
defined at a pre-determined, fixed priority When the arbitration method is selected as full/auto,
the BMS value is used instead of the local or default values
The point designator with the arbitrator suffix includes the full priority array, allowing the user to
see the value associated with all potential sources considered in the logic The active point
reflects the result of the arbitration logic
Because the arbitrated points are normally associated with sensors, the default value is invalid,
meaning the value must be provided either by the BMS or the local sensor
Figure 6. Ar itration method - full/auto
When the Arbitration Method is selected as local, the BMS value is ignored and local value is
used instead Though the arbitration logic still considers all inputs, any values sent by the BMS
are effectively ignored
Figure 7. Ar itration method - local

B–1 BAS-SVP046A-EN
Appendix B. Sym io™™ 800 Controller Display
Figure 8. Sym io™™ 800 controller display and LEDs
77––SSeeggmmeenntt ssttaattuuss ddiissppllaayy
Ta le 7. Codes for 7–segment display segment
Code Description
U0. Waiting for USB drives to mount
U2. Checking signature on the .scfw file
U3. Checking software maintenance plan
U4. Reformatting main filesystem (clearing database)
U5. Beginning update
U12. Searching for.scfw files on USB drive(s)
U51. Updating main firmware
U54. Updating FPGA image
U55. Updating U-boot image
U57. Updating recovery partition
NNoottee:: A code starting with an “F” indicates a failure, and requires Trane ervice to resolve the
issue.
PP11 LLiinnkk —— BBAACCnneett MMSS//TTPP oorr MMooddbbuuss RRTTUU
• RS-485 daisy chain
• Used for connection to a Master Controller

BAS-SVP046A-EN B–2
Figure 9. P2 Mod us device (factory installed Mod us slave devices)
NNoottee:: The P2 link is intended for factory devices only and should not have any other devices
added this link.
Figure 10. P3 machine us (glo al us — internal communication us)
NNoottee:: The P3 link is intended for factory devices only and should not have any other devices
added this link.
SSyymmbbiioo™™ 880000 CCoonnttrroolllleerr DDiissppllaayy

B–3 BAS-SVP046A-EN
Figure 11. IMC link terminations for optional Air-Fi and expansion module (XM70)
Figure 12. (4) USB connectors
The controller automatically detects devices on any of the ports (not port specific) The controller
ships with all ports enabled, but they can be disabled via the Web interface
SSyymmbbiioo™™ 880000 CCoonnttrroolllleerr DDiissppllaayy
