Trango Systems Altum AC User manual

Set the following:
Country Code - US-PTP-2
Wireless Profile - 802.11g+n
Channel Spectrum Width -
20/40 MHz
Channel - Auto
Transmit Power - Max
Mode - Access Point
ESSID - A600-2
(Note: This is the default
ESSID. You can change this
name if you’d like.)
Click
4
5
6
7
8
9
11
4
5
8
6
10
11
7
10
9
LT-9073-A Page 1 of 2
© Trango Systems • Phone: [phone] • Email: [e-mail] • Web: trangosys.com, support.trangosys.com, store.trangosys.com
2.4 GHz
Omni Antennas
Installed
Altum AC ™Quick Start Guide
2.4 GHz WiFi Access Point
Follow the steps in the Altum AC Quick Start Guide “Point-to-Point
Link Configuration” to setup a Altum AC link. You can find this on
the Trango support site http://support.trangosys.com.
Install two 2.4 GHz omni directional antennas to the
two N-Type connectors on the bottom of the Station.
Navigate to a web browser and enter the IP address for the Station. Our example in the “Point-to-Point Link Coniguration” Quick Staart
Guide is 192.168.1.20 Enter your Username and Password. The default Username is admin and Password is trango (case sensitive).
Log in to the radio by clicking
1
1
2
3
2
3
Navigate to Network > Wifi. In the first row that is labeled click
1 2 3
1
2
3
N-Type Connectors
2.4 GHz Omni Antennas
Step 2 - Install the 2.4 GHz Omni Antennas
Step 1 - Set up a Point-to-Point Link
Step 3 - Login to the Station Unit
Step 4 - Edit the Station’s WiFi Settings

LT-9073-A Page 2 of 2
© Trango Systems • Phone: [phone] • Email: [e-mail] • Web: trangosys.com, support.trangosys.com, store.trangosys.com
Under Interface Configuration select the Wireless Security tab. In the Encryption drop down menu select WPA2-PSK.
3 4
Select Cipher-Auto and set the password key. This key will be required by connected users on the WiFi. Click
5 6 7
Under Device Configuration > General Setup tab > Select Enable. Click
1 2
To view connected users on the WiFi access point, Navigate to Status > Overview.
Under Associated Stations the connected users will be displayed.
Navigate to Network > Wifi. In the first row that is labeled click
1 2 3
1
2
3
3
4
5
6
7
1
2
1 2
1
2
Step 5 - Set up Wireless Security (Optional)
Step 5 - Enable the 2.4 GHz Wireless Network
Step 6 - View Connected Users
