Transcend TS-USL3 User manual

TS-USL3,TS-USL3/N
TS-USP3,TS-USP3/N
USER’S MANUAL
Intel® Socket 370 CeleronTM /
Pentium® III CPU

TS-USL3 Family Motherboard
Supporting Intel® Pentium®III/Celeron Series Processor
66/100/133MHz Front Side Bus
Intel®815EChipset
Welcome!!
Congratulations on your purchase of this great value motherboard, with its range of special
features and innovative onboard functions built around the advanced architecture of the new
Intel®815EChipset. More detailsfollow laterinthis manual.
Our Website
Please come and visit us on our website at http://www.transcendusa.com/ You’ll find plenty of
interesting information about this and many other quality Transcend products.
Your User’s Manual
ThisUser’sManualisdesignedtohelp endusersandsystem manufacturerstosetupandinstall
themotherboard. Alloftheinformationwithinhasbeencarefullycheckedforaccuracy. However,
TranscendInformation,Inc. (hereinafterreferred toas “Transcend”) carriesno responsibilityor
liabilityforanyerrors orinaccuracieswhichthismanualmay contain.Thisincludesreferencesto
products and software. In addition, the information and specifications are subject to change
withoutpriornotice.
Disclaimer
Transcend provides this manual “as is” without any warranty of any kind, either expressed or
implied, including – but not limited to – the implied warranties, conditions of merchantability or
fitnessforaparticularpurpose. Transcend, itsmanagement,employees,distributorsandagents
areinno wayliableforany indirect,special,incidentalor consequentialdamages,includingloss
of profits, loss of business, etc. This freedom from liability remains in effect even if Transcend
has been advised of the possibility of such damages arising from any defect or error in this
manualorproduct.
Trademarks
All brands, product names and trademarks mentioned in this document are the properties of
theirrespective ownersor companiesand areused solelyfor identification orexplanation. It is
Transcend policy to respect all product rights.
Copyright
This manual may not, in whole or in part, be photocopied, reproduced, transcribed, translated
ortransmitted,inwhateverformorlanguage,withoutthepriorwrittenconsentofthemanufacturer,
exceptfor copiesretained bythe purchaserforpersonal archivingpurposes.
ManualVersion: 1.00
Release Date: November 2000
Copyright © 2000 Transcend Information, Inc.

TableofContents
CHAPTER 1 INTRODUCTION 1
1.1 Essential Handling Precautions......................................................................1
1.2 Package Contents........................................................................................2
1.3 Specifications and Features..........................................................................2
CHAPTER 2 HARDWARE INSTALLATION 5
2.1 Transcend TS-USL3 Motherboard...................................................................5
2.2 Layout of Transcend TS-USL3 Motherboard...................................................6
2.3 Jumper Setup................................................................................................7
2.3.1 66/100/133MHz System Configuration....................................................7
2.3.2 Using Jumper JP1 to Clear CMOS.........................................................8
2.3.3 Onboard Audio Setting...........................................................................10
2.3.4 Keyboard Wake Up.................................................................................10
2.3.5 VCC3 Adjust............................................................................................11
2.4 Connector Description.......................................................................................12
2.4.1 Primary/Secondary IDE Connectors......................................................12
2.4.2 Floppy Disk Drive Connector..................................................................13
2.4.3 Fan Power Connectors...........................................................................14
2.4.4 Memory Configuration.............................................................................15
2.4.5 Panel Connectors....................................................................................16
2.4.6 Wake-on-LAN Connector........................................................................18
2.4.7 Power Connector....................................................................................19
2.4.8 IrDA-Compliant Infrared Module Connector...........................................20
2.4.9 Internal Serial Port Connector COMB .................................................21
2.4.10 Internal Audio Connector..........................................................22

CHAPTER 3 BIOS SETUP 25
3.1 BIOS Setup ............................................................................................... 25
3.2 The Main Menu ......................................................................................... 25
3.3 Standard CMOS Features........................................................................... 27
3.4 Advanced BIOS Features............................................................................ 30
3.5 Advanced Chipset Features ........................................................................ 33
3.6 Integrated Peripherals .................................................................................36
3.7 Power Management Setup...........................................................................40
3.8 PnP/PCI Configuration Setup....................................................................... 43
3.9 PC Health Status ........................................................................................45
3.10 Frequency/Voltage Control..........................................................................46
3.11 Load Fail-Safe Defaults.................................................................................48
3.12 Load Optimized Defaults.............................................................................48
3.13 Supervisor Password..................................................................................49
3.14 User Password...........................................................................................50
3.15 Save & Exit Setup.......................................................................................50
3.16 Exit Without Saving ................................................................................... 51
CHAPTER 4 SOFTWARE SETUP 52
4.1 INF Update for 815E Chipset ....................................................................... 52
4.2 VGA Driver Setup.......................................................................................53
4.3 Intel Security Controller Driver.....................................................................54
4.4 Audio Driver Setup.......................................................................................55
CHAPTER 5 BIOS UPGRADE 58
5.1 How to Check Your BIOS File Name and Version ........................................ 58
5.2 HowtoDownloadthe CorrectBIOSFilefromthe Web.........................................58
5.3 How to Upgrade Your Motherboard BIOS ..................................................... 59
2.4.11 USB 3/4 Connector.........................................................................
2.5 External Back Panel I/O Ports.......................................................................24
23
2.4.12 EEPROM for Storage of the Alert Envelope...................................23
CHAPTER 6 APPENDIX 60

INTRODUCTION 1
CHAPTER 1 INTRODUCTION
1.1 Essential Handling Precautions
IMPORTANT. Read this page before unpacking your motherboard!
•Power Supply
Becareful! Always ensure thatthe computer isdisconnected from thepower supplybefore
workingon themotherboardand itscomponents.
•Static Electricity
Static electricity may cause damage to the delicate integrated circuit chips on your
motherboard. Before handling the motherboard outside of its protective packaging, ensure
thatthereisnostaticelectricchargeinyourbody. Astaticdischargesufficientlystrongenough
to damage computer components is not perceptible by a human. To avoid this risk, please
observethese simpleprecautionswhile handlingthemotherboard andother computercom-
ponents:
1.If possible,wearan anti-staticwrist strapconnectedto anatural earthground.
2.Toucha groundedor anti-staticsurface, ora metalfixture suchas apipe orthe chassisof
yoursystem, beforetouching themotherboard.
3.When youhaveremoved themotherboard fromitsanti-static packaging,tryto holdit only
bythe edges,withouttouching anycomponents.
4.Avoidcontacting thecomponentsonadd-on cards,motherboards,and moduleswithgold-
coloredconnectorswhich plugintothe expansionslots.
5.Itis safesttohandle systemcomponentsonly bytheir mountingbrackets.
6.Keep componentswhich arenot connectedto thesystemin theanti-static packaging
wheneverpossible.
Theseprecautionshelp toreducetheriskof staticbuild-upandensure anystaticdischargeis
harmlesstoyourequipment.
••
••
•Battery Replacement
The battery which holds the system settings memory (CMOS RAM) on your motherboard
should not require replacement for at least five years, probably much longer. In picture 2.2
(page 6), it is located near the lower left corner. Incorrect computer time and/or loss of time
mayindicate aweak motherboardbatttery.

Please replace your battery only with the same type, or a similar type recommended by the
battery manufacturer. If the battery is replaced incorrectly, there is a risk of a short circuit or
explosion. Usedbatteriesshould disposedofin accordancewiththe manufacturer’sinstruc-
tionsandlocalenvironmental regulations.
••
••
•Electric Screwdrivers
To reduce the risk of damage to the motherboard due to excessive torque, avoid setting
electric screwdrivers above 7.5 kg/cm.
1.2 Package Contents
Thismotherboard package shouldcontain thefollowing items. Please checkthem assoon as
youunpack. If you findanydamaged ormissing items,please contactyour retailer.
- Motherboard X 1
- 1 X CD-ROM
- 1 X FDD cable
- User’s Manual
- COM port cable x 1 (optional)
- Ultra DMA66/100 cable x 1
- USB Cable x 1 ( optional )
1.3 Specifications and Features
• •
• •
• CPU
- Supports Intel®Pentium III/CeleronTM Series
• •
• •
• Chipset
- Intel®815E (GMCH, ICH2); FSB: 66/100/133 MHz
• •
• •
• Display Cache Memory (TS-USL3,TS-USL3/Nonly)
- AIMM (AGP Inline Memory Module) Card (Optional)
• •
• •
• DRAM Memory
-Supports SynchronousDRAM
- 3 X 168-pin DIMM module sockets on board
- 8~512MB memory size
- 8/16/32/64/128/256/512MB DIMM
- 64 data bits structure only
2 INTRODUCTION

• •
• •
• I/O Bus Slot
-3 X Master/SlavePCI Bus slots(PCI 2.2compliant)
-1 XCNR (Communicationand NetwokingRiser) slot
• Award BIOS
-Supports PC99,Plug-and-Play
-Supports ACPI,APM, DMI,GreenFeature
• •
• •
• I/O Functions
-Supports PIO Mode3, 4, 5ATAPI devices andUltra DMA/33/66/100
- Supports 2 high speed UART 16550 COM ports
- Supports SPP/EPP/ECP LPT port
-Supports 3mode/1.44MB/2.88MB floppydrive
- Supports PS/2 Mouse and PS/2 Keyboard
-Supports IrDAport
- Supports 4XUSB ports(2 by cable)
- Supports VGA port
INTRODUCTION 3
-Supports Line-out,Line-inand MIC-injack
- Supports Game/MIDI port
- Supports 10/100 Mbps LAN port(TS-USL3/N,TS-USP3/N only)
• Switching Voltage Regulator
- Intel VRM 8.4 compliant
• •
• •
• On Board VGA(TS-USL3,TS-USL3/N only)
- Full 2D/3D/Direct X acceleration
-Texture-mapped3D withpoint-sampled,bilinear,trilinear,and anisotropicfiltering
- Supports 640 by 480(16,256,High,True color)
- Supports 800 by 600(256,High,True color)
- Supports 1024 by 768(256,High,True color)
- Supports 1152 by 864(256,High,True color)
- Supports 1280 by 1024(256,High,True color)
- Supports 1600 by 1200(256 colors)

4 INTRODUCTION
• PCB Dimensions
- Micro-ATX form factor, 4-layer PCB, 24.3cm x 22.5cm (9.6 in. x 8.9 in.)
• Other Features
- Year 2000 compliant
- Power failure resume
- Support Transcend ez BIOS
- BIOS Virus protection (warning)
- PS/2 Mouse and Keyboard Wake Up
-Supports Wake-on-LANfunction
- Remote Ring Wake Up
- Time Wake Up
- Board voltage monitors for CPU core, +3.3V, +/-5.0V, +/-12.0V, VTT, 3.3VSB/5VSB
- CPU overheat alarm
- CPU fan auto-off in sleep mode

HARDWARE INSTALLATION 5
CHAPTER 2 HARDWARE INSTALLATION
2.1 Transcend TS-USL3 Motherboard
Wake on LAN
·
WOL Header
IrDA Header USB3/4 CONNECTOR
AC97 CODEC
PCI IDE Connector
Bus Master
DMA Mode 2
·
PCI IDE Connector
·
·
PIO Mode 3/4/5
·
Ultra DMA/33/66/100
FDD ConnectorFDD Connector
·
Floppy Disk Drive
Connector
Expansion SlotsExpansion Slots
3
1 x CNR Slot
·
x PCI Slots
·
·
1 x AGP Slot
(Shared PCI)
CPU
·
Intel
®
FC-PGA Pentium III/
Celeron
TM
Socket 370 Series
·
Game/ MIDI port & Audio Jack
·
VGA port/Serial port &
Parallel printer port
·
2 x USB ports
·
PS/2 KB & PS/2 Mouse ports
Back
p
anel I/O
p
orts
·
Game/ MIDI port & Audio Jack
·
·
2 x USB ports 1xLAN port(Optional)
·
PS/2 KB & PS/2 Mouse ports
(Line-out,Line-in,MIC-in)
LPC Su
p
er I/O
3x168-pin SDRAM DIMM
Main Memor
y
·
Up to 512MB
·
Intel 815E chi
p
set
·
TS -USL3:Intel 815E
·
TS -
Chipset (GMCH, ICH2)
COMB
COMB
·

6 HARDWARE INSTALLATION
2.2 Layout of Transcend TS-USL3 Motherboard
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line_in
MIC Line_out
LiBatter
y
Transcend
PCI Slot1 (PCI1) PCI Slot2 (PCI2)
PCI Slot3 (PCI3)
T:Port 1
B:Port 2
USB
Battery
DIMM1(64bit 168pin SDRAM Module)
DIMM2(64bit 168pin SDRAM Module)
DIMM3(64bit 168pin SDRAM Module)
PRN
KB MOUSE
GMCH 815
Socket 370
Game + Audio
AUX
VIDEO
CD1
Panel
USB3/4
WOL
IrDA
Power-Fan
AGP
CPU-Fan
FDC
IDE2 IDE1
ICH2
MODEM
JP31
COM2
JP4
JP2
JP1
JP8
JP28
JP6
CASEr-Fan
Power Connector
JP3

The JP4 Jumper allows you to set the FSB (Front Side Bus) to 66/100/133MHz configuration.
WhentheJumperis setto“Auto”,thefreqencyrangedependson yourCPUtype. Whenyouset
theFSBto66MHz,youcanselect asystembusfrequencyfrom66MHzto99MHz through“CPU
Host/PCI Clock”of “Frequency/Voltage Control”in the BIOS Setup menu. When you set the
FSBto 100MHz,you canselect asystem busfrequency from100MHz to 132MHz. When you
setthe FSBto133MHz, youcan selecta systembusfrequency from133MHz to166MHz .
HARDWARE INSTALLATION 7
66/100/133MHz FSB Confi
g
uration Jumper
66MHz
100MHz
133MHz
JP4
AUTO
BUS_Freq
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend
2.3.1 66/100/133 MHz System Configuration
2.3 Jumper Setup

8 HARDWARE INSTALLATION
2.3.2 Using Jumper JP1 to Clear CMOS
To clear the CMOS data, you should turn off your computer’s power and short pin1 and pin2
in JP1.
CMOS_CLR
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend
CLEAR
NORMAL
JP1
Clear CMOS Jumper

Theonboard audioCODEC canbe enabled ordisabled viathis jumperto usean externalCNR
card. Disable the onboard audio CODEC, if you want to use a PCI Sound Card or an CNR
AudioCard. When youinstalla CNRcard, rememberthat theonboard audio CODECuses the
primarychannel;therefore,fortheonboard CODECtofunction,youmustsettheCNR cardtobe
secondary.
HARDWARE INSTALLATION 9
Audio Selection Jumper
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line_in
MIC Line_out
LiBatter
y
Transcend
JP2
Audio
Enable
Disable
2.3.3 Onboard Audio Setting (JP2 ON-BOARD AUDIO)

10 HARDWARE INSTALLATION
2.3.4 Keyboard Wake Up (3-pin KB-AWK)
This function makes the Keyboard Power Up the system. Set this jumper to “Enable”if you’d
like your Keyboard to Power Up your computer. Then, go to the ”Power On Function”in the
“Integrated Peripherals”inBIOS Setup, andchoose thesetting youprefer.
Keyboard Wake Up
Disable
Enable
KB-AWK
JP6
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend

VCC3 Adjust
JP28 VCC3
Low
Medium
High
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend
2.3.5 VCC3 Adjust
HARDWARE INSTALLATION 11
Keepthis selectionfixed unlessyou arefamiliar withthesystem. Default isMedium.

12 HARDWARE INSTALLATION
2.4 Connector Description
2.4.1 Primary/Secondary IDE Connectors
Thismotherboard supportstwo 40-pin IDEconnectors markedas IDE1(primary channel) and
IDE2(secondary channel). Eachchannelsupports twoIDE devicesfora totalof fourdevices.
ConnectyourHard Disk(themainone ifyouareusing morethanone)to the“Master”connector
(attheendof thecable)andconnectitto IDE1(seeimportantnotebelow). If yourHDDsupports
Ultra DMA/66, you must use an 80-wire cable, otherwise the HDD won’t be able to reach this
speed.
If you intend to operate two IDE devices from the same channel, one device must be set to
“Master”mode and the other to “Slave”mode. A Hard Disk Drive, CD ROM Drive or other IDE
devicecanhaveeithersetting,dependingondevice’sjumpersetting. Pleaserefertothedevice’s
manualformore information.
NOTE: The Connectors must be attached to the IDE channels correctly. Make sure
that the red stripe on the edge of the ribbon cable (this may be faint and
could be a dotted line) is the nearest to PIN 1 (on the left as the motherboard
is shown in the picture below).
IDE Connectors
PIN1
PIN1
Secondary IDE Connector
Primary IDE Connector
IDE2
IDE1
IDE
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend

HARDWARE INSTALLATION 13
2.4.2 Floppy Disk Drive Connector (34-pin FDC)
This connector supports the floppy disk drive ribbon cable which is one of the items in your
motherboardpackage. Afterconnectingthesingleendto theboard,connectthetwoplugsatthe
otherendtothe floppydrives. Remember,as inthelastsection,the redstripeonthe edgeofthe
ribboncablemust bethenearest toPIN1(on theleftas shownbelow),oryour connectionwon’t
work.
Floppy Disk Drive Connector
PIN1
FDC
Floppy Disk Drive Connector
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend

14 HARDWARE INSTALLATION
2.4.3 Fan Power Connectors
Therearethreefanpowerconnectorsonthemotherboard: CPU-FAN,POWER-FAN,andCASE-
FAN. Eachconnectorprovides+12V power. Thecablescanonlybeattachedoneway. Ifyoutry
toput themin the wrongway,they won’t fit. Theseconnectors supportcooling fans of500 mA
(6W)or less.
Fan Power Connectors
CPU-FAN
POWER-FAN
CASE-FAN
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend
GND
Rotation
+12V

HARDWARE INSTALLATION 15
2.4.4 Memory Configuration
This motherboard support PC100/PC133 SDRAM DIMM memory modules. You can install
either single-sided or double-sided memory modules into any socket, but cannot exceed 512
MB total.
NOTE: This motherboard supports memory modules with 8/16/32/64/128/256/512MB.
168Pin Memory DIMM Sockets
Unbuffered Position
3.3V Position
168-pin Unbuffered SDRAM Module (DIMM1)
168-pin Unbuffered SDRAM Module (DIMM2)
168-pin Unbuffered SDRAM Module (DIMM3)
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend

16 HARDWARE INSTALLATION
Panel Connector
POWER LED
+++
S_LED
HDD_LED
NC
RESET
SOFT_OFF SPEAKER
++
KEY LOCK
1
19
20
2
DIMM1
(
64bit168pin SDRAM Module
)
DIMM2
(
64bit168pin SDRAM Module
)
PCISlot1 (PCI1)
PCISlot2 (PCI2)
PCISlot3 (PCI3)
CPU-FAN
WOL
FDC
IDE2
IDE1
GMCH
COMB
AC97
IntelICH
66/100MHz
Pin1
COMA
VGA
ParallelPort
GamePort
Line
_
in
MIC Line
_
out
LiBatter
y
Transcend
2.4.5 Panel Connectors
Power LED Lead (3-pin POWER LED)
This3-pin connectorattaches tothe powerLED.
Pin1 : +5V
Pin3 : NC
Pin5 : GND
Keylock Lead (2-pin KEYLOCK)
Usethe keylockto enableor disable theKeyboard.
Pin7 : KEYLOCK
Pin9 : GND
Speaker Lead (4-pin SPEAKER)
This4-pin connectorconnectsto thecase-mountedspeaker.
Pin13 : +5V
Pin15 : GND
Pin17 : NC
Pin19 : SPK
