Transcend TS1-GSDOM22V Manual

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
1
Description
With a 7P Signal + 15P Power SATA interface, high
speed and low power consumption, SATA Flash
Modules is perfect replacement storage device for
PCs, Laptops, gaming systems, and handheld
devices.
Placement
Features
• RoHS compliant
• Fully compatible with devices and OS that support the
SATA 1.0a 1.5Gbps standard
• Non-volatile Flash Memory for outstanding data
retention
• Supports up to Ultra DMA Mode 4
• Built-in ECC (Error Correction Code) functionality and
wear-leveling algorithm ensures highly reliable of data
transfer
• 7P Signal + 15P Power male SATA connector
• Lower Power Consumption
• Shock resistance
Dimensions
Side Millimeters Inches
A 45.80 ±0.40 1.803 ±0.016
B 33.00 ±0.50 1.299 ±0.020
C 7.08 ±0.20 0.279 ±0.008

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
2
Specifications
Physical Specification
Form Factor SATA Flash Modules Vertical Type
Storage Capacities 1~2GB
Length 45.80 ±0.40
Width 33.00 ±0.50
Dimensions (mm)
Height 7.08 ±0.20
Input Voltage 5V ±10% / 3.3V ±5%
Weight 8 g
Connector SATA 7+15 pins combo connector
Environmental Specifications
Operating Temperature 0 ℃to 70 ℃
Storage Temperature - 40 ℃to 85 ℃
Power Requirements
Input Voltage 5V ±10%
Mode MAX (mA)
Write 171.1
Read 178.8
2GB SATA Flash Modules
Power Consumption
(DC 5V @25℃) Standby 112.6

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
3
* Note : 25 ℃, according to 7+15 pins combo connector test on GA-8IG1000MK, 256 MB RAM, IDE interface support
UDMA4, Windows®XP Version 2002 SP2, benchmark utility HDBENCH (version 3.4006), copied file 100MB
* Note: FAT format
Reliability
Data Reliability Built-in 4 symbol/page correction ECC
Data Retention 10 years
Connector Durability 10,000 times
Performance
Model P/N Read (KB/s) Write (KB/s) Random Read (KB/s) Random Write (KB/s)
2GB SATA Flash Module 49636 17519 47123 4598
Actual Capacity
Model P/N Capacity C/H/S Capacity (BIOS) DOS Format (Bytes) Windows Format (Bytes)
2GB SATA Flash
Module 2GB 3884 / 16 / 63 2004MB 2,003,697,664 2,003,697,664
Regulations
Compliance CE, FCC and BSMI

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
4
Pin Assignments
Pin No. Pin Name Pin No. Pin Name
01 GND 02 A+
03 A- 04 GND
05 B- 06 B+
07 GND 08 NC
09 NC 10 NC
11 GND 12 GND
13 GND 14 5V
15 5V 16 5V
17 GND 18 GND
19 GND 20 NC
21 NC 22 NC
Pin Layout
Pin out
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22
GND
A+
A-
GND
B-
B+
GND
NC NC NC
GND GND GND
5V 5V 5V
GND GND GND
NC NC NC

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
5
Block Diagram
DC Characteristics
Parameter Symbol Min. Max. Unit Remark
Supply Voltage VCC 2.97 5.5 V
High level output voltage VOH V
CC – 0.8 V
Low level output voltage VOL 0.8 V
2.4 V Non-schmitt trigger
High level input voltage VIH
2.05 V Schmitt trigger1
0.6 V Non-schmitt trigger
Low level input voltage VIL
1.25 V Schmitt trigger1
Pull up resistance2R
PU 52.7 141 KOhm
Pull down resistance RPD 47.5 172 kOhm
IDE
Flash Disk
Controller
Flash Memory
D0 – D7
-CE0
-CE1
-WE…-RE
Flash Memory
D0 – D7
-CE0
-CE1
-WE…-RE
D00 ~ D07
D10 ~ D17
-CE0, -CE2…
-CE1, -CE3…
Data bus
Control
Signal
Power
Others
SATA
Bridge
SATA 7+15 PIN Combo
Data
bus
Power

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
6
Command Set
Command Code FR SC SN CY DH LBA Status Note
1 Check Power Mode E5 or 98h – – – – Y – Support
2 Execute Drive Diagnostic 90h – – – – Y – Support
3 Erase Sector C0h – Y Y Y Y Y Not Support #3
4 Flush Cache E7h – – – – Y – Support
5 Format Track 50h – Y – Y Y Y Support
6 Identify Device ECh – – – – Y – Support
7 Idle E3h or 97h – Y – – Y – Support
8 Idle Immediate E1h or 95h – – – – Y – Support
9 Initialize Drive Parameters 91h – Y – – Y – Support
10 Key Management
Structure Read B9 (Feature
0-127) Y Y Y Y Y – NOT Support #1
11 Key Management Read
Keying Material B9 (Feature
80) Y Y Y Y Y – NOT Support #1
12 Key Management Change
Key Management Value B9 (Feature
81) Y Y Y Y Y – NOT Support #1
13 NOP 00h – – – – Y – NOT Support
14 Read Buffer E4h – – – – Y – Support
15 Read DMA C8h – Y Y Y Y Y Support
16 Read Long Sector 22h or 23h – Y Y Y Y NOT Support #2
17 Read Multiple C4h – Y Y Y Y Y Support
18 Read Sector(s) 20h or 21h – Y Y Y Y Y Support
19 Read Verify Sector(s) 40h or 41h – Y Y Y Y Y Support
20 Recalibrate 1Xh – – – – Y – Support
21 Request Sense 03h – – – – Y – Not Support #3
22 Security Disable Password F6h – – – – Y – Support
23 Security Erase Prepare F3h – – – – Y – Support
24 Security Erase Unit F4h – – – – Y – Support
25 Security Freeze Lock F5h – – – – Y – Support
26 Security Set Password F1h – – – – Y – Support

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
7
27 Security Unlock F2h – – – – Y – Support
28 Seek 7Xh – – Y Y Y Y Support
29 Set Feature EFh Y – – – Y – Support
30 Set Multiple Mode C6h – Y – – Y – Support
31 Set Sleep Mode E6h or 99h – – – – Y – Support
32 Standby E2 or 96h – – – – Y – Support
33 Standby Immediate E0 or 94h – – – – Y – Support
34 Translate Sector 87h – Y Y Y Y Y Not Support #3
35 Wear Level F5h – – – – Y – Support #4
36 Write Buffer E8h – – – – Y – Support
37 Write DMA CAh – Y Y Y Y Y Support
38 Write Long Sector 32h or 33h – – Y Y Y Y Not Support #2
39 Write Multiple C5h – Y Y Y Y Y Support
40 Write Multiple w/o Erase CDh – Y Y Y Y Y Not Support #3
41 Write Sector(s) 30h or 31h – Y Y Y Y Y Support
42 Write Sector(s) w/o Erase 38h – Y Y Y Y Y Not Support #3
43 Write Verify 3Ch – Y Y Y Y Y Support
#1: This command is optional, depending on the key Management scheme in use.
#2: Use of this command is not recommended.
#3: CFA feature set command is not supported by P-ATA to S-ATA bridge controller.
#4: If Security command 22~27 are supported, this command is not supported.
Definitions
FR = Features Register
SC =Sector Count register (00H to FFH, 00H means 256 sectors)
SN = Sector Number register
CY = Cylinder Low/High register
DH = Head No. (0 to 15) of Drive/Head register
LBA = Logic Block Address Mode Support
– = Not used for the command
Y = Used for the command

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
8
SMART Command Set
 SMART Command Set
SMART Feature Register Values
D0h Read Data D4h Execute OFF-LINE Immediate
D1h Read Attribute Threshold D8h Enable SMART Operations
D2h Enable/Disable Autosave D9h Disable SMART Operations
D3h Save Attribute Values DAh Return Status
1. If reserved size is below the Threshold, the status can be read from Cylinder register by Return Status command
(DAh).

SMART Data Structure
BYTE F / V Decription
0-1 X Revision code
2-361 X Vendor specific
362 V Off line data collection status
363 X Self-test execution status byte
364-365 V Total time in seconds to complete off-line data collection activity
366 X Vendor specific
367 F Off-line data collection capability
368-369 F SMART capability
370 F Error logging capability
7-1 Reserved
0 1=Device error logging supported
371 X Vendor specific
372 F Short self-test routine recommended polling time (in minutes)
373 F Extended self-test routine recommended polling time (in minutes)
374 F Conveyance self-test routine recommended polling time (in minutes)
375-385 R Reserved
386-395 F Date Code
396 V Number of MU in device (0~n)
397+(n*6) V MU number
398+(n*6) V MU data block

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
9
400+(n*6) V MU spare block
401+(n*6) V Init. Bad block
402+(n*6) V Last Defect Bad block ( Newest state)
511 V Data structure checksum
F=the content of the byte is fixed and does not change.
V=the content of the byte is variable and may change depending on the state of the device or
the commands executed by the device.
X=the content of the byte is vendor specific and may be fixed or variable.
R=the content of the byte is reserved and shall be zero.
* 4 Byte value : [MSB] [2] [1] [LSB]

T
T
TS
S
S1
1
1-
-
-2
2
2G
G
GS
S
SD
D
DO
O
OM
M
M2
2
22
2
2V
V
V
22P Vertical Type
SATA Flash Modules
Transcend Information Inc.
V1.1
10
Ordering Information
1. The above technical information is based on industry standard data and has been tested to be reliable. However,
Transcend makes no warranty, either expressed or implied, as to its accuracy and assumes no liability in
connection with the use of this product. Transcend reserves the right to make changes to the specifications at any
time without prior notice.
2. For specific capacity, performance, and reliability requirement, please contact with sales.
USA
Los Angeles:
E-mail: [email protected]
Maryland:
E-mail: [e-mail]
www.transcendusa.com
CHINA
E-mail: [e-mail]
www.transcendchina.com
GERMANY
E-mail: [e-mail]
www.transcend.de
HONG KONG
E-mail: [e-mail]
www.transcendchina.com
JAPAN
E-mail: [email protected]
www.transcend.jp
THE NETHERLANDS
E-mail: [e-mail]
www.transcend.nl
TAIWAN
No.70, XingZhong Rd., NeiHu Dist., Taipei, Taiwan, R.O.C
TEL [phone]
Fax [phone]
E-mail: [email protected]
www.transcend.com.tw
United Kingdom
E-mail: [e-mail]
www.transcend-uk.com
TS XG SDOM XX
Capacity:
1G-2G SATA Flash Module
Transcend Product
Connector type
7H = 7pin SATA horizontal
22V = 22pin SATA vertical
22H = 22pin SATA
horizontal
