2.5” Solid State Disk

Transcend Information Inc.

V1.08

1

Description

Due to smaller size (fit the standard dimensions of

2.5” IDE Hard Disk Drives), huge capacity, high

speed, and low power consumption, Solid State Disk

is perfect replacement storage device for PCs,

Laptops, gaming systems, and handheld devices.

Placement

Features

• RoHS compliant

•Fully compatible with devices and OS that support the

IDE standard (44-Pin, pitch = 2.00 mm)

•Non-volatile Flash Memory for outstanding data

retention

•Built-in ECC (Error Correction Code) functionality and

wear-leveling algorithm ensures highly reliable of data

transfer

•Supports up to Ultra DMA Mode 5

•Shock resistance

Dimensions

Side Millimeters Inches

A 100.00 ±0.40 3.937 ±0.016

B 69.85 ±0.20 2.750 ±0.008

C 7.20 ±0.15 0.288 ±0.004

T

TS

S

S8

8

8G

G

GS

S

SS

S

SD

D

D2

2

25

5

5-

-

-S

S

T

TS

S

S1

1

16

6

6G

G

GS

S

SS

S

SD

D

D2

2

25

5

5-

-

-S

S

T

TS

S

S3

3

32

2

2G

G

GS

S

SS

S

SD

D

D2

2

25

5

5-

-

-S

S

S/

/

/M

M

T

TS

S

S6

6

64

4

4G

G

GS

S

SS

S

SD

D

D2

2

25

5

5-

-

-S

S

S/

/

/M

M

T

TS

S

S1

1

12

2

28

8

8G

G

GS

S

SS

S

SD

D

D2

2

25

5

5-

-

-M

M

2.5” Solid State Disk

Transcend Information Inc.

V1.08

2

Specifications

Physical Specification

Form Factor 2.5-inch HDD

Storage Capacities 8 GB to 128 GB

Length 100.0 0 ±0.40

Width 69.85 ±0.20

Dimensions (mm)

Height 7.20 ±0.15

Input Voltage 3.3V/5V ±5%

Weight 90g ±5g

Connector 44-Pin standard IDE/ATA connector (Pitch 2.0 mm)

Environmental Specifications

Operating Temperature 0 ℃to 70 ℃

Storage Temperature - 40 ℃to 85 ℃

Power Requirements

Input Voltage 5V ±5% @25℃

Mode Max. (mA) Max. (W)

Write(peak) 325.5 1.6

Read(peak) 295.7 1.5

Power Consumption

(8/16/32GB) Idle(peak) 156.8 0.8

Write(peak) 354.8 1.8

Read(peak) 312.6 1.6

Power Consumption

(64/128GB) Idle(peak) 156.3 0.8

Interface Specification

Jumper Settings Master/Slave/Cable-select Settings

ATA/ATAPI 6

ATA Compatibility UDMA Modes 5
