Transition Networks CBFTF1011-110 User manual

Part Number Copper - two (2) ports
10Base-T/100Base-TX
Duplex Fiber-Optic - one (1) port
100Base-FX
CBFTF1011-110 RJ-45
100 m (328 ft)*
ST, 1300 nm multimode
2 km (1.2 miles)*
CBFTF1013-110 RJ-45
100 m (328 ft)*
SC, 1300 nm multimode
2 km (1.2 miles)*
CBFTF1014-110 RJ-45
100 m (328 ft)*
SC, 1310 nm single mode
20 km (12.4 miles)*
CBFTF1015-110
(long haul)
RJ-45
100 m (328 ft)*
SC, 1310 nm single mode
40 km (24.8 miles)*
CBFTF1016-110
(extra long haul)
RJ-45
100 m (328 ft)*
SC, 1310 nm single mode
60 km (37.2 miles)*
CBFTF1017-110
(long wave length)
RJ-45
100 m (328 ft)*
SC, 1550 nm single mode
80 km (49.7 miles)*
CBFTF1018-110 RJ-45
100 m (328 ft)*
MT-RJ, 1300 nm multimode
2 km (1.2 miles)*
CBFTF1025-110 RJ-45
100 m (328 ft)*
MT-RJ, 1310 nm single mode
5 km (3.1 miles)*
User’s Guide
CBFTF10xx-11x
Slide-in-Module Media Converter
• Copper to Fiber
• 10/100 Bridging (3-Port)
• 10/100Base-TX to 100Base-FX
The CBFTF10xx-11x 3-port Ethernet/fast
Ethernet bridging media converter is designed
to be installed into a Transition Networks
PointSystem™ chassis and allows connection
of 10Base-T Ethernet and/or 100Base-TX fast
Ethernet twisted-pair copper network devices
to network devices on a 100Base-FX fast
Ethernet fiber network.
* Typical maximum cable distance. Actual distance is dependent upon the
physical characteristics of the network.
Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .8
Cable Specifications . . . . . . . . . .11
Technical Specifications . . . . . . .13
Troubleshooting . . . . . . . . . . . . .14
Compliance Information . . . . . . .15
Contact Us . . . . . . . . . . . . . . . . .16

2
CBFTF10xx-11x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
* Typical maximum cable distance. Actual distance is dependent upon the
physical characteristics of the network. (TX) = transmit (RX) = receive
** CBFTF1029-110 and -111 are intended to be installed in the same network
where one is the local converter and the other is the remote converter.
*** CBFTF1029-112 and -113 are intended to be installed in the same network
where one is the local converter and the other is the remote converter.
Installation
Copper and Fiber Ports
The figure below illustrates the locations of the
two (2) twisted-pair copper ports and the one (1)
fiber port.
Part Number Copper - two (2) ports
10Base-T/100Base-TX
Fiber-Optic - one (1) port
Single Fiber
CBFTF1029-110 RJ-45
100 m (328 ft)*
SC, 1310 nm (TX)/1550 nm (RX)
single mode, 20 km (12.4 miles
CBFTF1029-111 RJ-45
100 m (328 ft)*
SC, 1550 nm (TX)/1310 nm (RX)
single mode, 20 km (12.4 miles)*
CBFTF1029-112 RJ-45
100 m (328 ft)*
SC, 1310 nm (TX)/1550 nm (RX)
single mode, 40 km (24.8 miles)*
CBFTF1029-113 RJ-45
100 m (328 ft)*
SC, 1550 nm (TX)/1310 nm (RX)
single mode, 40 km (24.8 miles)*
CBFTF110
10/100TX
FD LACT PWR
10/100TX
Twisted-Pair
Port 1 (TP1)
Twisted-Pair
Port 2 (TP2)
Fiber Port 1
(F1)
100Base-FX
The stand-alone version of the media converter is SBFTF10xx-11x. For more
information, see the SBFTF10xx-11x user’s guide on-line at: www.transition.com.
Installation -- Continued
Set the Dip Switches
The dip switches are located on the side of the media converter. Use a small,
flat-blade screwdriver or a similar device to set each dip switch.
“SW1” switches 1 - 6
Dip switches 1, 2, and 3 apply only to twisted-pair copper port 1 (TP1).
Dip switch 4 applies to fiber port 1 (F1).
Dip switches 5 and 6 apply to both twisted-pair copper ports (TP1 and TP2).
“Config. Switches” 1 - 4
Dip switches 1, 2, 3, and 4 apply only to twisted-pair copper port 2 (TP2).
NOTE: Switches 1, 2, and 3 apply only to twisted-pair copper port 1 (TP1).
[email protected] -- Click the “Transition Now” link for a live Web chat. 3
1. Twisted-Pair Auto-Negotiation
UP (Enabled) - The media converter “advertises”
ALL rate and mode capabilities to the network:
• 100Mb/s full-duplex • 100Mb/s half-duplex,
• 10Mb/s full-duplex • 10Mb/s half-duplex.
DOWN (Disabled) - The bridging media
converter does not “advertise” the rate and mode
capabilities to the network. Switches 2 and 3are
then used to set the twisted-pair rate and mode.
2. Twisted-Pair Rate
UP (100Base-TX) - Sets the twisted-pair rate to
100Base-TX.
DOWN (10Base-T) - Sets the twisted-pair rate to
10Base-T.
3. Twisted-Pair Mode
UP (Full-Duplex) - The twisted-pair cable
distances are constrained by the cable
requirements (see pages 1 and 2).
DOWN (Half-Duplex): - The twisted-pair cable
distances are constrained by the 512-Bit Rule (see
page 9).
DOWN
1
UP
Twisted-Pair Auto-Negotiation ON
Twisted-Pair Auto-Negotiation OF
F
Twisted-pair 100Base-TX
Twisted-pair 10Base-T
DOWN
UP
2
Twisted-pair Full-Duplex
Twisted-pair Half-Duplex
DOWN
UP
3

4
CBFTF10xx-11x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Installation -- Continued
Set the Dip Switches -- Continued
NOTE: Dip switch 4 (in the “SW” set) applies to fiber port 1 (F1).
4. Fiber Mode (Fiber Port 1)
UP (Full-Duplex) - The cable distances for fiber port
1 (F1) are constrained by the cable requirements (see
pages 1 and 2).
DOWN (Half-Duplex) - The cable distances for fiber
port 1 (F1) are constrained by the 512-Bit Rule (see
page 9).
NOTE: Dip switches 5 and 6 (in the “SW” set) apply to both twisted-pair copper
ports (TP1 and TP2).
5. AutoCross
UP (Enable) - The media converter connects
automatically to either straight-through or crossover
twisted-pair copper cable (see page 12).
DOWN (Disable) - Either straight-through or
crossover twisted-pair copper cable must be
installed, according to the site requirements
6. Not in use
Fiber Full-Duplex
Fiber Half-Duplex
DOWN
UP
4
AutoCross Enable
AutoCross Disable
UP
5
DOWN
[email protected] -- Click the “Transition Now” link for a live Web chat. 5
Installation -- Continued
Set the Dip Switches -- Continued
NOTE: Dip switches 1, 2, 3, and 4 (in the Config. Switches set) apply only to
twisted-pair copper port 2 (TP2).
1. Twisted-Pair Auto-Negotiation
UP (Enabled) - The media converter “advertises” ALL
rate and mode capabilities to the network:
• 100Mb/s full-duplex • 100Mb/s half-duplex,
• 10Mb/s full-duplex • 10Mb/s half-duplex.
DOWN (Disabled) - The bridging media converter
does not “advertise” the rate and mode capabilities
to the network. Switch 2 and switch 3 are then used
to set the twisted-pair rate and mode.
2. Twisted-Pair Rate
UP (100Base-TX) - Sets the twisted-pair rate to
100Base-TX.
DOWN (10Base-T) - Sets the twisted-pair rate to
10Base-T.
3. Twisted-Pair Mode
UP (Full-Duplex) - The twisted-pair cable distances
are constrained by the cable requirements (see pages
1 and 2).
DOWN (Half-Duplex) - The twisted-pair cable
distances are constrained by the 512-Bit Rule (see
page 9).
4. Monitor for Twisted-Pair Port 2 (TP2)
UP (OFF) - The twisted-pair port 2 (TP2) functions as
directed by switches 1,2, and 3.
DOWN (ON) - The twisted-pair port 2 (TP2)
functions as a “sniffer” port and transmits all packets
received from ports F1 and TP1.
Twisted-Pair Full-Duplex
Twisted-Pair Half-Duplex
UP
DOWN
3
Monitor on TP2 OFF
Monitor on TP2 ON
UP
DOWN
4
Twisted-Pair 100Base-TX
Twisted-Pair 10Base-T
UP
DOWN
2
UP
DOWN
1
Twisted-Pair Auto-Negotiation ON
Twisted-Pair Auto-Negotiation OF
F

6
CBFTF10xx-11x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Install the Slide-in-Module
CAUTION: Wear a grounding device and observe electrostatic discharge
precautions when installing the CBFTF10xx-11x slide-in-module media
converter. Failure to observe this caution could result in damage to, and
subsequent failure of, the media converter.
1. Carefully slide the slide-in-module into two adjacent installation slots,
aligning the module with the installation guides.
2. Ensure that the module is firmly seated against the back of the chassis.
3. Push in and rotate the attached panel fastener screw clockwise to secure
the module to the chassis front.
CFMFF100
10BASE-2
CECF100 CFMFF100
050½
LinkAlert
ED
CETCF100 CFETF100
LA PWR
RXF
RXC
LNK
COL
SPD PWR
FRX
CRX
FLNK
CLNK
100BASE-TX
RX
TX
100BASE-FX
LinkAlert
ED
050½
LA PWR
RXF
RXC
LNK
COL
10BASE-2
10BASE-FL
10BASE-T
LKS
PWR
LKM
LKS
PWR
LKM
Multimode
Singlemode
TX
RX
TX
RX
Multimode
Singlemode
TX
RX
TX
RX
I
0
TERM
INIT
RX
TX
LNK
PWR
CPSMM120
SERIAL
10BASE-T
R
E
S
E
T
I
0
Panel Fastener Screw
The slide-in-module media converter
is powered through the Transition
Networks PointSystem™ chassis.
Installation - Continued
Set the Hardware/Software Jumper
The hardware/software jumper is located on the circuit
board and is labeled “H” and “S”. Use a pair of needle-
nose pliers to set the jumper to the desired location.
Hardware The media converter settings are determined
by dip switch settings (p. 3-5).
Software The media converter settings are determined
by the most-recently saved, on-board
microprocessor settings.
Software Mode
Hardware Mode
HS
HS
[email protected] -- Click the “Transition Now” link for a live Web chat. 7
Installation -- Continued
Install the Copper and Fiber Cables
• If half-duplex mode is used, refer to the 512-Bit Rule (see page 9).
• If full-duplex mode is used, the 512-Bit Rule does not apply. The cable
lengths are constrained by the cable requirements (see pages 1 and 2).
Twisted-Pair Copper Cable
The AutoCross feature allows either MDI (straight-through) or MDI-X
(crossover) cable connections to be configured automatically, according to the
network conditions.
1. Locate or build IEEE 803.2™ compliant 10Base-T or 100Base-TX cables,
with RJ-45 connectors installed at both ends.
2. Connect the RJ-45 connector at one end of the cable to the RJ-45 port on
the CBFTF10xx-11x media converter.
3. Connect the RJ-45 connector at the other end of the cable to the RJ-45
port on the other device (switch, workstation, etc.).
RJ-45 port
on the other device
(switch, work station, etc.)
RJ-45 port
on the media
converter
Connect the fiber cable
to the media converter
as shown.
Connect the fiber cable
to the other device
(media converter,
hub, etc.) as shown
RX
TX
RX
TX
Fiber Cable
1. Locate or build IEEE 803.2™ compliant 100Base-FX fiber cable with
male, two-stranded TX to RX connectors installed at both ends.
2. Connect the fiber cables to the CBFTF10xx-11x media converter as
described:
• Connect the male TX cable connector to the female TX port.
• Connect the male RX cable connector to the female RX port.
3. Connect the fiber cables to the other device (another media converter,
hub, etc.) as described:
• Connect the male TX cable connector to the female RX port.
• Connect the male RX cable connector to the female TX port.

8
CBFTF10xx-11x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Operation
Status LEDs
Use the status LEDs next to the fiber ports to monitor the media converter and
the fiber network connections.
F(ull) D(uplex)
On = Full-duplex connection.
Off = Half-duplex connection.
L(ink) ACT(ivity)
On = Fiber link connection.
Flashing = Fiber network activity.
P(o)W(e)R
On = Connection to external AC or DC power.
Use the bi-color twisted-pair status LEDs to monitor the twisted-pair copper
network connections.
Duplex/Link LED
Amber = A link on the half-duplex twisted-
pair copper link.
Flashing Amber = Activity on the half-duplex
copper link.
Green = A link on the full-duplex twisted-
pair copper link.
Flashing Green = Activity on the full-duplex
copper link.
Speed LED
Amber = 10 Mb/s operation.
Green = 100 Mb/s operation.
FD LACT PWR
The “FD” and “LACT” LEDs near the top of the
media converter refer to Fiber Port 1 (F1).
Duplex/Link Speed
10/100TX
[email protected] -- Click the “Transition Now” link for a live Web chat. 9
Operation -- Continued
Product Features
Full-Duplex Network
In a full-duplex network, maximum cable lengths are determined by the type
of cables that are used. See pages 1 and 2 for the cable specifications for the
different CBFTF10xx-11x models.
The 512-Bit Rule does not apply in a full-duplex network.
Half-Duplex Network (512-Bit Rule)
In a half-duplex network, the maximum cable lengths are determined by the
round trip delay limitations of each fast Ethernet collision domain. (A
collision domain is the longest path between any two terminal devices, e.g. a
terminal, switch, or router.)
The 512-Bit Rule determines the maximum length of cable permitted by
calculating the round-trip delay in bit-times (BT) of a particular collision
domain. If the result is less than or equal to 512 BTU, the path is good.
For more information on the 512-Bit Rule, see the white paper titled
“Collision Domains” on the Transition Networks website at:
www.transition.com.
Distance Extension
The CBFTF10xx-11x 3-port Bridging media converter segments up to two (2)
10Base-T copper Ethernet and/or 100Base-TX copper fast Ethernet and one
(1) 100Base-FX fiber fast Ethernet collision domains.
In a half-duplex Ethernet or fast Ethernet environment, the CBFTF10xx-11x
media converter extends network distances by segmenting collision domains
so that the 512-Bit Rule applies separately to each collision domain (see page
9).
In a full-duplex Ethernet or fast Ethernet environment, the CBFTF10xx-11x
media converter extends network distances to the physical cable limitations
imposed by the selected twisted-pair copper fiber cables (see pages 1 and 2).
Rate Conversion
The CBFTF10xx-11x media converter allows connection of 10Mb/s terminal
devices on a 10Base-T legacy Ethernet copper network to 100Mb/s terminal
devices on a 100Base-TX fast Ethernet copper network and/or to 100Mb/s
terminal devices on a 100Base-FX fast Ethernet fiber network.

10
CBFTF10xx-11x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Operation -- Continued
Product Features -- Continued
Congestion Reduction
The CBFTF10xx-11x media converter does not forward collision signals or
error packets from one collision domain to another, improving baseline
network performance. In addition, the media converter filters packets
destined for local devices, also reducing network congestion.
Auto-Negotiation
The Auto-Negotiation feature allows the CBFTF10xx-11x media converter to
automatically configure itself to achieve the best possible mode of operation
over a link. The media converter broadcasts its speed (10 Mb/s or 100 Mb/s)
and duplex capabilities (full or half) to the other devices and negotiates the
best mode of operation. Auto-Negotiation allows quick and easy installation
because the optimal link is established automatically.
A scenario where the media converter is linked to a non-negotiating device is
a case where the user may want to disable Auto-Negotiation. In this instance,
the mode of operation will drop to the least common denominator between
the two devices (e.g.: 10 Mb/s, half-duplex). Disabling this feature gives the
user the ability to force the connection to the best mode of operation.
AutoCross™
When the AutoCross feature is activated, it allows either straight-through
(MDI) or crossover (MDI-X) copper cables to be used when connecting to
10Base-T or 100Base-TX devices. AutoCross determines the characteristics of
the connection and automatically configures the unit to link up, regardless if
the copper cable is MDI or MDI-X configuration. (Transition networks
recommends leaving the device in the default “enable” mode.)
[email protected] -- Click the “Transition Now” link for a live Web chat. 11
Cable Specifications
The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber Cable
Bit Error Rate: <10-9
single mode fiber (recommended): 9 µm
Multimode fiber (recommended): 62.5/125 µm
Multimode fiber (optional): 100/140, 85/140, 50/125 µm
CBFTF1011-110 1300 nm multimode
CBFTF1013-110 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
CBFTF1014-110 1310 nm single mode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm
Link Budget: 16.0 dB
CBFTF1015-110
(long haul) 1310 nm single mode
Fiber-optic Transmitter Power: min: -8.0 dBm max: -2.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 26.0 dB
CBFTF1016-110
(extra long haul) 1310 nm single mode
Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 29.0 dB
CBFTF1017-110
(long wave length) 1550 nm single mode
Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 29.0 dB
CBFTF1018-110 1300 nm multimode
Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.5 dBm max: -14.0 dBm
Link Budget: 14.5 dB
CBFTF1025-110 1310 nm single mode
Fiber-optic Transmitter Power: min: -11.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -20.0 dBm max: -3.0 dBm
Link Budget: 9.0 dB
CBFTF1029-110 1310 nm (TX) / 1550 nm (RX) simplex
CBFTF1029-111 1550 nm (TX) / 1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
CBFTF1029-112 1310 nm (TX) / 1550 nm (RX) simplex
CBFTF1029-113 1550 nm (TX) / 1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 25.0 dB
The fiber optic transmitters on this device meet Class I Laser safety requirements
per IEC-825/CDRH standards and comply with 21 CFR1040.10 and
21CFR1040.11.

12
CBFTF10xx-11x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Cable Specifications -- Continued
Copper Cable
Category 3: (Minimum requirement for 10 Mb/s operation)
Gauge 24 to 22 AWG
Attenuation 11.5 dB/100m @ 5-10 MHz
Maximum Cable Distance 100 meters
Category 5: (Minimum requirement for 100 Mb/s operation)
Gauge 24 to 22 AWG
Attenuation 22.0 dB /100m @ 100 MHz
Maximum Cable Distance 100 meters
• Straight-through or crossover twisted-pair cable may be used.
• Shielded (STP) or unshielded (UTP) twisted-pair cable may be used.
• Pins 1&2 and 3&6 are the two active pairs in an Ethernet network .
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
Crossover Cable
1
2
3
6
Straight-Through Cable
Twisted Pair #1
Twisted Pair #1
Twisted Pair #2
Twisted Pair #2
1
2
3
6
1
2
3
6
1
2
3
6
SNMP
Use SNMP at an attached terminal or at a remote location to monitor the
media converter by monitoring:
• Media converter power
• Copper link and fiber link status
• Copper port speed
• Hardware switch settings
Also, use SNMP to enter network commands that:
• Enable/disable Auto-Negotiation on copper
• Force 10Mb/s or 100Mb/s on copper
• Force full-duplex or half-duplex on copper and/or fiber
• Enable/disable pause and source address change
• Enable/disable monitor port (advanced filters available)
• Select advertised modes (when Auto-Negotiation is enabled)
See the on-line documentation that comes with Transition Networks
FocalPoint™ software for applicable commands and usage at
www.transition.com
[email protected] -- Click the “Transition Now” link for a live Web chat. 13
Technical Specifications
For use with Transition Networks Model CBFTF10xx-11x or equivalent.
Standards IEEE 802.3™
Data Rate 10 Mb/s, 100 Mb/s
Dimensions 3.4" x 0.87" x 5.0" (86 x 22 x 182 mm)
Weight 3 oz. (91 g) (approximate)
Power Consumption 4.95 watts
MTBF 426,000 hours (MIL217F2 V5.0) (MIL-HDBD-217F)
1,326,000 hours (Bellcore7 V5.0)
Packet Size: Memory: 256K bytes (2 Mbit)
Unicast MAC addresses: 4K
Maximum packet size: 1536 bytes
Environment Tmra*: 0 to 50°C (32 to 122°F )
Storage Temp: -20 to 85°C (-4 to 185°F)
Humidity: 5 to 95%, non condensing
Altitude: 0 to 10,000 feet
Warranty Lifetime
* Manufacturer’s rated ambient temperature: Tmra range for this slide-in-module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this slide-in-module will
be installed.
The information in this user’s guide is subject to change. For the most up-to-date
information, view the user’s guide on-line at: www.transition.com.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into the
beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other
than those specified herein may result in hazardous radiation exposure.

14
CBFTF10xx-11x
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Troubleshooting
If the media converter fails, isolate and correct the failure by determining the
answers to the following questions and then taking the indicated action:
1. Is the power LED illuminated?
NO
• Is the media converter inserted properly into the chassis?
• Is the power cord properly installed in the chassis and at the external
power source and does the external power source provide power?
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the “Duplex/Link” LED illuminated on a port with twisted-pair cable
installed?
NO
• Check the copper cables for proper connection.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Amber = The media converter has selected half-duplex mode.
• Green = The media converter has selected full-duplex mode.
• If the mode is not correct, disconnect and reconnect the twisted pair
cable to restart the initialization process.
• Proceed to step 3.
3. Is the “LACT” LED illuminated on the fiber cable port?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables are connected to the RX and TX
ports, respectively, on the 100Base-FX device.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 4.
4. Is the “Speed” LED illuminated on a port with twisted-pair cable
installed?
NO
• Check the copper cables for proper connection.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Amber = The media converter has selected 10Mb/s operation.
• Green = The media converter has selected 100Mb/s operation.
• If the speed is not correct, disconnect and reconnect the twisted pair
cable to restart the initialization process.
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
[email protected] -- Click the “Transition Now” link for a live Web chat. 15
Compliance Information
CISPR22/EN55022 Class A + EN55024
CE Mark
FCC Regulations
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the
interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus
set out on the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la Class A prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le ministère des Communications du Canada.
European Regulations
Warning This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Achtung! Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können
bei Betrieb dieses Gerätes Rundfunkstörungen auftreten. In diesem Fäll ist der Benutzer für
Gegenmaßnahmen verantwortlich.
Attention! Ceci est un produit de Classe A. Dans un environment domestique, ce produit
risque de créer des interférences radioélectriques, il appartiendra alors à l'utilsateur de
prende les measures spécifiques appropriées.
VCCI Class 1 Compliance
This equipment is in the 1st Class category (information equipment to be used in commercial
and/or industrial areas) and conforms to the standards set by the Voluntary Control Council
For Interference by Data Processing
Equipment and Electronic Office
Machines aimed at preventing radio
interference in commercial and/or
industrial areas. When used in a
residential area or in an adjacent area
thereto, interference may be caused to
radio and TV receivers, etc. Read the
instructions for correct handling.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-
Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer
Konformität.

Trademark Notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright Restrictions
© 2001-2005 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any
means - graphic, electronic, or mechanical - without written permission from Transition
Networks.
Printed in the U.S.A. 33195.D
Contact Us
Technical Support
Technical support is available 24 hours a day.
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Transition Now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based Seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
[email protected]
Address
Transition Networks
6475 City West Parkway
Minneapolis, MN 55344, USA
telephone: [phone]
toll free: 800-526-9267
fax: [phone]
Declaration of Conformity
Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 USA
Model: CBFTF10xx-11x Series Media Converters
Part Number(s): CBFTF1011-110, CBFTF1013-110, CBFTF1014-110, CBFTF1015-110,
CBFTF1016-110, CBFTF1017-110, CBFTF1018-110, CBFTF1025-110,
CBFTF1029-110, CBFTF1029-111, CBFTF1029-112, CBFTF1029-113
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the
CBFTF10xx-11x to which this declaration refers is
in conformity with the following standards.
CISPR 22:1993; EN 55022:1998 Class A; EN 55024:1998; FCC Part 15 Subpart B;
21 CFR subpart J; EN 61000-2-3:1995; EN 61000-3-3:1995
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
_April 16, 2001_____
Stephen Anderson, Vice-President of Engineering Date
