Transition Networks CRS2F31-100 Series User manual

User’s Guide
CRS2F31xx-100
Slide-in-Module Media Converter
RS-232 to Fiber
Transition Networks CRS2F31xx-100 series media
converters are designed to be installed in the
PointSystem™ chassis and connect copper RS-232
cable to fiber-optic cable at asynchronous data rates up
to 115 kB/s.
The CRS2F31xx-100 is designed to be installed in pairs
where one is the local media converter and the other is
the remote.
Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .6
Cable Specifications . . . . . . . . . . .7
Technical Specifications . . . . . . . .8
Troubleshooting . . . . . . . . . . . . . .9
Contact Us . . . . . . . . . . . . . . . . .11
Compliance Information . . . . . . .12
Part Number Port One - Copper Port Two - Duplex Fiber-Optic
CRS2F3111-100 RS-232
15 m (50 ft)
ST, 1300 nm multimode
2 km (1.2 miles)*
CRS2F3113-100 RS-232
15 m (50 ft)
SC, 1300 nm multimode
2 km (1.2 miles)*
CRS2F3114-100 RS-232
15 m (50 ft)
SC, 1310 nm single mode
20 km (12.4 miles)*
CRS2F3115-100 RS-232
15 m (50 ft)
SC, 1310 nm single mode
40 km (24.8 miles)*
CRS2F3129-100 RS-232
15 m (50 ft)
SC, 1310 TX/1550 RX nm single mode
20 km (12.4 miles)**
CRS2F3129-101 RS-232
15 m (50 ft)
SC, 1550 TX/1310RX nm single mode
20 km (12.4 miles)**
CRS2F3129-102 RS-232
15 m (50 ft)
SC, 1550 TX/1310RX nm single mode
40 km (12.4 miles)**
CRS2F3129-103 RS-232
15 m (50 ft)
SC, 1550 TX/1310RX nm single mode
40 km (24.8miles)**
* Typical maximum cable distance.
Actual distance is dependent upon the
physical characteristics of the network
installation.
**Install CRS2F3129-100/101 or CRS2F3129-102/103 in the same network
where one is the local converter and the other is the remotec onverter.

224-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CRS2F31xx-100
Installation
CAUTION: Wear a grounding device and observe electrostatic discharge precautions
when setting the switches and jumper. Failure to observe this caution could result in
damage to, and subsequent failure of, the media converter.
Set the DTE/DCE Switch
The DTE/DCE switch is located on the side of the media converter. How the
DTE/DCE switch is set depends on the type of device connected to the media
converter:
• DTE (Data Terminal Equipment).
• DCE (Data Communication Equipment).
... and the type of RS-232 cable:
• Straight-through configuration cable.
• Null-modem configuration cable.
Using Straight-Through RS-232 Cable
DCE Configuration
CRS2F31xx-100
switch set to DTE
CRS2F31xx-100
switch set to DTE
DTE device
DTE device
RS-232 straight-
through cable
RS-232 straight-
through cable
Set the switch to DTE
configuration if the media
converter is connected to a DCE
device via a straight-through RS-
232 cable.
Set the switch to DCE
configuration if the media
converter is connected to a DTE
device via a straight-through RS-
232 cable.
DTE Configuration
[email protected] -- Click the “Transition Now” link for a live Web chat. 3
Set the Loop-Back Switch
The loop-back switch is located on the front panel of the media converter and is
used to debug network faults.
To set the switch, use a small flat-blade
screwdriver or a similar device.
Norm Set the switch to “Norm” for
normal operation.
Loop Set the switch to “Loop” to enable
both fiber and copper loop-back.
Loop
Norm
Loop
Norm
Normal Operation Fiber/Copper
Loop Back
Installation -- Continued
Using Null-Modem RS-232 Cable
DCE Configuration
CRS2F31xx-100
switch set to DTE
CRS2F31xx-100
switch set to DTE
DTE device
DTE device
RS-232 straight-
through cable
RS-232 straight-
through cable
Set the switch to DCE
configuration if the media
converter is connected to a DCE
device via a null-modem RS-232
cable.
Set the switch to DTE
configuration if the media
converter is connected to a DTE
device via a null-modem RS-232
cable.
DTE Configuration

424-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CRS2F31xx-100
Installation -- Continued
CAUTION: Wear a grounding device and observe electrostatic discharge precautions
when setting the hardware/software jumper and installing the media converter. Failure
to observe this caution could result in damage to, and subsequent failure of, the media
converter.
Set the Hardware/Software Jumper
• The jumper is located on the circuit board.
• Use small needle-nose pliers to set the jumper.
Hardware The media converter mode is determined by the
switch settings.
Software The media converter mode is determined by the
most-recently saved, on-board microprocessor
settings.
Installing the Slide-in-Module
To install the CRS2F31xx-100 media converter slide-in-module:
1. Locate an empty installation slot on the PointSystem™ chassis.
2. Carefully slide the slide-in-module into the installation slot, aligning the
module with the installation guides.
3. Ensure that the module is firmly seated inside the chassis.
4. Push in and rotate the attached panel fastener screw clockwise to secure the
module to the chassis front.
Media Converter
PointSystem Chassis
Panel Fastener
Slot
H
H
S
S
J2
Software Mode
Hardware Mode
Power the Media Converter
The media converter is powered through the PointSystem™ chassis.
[email protected] -- Click the “Transition Now” link for a live Web chat. 5
Install the Copper Cable
Note: Shielded RS-232 cables are required for EMC compliance.
1. Locate or build RS-232 cables with a female connector for the media converter
end and the correct gender connector for the DTE/DCE device at the other end.
And with either straight-through or null-modem cable configuration.
2. Connect the female RS-232 connector at one end of cable to the male RS-232
port on the first CRS2F21-100 media converter.
3. Connect the RS-232 connector at the other end of the cable to the RS-232 port
on the DTE/DCE device.
1
2
3
4
5
6
7
9
8
5
4
3
2
1
9
8
6
7
1
2
3
4
5
6
7
9
8
1
2
3
4
5
6
7
9
8
Straight-Thru Configuration cable
with handshakingsignals
(Optional configuration: no connectionpin9)
Null-Modem configuration cable with
handshakingsignaling
(Requirementsfordifferent equipment may vary)
Installation -- Continued
Install the Fiber Cable
1. Locate or build fiber cable with male, two-stranded TX to RX connectors
installed at both ends.
2. Connect the fiber cables to the first CRS2F31xx-100 media converter as
described:
• Connect the male TX cable connector to the female TX port.
• Connect the male RX cable connector to the female RX port.
3. Connect the fiber cables to the other CRS2F31xx-100 media converter as
described:
• Connect the male TX cable connector to the female RX port.
• Connect the male RX cable connector to the female TX port.
Connect fiber cable
to media converter
as shown.
Connect fiber cable
to other device
(media converter,
hub, etc.) as shown
RX
TX
RX
TX

624-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CRS2F31xx-100
Operation
After installation, the media converter should function without
operator intervention. Use the status LEDs to monitor the
media converter operation in the network.
PWR On The media converter is connected to
external power.
FL On A link has been established with the
fiber connector.
Flashing The media converter is in loop-back
mode.
RX Flashing The RS-232 connector is receiving
data.
TX
RX
LoopNorm
RX FL PWR
SNMP
Use SNMP at an attached terminal or at a remote location to monitor the media
converter by monitoring:
• Local/remote fiber link status
• Local/remote hardware/software mode
• Local/remote loop-back
Also, use SNMP to enter network commands for:
• Local/remote loop-back
See the on-line documentation that comes with Transition Networks FocalPoint™
software for applicable commands and usage at www.transition.com.
Remote Management
The CRS2F31xx-100 can remotely manage the SRS2F31xx-100 (the stand-alone
version of the media converter) or another CRS2F31xx-100. For example, a local
CRS2F3111-100 converter (that is installed in a managed Transition Networks
PointSystem™ chassis) is connected, via fiber, to a remote SRS2F3111-100
converter.
The SNMP section (below) lists the commands that can be used to monitor and
manage both the local and remote media converter.
Note: In a managed network, both the local and remote media converters must be
set to “software” mode.
[email protected] -- Click the “Transition Now” link for a live Web chat. 7
Cable Specifications
Fiber Cable
Bit Error Rate: <10-9
Single mode fiber (recommended):9μm
Multimode fiber (recommended): 62.5/125 μm
Multimode fiber (optional): 100/140, 85/140, 50/125 μm
CRS2F3111-100 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
CRS2F3113-100 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
CRS2F3114-100 1310 nm single mode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm
Link Budget: 16.0 dB
CRS2F3115-100 1310 nm single mode
Fiber-optic Transmitter Power: min: -8.0 dBmmax: -2.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 26.0 dB
CRS2F3129-100 1310TX/1550RX nm single mode
CRS2F3129-101 1550TX/1310RX nm single mode
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
CRS2F3129-102 1310TX/1550RX nm single mode
CRS2F3129-103 1550TX/1310RX nm single mode
Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 25.0 dB

824-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CRS2F31xx-100
Technical Specifications
For use with Transition Networks Model CRS2F31xx-100 or equivalent
Data Rate 115 kB/s (asynchronous)
Dimensions 3.4" x 5.0" x 0.86" (86 mm x 127 mm x 22 mm)
Weight 3 oz. (91 g) approximately
Power Consumption 5 Watts
MTBF 2,613,860 hours (MIL217F2 V5.0) (MIL-HDBD-217F)
6,569,957 hours (Bellcore7 V5.0)
Environment Tmra*:
Storage Temp:
Humidity:
Altitude:
0 to 50°C (32° to 122° F )
-40° to +85°C (-40° to +185°F)
5 to 95%, non condensing
0 to 10,000 feet
Warranty Lifetime
*Manufacturer’s rated ambient temperature. Tmra range for this slide-in-module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this slide-in-module will be
installed.
WARNING: Visible and invisible laser radiation when open. Do not stare into the
beam or view the beam directly with optical instruments. Failure to observe this
warning could result in an eye injury or blindness.
WARNING: Use of controls, adjustments or the performance of procedures other than
those specified herein may result in hazardous radiation exposure.
Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422,
RS485, DS1, DS3, Video Coax, etc., are intended to be connected to intra-building
(inside plant) link segments that are not subject to lightening transients or power faults.
Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422,
RS485, DS1, DS3, Video Coax, etc., are NOT to be connected to inter-building
(outside plant) link segments that are subject to lightening transients or power faults.
6
7
8
9
1
2
3
4
5
Data SetReadyData CarrierDetect
Request to Send
Clearto Send
NotUsed
Receive Data
TransmitData
Data Terminal Ready
Signal Ground
Protective Ground
RS-232 Copper Cable
CRS2F3115-100
Gauge: 24 to 22 AWG
Maximum Data Rate (asynchronous): 115 kB/s
Maximum Cable Distance: 15 m (50 ft.)
RS-232 Signals:
[email protected] -- Click the “Transition Now” link for a live Web chat. 9
Troubleshooting
If the media converter fails, isolate and correct the failure by determining the answers
to the following questions and then taking the indicated action:
1. Is the P (power) LED illuminated?
NO
• Is the media converter inserted properly into the chassis?
• Is the power cord properly installed in the chassis and in the grounded AC outlet?
• Does the grounded AC outlet provide power?
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the RX (copper) LED flashing?
NO
• Disconnect and reconnect the RS-232 copper cable to restart the initialization
process.
• Restart the attached device on the other end of the RS-232 cable to restart the
initialization process.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Proceed to step 3.
3. Is the FL (fiber) LED illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the media converter are connected to the RX
and TX ports, respectively, on the other media converter.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Proceed to step 4.
4. Is the FL (fiber) LED flashing?
YES
• The media converter is in loop-back mode. To disable the loop-back function in
“Hardware” mode, set the loop-back switch to the "Norm" position. In “Software”
mode, at the SNMP interface, select “disable loop-back” option.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
NO
• Proceed to step 5.

10 24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CRS2F31xx-100
5. Is Data Transfer Failing?
YES
• Verify the local copper connection by starting a local copper loop-back (hardware
mode: set the loop-back switch on the local media converter to “loop”, software
mode: enter the local copper loop-back command) and then use a bit error test unit to
run a bit error test.
• Verify the local fiber connection by starting a remote fiber loop-back (hardware
mode: set the loop-back switch on the remote media converter to “loop”, software
mode: enter the remote fiber loop-back command) and then use a bit error test unit to
run a bit error test.
• Verify the remote copper connection by starting a remote copper loop-back
(hardware mode: set the loop-back switch on the remote media converter to “loop”,
software mode: enter the remote copper loop-back command) and then use a bit error
test unit on the remote end to run a bit error test.
• Verify remote fiber connection by starting a local copper loop-back (hardware
mode: setting the loop-back switch on the local media converter to “loop”, software
mode: enter the local fiber loop-back command) and then use a bit error test unit on
the remote end to run a bit error test.
NO
• Contact Technical Support: US/Canada: 1-800-260-1312, International: 00-1-952-
941-7600.
Remote ConverterLocal Converter
w/SNMP Management
reppocrebiFreppoc
Remote ConverterLocal Converter
w/SNMP Management
reppocrebiFreppoc
Remote ConverterLocal Converter
w/SNMP Management
reppocrebiFreppoc
Remote ConverterLocal Converter
w/SNMP Management
reppocrebiFreppoc
Declaration of Conformity
Name of Mfg: Transition Networks
10900 Red Circle Drive Minnetonka MN 55343 U.S.A.
Model: CRS2F31xx-10x Series Media Converter
Part Number: CRS2F3111-100, CRS2F3113-100, CRS2F3114-100,
CRS2F3115-100, CRS2F3129-100, CRS2F3129-101,
CRS2F3129-102, CRS2F3129-103
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the CRS2F31xx-10x to which this declaration refers is in
conformity with the following standards.
CISPR 22: 1993; EN 55022:1998 Class A; FCC Part 15 Subpart B; EN 55024: 1998;
21 CFR subpart J
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
[email protected] -- Click the “Transition Now” link for a live Web chat. 11
Contact Us
Technical Support
Technical support is available 24 hours a day.
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Transition Now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based Seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
[email protected]
Address
Transition Networks
10900 Red Circle Drive Minnetonka MN 55343, U.S.A.
telephone: [phone]
toll free: 800-526-9267
fax: [phone]
July 2008_____
Stephen Anderson, Vice-President of Engineering Date

Compliance Information
CISPR22/EN55022 Class A + EN55024
CE Mark
FCC Regulations
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which
case the user will be required to correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus
set out on the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la Class A prescrites dans le Règlement sur le brouillage
radioélectrique édicté par le ministère des Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses
Gerätes Rundfunkstörungen auftreten. In diesem Fäll ist der Benutzer für Gegenmaßnahmen
verantwortlich.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures spécifiques
appropriées.
Trademark Notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright Restrictions
© 2003-2005 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means -
graphic, electronic, or mechanical - without written permission from Transition Networks.
Printed in the U.S.A. 33278.H
In accordance with European Union Directive 2002/96/EC of the European Parliament
and of the Council of 27 January 2003, Transition Networks will accept post usage
returns of this product for proper disposal. The contact information for this activity can
be found in the 'Contact Us' portion of this document.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-
Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer
Konformität.
