MODELS: EIS-1, EIS-2 O R E I S- 4
USER MANUAL
: DOOR ENTRY UNIT
Programming Software
v.02 2018

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%1%
Contents
1!FOR YOUR SAFETY ..............................................................................................................................................4!
2!INTRODUCTION .................................................................................................................................................... 5!
3!EIS-1, EIS-2, EIS-4 FEATURES AND APPLICATIONS ................................................................................... 6!
4!START UP ................................................................................................................................................................7!
5!LED INDICATION..................................................................................................................................................8!
6!CONNECTION DIAGRAM ...................................................................................................................................9!
7!EIS UNIT MANAGEMENT .................................................................................................................................10!
8!EIS FUNCTIONS WITH PROGRAMMING INSTRUCTIONS......................................................................11!
8.1!WEB SERVER -LOG IN ................................................................................................................................................... 11!
8.2!WEB SERVER –ADDING UNITS TO USER PROFILE.................................................................................................12!
8.3!WEB SERVER-UNIT MANAGEMENT ........................................................................................................................... 14!
8.4!INTERCOM CONFIGURATION ...................................................................................................................................... 15!
8.5!KEYPAD PIN ENTRY –ACCESS .................................................................................................................................... 17!
8.6!WIEGAND ACCESS.......................................................................................................................................................... 19!
8.7!CALLER ID ACCESS ........................................................................................................................................................ 21!
8.8!OUTPUTS SETTINGS ....................................................................................................................................................... 22!
8.9!EIS WIEGAND OUTPUT INTEGRATION ...................................................................................................................... 24!
8.10!TIMER-TIMED CONTROLED OUTPUT......................................................................................................................... 25!
8.11!ADMINISTRATION .......................................................................................................................................................... 27!
8.12!EVENT LOGING................................................................................................................................................................ 29!
8.13!MISCELLANEOUS............................................................................................................................................................ 30!
8.14!PIN ACCESS NOTIFICATION FUNCTION .................................................................................................................... 31!
9!WIEGAND INPUT DATA FORMATS ...............................................................................................................33!
9.1!WIEGAND 26 BIT, DIFFERENT DATA FORMATS ...................................................................................................... 35!
9.2!WIEGAND 30 BIT, DIFFERENT DATA FORMATS ...................................................................................................... 36!

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%2%
Figures
Figure 1: EIS: Connection diagram .....................................................................................................9!
Figure 2: WEB Server-Sign In page ..................................................................................................11!
Figure 3: WEB Server-Main page select ADD mode........................................................................12!
Figure 4: WEB Server-Main page adding EIS units..........................................................................13!
Figure 5: WEB Server-Unit management window ............................................................................14!
Figure 6: WEB Server-Intercom settings...........................................................................................15!
Figure 7: WEB Server-Keypad PIN Access: Permanent PIN codes .................................................17!
Figure 8: WEB Server-Adding Wiegand devices with temporary use. .............................................18!
Figure 9: WEB Server-First Wiegand interface support....................................................................19!
Figure 10: WEB Server-Wiegand interface support. .........................................................................20!
Figure 11: WEB Server-Adding Wiegand devices with permanent use.Error! Bookmark not
defined.!
Figure 12: WEB Server-Adding Wiegand devices with temporary use.Error! Bookmark not
defined.!
Figure 13: WEB Server-Caller ID Access .........................................................................................21!
Figure 14: WEB Server-Output setting..............................................................................................22!
Figure 15: WEB Server-Wiegand Output settings.............................................................................24!
Figure 16: WEB Server-Timer setting →Day mode. ........................................................................25!
Figure 17: WEB Server-Timer setting →Week mode.......................................................................25!
Figure 18: WEB Server-Notification numbers ..................................................................................27!
Figure 19: WEB Server-Input alarm configuration ...........................................................................27!
Figure 20: WEB Server-Log event ....................................................................................................29!
Figure 21: WEB Server-Misc ............................................................................................................30!
Figure 22: WEB Server-Global enabling of the notificaton function................................................31!
Figure 23: WEB Server-Selecting administrator numbers for notification. ......................................32!
Figure 24: WEB Server-First Wiegand interface support..................................................................33!
Figure 25: WEB Server-Second Wiegand interface support. ............................................................34!

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%3%
Tables
Table 1: WEB Server-SPIN entry parameters. ..................................................................................18!
Table 2: WEB Server-SPIN entry parameters. .................................. Error! Bookmark not defined.!
Table 3: WEB Server-Timer setting, output mode options ...............................................................26!
Table 4: Wiegand 26: Mode 0............................................................................................................35!
Table 5: Wiegand 26: Mode 1............................................................................................................35!
Table 6: Wiegand 26: Mode 2............................................................................................................35!
Table 7: Wiegand 26: Mode 3............................................................................................................35!
Table 8: Wiegand 30: Mode 0............................................................................................................36!
Table 9: Wiegand 30: Mode 1............................................................................................................36!
Table 10: Wiegand 30: Mode 2..........................................................................................................36!
Table 11: Wiegand 30: Mode 3..........................................................................................................36!

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%4%
1FOR YOUR SAFETY
SWITCH ON SAFELY
Do not switch the unit on when use of wireless phone is prohibited or when it may cause
interference or danger.
INTERFERENCE
All wireless phones and units may be susceptible to interference, which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the unit off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the unit at a refueling point. Do not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the unit where blasting is in progress.
USE SENSIBLY
Use only in the normal position as explained in the product documentation. Do not touch the
antenna unnecessarily.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%5%
2INTRODUCTION
EIS-1, EIS-2, EIS-4 (EIS) is a simple but powerful GSM intercom communication system designed
to ensure low-cost, simple to install/use, reliable and single box solution for intercom application. It
is designed for unlimited range, wire free GSM intercom, pin code access, caller ID control and
Wiegand access support.
Optional EIS supports alarm detection, stay-alive messages, credit detection etc.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%6%
3EIS-1, EIS-2, EIS-4 FEATURES and APPLICATIONS
Features:
⇒Built-in 5 band GSM module
⇒Up-to 4 intercom call button support (5 numbers each)
⇒Keypad Access entry support (up-to 1000 PIN codes)
⇒Caller ID numbers control (up-to 1000 caller ID numbers)
⇒Up to 100 temporary SPIN access codes
⇒Input Wiegand receiver(up-to 1000 receivers)
⇒2 outputs (relay supported)
⇒Programming with PC via “USB to Mini USB cable” connected to the unit
⇒Programming by WEB server
⇒Programming by SMS commands
Applications:
⇒Single box, wire free intercom solution
⇒Remote gate opener – Caller ID number recognition
⇒Simple (Wiegand) access system

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%7%
4START UP
EIS unit accepts a standard GSM Sim (T-Mobile or AT&T) card.
VERY
IMPORTANT
USE A MICRO SIM CARD
WARNING
DO NOT Insert or remove the SIM card while the unit is powered ON!!
IMPORTANT
Before inserting SIM card to unit make sure the PIN code is
removed!!
⇒Insert SIM card in EIS unit.
⇒Connect power cable to EIS unit (YOU MUST POWER THE EIS UNIT WITH THE
POWER SUPPLY INCLUDED). Do not power with any other power supply.
⇒Power up the unit.
⇒Wait until LED1 (Blue) starts flashing. This is set in around 30 – 45 seconds.
⇒EIS unit is now ready to operate.
NOTE
EIS device will “beep” in 15s intervals until the unit reaches normal operation.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%8%
5LED INDICATION
Blue LED (LED1)
-Indicates the level of the GSM signal from 1 to 5 LED flashes (1 is weak signal, 5 is
excellent signal)
Red LED (LED2)
-GSM module Activity
Yellow LED (LED3)
-Short flashing indicates that the GSM module is ON, but it is not yet connected on the GSM
network. After connection, yellow led is flashing with short pulse (1/2 s) ON and a long
pulse OFF (5s).

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%9%
6CONNECTION DIAGRAM
Before connection the EIS please take a look at connection diagram.
Figure 1: EIS:Connection diagram
********************************************************************************
********************************************************************************
IMPORTANT
DO NOT USE Power out (12V AUX) for electric lock driving! Use
separate power source for door electric lock!

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%10%
7EIS UNIT MANAGEMENT
Unit supports different types of management (programming):
********************************************************************************
⇒Unit can be programmed remotely by using WEB server access.
Access it by EISWARE.com
⇒EISWARE APP on IPHONE or ANDROID
Must have data plan enabled to get data transfer on either method.
********************************************************************************
These are alternative solutions to accomplish the programming.
⇒Unit can be programmed remotely by SMS commands (Optional).
⇒Unit can be programmed directly by USB connection, with the use of configuration software
running on PC (EIS Ware).

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%11%
8EIS FUNCTIONs with PROGRAMMING
INSTRUCTIONs
As mentioned in previous chapters EIS unit can be programmed in various way, this document will
focus on most common programming way: WEB programming.
IMPORTANT
SIM card in the EIS unit MUST have DATA PLAN to be able to use WEB
programming!
8.1 WEB SERVER - LOG IN
The web server can be find under the address: https://www.eisware.com/.
Figure 2: WEB Server-Sign In page
User must first use the Sign IN section to create working profile on the server. The profile can be
created by using social login like Facebook, Google account or Twitter. If user lacks any of the
social profile it can proceed to Sign UP page use standard user name and password entry.
NOTE
Server support Firefox, Google Chrome and Safari.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%12%
8.2 WEB SERVER –ADDING UNITS TO USER PROFILE
After login the user will be diverted to WEB server main window. This page is used to
add/remove/search for EIS units from the user’s profile.
Select “+” sign to select ADD EIS units to user’s profile.
Figure 3: WEB Server-Main page select ADD mode

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%13%
Figure 4: WEB Server-Main page adding EIS units
User than provides required data:
•Name: Name for the added unit - mandatory information.
•IMEI: Identification number of the unit, can be found in the enclosure of the unit -
mandatory information. The IMEI is located on the cellular chip and also should be on the
card board box of the EIS.
•Phone Number: The telephone number of the SIM card in the EIS unit - mandatory data.
•GPRS settings: Information needed to enable data connection between the server and the
unit. Selectable from the drop-down menu - mandatory data.
•Location: Notification field, used by the user to provide extra data for its own information -
optional data.
By clicking the “+” (insert sign) after filling mandatory data, the unit will be added to the user
profile.
First building of the unit data-base may take a few minutes.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%14%
8.3 WEB SERVER-UNIT MANAGEMENT
After the EIS unit is added to user database, the user can change the configuration of the specific
unit.
All changes made by the user are listed in the Change Log window. By clicking Send to device
button ALL changes are send to the unit. User can (Revert) all changes made, before sending, by
clicking (Revert all) or select particular entry and revert it.
Figure 5: WEB Server-Unit management window

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%15%
8.4 INTERCOM CONFIGURATION
Primary function of the EIS unit is intercom support. Selecting (calling) apartment number is
achieved pressing the call button beside appropriate name plate.
This actions will start a voice call procedure from Phone number 1 till Phone number 5. After the
call is answered the called user has the option to trigger the output by pressing “11” for opening
Output 1 or “21” for triggering Output 2.
If the call is answered the unit will stop dialing next numbers on the list.
** To terminate the call press any button.
Management of the intercom function is found under Intercom tab.
Figure 6: WEB Server-Intercom settings.
Intercom management parameters:
•Telephone number 1…Telephone number 5: Number that the unit will call when call
button pressed.
•Delay before dialing next no. on the list: Time delay in second before next user on the list
gets dialed if the call to the previous user is not answered.
•Extension number: Parameter is used to set the DTMF number in auto self-select function
•Extension no. delay: Parameter is used to set the delay (in sec.) for sending DTMF number
in auto self-select function.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%16%
•Work time start, Work time end: Parameters are used to define work time schedule.
Inside this limits number under position 1 to 4 will be dialed, outside this limits number
under position 5 will be dialed.
Voice call setting
•Microphone level: Increasing the level will increase the sensitivity of the unit microphone
decreasing will decrease the sensitivity.
•Speaker level: Increasing the level will increase the volume of the unit speaker, decreasing
will decrease the level of the speaker.
•Ringing sound: By selecting Playing the unit will play the dial tone in the connection phase
of the call, by selecting Muted the unit will not play any sound in the connection phase of
the call.
•On activate input: By selecting Play beep sound (buzzer) the unit will provide audio feed
back (buzzer BEEP) when the apartment entry is selected, by selected Muted unit will
provide no audio feedback when the apartment entry is selected.
NOTE
EIS-1 has 1 CALL button.
EIS-2 has 2 CALL buttons.
EIS-4 has 4 CALL buttons.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%17%
8.5 KEYPAD PIN ENTRY – ACCESS
Secondary use of on-board keypad is access by entering PIN codes. Pin codes must be at least 4
digits.
Pin codes can be defined in two sections. First section is permanent pin code and second is
temporary pin codes which are limited by the consecutive time they are entered.
Permanent pin codes are placed in Pin access tab.
They are placed in two tables. For each table user can define which output they will trigger.
Figure 7: WEB Server-Keypad PIN Access: Permanent PIN codes
PIN entry: For each PIN entry user need to select PIN code value and optional User name.
Temporary pin codes are placed in Temporary pin access tab.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%18%
Figure 8: WEB Server-Adding Wiegand devices with temporary use.
•Temp PIN codes activate output: Selecting the output that will be triggered in case of
correct SPIN code.
•SPIN entry: For each SPIN entry user need to select appropriate values.
SPIN options
Description
SPIN value
Temporary PIN code
User name
Name of the user
Notify
If SPIN code is used, administrator numbers CAN be notified
Counter limit
Enable/Disable counter limitation (consecutive use)
Timer limit
Enable/Disable timer limitation
Timer mode
Timer limit mode: Day limit (day limitation), Timer limit
(hours of a day access limitation)
Rules valid on weekend
Enable/Disable timer limitation for weekend days
Counter
Number of allowed use of SPIN code
Timer start/Timer end
Bottom and Top timer limitation
Table 1: WEB Server-SPIN entry parameters.

EIS-1,'EIS-2,'EIS-4'
USER'MANUAL!
Page%19%
8.6 WIEGAND ACCESS
EIS unit has onboard support for 2 Wiegand output based device. With the use of external replicator
more Wiegand devices can be connected to the unit.
Configuration of first Wiegand interface is found in Digital interface tab. First Wiegand interface
can be found on board with a dedicated Wiegand connector and cables.
Figure 9: WEB Server-First Wiegand interface support.
•Mode: Select appropriate data formatting (Advise unit provider for more info if needed,
mode 2 is most common setting)
•Facility code: User can Enable or Disable facility code field.
NOTE
See Chapter 9-WIEGAND INPUT DATA FORMATs for detailed explanation
of different data format options.
Second Wiegand interface is shared with alarm input lines, user must select Wiegand in Input
operation mode found in the Inputs tab.
