TransTel Communications SuperKey SK-824 User manual

TransTel Communications, Inc.
1095 Jupiter Park Drive, Suite 7
Jupiter, FL 33458
http://www.transtelcommunications.com
Phone [phone] ©2000 TransTel
TMS-100 Plug-N-Play
For
SK-824 Electronic
Telephone System
Installation - Quick Reference Guide
TransTel Communications, Inc

©2000 TransTel Communications, Inc.

Page 3
Notes For SK-824 &
TMS-100 Plug and Play Voice Mail
SK-824 - Information
The table listed below shows the database changes necessary for a
SK-824 Plug and Play KSU in order to install a TMS-100 configured as
a Plug and Play.
First, you must decide which Single Line Telephone Station Circuits
that you wish to use for voice mail. This document assumes you are
using a 4 port TMS-100 voice mail system. If you are using a larger or
smaller TMS-100, you will need to list more or fewer stations. Please
enter the extension numbers and the circuit numbers for the 4 ports
you intend to use.
The circuit numbers consist of a 2 digit code.
The first digit is the physical card in the cabinet. There are three
possible cards in the cabinet of a SK-824.
The second digit of the circuit number is the physical circuit on
the station card. All station cards are 8 circuit cards. If you
connect your voice mail to the last 4 circuits on a station
card, the circuits will be connected on circuits 5, 6, 7 and 8.
This information is necessary in order to properly program the SK-824
for integration with the TMS-100.
Valid circuit numbers are: 11 through 18
21 through 28
31 through 38
Basic Information Extension Number Equipment Number
Voice Mail Port 1
Voice Mail Port 2
Voice Mail Port 3
Voice Mail Port 4

Page 4
Database Items that must be changed for Plug-N-Play installation
for SK-824. This is for a system with a 4 port TMS-100 and a SK-
Item Description Plug-N-Play
01-01-05 Busy Reminder Tone Interval 6=30 seconds
01-02-01 Single Line Telephone Dial
Tone Timeout 5=16 seconds
01-02-02 Single Line Telephone – Inter
Digit Timeout 5=16 seconds
01-02-04 SLT Release (Disconnect) 6=1000 ms
01-03-07 Dial Tone Options 0=Normal
01-04-01 Callback Timer 0=None
01-06-01 Transfer Recall - Busy 2=15 seconds
01-06-02 Transfer Recall - No Answer 2=15 seconds
01-08-01 CO Hunt Interval 3=6 seconds
01-08-03 SLT Busy Remind Tone 1=Disable
01-09-03 CO Disconnect Timer 4=320
milliseconds
01-10 Voice Mail digit string dddddddd
01-12-05 VM Integration Type 7=10 digit muted,
no CO codes sent
The following programming changes will be determined by the
extension number where the voice mail is connected. Please refer to
the entries you made on page 3 of this document.
Item Description Plug-N-Play
25-____-03 Call Split – Voice Mail Port 1 1=Disable
25-____-03 Call Split – Voice Mail Port 2 1=Disable
25-____-03 Call Split – Voice Mail Port 3 1=Disable
25-____-03 Call Split – Voice Mail Port 4 1=Disable
Form 25 – Extension Number – 03
Enter the voice mail extension numbers in the blank spaces below and
make sure the system programming is changed to accept this.

Page 12
Basic Plug and Play Information
Greetings Text
The following greetings are recorded on the Plug-N-Play TMS system.
User ID 990 Greeting 3
Hello, this is User ID 990 on the TMS series system. This is your first
answer greeting. Normally, this message will say, "Thank you for
calling XYZ corporation." You should replace this message with a
custom greeting of your own. Please refer to Section 3, Recording your
Greetings, in the TMS Administration and Programming Guide. Look in
the section entitled Record the Company Greeting. When this
message is finished, TMS will move to User ID 991.
User ID 991 Greeting 3
This is User ID 991. This messageis generally used to give incoming
callers instructions on how to navigate your individual TMS system.
This message should be replaced with your own instructions on how to
reach the departments or people or to give them options to move to
other User ID's within the system. To re-record this message, follow
the directions given in Section 3 of the TMS Administration and
Programming Guide. You will find specific instructions listed under the
category, Record Caller instructions.
When this message is complete, if the incoming caller has not dialed
anything, TMS will offer the option of sending the call to User ID 0, the
Operator.
User ID 11 through 34
You have reached the voice mailbox of User ID xx. Please leave a
message at the tone, or you may dial 0 to reach the system operator.
User ID 411
Enter the first 3 letters of the first or last name of the person you wish to
reach. When you hear the name of the person, please dial the
extension number given after the person’s name.
User ID 412
If you heard the name of the person you wish to reach, please dial the
extension number at this time. If you wish to check the directory again,
please press 1 or you may reach the system operator by dialing 0.
Page 5
For example: If your voice mail ports are connected to extensions 31,
32, 33 and 34, you need to program 25-31-03, 25-32-03, 25-33-03 and
25-34-03 all with the value of 1. This setting is vital to proper
programming for voice mail connectivity.
Form 26 – Extension Number - 04
Enter the voice mail extension numbers in the blank spaces below and
make sure the system programming is changed to accept this.
For example: If your voice mail ports are connected to extensions 31,
32, 33 and 34, you need to program 26-31-04, 26-32-04, 26-33-04 and
Item Description Plug-N-Play
26-____-04 Station Conference Voice Mail Port 1 1=Disable
26-____-04 Station Conference Voice Mail Port 2 1=Disable
26-____-04 Station Conference Voice Mail Port 3 1=Disable
26-____-04 Station Conference Voice Mail Port 4 1=Disable
Item
Description Plug-N-Play
28-____-05 Toll Class – Day Service Voice Mail Port 1 9=Disable
28-____-05 Toll Class – Day Service Voice Mail Port 2 9=Disable
28-____-05 Toll Class – Day Service Voice Mail Port 3 9=Disable
28-____-05 Toll Class – Day Service Voice Mail Port 4 9=Disable
Form 28 - Extension Number - 05
Toll Classification - Day Service
Like the previous forms listed, you need to enter the extension numbers
that are connected to voice mail.

Page 6
Item Description Plug-N-Play
28-____-06 Toll Class – Night Service Voice Mail Port 1 9=Disable
28-____-06 Toll Class – Night Service Voice Mail Port 2 9=Disable
28-____-06 Toll Class – Night Service Voice Mail Port 3 9=Disable
28-____-06 Toll Class – Night Service Voice Mail Port 4 9=Disable
Form 28 – Extension Number – 06
Toll Classification – Night Service
Like the previous forms listed, you need to enter the extension numbers
that are connected to voice mail.
Note regarding Form 28: The entries for toll restriction are designed
as a preventative measure to prevent possible toll abuse by outside
callers. The programming listed on forms 28-Extension Number-05
and 28-Extension Number-06 above will prevent the voice mail
system from dialing any outside calls. If your application requires
the use of a pager(s) you may choose to set the toll restriction levels for
the voice mail at 0 or build an appropriate toll restriction table for the
voice mail.
Form 29 – Circuit Number – 02 - Equipment Type
Please note that this form uses the circuit number (cabinet-slot-circuit)
and NOT the extension number of the voice mail port. Refer to the
entries and instructions from page 3 of this booklet.
Item Description Plug-N-Play
29-____-02 Equipment Type Voice Mail Port 1 8=Voice Mail Port
29-____-02 Equipment Type Voice Mail Port 2 8=Voice Mail Port
29-____-02 Equipment Type Voice Mail Port 3 8=Voice Mail Port
29-____-02 Equipment Type Voice Mail Port 4 8=Voice Mail Port
Note: Setting the equipment type to Voice Mail Port causes the SK-
824 to send proper integration digit strings to the voice mail system and
proper operation of Message Waiting.
Page 11
I n the Chains section everything should be blanks, except for Done,
which should be set to 999 and Delay, which should be set at 0. User
The substance of the notification templates should be as follows
(referring to the lower portion of the Notification screen:
Message Waiting On Template:
Message Waiting Off Template:
Message Waiting Template Notes:
Default Plug and Play Systems
All TMS-100 systems configured as Plug and Play have Message
Waiting ON and Message Waiting OFF codes enabled (Enable = YES).
Note: On TMS-100 Voice Mail systems User ID 17 and User ID 18
do not have the Message Waiting ON codes enabled. This is due
to the fact that TMS-100 Plug and Play voice mail systems are
configured as if they are connecting to a SK-824 telephone
system.
Title: MESSAGE OFF Type: PICKUP Variable:
Method: 7072%U
Enabled MTWTFSS From To Notify
After Continue Every Max Times
YES YYYYYYY 00:00 23:59 0 min 60 min. 1
Title: MESSAGE ON Type: NORMAL Variable:
Method: 7071%U
Enabled MTWTFSS From To Notify Continue Max Times
YES YYYYYYY 00:00 23:59 0 min 60 min. 1
MESSAGE ON SMTWTFS 00:00-23:59 0 min/60 min
MESSAGE OFF SMTWTFS 00:00-23:59 0 min/60 min
<DISABLED>
<DISABLED>

Page 10
Using 3 Digit or 4 Digit Extension Numbers
If you program your SK-824 for 3 digit extension numbering or 4 digit
numbering, you will need to change the integration information for the
TMS system. Perform the following steps:
1. Shut down the TMS system by pressing <ALT> <S>.
TMS will ask for a password. Factory default password is TMS (all
capital letters). Enter the password and press <Enter>.
2. TMS will ask if you really want to shut down. Press Y
3. TMS will confirm once again that you want to shut down. Press Y
4. When you return to the DOS Prompt (C:\TMS) type SETUP and
press <ENTER>.
5. Select Option 1.
6. Press key <F1>,
7. You will be presented with a list of telephone systems. Scroll down
using the down arrow keys on the keyboard until you see the
entries for the TransTel SK-824. Highlight the entry that is correct
for your installation (2 digit, 3 digit or 4 digit numbering plans) and
press <Enter>.
8. Your system is now configured for proper integration for the
selected extension numbering plan.
9. Press <ESC> <ESC>. You will be at the DOS prompt (C:\TMS).
10. Type TMS and press Enter. TMS will start.
MAILBOX 997 – Default Values
Mailbox 997 is the system “default” mailbox. When you create a new
mailbox, it will have the same parameters as mailbox 997. This
relieves you from the necessity to program each item for each mailbox
individually. If you need to change the default values for some reason,
changing them in 997 will cause any new mailboxes created after the
changes to share the values stored in mailbox 997.
Mailbox 997 Factory Defaults
Maximum Rings: 0
Do Not Disturb: OFF Lock: OFF
Screen Calls: OFF Lock: OFF
Store Messages? YES Max: 180 sec
Copy Messages To:
Message Volume: 0 Guests: -1
Current Greeting 0 Max: 45 seconds
Busy Message? SYS Name/Ext? YES
Page 7
Form 42 – CO Line – xx - Day Ringing Assignment
Form 42 determines the stations that will ring on an incoming call. We
recommend that you program the voice mail extensions as the first 4
extensions to ring on each incoming CO line, with one or more
extensions programmed as “backup” answering positions in case of a
voice mail failure or a situation where all voice mail ports are in use.
Ringing extensions are programmed one after the other on this form.
The system automatically assigns stations to ring when the system is
initialized, so you might find it advantageous to use DSS button 8
(Clear All) to empty the ringing assignment form before you program
the ringing stations on it.
A version of Form 42 exists for each CO line in the system. A SK-824
system can have up to 8 CO lines, so Form 42-01-xx through 42-08-xx
may exist in your SK-824.
Form 43 – CO Line – xx - Night Ringing Assignment
Form 43 determines the stations that will ring on an incoming call when
the system is in Night Service. This form works for Night Service in the
same manner as Form 42 does for Day Service.
The system automatically assigns stations to ring when the system is
initialized, so you might find it advantageous to use DSS button 8
(Clear All) to empty the ringing assignment form before you program
the ringing stations on it.
A version of Form 43 exists for each CO line in the system. A SK-824
system can have up to 8 CO lines, so Form 43-01-xx through 43-08-xx
may exist in your SK-824.
Form 46 – CO Line – 07 - Day Ring Type
Form 46 – CO Line – 08 - Night Ring Type
Incoming Ringing Type should be set to type 3 (Hunt) for all incoming
trunks that are to be answered by voice mail. This setting provides
optimum control of incoming ringing. When set to 3, the first available
voice mail port receives incoming ring signal. If the first port is busy,
the system will automatically step to the second port. Should the first
port not answer for any reason, the second port will be added on after
the expiration of the timer set on Form 01-08-01. Using this ringing
sequence calls can be answered in a timely manner by the voice mail
without tying up more than one voice mail port per call.
There is a version of Form 46 for each CO line installed in your system.

Page 8
47-01 Hunt Group Access Code _____ 1
Form 48-01-xx - Hunt Group Members
Form 48-01 determines the extensions that are members of Hunt
Group 1 during day service. Program this form with the extension
numbers that are connected to the voice mail system.
48-01-xx Hunt Group Members
____ ____
____ ____
So Form 46-01-xx through 46-40-xx may exist in your SK-200.
Form 47-01 – Hunt Group Access Code
In order for stations to easily call the voice mail system, each of the
voice mail extensions must be assigned to a Hunt Group. We
recommend that you program your voice mail ports into Hunt Group 1.
Form 47-01 assigns the Access Code and the Hunt type to the First
Hunt Group.
The Access code you apply for this group is entirely up to you, but the
guidelines for Hunt Group assignment are as follows:
1 The Access code for the Hunt Group must be the same
length as your extension numbering plan.
The Access code must be unique to the system. Your
access code cannot be the same as an extension in the
system.
2 Your access code can begin with the digits 1 through 6.
2 digit extensions: 10 through 69 are OK.
3 digit extensions: 100 through 699 are OK
4 digit extensions: 1000 through 6999 are OK
Note: The access code you select for the Hunt Group cannot
conflict with an existing extension in the SK-824.
Page 9
TMS Information
The following parameters have been pre-set by TransTel to enable
Plug-N-Play operation.
Database Entry/Verification TMS-100
System Setup
Option 1. System Dial Codes
Item Entry
# Dial code to put a caller on transfer hold F,
# Dial code to use when there is no transfer dialtone (blank)
# Dial code to return to caller after Ring No Answer (blank)
# Dial code to return to caller when there is a Busy F-
# Dial code to use after a call screening reject F
# Dial code to connect the caller to the extension H
# Number of seconds to wait for dialtone detection 0
# Number of 1/100 seconds to use for Flash time 35
# Which DTMF tone to listen to for answer detection A
# Which DTMF tone to listen to for hangup detection C
# What to dial BEFORE dialing the User ID extension (blank)
# What to dial AFTER dialing the User ID extension H
# What to dial when the system first starts up (blank)
# What to dial when the system performs a shutdown (blank)
# What to dial when a port goes off-hook (blank)
Option 3. System Integration Patterns
If you use 2 digit extension numbering in your SK-200 the proper
Integration is already installed from the factory as listed below:
Item Entry
Integration Timeout by 1/10 10
Forward from Ring No Answer 1300rr00xx
Forward from Ring No Answer 1100rr00xx
Forward from Ring No Answer 2500rr00xx
Forward from Ring No Answer 2100rr00xx
Forward from Ring No Answer 2300rr00xx
Forward from Busy extension 1200rr00xx
Forward from Busy extension 2200rr00xx
Direct call from extension 1400ee00xx
Direct call from a CO trunk 2ttttt00xx
Direct call record 1500ii00xx
