TRAVELLER 1072569 User manual

1072569
User Manual
3000W
POWER INVERTER

1072569
P a g e | 1
Two set of heavy duty input cable
AC outlets Digital display
Posts
ON/OFF button
Remote control connection
port (remote control switch
is not included)
USB port

1 SAFETY GUIDELINES
3000W POWER INVERTER
1072569
P a g e | 2
Important
•Before connecting or using your 3000 watt inverter, please
read and understand this User’s Manual.
Please keep this manual for future reference.
Safety Precautions
•Incorrect installation or misuse of your DC toAC inverter may
result in damage or hazardous conditions tothe user. Please
pay special attention tothe following instructions and
warnings.
Warning！
Shock hazard! Keep away from children!
•
The safety will keep each AC outlet with only max 1500W power
output. Any appliance over 1500W will not be powerd by this unit,
and the overloading protection will be activated.
DO NOT open the case of the inverter.
DO NOT insert any foreign objects into the unit outlets, vents or
fan openings.
DO NOT expose the unit to rain, water or any other liquid, it is
not designed to be waterproof.
DO NOT operate the unit near flammable fumes or gases such
as the cabin of a gasoline power boat, or near propane tanks.
DO NOT operate the unit in an enclosed area that contains
automotive type lead-acid batteries. This type of battery emits
explosive hydrogen gas which can be ignited by sparks.

DO NOT connect the unit to any utility power distribution
systems or branch circuits.
DO NOT use the inverter in temperatures over 104℉(40℃) or
under 32℉(0℃).
1072569
P a g e | 3
The case tothe unit may become very hot under high power
operation reaching 140℉(60℃). Be sure that there is at least
2in. (5cm) of unobstructed air space around the entire housing
of the inverter at all times. During use, do not place materials
that could be damaged by heat near the unit.
Failure to follow these safety guidelines will resultin
personal injury and/or the damage to the unit. It may also be
void of the warranty.
Caution！
DO NOT connect the unit to live AC power circuits or there
would be damage tothe inverter.
Connect the unit to batteries with a normal output of 12V DC
only. Both 6V battery voltage and 24V battery voltage will
damage the unit.
Know the voltage requirement of your appliances, the 115V
3000W power inverter can properly supply the power of those
appliances that do not exceed its capacity.
The wattage (WATT) or amperes (AMP) can normally be seen
stamped or printed on most appliances and equipment or in the
user’s manual . To calculate the continuous load: Continuous
load = AMP X 115 (AC voltage);
DO NOT operate the inverter if it has received a sharp blow,
been dropped or otherwise damaged in any way.

1072569
P a g e | 4
The unit must be operated in an area that meets the following
requirements in order to operate safely and provide optimum
performance:
Your 3000W Power Inverter supplies 3000 watts of continuous
power with 6000 watts of surge power. When you turn on an
appliance or a tool that operates using a motor or tubes, it
requires an initial surge of power to start up. This surge of power
is referred to as the “starting load” or “peak load”. Once started,
the tool or appliance requires less power to continue to operate.
This is referred to as the “continuous load” in terms of power
requirements. You will need to determine how much power your
tool or appliance requires to start up and its continued running
power requirements.
2 OPERATING INSTRUCTIONS
Description
Don’t allow water or other liquid to drop
or splash on the unit.
Dry
Ambient air temperature should be 0℃~40℃
(the cooler the better within this range).
Cool
Leave at least 2in. (5cm) clearance around
the unit for air flow. Ensure that the
ventilation openings are not obstructed.
Ventilated
Do not operate the unit in the same
compartment as batteries or in any
compartment capable of storing flammable
liquids like gasoline.
Safe
Do not operate the unit in an area that is
prone to dirt, dust or debris. Especially
important if used in a work environment.
Clean

1072569
P a g e | 5
The inverter should be connected to your 12V power source with
the two sets of DC cables to four posts (included). We
recommend that the equipment or appliance switch be in the
“OFF” position prior to plugging into the AC receptacle of the
inverter.
Connecting the inverter:
1) Place the inverter on a flat surface, such as on the vehicle
floor.
2) Please make sure that the inverter is off.
3) Attach the ring type connector marked with red to the positive
(+) DC terminal on the power inverter, and attach the ring
connector marked with black to the negative (-) DC terminal.
4) Tighten the nut on each DC terminal until it is snug. DO NOT
over-tighten.
5) Connect the other end of the DC cables to 12V battery, red to
positive and black to negative.
Caution!
Reverse the polarity will arouse blown fuse or damage to the
inverter, which may also void the warranty.
6) Repeat step (3)-(5) to connect another set of DC cables
Notice: As this is a heavy duty unit, it requires two set of cable
connecting to carry the electrical power.
7) Press the ON button to turn inverter on.
8) Plug the AC product(s) you wish to operate into the AC
outlet(s).
9) Switch them on, one at a time.
10) When the power inverter is not in use, disconnect the DC
O-ring from the battery to prevent slight discharge of battery
.

Caution!
If there are one more AC products connecting to the inverter,
turn on the larger power product first.
1072569
P a g e | 6
1
SINGLE BATTERY CONNECTION
FOR 3000W INVERTER
POWER
INVERTER
VEHICLE
GROUND
RED
RED
BLACK
BLACK
POWER
INVERTER
VEHICLE
GROUND
RED
RED
BLACK
BLACK
DUAL BATTERY CONNECTION
FOR 3000W INVERTER
TWO SET CABLE
TWO SET CABLE
TWO SET CABLE
TWO SET CABLE

1072569
P a g e | 7
Caution!
Most vehicle batteries are designed to provide short period of
very high current for starting the engine. They are not designed
for a constant “deep discharge”. Constantly operating the unit
from a vehicle battery until the low voltage shut off will affect the
life of the battery. If you are operating electrical products for
extended periods of time, you should consider connecting the unit
to a separate deep discharge battery.
Caution！
Although the inverter incorporates protection against
over-voltage, it may still be damaged if the input voltage
exceeds 16 volts.
Cable Gauge suggection :
it's highly recommend to use the included oring cables to
connection the inverter to 12V battery. if you want longer cable,
please refer to below chart of copper cable gauge suggestion:
Length Guage (2sets)
3FT
4FT
5FT
6FT
7FT
8FT
9FT
10FT
6AWG
5AWG
4AWG
4AWG
3AWG
3AWG
2AWG
2AWG

1072569
P a g e | 8
3000W Power Inverter, a high performance solution to use
household power while on the road. Connected to the 12V volt
output in your vehicle, the inverter efficiently and reliably supplies
115V/60Hz AC power for a wide variety of loads, such as all kinds
of jacklights, TV sets, audio/video systems and electromotion tools
with total power consumption under 3000 watts. It has been tested
and found to be in line with the requirement of ETL certification.
With proper care and appropriate usage, it will give you years of
dependable service in your car, truck, RV and boat.
The unit is not designed to be waterproof. It applies to the
ambient temperature for 32℉~104℉（0℃~40℃).
3 FEATURES
Appliances
are working,
but error
code"LUP"
displayed,
alarming
Low input
voltage alarm
The input voltage
is getting low,
dropped to
11+/-0.3V
Error code
"LUP" displayed,
no output,
alarming
Low input
voltage
shut off
The input voltage
is low, dropped to
10.5+/-0.3V
Remove all
appliances ，turn
off the unit and
recharge battery
Error codes explanation and trouble shooting
Indication Protection type Possible cause Solution
The inverter is designed with automatic shutdown features in
abnormal conditions for safe operation. Please refer to below
chart for details.

1072569
P a g e | 9
Indication
Error code"OUP"
displayed, no
output, alarming
High input
voltage
shut off
The input voltage
is too high, over
15V
Remove all
appliances , turn
off the unit and
check the battery
voltage , make
sure it is within
11-15V
Error code"OLP"
displayed, no
output, alarming
Over load
shut off
Appliances
connected are
more than
inverter's output
capacity 3000W
or short circuit
Remove all
appliances , turn
off the unit and
reduce the loads
within 3000W.
Check if short
circuit occurred.
Error code"OCP"
displayed, no
output, alarming
Over heat
shut off
The inverter is
over heated
Remove all
appliances , turn
off the unit and
remove objects
covering inverter if
any, cool down for
15 minutes, restart.
Protection type Possible cause Solution
Error code"OPP"
displayed, no
output, alarming
No indicator, no
output
/
Short circuit
shut off
There is short
circuit.
Remove all
appliances , turn off
the unit .Check and
solve short circuit
and restart
Replace battery
check cable
connection, tighten
as required
Ask for technician's
help
Battery is defective
Loose connection
Inverter is
damaged

Waning！
1072569
P a g e | 10
1. Normal working conditions:
Under normal working condition, the digital display shows the
input voltage ( in V) and the output power( in W or KW)
intermittently.
Green indicator on
Yellow in dicator on
Red indicator on
the number displaying is the input voltage
the number displaying is the output power in KW
the number displaying is the output power in W
Digital display explanation:
2. Abnormal condition:
If there is error occurred, the inverter will shut down , alarm, and
digital display shows an error code (refer to page 9 "Error codes
explanation and trouble shooting"
One AC outlet is limited to 1500W only

Battery Operating Time
Operating time will vary depending on the charge level of the
battery, its capacity and the power level drawn by the particular
AC load.
When using a vehicle battery as a power source, it is strongly
recommended to start the vehicle every one hour or two to
recharge the battery before its capacity drops too low. The
inverter can operate while the engine is running, but the normal
voltage dropping during starting of the engine may trigger the
inverter’s low voltage shutdown feature.
Interference with Electronic Equipment
Generally, most AC products operate with the inverter just as they
would with household AC power. Below is the information
concerning two possible exceptions.
1072569
P a g e | 11
Buzzing in audio systems and radios
Some stereo systems and AM-FM radios have inadequate
internal power supply filtering and “buzz” slightly when powered
by the inverter. Generally, the only solution is an audio product
with a higher quality filter.
Television interference
The inverter is shielded to minimize its interference with TV
signals. However, with weak TV signals interference may be
visible in the form of lines scrolling across the screen. The
following should minimize or eliminate the problem:
•Increase the distance between the inverter and the TV, antenna
and cables.
•Adjust the orientation of the inverter television, antenna and
cables.
•Maximize TV signal strength by using a better antenna and use
shielded antenna cable where possible.

Max. Continuous Power……………………….....…….……..3000W
Surge Capacity (Peak Power)………………………………..6000W
Single Outlet Max. Continuous Output………...………....... 1500W
Input Voltage Range………………………………………11-15V DC
Output Voltage Range………………………………… 104-125V AC
Output Frequency………….…………………………...…..60+/- 2Hz
USB Output…………..……....…………………………....….5V 2.1A
Wave Form……………………………….………..Modify Sine Wave
4 SPECIFICATIONS
1072569
P a g e | 12
