Travla C134 Setup guide

Install CD-ROM to Driver Bracket
4.
11
22
Install HDD to Driver Bracket
5.
1. Attach HDD underneath the Drive Bracket
2. Tighten HDD with screws "B" (x4)
1. Slide in CD-ROM to Drive Bracket
2. Tighten CD-ROM with screws “C”
C
C
CD-ROM
HDD
B
B
B
B
1
2
Index
1) Remove Motherboard (MB) tray
2) Remove Drive Bracket from
motherboard
3) Install (0.8") memory
4) Install CD-ROM to Drive Bracket
5) Install Hard Drive to Drive Bracket
Travla Series
Model : C134
2" x 7" x 10" (HxWxL)
QUICK START
USER GUIDE

WARNING: Install and service to
this product is performed only by
qualified personnel to avoid risk of
injuries.
AA BB CC DD
A. M3 (8mm) socket screw
C. CD-ROM screw
B. M3 (5mm) screw
Screw Idenfication Guide
D.Thumb screw
22
1.
1. Remove screw “D” (x2)
2. Pull out Motherboard tray
1. Remove Motherboard (MB) Tray
1
8
835
5
EE
E. Hex washer screw
D
D
Remove Drive Bracket from MB
2.
3.
B
B
B
Drive Bracket
CD-ROM
Cover Bracket
Install (0.8" Height) Memory
3.
22
1. DIMM socket level up to 45 degrees
2. Insert DDR memory into the socket
B
1
B
B
Remove all screws "B" (x6) on top of drive bracket
Front Panel
I/O Gaskets
I/O gasket for EPIA-M
I/O gasket for EPIA-CL
USB 2.0
Microphone
Speaker
IEEE 1394
Power Switch
Power LED
HDD LED
