Trek 610D User manual

TREK, INC. TEL: [phone]
190 Walnut Street FAX: [phone]
Lockport, NY 14094-3710 NTERNET: www.trekinc.com
E-MAIL: [e-mail]
Model 610D Operator’s Manual Rev. B6 Part Number: 23120 0324/JNC
OPERATOR’S MANUAL
MODEL 610D
HIGH-VOLTAGE
SUPPLY/AMPLIFIER/CONTROLLER

Rev. 01 Q-Form-CE-003
Declaration of Conformity
We: Trek, Inc.
11601 Maple Ridge Road
Medina, New York 14103
Tel: [phone]
Fax: [phone]
Name and address of manufacturer:Introducer of product to the market:
Declare under our sole responsibility that the product,
Product Name: Supply / Amplifier
Model Number: 610D
Product Options: All
to which this declaration relates is in conformity with European Council (EC) standards and other
normative documents, including:
89/336/EEC Electromagnetic Compatibility Compliance
73/23/EEC Low Voltage Parameters and Limits Compliance
The following is a list of normative references and acceptable levels:
Safety: EN 61010-1:1993/A2:1995 General Safety Requirements
Emissions: EN 55011:1998 EMC Family Standard,Group1, Class B
EN 61000-3-2:1995/A2:1998 Harmonic Current, Class A
EN 61000-3-3:1995 Voltage Fluctuations and Flicker
Immunity: EN 50082-1:1998 EMC Generic Immunity Standard
IEC 61000-4-2:1995 Electrostatic Discharge, 4 kV CD, 8 kV AD
IEC 61000-4-3 /A1:1997 Radiated RF Electromagnetic Field, 3 V/m
IEC 61000-4-4:1995 Electrical Fast Transient/Burst, level 2
IEC 61000-4-5:1995 Surge Immunity, line to line –level 2,
line to earth –level 3
IEC 61000-4-6:1996 Conducted Disturbance Induced by RF, 3 V/m
IEC 61000-4-11:1994 Voltage Dips 60% Ut, Interruption 100% Ut
following the provisions of ISO/IEC Guide 22 of the European Council (EC) Directive.
Where and When Issued:
Medina, New York James B. Borkholder
July 2001 Compliance Engineer

Rev. 01 Q-Form-CE-003

Thank You
Thank you for buying a Trek instrument. This instrument has been designed and built
to high standards to give you years of trouble-free service.
If you have any questions, please feel free to contact your Trek Representative at:
Write: TREK, INC.
1:DOQXW6WUHHW
/RFNSRUW, NY 14-710
Fax: () -10
Telephone: In the United States: 1 800 FOR-TREK
International Customers: 1 () 8-
Internet: www.trekinc.com
E-Mail: [e-mail]
We welcome any comments or suggestions you may have relative to the operation,
performance, and/or quality of this product.
Trek products are covered by United States and foreign patents, issued and pending.
Information in this publication supersedes that in all previously published material.
Specifications are subject to change without notice.
Copyright © 2012 TREK, INC. All rights reserved. Printed in the U.S.A.

Table of Contents
Safety ........................................ iii
Preface........................................vii
Section I General Information
Introduction .....................................I-1
Specifications ....................................I-3
Incoming Inspection ................................ I-11
Incoming Confidence Test ...........................I-11
Section II Installation
Mounting ......................................II-1
Power Connection..................................II-1
Load Connection ..................................II-2
Input Connection ..................................II-2
Output Monitor Connection.............................II-4
Current Monitor ...................................II-4
External Control Connection ............................II-5
Digital Enable Connection .............................II-6
Section III Operation
Front Panel Features ................................III-1
Rear Panel Features.................................III-5
Normal Operation .................................III-7
Operating the Model 610D as a High-Voltage Supply ............III-7
Operating the Model 610D as a High-Voltage Amplifier ...........III-9
Operating the Model 610D as a Current Supply ...............III-11
Operating the Model 610D as a Transconductance Amplifier ........III-12
The Compliance Feature ...........................III-14
Setting a Current Limit ............................III-15
i

Section III Operation (cont.)
Setting a Voltage Limit ............................III-16
Remotely Turning On and Off the High-Voltage Output ..........III-17
Using the Digital Enable to Control the High-Voltage Output........III-17
Monitoring the Output Voltage ........................III-17
Monitoring the Load Current .........................III-18
I(t), I(r), and I(s) Explained ............................III-19
Section IV Maintenance
Safety........................................IV-1
Maintenance Assistance ..............................IV-1
Customer Service Assistance .........................IV-1
Repairs .....................................IV-2
Preventative Maintenance ...........................IV-2
Cleaning the Instrument ............................IV-2
Servicing the Fuses ..............................IV-3
Appendixes
Appendix A: Accessories
Included Accessories ..........................Accessories -1
Optional Accessories ..........................Accessories -1
Appendix B Warranty Statement
One year warranty .............................Warranty -1
Appendix C 6DOHVDQG6HUYLFH6DOHV
Inside the United States ............................Sales - 1
Outside the United States ...........................Sales - 2
Appendix D Authorized Service Organizations
Authorized Service Organizations .....................Service - 1
ii
Table of Contents

Safety
Review the following safety precautions to maintain safety and prevent damage to
the instrument or equipment connected to it.
The safety features of this instrument may be ineffective if the equipment is not
operated in the manner stated in this manual.
Refer all maintenance procedures to qualified personnel.
Safety Precautions
Use the Power Cord Provided
To avoid fire hazard, use only the power cord provided with this instrument.
Avoid Electric Overload
To avoid electric shock or fire hazard, do not apply a voltage to a terminal that is
outside the range specified for that terminal.
Avoid Electric Shock
To avoid electric shock, do not touch the high-voltage output connector or the load
circuit while the instrument is on.
Ground the Product
This product is grounded through the ground conductor of the power cord. To avoid
electric shock, the ground conductor must be connected to earth ground. Before
making connections to the input and output terminals of the product, ensure that the
product is properly grounded.
iii

Safety Precautions (cont.)
Do Not Operate Without Covers
To avoid electric shock or fire hazard, do not operate this instrument with the covers
removed.
Use Proper Fuses
To avoid fire hazard, use only the fuse type and rating specified for this instrument.
Indoor Use Only
This instrument is intended for indoor use only.
Do Not Operate in Wet or Damp Conditions
To avoid electric shock, do not operate this instrument in wet or damp conditions.
Do Not Operate in an Explosive Environment
To avoid injury or fire hazard, do not operate this instrument in an explosive
environment.
Product Protection Precautions
Use the Proper Power Source
Do not operate this instrument from a power source that is different than the voltage
specified on the serial number tag.
Provide Proper Ventilation
To prevent the instrument from overheating, provide proper ventilation.
Do Not Operate with Suspected Failures
If you suspect there is damage to this instrument, have it inspected by qualified
personnel.
iv
Safety

Safety Terms and Symbols
Terms in the Manual
These terms may appear in this manual:
Warning: Warning statements identify conditions or practices that could result in
injury or loss of life.
Caution: Caution statements identify conditions or practices that could result in
damage to this product or other equipment.
Symbols on the Product
These symbols may appear on the instrument:
Warning, risk of electric shock
Caution, refer to Operator’s Manual
CAT I Installation category I (overvoltage category): Classification for the
operation of a unit using voltage systems or circuits with required
standardized limits for transient voltages. Category I pertains to
voltages supplied at the peripheral level, with smaller tolerances for
transient voltages as specified by the Low-Voltage Safety standard
(EN 61010-1).
CAT II Installation category II (overvoltage category): Classification for the
operation of a unit using voltage systems or circuits with required
standardized limits for transient voltages. Category II pertains to
using voltage supplied on the local level (example: local wall outlets)
with smaller tolerances for transient voltages as specified by the
Low-Voltage Safety standard (EN 61010-1).
v
Safety

vi
Safety

Preface
This manual provides user information for the Model 610D High-Voltage
Supply/Amplifier/Controller. It contains the following chapters and appendixes:
•General Information contains a brief product description, specifications, and an
incoming confidence test that can be used to verify the instrument was not
damaged during transit.
•Installation describes how to set up the instrument for operation. Information is
included on mounting the instrument, the load connection, and the various input
and output connections.
•Operation contains a description of the product’s features and a detailed
explanation of proper operating procedures.
•Maintenance provides information on periodic maintenance procedures and fuse
replacement.
•Appendix A: Accessories describes other products that are useful with the
Model 610D.
•Appendix B: Warranty Statement describes the terms and conditions of the
Trek warranty.
•Appendix C: Authorized Sales Organizations contains contact information
for Trek sales organizations throughout the world.
•Appendix D: Authorized Service Organizations contains contact information
for Trek service organizations throughout the world.
vii

viii

Section I General Information
Danger: This instrument is not rated for use in an explosive environment.
DO NOT use it in an explosive environment or an explosion may result.
This manual provides instructions to install and operate the Trek Model 610D
High-Voltage Supply/Amplifier/Controller.
We recommend you take the time to read this manual to take full advantage of the
features and benefits of the instrument.
Introduction
The Trek Model 610D is a high-voltage supply/amplifier/controller with an output
voltage range of 0 V to ±10 kV and an output current range of 0 to 2000 µA. It can
be operated in any of six modes:
•As a high-voltage amplifier, it amplifies an externally applied signal.
Its gain is fixed at 100 V/V or 1000 V/V, switch selectable,
•As a high-voltage reference supply, it responds to a front panel dial
commanding an output voltage,
•As a transconductance amplifier, it responds to an externally applied
voltage signal to produce a proportional output current. The
transconductance gain is fixed at 20 µA/V or 200 µA/V, switch
selectable,
•As a current supply, it responds to a front panel dial commanding an
output current,
•As a high-voltage controller, it is maintained as in the high-voltage
amplifier mode, but the input amplifier’s input and feedback elements
are uncommitted and available for configuration by the user,
•As a transconductance controller, it is maintained as in the
transconductance amplifier mode, but the input amplifier’s input and
feedback elements are uncommitted and available for configuration by
the user.
I- 1

Introduction (cont.)
The Model 610D features a compliance limit function. When in a CURRENT
command mode, the compliance function is voltage. When in a VOLTAGE
command mode, the compliance function is current.
The current compliance limit function can be based upon either the total current or a
specific load current path.
The Model 610D features a four-quadrant, active output stage that sinks or sources
current into reactive or resistive loads throughout the output voltage range. This is
essential for achieving the accurate output response and high slew rates demanded by
reactive loads.
The Model 610D is protected against overvoltage and overcurrent conditions that
may be generated by active loads or by output short circuits to ground.
Precision voltage and current monitors provide low-voltage representations of the
high-voltage output and load current for monitoring purposes, or for use as feedback
signals in a closed-loop system.
The current monitors provide a means for close regulation of either the total load
current, I(t), or a specific current path, I(r). When the load includes several current
paths, only one is closely regulated.
The Model 610D can be operated on a bench top or, with optional hardware, in a
standard 19-inch rack.
I- 2
General Information

Specifications
All specifications are with no load unless otherwise specified.
Features
High-Voltage Switch A three-position switch to select ON,
OFF, or REMOTE.
Mode Switch A three-position switch to select either the
Supply, Amplifier, or Controller mode of
operation.
Supply Mode Voltage Control
Range Selection A two-position switch to select
0 to ±1 kV or 0 to ±10 kV.
Output Level Selection A precision potentiometer with a
graduated dial.
Polarity Selection A three-position switch to select positive
(+), negative (-), or OFF.
Compliance Feature
Compliance Level Selection A precision potentiometer with a
calibrated dial used to set the current limit
when operating in the voltage mode, or to
set a voltage limit when operating in the
current mode.
Compliance Indicator An yellow LED will illuminate when the
instrument is in a compliance limit
condition.
Compliance Limit
Current mode Adjustable to within 20 V of the output
setting.
Voltage mode Adjustable to within 0.5 µA of the output
setting.
I- 3
General Information

Specifications (cont.)
Features (cont.)
Front Panel Display A 3 ½-digit LED display can be selected
to indicate the voltage output or the
current output.
Range
Voltage 0 to ±1 kV or 0 to ±10 kV,
switch selectable.
Current 0 to ±199.9 µA or 0 to ±1999 µA,
switch selectable.
Resolution
Voltage
1 kV Range 1 V.
10 kV Range 10 V.
Current
200 µA Range 0.1 µA.
2000 µA Range 1 µA.
Zero Offset ±1 count, referred to the Voltage and
Current monitors.
I- 4
General Information

Specifications (cont.)
AS A HIGH-VOLTAGE SUPPLY
Output Voltage Range 0 to +1 kV, 0 to -1 kV, 0 to +10 kV,
or 0 to -10 kV, switch selectable and
adjustable using a precision potentiometer
with a dial.
Resolution
1 kV range 1 volt.
10 kV range 10 volts.
Accuracy Better than 0.1% of full scale.
Compliance Current Range 0 to ±2000 µA DC, using a precision
potentiometer with a dial.
Output Noise Less than 700 mV rms (measured with a
20 kHz true rms meter).
Regulation
Line Better than 0.01% for all line voltages.
Load Better than 0.01% for a load change from
1 µA to 1000 µA.
Stability
Drift with Temperature Less than 100 ppm/°C.
Drift with Time Less than 100 ppm /24 hours.
I- 5
General Information

Specifications (cont.)
AS A CURRENT SUPPLY
Output Current Range 0 to 200 µA or 0 to 2000 µA, switch
selectable and adjustable using a
precision potentiometer with a dial.
Resolution
200 µA range 0.2 µA.
2000 µA range 2 µA.
Compliance Voltage Range 0 to ±10 kV DC, adjustable using a
precision potentiometer with a dial.
Regulation
Line Better than 0.01% for all line voltages.
Load Better than 0.01% for a load change from
10 V to 10 kV.
Stability
Drift with Temperature Less than 100 ppm/°C.
Drift with Time Less than 100 ppm/24 hours
AS A HIGH-VOLTAGE AMPLIFIER AND CONTROLLER
Output Voltage Range 0 to ±1 kV or 0 to ±10 kV DC or peak AC,
switch selectable.
Input Voltage Range 0 to ±10 V DC or peak AC.
Voltage Gain
1 kV Range 100 V/V.
10 kV Range 1000 V/V.
I- 6
General Information
